Velleman DVM645BI User manual

DVM645BI
BENCH MULTIMETER
TAFELMULTIMETER
MULTIMETRE DE TABLE
BANCO MULTÍMETRO
TISCHMULTIMETER
User Manual
Gebruikershandleiding
Manuel d'utilisation
Gebrauchsanleitung

DVM645BI GB1
DVM645BI – BENCH MULTIMETER
Introduction
This manual contains instructions and warnings that must be observed to ensure
safe operation and to keep the meter in a safe condition.
WARNING
READ "SAFETY INFORMATION"
BEFORE USING THE BENCH MULTIMETER
This multimeter is a portable 4000-count instrument that is designed for use in the
laboratory, the field, at home, and in other environments. This multimeter features
a compact design with rounded corners for easy handling, with a rugged shock-
resistant and fire-retardant case. It also has electronic overload protection for all
functions and ranges.
Unpacking and Inspection
Upon removing your new Bench Multimeter from its packaging, you should have
the following items:
1. Bench multimeter
2. Test lead set (one black, one red)
3. Carrying strap
4. Power lead
5. Instruction manual
If any of the above items are missing or are received in a damaged condition,
please contact the distributor from whom you purchased the unit.
Safety Precautions
Injury or death can occur even with low voltage and low current. It is extremely
important that you read this safety information before using your multimeter.
Follow all safety practices and proper operating procedures for the equipment
under test.
1. Exercise extreme caution when: measuring voltages above 20 volts,
measuring currents greater than 10mA, measuring AC power lines with
inductive loads, measuring AC power lines during electrical storms.
2. Always inspect your multimeter, test leads and accessories for signs of
damage or abnormality before every use. If there are any abnormalities

DVM645BI GB2
(i.e. broken or damaged test leads, cracked case, display not reading,
etc.) do not attempt to do any measurements.
3. Never earth yourself when making electrical measurements. Do not touch
exposed metal pipes, outlets, fixtures, etc., which might be at earth
potential. Keep your body insulated from earth by using dry clothing,
rubber shoes, rubber mats, or any approved insulating material.
4. Never touch exposed wiring, connections, test probe tips, or any live
circuit conductors when making measurements.
5. Never replace the protective fuse inside the multimeter with a fuse other
than the specified or approved type. Replace only with the same type of
fuse. To avoid electric shock, disconnect the test leads and any input
signals before replacing the fuse.
6. Replace only with the same type of battery. To avoid electric shock,
disconnect the power lead from the mains, and the test leads and any
input signal before replacing the battery.
7. Do not operate this multimeter in an explosive atmosphere (ie. in the
presence of inflammable gases or fumes, vapour or dust).
8. Measuring voltages that exceed the limits of the multimeter may damage
the meter and expose the operator to a shock hazard. Always respect the
meter voltage limits as stated on the front of the meter.
9. Never apply more than 500V DC between the COM connector and earth.
10. When testing for the presence of voltage or current, make sure the
voltage or current ranges are functioning correctly. Take a reading of a
known voltage or current before assuming a zero reading indicates no
current or voltage.
11. Do not attempt to calibrate or service the meter unless you are trained to
do so and another person capable of rendering first aid and resuscitation
is present.
12. Remember: Think Safety, Act Safely
Safety Information
The multimeter complies with Protection Class II, Overvoltage CAT II of IEC1010-
1 (EN61010-1). Pollution degree 2 in accordance with IEC-664 indoor use. If the
equipment is used in a non-compliant manner, the protection provided by the
equipment may be insufficient.
This product complies with the requirements of the following European
Community Directives: 89/336/EEC (EMC) and 73/23/EEC (LVD) as amended by
93/68/EEC (CE marking).

