Vents SO Series User manual

AXIAL FAN
User's manual
www.ventilation-system.com
RO/SO
EN

2
EN
CONTENTS
Delivery set............................................................................................................................................................................................................................................. 7
Brief description .................................................................................................................................................................................................................................. 7
Operation guidelines ....................................................................................................................................................................................................................... 8
Designation key ................................................................................................................................................................................................................................. 9
Mounting and set-up....................................................................................................................................................................................................................... 10
Connection to power mains ....................................................................................................................................................................................................... 12
Electronics operation algorithm ............................................................................................................................................................................................... 14
Technical maintenance................................................................................................................................................................................................................... 15
Storage and transportation regulations............................................................................................................................................................................... 16
Manufacturer’s warranty................................................................................................................................................................................................................ 17

3
EN
This user’s manual is a main operating document intended for technical, maintenance, and operating staff.
The manual contains information about purpose, technical details, operating principle, design, and installation of the RO/SO
unit and all its modifications.
Technical and maintenance staff must have theoretical and practical training in the field of ventilation systems and should
be able to work in accordance with workplace safety rules as well as construction norms and standards applicable in the
territory of the country.
The information in this user’s manual is correct at the time of the document’s preparation.
The Company reserves the right to modify the technical characteristics, design, or configuration of its products at any time
in order to incorporate the latest technological developments.
No part of this publication may be reproduced, stored in a retrieval system, or transmitted, in any form or by any means in any
information search system or translated into any language in any form without the prior written permission of the Company.
READ THE USER’S MANUAL CAREFULLY BEFORE PROCEEDING WITH INSTALLATION WORKS.
COMPLIANCE WITH THE MANUAL REQUIREMENTS ENSURES RELIABLE OPERATION AND LONG
SERVICE LIFE OF THE UNIT.
KEEP THE USER’S MANUAL AVAILABLE AS LONG AS YOU USE THE UNIT. YOU MAY NEED TO RE-READ
THE INFORMATION ON THE PRODUCT SERVICING.

4
EN
FOLLOW THE USER’S MANUAL REQUIREMENTS TO ENSURE DURABLE AND
TROUBLE-FREE OPERATION OF THE UNIT.
Disconnect the unit from power supply prior to any connection,
servicing, maintenance, and repair operations.
Only qualied electricians with a work permit for electrical
units up to 1000 V are allowed for installation and maintenance.
The present user’s manual should be carefully read before
beginning works.
• Single-phase power mains must comply with the acting local electrical
norms and standards.
• Fixed electrical wiring must be equipped with an automatic circuit
breaker.
• The unit must be connected to power mains through a QF automatic
circuit breaker integrated into the fixed wiring system. The gap
between the circuit breaker contacts on all poles must be not less
than 3 mm. Check the unit for any visible damages of the impeller

5
EN
and the casing before starting installation. The casing internals must
be free of any foreign objects that can damage the impeller blades.
• While mounting the unit, avoid compression of the casing!
Deformation of the casing may result in the motor jam and noisy
operation. Misuse of the unit and any unauthorised modifications are
not allowed.
• Take steps to prevent ingress of smoke, carbon monoxide, and other
combustion products into the room through open chimney flues or
other fire-protection devices. Sufficient air supply must be provided
for proper combustion and exhaust of gases through the chimney
of fuel burning equipment to prevent back drafting. Transported air
must not contain any dust or other solid impurities, sticky substances,
or fibrous materials.
• Do not use the unit in a hazardous or explosive environment
containing spirits, gasoline, insecticides, etc.
• Do not close or block the intake or extract vents in order to ensure the
efficient air flow.

6
EN
THE PRODUCT MUST BE DISPOSED SEPARATELY AT THE END OF ITS SERVICE LIFE.
DO NOT DISPOSE THE UNIT AS UNSORTED DOMESTIC WASTE.
• Do not sit on the unit and do not put objects on it.
• The unit is allowed to be used by children aged from 8 years old
and above and persons with reduced physical, sensory, or mental
capabilities or no experience and knowledge provided that they have
been given supervision or instruction regarding safe use of the unit
and understand the risks involved.
• Do not allow children to play with the unit.

