Verex Monitor XL User manual

LCD Keypad User's Guide
rev1.2
Attention: Security Representative / Installer,
Please give this guide to the customer before beginning work on the system.
™

21-3600E rev1.2 (10.3.2006) © 2006 CSG Security Inc. / Sécurité CSG Inc. i
For topics not listed here, please see the Index
Welcome.....................................................................................................................................1
The Monitor xL™ LCD Keypad............................................................................................................. 2
Alarms, Turning Protection On and Off ..................................................................................5
Alarm Monitoring Features ................................................................................................................... 6
Audible Keypad Tones ......................................................................................................................... 6
Sirens ................................................................................................................................................... 7
Dealing with Alarms (what to do if the keypad is beeping) ................................................................... 7
Silencing a False Alarm........................................................................................................................ 7
Using the Emergency Keys .................................................................................................................. 8
Worklate: Extending the Scheduled Closing Time............................................................................... 8
Suspending Schedules for an Area or Areas........................................................................................ 9
Turning Protection ON, STAY, or Viewing the Present Arming-Level................................................... 9
Turning Protection OFF...................................................................................................................... 10
Turning Protection On by Area Groups, a Group of Areas or Individual Areas................................... 10
Area Priority Protection On/Off........................................................................................................... 11
Common Area Protection On/Off........................................................................................................ 11
Turning ON an Area’s Protection using an Access TOKEN................................................................ 11
Turning OFF an Area’s Protection using an Access TOKEN.............................................................. 11
UK System Operation......................................................................................................................... 12
UK and European System Operation ................................................................................................. 12
Checking Status and Controlling Items................................................................................15
Status and Control Features............................................................................................................... 16
Using the Function Keys..................................................................................................................... 16
Checking the System Status (monitored conditions for a system control unit) ................................... 16
Checking the Status of Sensors (Points) and Areas........................................................................... 17
Bypassing or Isolating a Faulty Sensor............................................................................................... 17
Checking Status or Controlling Readers or Doors.............................................................................. 18
Checking the Status or Controlling an Elevator Reader ..................................................................... 19
Checking the Status of an Application Module (POD)........................................................................ 19
Administration and Maintenance Tasks ...............................................................................21
Changing Your Own PIN.................................................................................................................... 22
Adding a User to the System.............................................................................................................. 22
Default Authority Settings................................................................................................................... 23
Viewing or Changing Settings for a User............................................................................................ 24
Deleting a User................................................................................................................................... 26
Setting the Date and Time.................................................................................................................. 26
Manually calling the Director PC from the LCD Keypad:.................................................................... 27
Viewing the History............................................................................................................................. 27
Printing the History Log...................................................................................................................... 28
Changing the Printed History Language............................................................................................. 28
Testing Monitored Sensors (Performing a Walk Test)....................................................................... 29
Testing Panic Buttons (Performing a Hold-up Test) ........................................................................... 30
Testing Sirens (System Test)............................................................................................................. 30
Reference Topics ....................................................................................................................31
System Information............................................................................................................................. 32
Contents

ii Monitor xL™ LCD Keypad User's Guide 21-3600E rev1.2
Residential Fire Safety / Evacuation Plan........................................................................................... 34
Arming Station Reference .................................................................................................................. 36
Wireless Keypad Reference............................................................................................................... 39
Error Messages and Trouble Indications............................................................................................ 40
Things to Do to Prevent False Alarms................................................................................................ 41
Index.........................................................................................................................................42