DVM645BI GB3
Chapter 1
A quick tour
Explanation of Symbols
Attention ! Refer to the operating instructions
Dangerous voltage may be present at terminals
Ground (Earth Terminal)
AC - Alternating Current
DC - Direct Current
Audible Continuity
Equipment protected throughout by Double Insulation
(Protection Class II)

DVM645BI GB4
Instrument Layout
Figure 1-1. Bench Multimeter (Front)
Figure 1-2. Bench Multimeter (Back)

DVM645BI GB5
1. VΩ
ΩΩ
ΩHz Volts, Ohms, Diode, and Frequency Input Terminal
This is the positive input terminal for all functions except current measurement.
The red test lead is connected to this.
2. COM Common Terminal
This is the negative (ground) input terminal for all measurement modes. The
black test lead is connected to this.
3. mA Milliamp Input Terminal
This is the positive input terminal for current measurements (AC or DC) up to
400mA. The red test lead is connected to this.
4. A 10 Amp Input Terminal
This is the positive input terminal for current measurements (AC or DC) up to
10A. The red test lead is connected to this.
5. Function / Range Selector Rotary Switch
This rotary switch selects the function, and selects the desired range.
6. Function / Range Selector Buttons
This button selects the function, and selects the desired range.
7. The LCD Display
The LCD display indicates the measured value of a signal, the function mode,
and indicators.
8. The Battery Cover
9. Power Supply Input with Fuse
WARNING
To avoid user injury and multimeter damage, the multimeter must be set to
the same AC voltage value as the mains before connecting the power lead
to the mains and switching on.
This switch is used to turn the AC Power on and off. When the AC Power is on,
the DC Power is automatically switched off.
10. The Power Switch

DVM645BI GB6
Using the Rotary Switch
Turn the multimeter on by turning the rotary switch to any function.
Using the Buttons
The buttons are push type switches. The functions are as follows:
1. BACK LIGHT Button
You can turn the back light on or off by pressing the button. When powered
by the battery, the back light will automatically switch off again after a short period
of time.
2. FUNCTION SELECTOR Button
In the resistance and continuity range, each press of the button switches
alternately between resistance and continuity.
In the frequency and adaptive test range, each press of the button switches
alternately between frequency and adaptive test.
In the DC and AC amps range, each press of the button switches alternately
between DC amps or AC amps.
In the DC and AC milliamps range, each press of the button switches
alternately between DC milliamps or AC milliamps.
3. Data Hold: HOLD Button
Press the button to toggle in and out of the Data Hold mode, except if the
multimeter is already in the Min/Max Recording Hold mode.
When in the Data Hold mode, the " " indicator is displayed and the last reading is
held on the display, the beeper emits a tone.
Pressing the button when the multimeter is in the Data Hold mode will cause
it to exit Data Hold and enter the Min/Max Recording Hold mode.
In the Min/Max Recording Hold mode, press the button to stop recording the
readings, press again to resume recording.
However, the multimeter is still operating in Data Hold mode, therefore, the buzzer
will still sound if the over range or continuity mode occurs. And the range will also
change if it is in auto range.
4. Delay Data Hold: DELAY HOLD Button
Press the button to toggle in and out of the Data Hold mode, and the " "
indicator turns on or off.

DVM645BI GB7
5. Min/Max Recording Hold: MIN/MAX Button
Press the button to enter the Min/Max Recording Hold mode. The minimum
and maximum values are then reset to the current input, the readings are stored in
memory, and the " " indicator turns on. Push the button to cycle through the
minimum (MIN), maximum (MAX), and current readings. The "MIN" or "MAX"
indicator turns on to indicate what value is being displayed.
In the Min/Max Recording Hold mode, press the button to stop recording the
readings, press again to restart recording. If recording is stopped, the minimum,
maximum, or current values and the analogue display are frozen. In the Min/Max
Recording Hold mode, if a new minimum value exceeds the actual minimum
readings, or a new maximum value is an overload value, the minimum or
maximum value will be held on the display, but the analogue display will continue
to be active.
If in auto range, the mode is held just before the range.
6. Relative Display: REL Button
Press the button to enter the Relative Display mode, the "REL" indicator turns
on, the displayed reading is stored as a reference value, and the display is then
set to zero.
In the Relative Display mode, the value shown on the LCD is always the
difference between the stored reference value and the current reading. If the new
reading is the same as the reference value, the display will indicate zero.
The bar graph displays absolute value, not relative value. And the over range also
occurs according to the absolute value.
With auto-range, the range is held just before range.
Press and hold down the button for more than one second to exit the relative
mode.
7. RANGE Button
Press the button to select the Manual Range mode and turn off the "AUTO"
indicator.
In the Manual Range mode, each time the button is pressed, the range (and
the input range indicator) increments and a new value is displayed.
To exit the Manual Range mode and return to auto range, press and hold down
the button for more than one second. The "AUTO" indicator turns back on.
The DC V, AC V, resistance and capacitance measurements are always first set
to the auto range by default.
The frequency measurement is always set to the auto range.
The continuity, diode, ADP, DC A and AC A measurements are always set to the
manual range.
When the power is turned on, the default range is selected.