7
EN
DELIVERY SET
Fan — 1 pc.
Screws and dowels — 4 pcs.
Plastic screwdriver (for models with a timer) — 1 pc.
User’s manual — 1 pc.
Packing box — 1 pc.
BRIEF DESCRIPTION
The unit described herein is an axial fan for exhaust ventilation of small to medium-sized premises heated during winter.
The fan design can also include a non-return valve to prevent back flow when the fan is switched off.
The fan design is constantly being improved, thus some models may be slightly different from those described in this
manual.
B
d
B
L
L
l
l
D
D
H
d
C
H
C
RO
SO

8
EN
OVERALL DIMENSIONS
B
d
B
L
L
l
l
D
D
H
d
C
H
C
RO
SO
OPERATION GUIDELINES
The fan is connected to 220...240 V/50 (60) Hz or 12 V/50 Hz single-phase AC mains depending on the model and is designed
for continuous operation without disconnection from the electric mains.
Air motion direction in the system must match the pointer on the fan casing.
Ingress protection rating against access to hazardous parts and water ingress is IP24.
The fan is rated for operation at the ambient temperature ranging from +1 °C up to +45 °C.
The unit is rated as a Class II (220-240 V/50 Hz) or Class III (12 V/50 Hz) electrical appliance; (IEC 60335-1:1991).
Model D B l L H C d
SO 100
100 mm
177 mm
88 mm
121 mm 103 mm 57 mm 118 mm
RO 100 172 mm
SO 125
125 mm
177 mm
122 mm 124 mm 71 mm 143 mm
RO 125 172 mm

9
EN
DESIGNATION KEY
ХХ 100 Х Х Х X (X/Y) (X)
Packing
Mains parameters,
where X is voltage, Y is frequency (220-240 V/50 Hz by default)
Colour (white by default)
Basic options:
L: motor on ball bearings
K: non-return valve with a membrane made of lightweight KO polymer
K1: non-return valve with a membrane made of KO1 plastic
V: pull cord switch
T: timer
TH: timer and humidity sensor
VT: pull cord switch, timer
VTH: pull cord switch, timer, humidity sensor
Motor and impeller modications:
Turbo: high-powered motor
Q: low-noise motor
12: motor with 12 V/50 Hz rated voltage
Press: high pressure impeller
Outlet spigot diameter [mm]
RO, SO fan series
Designation key example:
RO 100-Q VT K: RO series fan with a Ø 100 mm spigot, equipped with a pull cord switch, a timer and a non-return valve,
with standard power supply parameters, white, in a corrugated box.

10
EN
MOUNTING AND SET-UP
Cut off power supply and make sure electricity has been
turned off.
The fan is designed for wall or ceiling mounting with direct
air exhaust to the ventilation shaft or into the round air duct
of matching diameter.
QF
L N
Unscrew the retaining screw. Remove the front panel of
the fan by turning it counter-clockwise.
Mark the holes for fixing the fan and the power cable.

11
EN
Lead the power cable to the ventilation hole, drill the
mounting holes and install the dowels.
Fix the fan with the screws.
Connect the fan to the electric mains according to the connections diagram. Install the front panel by turning it
clockwise. Screw the retaining screw.

12
EN
CONNECTION TO POWER MAINS
The fan is connected to 220...240 V/50 (60) Hz or 12 V/50 Hz single-phase AC mains depending on the model.
WARNING!
The fans rated for 12 V power voltage (stated on the packing box and on the fan casing) connect to 12 V AC power mains
with frequency of 50 Hz only!
RO/SO
QF
L
L
N
N
S
RO/SO V
QF
L
L
N
N

13
EN
RO/SO T/TH
-
60% 90%
H
+
+
2min
30min
T
N
QF
LT
N
L
L
S
RO/SO VT/VTH
-
60% 90%
H
+
+
2min
30min
T
N
QF
LT
N
L
L
Terminal designations on the wiring diagram:
L — line LT — timer control line S — ON\OFF switch
N — neutral QF — automatic circuit breaker

14
EN
ELECTRONICS OPERATION ALGORITHM
The fan with the timerT is started after actuation of the external switch, e.g. the light switch. The control voltage is supplied
to the input terminal LT.
After the control voltage is off, the fan continues to operate within the time set by the timer ranging from 2 to 30 minutes.
The Vand VT models are turned on and off by an integrated pull-cord switch.
The fan with the timer and the humidity sensor TH – the fan starts after the control voltage is supplied to the input
terminal Sor if indoor humidity level Hexceeds the set point adjustable from ~60 % to ~90 %.
After the control voltage is off or the humidity level has decreased, the fan will keep running within the time set by the timer
ranging from 2 to 30 minutes.
To set the maximum humidity setpoint, set the potentiometer to Hmax position (90 %).
To adjust the fan timer, turn the control knob Tclockwise to increase and counter-clockwise to decrease the turn-on delay
time respectively.
To adjust the humidity set point turn the control knob Hclockwise to increase and counter-clockwise to decrease the
humidity sensor set point.
WARNING! The timer circuit is live! Disconnect the fan from power mains prior to any adjustment operations.
The fan delivery set includes a specially designed plastic screwdriver for fan settings adjustments (only for
models equipped with a timer). Use it to change the turn-on and turn-o delay time and the humidity set point.
Do not use a metal screwdriver, knife, etc. for adjustment operations not to damage the circuit board.
DO NOT USE A METAL SCREWDRIVER, KNIFE, ETC. FOR ADJUSTMENT
OPERATIONS NOT TO DAMAGE THE CIRCUIT BOARD.