21-3600E rev1.2 Monitor xL™ LCD Keypad User's Guide iii
About This Guide
This guide provides details on performing
various tasks in a Monitor xL™ system using
an LCD keypad.
To locate a desired topic, refer to the table of
contents (near the front of this guide), or the
Index (near the back of this guide).
Tip: The bottom of each odd-numbered page also
gives an indication as to your general position
within this guide.
Also See (Related Documents)
For details on using the Director software,
refer to the on-line help or User's Guide
provided with the software.
Copyrights and Trademarks
™ Monitor xL is a trademark of CSG Security
Inc./Sécurité CSG Inc.
™ Pentium is a trademark of Intel Corporation
™ ® Microsoft, Windows, Windows2000, and
Windows XP, are trademarks or registered
trademarks of the Microsoft Corporation.
© Copyright 2006
CSG Security Inc./Sécurité CSG Inc.
All rights reserved.
Disclaimer
In the interests of ongoing improvement in quality
and design, we reserve the right to change product
specifications without prior notification. All
software, firmware, drawings, diagrams,
specifications, catalogues, literature, manuals and
other materials relating to the design, use, and
service of related products shall constitute the
proprietary information of the manufacturer.
Industry Canada Customer Information
NOTICE:
This equipment meets the applicable Industry
Canada Terminal Equipment Technical
Specifications. This is confirmed by the
registration number. The abbreviation, IC,
before the registration number signifies that
registration was performed based on a
Declaration of Conformity indicating that
Industry Canada technical specifications were
met. It does not imply that Industry Canada
approved the equipment.
The Ringer Equivalence Number (REN)
assigned to each terminal equipment provides
an indication of the maximum number of
terminals allowed to be connected to a
telephone interface. The termination on an
interface may consist of any combination of
devices subject only to the requirement that the
sum of the Ringer Equivalence Numbers of all
the devices does not exceed five.
The REN for the Monitor xL using the North
American Modem is 0.1
The REN for the Monitor xL using the
Worldwide Modem is 0.0
Repairs to certified equipment should be
coordinated by a representative designated by
the supplier. Any repairs or alterations made by
the user to this equipment, or equipment
malfunctions, may give the telecommunications
company cause to request the user to
disconnect the equipment.
Users should ensure for their own protection
that the electrical ground connections of the
power utility, telephone lines and internal
metallic water pipe system, if present, are
connected together. The precaution may be
particularly important in rural areas.
Caution: Users should not attempt to make
such connections themselves, but should
contact the appropriate electric inspection
authority, or electrician, as appropriate.
NORTH AMERICA:
Customer Instructions Pertaining to
FCC Regulations
This equipment complies with the Federal
Communications Commission (FCC) rules and
regulations governing telephone equipment
and the Technical Requirements for
Connection to the Telephone Network
published by the industry’s Administrative
Council for Terminal Attachments (ACTA). On
modem board of this equipment is a label that
contains, among other information, a product
identifier in the format US:AAAEQ##TXXXX.
If requested, this number must be provided to
the telephone company.
This equipment is designed to be connected to
the telephone network or premises wiring
using a hard wired connection that does NOT
rely on a modular jack. If a modular jack is