DVM645BI GB8
8. Data Memory: MEM STO Button
Press the button to enter the Data Memory mode and turn on the "MEM"
indicator. All the display data is then stored in the memory. The stored data can
be read out and displayed on the LCD, which then switches to the Data Recall
Hold mode.
9. Data Recall Hold: MEM RCL Button
Press the button to enter the Data Recall mode and turn on the "MEM" and
"" indicator. The stored data can be read out and displayed on the LCD, which
then switches to the Data Recall Hold mode.
While storing data in the memory display, the "MEM" indicator flashes. The Data
Recall Hold mode is exited by pressing the button or the button.
Buzzer Output
A 2kHz buzzer sounds in the following cases:
1. When the key is operated.
2. When the over-range occurs, except for resistance (Ω
ΩΩ
Ω), frequency (Hz),
continuity ( ) and diode ( ) measurements.
3. When the continuity measurement results in less than 40Ω.
4. When the relative mode is exited.
5. When the mode is changed from manual to auto range by operating the
button. Please refer to the timing chart for the timing.
Low Battery Indication
The " " indicator is displayed when the battery voltage falls below the reliable
operating level.

DVM645BI GB9
Chapter 2
Measurements
Introduction
WARNING
To avoid user injury and multimeter damage, the
multimeter must be set to the correct value of mains
voltage before connecting the power lead to the mains and
switching on.
Before doing any measurements always examine the multimeter and accessories
for any damage, contamination (excessive dirt, grease, etc.) and defects. Examine
the test leads for cracked or frayed insulation and make sure the lead plugs fit
snugly into the multimeter sockets. If there are any abnormalities, do not attempt
to do any measurements.

DVM645BI GB10
Red
Circui
t
Measuring DC Volts
Figure 2-1. Measuring DC Volts
WARNING
To avoid possible electric shock, multimeter damage and/or
equipment damage, do not attempt to do any voltage measurements if
the voltage is above 1000V DC / 750V AC RMS. 1000V DC / 750V AC
RMS are the maximum voltages that this multimeter is designed to
measure.
cTurn the Selector to Volts DC
dConnect the leads as shown
eis not available in Volts DC, all other buttons can be used.
1. Insert the black and red test leads into the COM and VΩ
ΩΩ
ΩHz input terminals
respectively.
2. Select the desired DC voltage range, or set to auto range.
3. When the magnitude of the voltage to be measured is unknown, always start
with the highest range.
4. Connect the test leads in parallel with the circuit to be measured. Be careful
not to touch any live conductors with your hands. Note the reading.
5. For DC voltage readings, the red lead should be connected to the positive side
of the circuit, the black lead to the negative side. A minus sign on the left-hand
side of the LCD will appear if the leads are connected the other way around.
6. When all measurements have been completed, disconnect the test leads from
the circuit under test. Remove the test leads from the multimeter.

DVM645BI GB11
Red
Circuit
Measuring AC Volts
Figure 2-2. Measuring AC Volts
WARNING
To avoid possible electric shock, multimeter damage and/or
equipment damage, do not attempt to do any voltage measurements if
the voltage is above 1000V DC / 750V AC RMS. 1000V DC / 750V AC
RMS are the maximum voltages that this multimeter is designed to
measure.
cTurn the Selector to Volts AC
dConnect the leads as shown
eis not available in Volts AC, all other buttons can be used.
1. Insert the black and red test leads into the COM and VΩ
ΩΩ
ΩHz input terminals
respectively.
2. Select the desired AC voltage range, or set to auto range.
3. When the magnitude of the voltage to be measured is unknown, always start
with the highest range.
4. Connect the test leads in parallel with the circuit to be measured. Be careful
not to touch any live conductors with your hands. Note the reading.
5. When all measurements have been completed, disconnect the test leads from
the circuit under test. Remove the test leads from the multimeter.

