Aufbauanleitung / assembly instructions mod. 2296 - 2297
1. Montagematerial
1. fitting material
2. Den Unterbau auspacken und aufstellen.
Sollte der Unterbau kippeln, kann dies mit den
schwar en Stellschrauben, welche sich unter
der Bodenplatte befinden, ausgeglichen
werden.
2. Unpack the table-base and put it onto the floor.
Any wobbling can be eliminated by adjusting
the black screws, which are located under the
base plate.
3. Den Oberbau auspacken und umgedreht auf
gepolsterten Montageböcken ablegen.
Die schwar en Schrauben etwa 10 mm lösen.
3. ay the table-top upside down onto two
padded assembling trestles.
Turn out the black screws for about 10 mm.
4. Beide Aus üge etwa 50 mm heraus iehen.
Je 2 Stehbol en in die Aluminium-Profile ein-
führen. Der Abstand der Stehbol en bis ur
Profilmitte (Bohrung) muss 384 mm betragen.
4. Draw out both pullouts 50 mm. Insert 2 stud
bolts into each aluminium-profile. The
distance of the stud bolts to the middle of the
aluminium-profile must be 384 mm.
2296 - 2297 1 / 4 Änderungsdatum: 11.08.16
SW13
4x
19,3 x 11
4x M8
4x
M8 x 28
4x
384 mm
M8 x 28
5. Den Oberbau wenden und mit den 4 Steh-
bol en in die silberne Halteplatte des
Unterbaus einstecken.
5. Turn the table-top and put it onto the table-
base. Stick the 4 stud bolts into the allocated
holes of the table-base plate.
6. Die Stehbol en mit je einer Scheibe und einer
Mutter fixieren.
Zum Fest iehen der Muttern die mitgelieferte
Stecknuss (SW13) verwenden.
6. Fix each stud bolt by a washer and a scew-
nut.
Use the provided box nut (AF13) to tighten the
nuts.
7. Die Platte mit den Metall-Klebepunkten in die 4
Aluminium-Hülsen einrasten lassen.
Darauf achten, dass sich die beiden Markie-
rungspunkte auf einer Seite befinden.
7. et the metal-swivel of the main ceramic plate
stick into the 4 aluminium-swivels.
Take care that the dot on the main ceramic
plate is on the same side as the dot on one of
the ceramic pullout.
8. Die Aus üge heraus iehen, hochklappen und
wieder heranschieben. Nun...
8. Pull out extensions, fold them out and push
back. Now...
2296 - 2297 2 / 4 Änderungsdatum: 11.08.16
19,3 x 11
M8
9. ...die Hauptplatte mit den Aluminiumhülsen so
justieren, dass sich die Oberkanten der Haupt-
und der Aus ugsplatten auf einer Höhe
befinden.
9. ...adjust the top with aluminium bushes so that
the upper side of the main glass is at one level
with the extentensions glasses.
2296 - 2297 3 / 4 Änderungsdatum: 11.08.16
10. Fertig (Grund ustand).
10. Ready.
11. Fertig (ausge ogen).
11. Ready.
2296 - 2297 4 / 4 Änderungsdatum: 11.08.16