15
EN
TECHNICAL MAINTENANCE
The fan maintenance periodicity is at least once per 6 months.
Maintenance steps:
Disconnect the fan from power supply. Unscrew the
retaining screw. Remove the front panel.
Clean the fan with a soft dry cloth or a brush.
Wash the front panel under running water. Wipe the fan
surfaces dry.
Cover the fan with the front panel. Screw the retaining
screw. Connect power supply.
WARNING! Do not allow water or liquid come into contact with electric components!

16
EN
STORAGE AND TRANSPORTATION REGULATIONS
• Store the unit in the manufacturer’s original packaging box in a dry closed ventilated premise with temperature range
from +5 ˚С to +40 ˚С and relative humidity up to 70 %.
• Storage environment must not contain aggressive vapors and chemical mixtures provoking corrosion, insulation, and
sealing deformation.
• Use suitable hoist machinery for handling and storage operations to prevent possible damage to the unit.
• Follow the handling requirements applicable for the particular type of cargo.
• The unit can be carried in the original packaging by any mode of transport provided proper protection against precipitation
and mechanical damage. The unit must be transported only in the working position.
• Avoid sharp blows, scratches, or rough handling during loading and unloading.
• Prior to the initial power-up after transportation at low temperatures, allow the unit to warm up at operating temperature
for at least 3-4 hours.

17
EN
MANUFACTURER’S WARRANTY
The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility.
We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/
EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and
of the Council and CE-marking Council Directive 93/68/EEC. This certificate is issued following test carried out on samples
of the product referred to above.
The manufacturer hereby warrants normal operation of the unit for 60 months after the retail sale date provided the user's
observance of the transportation, storage, installation, and operation regulations. Should any malfunctions occur in the
course of the unit operation through the Manufacturer's fault during the guaranteed period of operation, the user is entitled
to get all the faults eliminated by the manufacturer by means of warranty repair at the factory free of charge. The warranty
repair includes work specific to elimination of faults in the unit operation to ensure its intended use by the user within the
guaranteed period of operation. The faults are eliminated by means of replacement or repair of the unit components or a
specific part of such unit component.
The warranty repair does not include:
• routine technical maintenance
• unit installation/dismantling
• unit setup
To benefit from warranty repair, the user must provide the unit, the user's manual with the purchase date stamp, and the
payment paperwork certifying the purchase. The unit model must comply with the one stated in the user’s manual. Contact
the Seller for warranty service.
The manufacturer’s warranty does not apply to the following cases:
• User’s failure to submit the unit with the entire delivery package as stated in the user’s manual including submission
with missing component parts previously dismounted by the user.
• Mismatch of the unit model and the brand name with the information stated on the unit packaging and in the user's
manual.
• User’s failure to ensure timely technical maintenance of the unit.
• External damage to the unit casing (excluding external modifications as required for installation) and internal
components caused by the user.

18
EN
• Redesign or engineering changes to the unit.
• Replacement and use of any assemblies, parts and components not approved by the manufacturer.
• Unit misuse.
• Violation of the unit installation regulations by the user.
• Violation of the unit control regulations by the user.
• Unit connection to power mains with a voltage different from the one stated in the user's manual.
• Unit breakdown due to voltage surges in power mains.
• Discretionary repair of the unit by the user.
• Unit repair by any persons without the manufacturer’s authorization.
• Expiration of the unit warranty period.
• Violation of the unit transportation regulations by the user.
• Violation of the unit storage regulations by the user.
• Wrongful actions against the unit committed by third parties.
• Unit breakdown due to circumstances of insuperable force (fire, flood, earthquake, war, hostilities of any kind,
blockades).
• Missing seals if provided by the user’s manual.
• Failure to submit the user’s manual with the unit purchase date stamp.
• Missing payment paperwork certifying the unit purchase.
FOLLOWING THE REGULATIONS STIPULATED HEREIN WILL ENSURE A LONG AND TROUBLE-FREE
OPERATION OF THE UNIT.
USER’S WARRANTY CLAIMS SHALL BE SUBJECT TO REVIEW ONLY UPON PRESENTATION OF THE
UNIT, THE PAYMENT DOCUMENT AND THE USER’S MANUAL WITH THE PURCHASE DATE STAMP.

19
EN
Quality Inspector's Stamp
Manufacture Date
Sold by
(name and stamp of the seller)
Purchase Date

V209EN-01
Certificate of acceptance
The fan is recognized as serviceable.
RO 100 -turbo V L
SO 100 -12 T K
RO 125 -Q TH K1
SO 125 -press VT
VTH