DVM645BI GB12
Red
Circuit
Measuring DC and AC Amps
Figure 2-3. Measuring Amps
WARNING
Do not attempt to measure high currents. Use a current clamp for
measurements >10A. The 10A input terminal is protected by a
F15A/250V fast blow ceramic fuse.
cTurn the selector to DC and AC Amps.
dConnect the leads as shown
eis not available in DC and AC Amps, all other buttons can be used.
Each press of the button switches alternately between DC and AC Amps.
1. Insert the black and red test leads into the COM and Ainput terminals
respectively.
2. Turn off or disconnect the circuit to be measured from all power sources,
connect the multimeter in series with the conductor where the current is to be
measured.
3. Switch on the power to the circuit under test. Note the reading.
4. After completing the measurement, turn off the power to the circuit under test,
disconnect the test leads from the multimeter.
5. The DC and AC Amps measurements are always fixed range.

DVM645BI GB13
Red
Circuit
Measuring DC and AC Milliamps
Figure 2-4. Measuring Milliamps
WARNING
Do not attempt to measure high currents. The mA input terminal is
protected by a F1A/250V fast blow ceramic fuse.
cTurn the selector to DC and AC Milliamps.
dConnect the leads as shown.
eis not available in DC and AC Milliamps, all other buttons can be used.
Each press of the button switches alternately between DC or AC Milliamps.
1. Insert the black and red test leads into the COM and mA input terminals
respectively.
2. Select the desired DC current range or AC current range.
3. Turn off or disconnect the circuit to be measured from all power sources,
connect the multimeter in series with the conductor where the current is to be
measured.
4. Switch on the power to the circuit under test. Note the reading.
5. After completing the measurement, turn off the power to the circuit under test,
disconnect the test leads from the multimeter.
6. The DC and AC Milliamps measurements are always fixed range.

DVM645BI GB14
Red
Circuit
Measuring Frequency and Adaptive Measurement
Figure 2-5. Measuring Frequency and Adaptive Measurement (ADP)
cTurn the selector to frequency and adaptive measurement.
dConnect the leads as shown
eis not available in frequency and adaptive measurement, all other buttons
can be used.
Each press the button switches alternately between frequency and adaptive
measurement.
1. Insert the black and red test leads into the COM and VΩ
ΩΩ
ΩHz input terminals
respectively.
2. In the frequency test, it is not necessary to know the range, as the multimeter
will automatically range up or down to display the best resolution. Manual range is
not available.
3. Ensure that the amplitude level of the signal to be measured is not greater
than the input voltage limit (250V DC/AC rms). The signal amplitude must also be
greater than the sensitivity level.
4. Attach the probe tips to the points across which the frequency is to be
measured, and read the result directly from the display.
5. The frequency range is always set to auto range.
The Adaptive (ADP) Measurement is as follows:
1. Connect the ADP signal terminal (-) and (+) to the COM and VΩ
ΩΩ
ΩHz input
terminals respectively.
2. The ADP voltage is supplied to the multimeter directly. The result is displayed
on a scale of 10 units per 1mV.
3. The ADP measurement is always fixed range. The full range is 400mV DC.

DVM645BI GB15
Red
Measuring Capacitance
Figure 2-6. Measuring Capacitance
WARNING
Turn off the power to the device under test and discharge all
capacitors.
cTurn the selector to capacitance.
dConnect the leads as shown: insert the black and red test leads into the COM
and VΩ
ΩΩ
ΩHz input terminals respectively.
eis not available with capacitance, all other buttons can be used.
1. Turn off the power to the device under test and discharge all capacitors.
2. Completely discharge the capacitor before measuring its capacitance value.
3. Set to the capacitance range that gives the most accurate reading or select
auto range.
4. Connect the crocodile clips to the capacitor leads or insert the capacitor leads
into the multimeter measuring socket. Always observe the correct polarity when
measuring electrolytic capacitors.
5. Read the capacitance value directly from the display. The accuracy of the
capacitance measurement can be improved by first pressing the button
(Relative mode) in order to zero the display and automatically subtract the
residual multimeter and test lead capacitance. The Relative mode also selects
manual range.
6. Residual charge in the capacitor, or capacitors with poor insulation resistance
or poor dielectric absorption may cause measurement errors.
NOTE: A safe way to discharge a capacitor is to connect a 100kΩresistor across
the two capacitor leads.