iv Monitor xL™ LCD Keypad User's Guide 21-3600E rev1.2
installed, it is the responsibility of the installing
company to ensure that the jack and/or plug is
compliant with the criteria of the
telecommunication industry.
The Ringer Equivalence Number (or REN) is
used to determine the number of devices that
may be connected to a telephone line.
Excessive REN’s on a telephone line may
result in the devices not ringing in response to
an incoming call. In most, but not all areas, the
sum of REN’s should not exceed five (5.0). To
be certain of the number of devices that may
be connected to a line, as determined by the
total REN’s, contact the local telephone
company.
The REN for the Monitor xL using the North
American Modem is 0.2
The REN for the Monitor xL using the
Worldwide Modem is 0.0
CAUTION: If this equipment (Monitor xL) is
deemed potentially harmful to the telephone
network, the telephone company will attempt
to notify you in advance of discontinuing
service. . If advance notice is not practical, the
telephone company will notify you as soon as
possible. If service is disconnected, you will be
advised of your right to file a complaint with
the Federal Communications Commission
(FCC) should you believe it necessary.
The telephone company may make changes
in its facilities, equipment, operations or
procedures that could affect the operation of
this equipment. Should this occur, advance
notice you be provided in order for you to
make necessary modifications to maintain
uninterrupted service.
If trouble is experienced with this equipment
(Monitor xL), for repair or warranty information,
please contact the installing company.
If the equipment is causing harm to the
telephone network, the telephone company may
request that you disconnect the equipment until
the problem is resolved.
There are no user serviceable parts which may
be repaired by the customer. All repairs must
be performed by an authorized dealer
representative.
This equipment cannot be used on public coin
phone service provided by the telephone
company. Connection to party line service is
subject to state tariffs. (Contact the state
public utility commission, public service
commission or corporation commission for
information.)
WARNING NOTICE:
NORTH AMERICA
AUSTRALIA
This equipment has been tested and found to
comply with the limits for a Class A digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference when the equipment is operated
in a commercial environment. This equipment
generates, uses, and can radiate radio
frequency energy and, if not installed and
used in accordance with the instruction
manual, may cause harmful interference to
radio communications. Operation of this
equipment in a residential area is likely to
cause harmful interference in which case the
user will be required to correct the interference
at their own expense.
This is a class A product. In a domestic
environment this product may cause radio
interference in which case the user may be
required to take adequate protection
measures.
WARNING: Changes or Modifications not expressly
approved by VEREX Technology could void the
user’s authority to operate this equipment.
Restrictions and Requirements for UL
Listed Systems
•Access control is not permitted for UL
listed residential systems.
•The system must be tested on a weekly
basis, including all fire initiating devices.
Please see “Testing Monitored Sensors”
in this manual for details.
•Detectors and fire initiating devices will
be disabled while making programming
changes to the system.

21-3600E rev1.2 Monitor xL™ LCD Keypad User's Guide v
CE – Conformity
The Monitor xL System described in this manual conforms to the requirements of the Council Directive
89/336/EEC – The EMC Directive and 73/23/EEC – The Low Voltage Directive. 1999/5/EC-The
R&TTE Directive. To maintain compliancy with this directive, it is essential to adhere to the installation
recommendations described within this manual.
Standards to which Conformity is Declared:
•CISPR 11:2003 / EN55011:2003 – Class A – Limits and methods of measurements of radio
disturbance characteristics for industrial, scientific and medical (ISM) radio-frequency equipment.
•CISPR 22:2003 / EN55022:2003 Class A – Limits and methods of measurement of radio
disturbance characteristics of information technology equipment.
•EN 50130-4:1995 – Electromagnetic compatibility – product family standard: Immunity requirements
for components of fire, intruder and social alarm systems.
•EN 60950-1: 2001 – Safety of Information Technology
•TBR21:1998 – Terminal Equipment Attachment requirements for the connection to the analogue
PSTN
Standard Description Severity Applied Performance
Criteria
IEC 1000-4-2
EN 61000-4-2 Electrostatic Discharge 6kV Contact Discharge (direct and indirect) 8kV Air Discharge A A
IEC 1000-4-3
EN61000-4-3
ENV
50140/240
Radiated RF
Immunity 10V/m, 80-2000 MHz, 1 kHz 80% AM modulation
10V/m 80-2000 MHz, Pulse Modulation with
1 Hz Square
A
A
IEC 1000-4-4
EN 61000-4-4 Electrical Fast Transient +/-2kV on AC lines +/-1kV on DC & I/O lines A A
IEC 1000-4-5
EN 61000-4-5 Surge Withstand
Immunity
+/-2kV Common Mode on AC lines
+/- 1kV Differential Mode on AC Line
+/-2kV Common Mode on I/O lines.
A
A
A
IEC 1000-4-6
EN 61000-4-6
ENV 50141
Conducted RF
Immunity 10Vrms, 0.15-100 MHz, 1kHz 80% AM modulation on AC lines
10Vrms, 0.15-100 MHz, 1kHz 80% AM
modulation on I/O lines
10Vrms, 0.15-100 MHz, Pulse Modulation
with 1 Hz Square.
A
A
A
IEC 1000-4-
11
EN61000-4-
11
Dip
Dropouts
Voltage
Variation
60% for 0.5, 1, 5 & 10 cycles repeated 3
times every 10s
30% for 0.5, 1, 5 & 10 cycles repeated 3
times every 10s
100% for 0.5, 1, 5 & 10 cycles repeated 3
times every 10s.
+10%, -15% for AC from nominal
A
A
A
A
IEC 1000-3-2
EN61000-3-2 Harmonic Current
Emissions
Class A (Other), Class B (Portable
Equipment), Class C (Lighting Equipment) or
Class D (Special Current Waveform)
PASS
IEC 1000-3-3
EN61000-3-3 Voltage Fluctuation
and Flicker in
Low-Voltage
Supply
Systems
Voltage Fluctuation
Flicker PASS PASS
Not verified by UL