DVM645BI GB16
Red
Testing Diodes
Figure 2-7. Diode Test
WARNING
Measurements must always be done with the circuit power OFF.
cTurn the selector to Diode.
dConnect the leads as shown: insert the black and red test leads into the COM
and VΩ
ΩΩ
ΩHz input terminals respectively.
eand are not available in diode test, all other buttons can be used.
1. Select the ( ) position by turning the rotary switch.
2. Insert the black and red test leads into the COM and VΩ
ΩΩ
ΩHz input terminals
respectively.
3. The red lead should be connected to the anode and the black lead to the
cathode of the diode.
4. The typical voltage drop should be about 0.6V for a silicon diode or 0.3V for a
germanium diode.
5. If the diode is reverse biased or there is an open circuit and the reading will be
between 3.000V and 3.400V.
6. The Diode test is always fixed range.

DVM645BI GB17
Red
Measuring Resistance and Continuity
Figure 2-8. Measuring Resistance and Continuity
cTurn the selector to Resistance and Continuity measurement.
dConnect the leads as shown.
eis not available in continuity test, all other buttons can be used.
Each press of the button switches alternately between resistance and
continuity measurement.
Resistance measurement is as follows:
1. Select resistance by pressing the button.
2. Insert the black and red test leads into the COM and VΩ
ΩΩ
ΩHz input terminals
respectively.
3. Select the desired ohms (Ω) range or set to auto range. Connect the black and
red test probes to the circuit or device under test. First make sure that the circuit
or device is dead.
4. Turn off any power to the resistor to be measured. Discharge any capacitors.
Any voltage present during a resistance measurement will cause inaccurate
readings and could damage the meter if the overload protection of 250V DC or AC
rms is exceeded.
5. Open circuits will be displayed as an overload condition and the MSD (Most
Significant Digit) will blink.

DVM645BI GB18
6. The resistance of the test leads can diminish accuracy in the lowest (400Ω)
range. The error is usually 0.1 to 0.2Ωfor a standard pair of test leads. To
determine the error, short the test leads together and the use the Relative
mode to automatically subtract the lead resistance from the resistance
measurement.
7. After all measurements have been completed, disconnect the test leads from
the circuit and multimeter input terminals.
The Continuity ( ) measurement is as follows:
1. Select the continuity measurement by pressing the button.
2. Insert the black and red test leads into the COM and VΩ
ΩΩ
ΩHz input terminals
respectively.
3. Connect the black and red test probes to the circuit or device under test. First
make sure that the circuit or device is dead.
4. An audible tone will sound when the resistance is less than approximately
40Ω.
5. After the continuity measurement has been completed, disconnect the test
leads from the circuit and multimeter input terminals.
6. The continuity measurement is always fixed range. Open circuit voltage is
approximately 0.45V.

DVM645BI GB19
Chapter 4
Specifications
General Specifications
Maximum voltage between terminals and earth: CAT. II 1000V DC or 750V AC
rms (sine)
Display: 3 3/4 digit (4000 count) digital indication. Frequency range: 9999 counts
max.
42 segment analogue bar graph
Full indicators, automatic polarity indication
Measuring rate: Digital 2 times per second
Analogue bar graph 20 times per second
Capacitance 1 time per second
Over range indications: MSD (Most Significant Digit) blinks
Low Battery indication: The " " indicator is displayed when the battery
voltage drops below the reliable operating level.
Temperature coefficient: 0.15 x specified accuracy per °C
< 18°C to >28°C
Temperature: Operating: 5°C to 35°C
Storage: -10°C to 60°C
Relative humidity: 20% to 75% RH (5°C to 35°C)
Back light
Safety:
Power requirements
Size
Weight
Accuracy is given as ± (% of reading + number of least significant digit) at 18°C to
28°C, with relative humidity up to 75%.
All specifications assume less than 1 year since calibration.