#

21-3600E rev1.2 Welcome Alarm Status Admin Reference
1
Dear Customer,
•It is recommended that you review the different operating procedures in this guide
while your system is being installed. Ask your Security Representative / Installer to
explain any questions that you may have about the various topics.
•It is important to check the section at the back of this booklet that will list information
about your alarm system named “Reference Topics”. Ask your Security
Representative / Installer to supply the information that should be entered into this
section.
Thank-you.
Welcome

2 Monitor xL™ LCD Keypad User's Guide 21-3600E rev1.2
1,- # 2ABC 3DEF
45
JKL 6MNOGHI
78
TUV 9WXYPRS
0Z_Q
X
X
Keypad Lights
Red Flashing:
Protection ON
Solid: Partial
protection
(STAY)
Green On
Always with
power
present.
Red Green Yellow
WELCOME
Enter ID:
Yellow On when
trouble condition
present. Flashing
when there is no
AC mains.
The Monitor xL LCD (liquid crystal display)
keypad provides an integrated 2-line display
and multi-function backlit keypad. (The
keypad is hidden behind a hinged access
cover.)
What You can do with the
LCD Keypad
Monitor xL™ LCD keypads provide a
convenient local interface that allows:
•Turning protection on and off;
•Checking status of items;
•Controlling / commanding items;
•Performing administrative tasks;
•Some models can act as a card reader to
permit access to locked doors.
Keypad Display and Buttons
The display is your 'window' into the Monitor xL
system.
When you enter your user ID and/or PIN, you
will be given access to all menus and features
as assigned through your user authorities.
Buttons under the Display Screen
The buttons directly under the display screen
allow selecting associated items on the display
screen. This means the item displayed on the
screen above each button.
Like the rest of the keypad, these buttons are backlit
for use in poor lighting conditions.
The Numeric Keypad
The main keypad (in the bottom-left portion of
the unit) provides a convenient way to enter
numbers, and letters as well (when applicable).
The Key
This is the "escape" key, which allows you to
return to a previous screen, or exit from a
menu altogether (log out).
The ◄arrow ►Keys on the Keypad
These keys allow selecting different items and
topics. When available, the left ◄or right ►
arrow keys will appear on-screen.
Emergency Keys and Programmed
Function Keys
Pressing a number and the ƒkey at the same
time will perform the action as programmed for
that key-sequence. The emergency keys at
the bottom of the keypad each transmit a
specific emergency message (to the central
monitoring station).
For more information on the emergency keys, refer
to "Using the Emergency Keys" in the "Alarms…"
chapter.
For details on the programmable function keys, refer
to "Using the Function Keys" in the "Status &
Control" chapter.
The Monitor xL™ LCD Keypad

21-3600E rev1.2 Welcome Alarm Status Admin Reference 3
If You Are Being Forced to Enter
Protected Premises
A duress (panic) alarm is triggered when you
enter your PIN with the last two digits
reversed. This can be done at reader
keypads, system LCD keypads, and Suite
Security LED keypads.
Normal PIN Example: 1 2 34
If being forced to Enter: 1 2 43
This feature will be available unless it was disabled
by your service technician when the system was
initially set up.
Logging Into the Keypad
(User ID and/or PIN)
NOTE: Your Security Representative /
Installer will supply you with your User ID
and PIN number for pressing into the
keypad and logging in to the system.
(The default Master user ID and PIN is:
e.g. ID: 01 or 001, PIN: 7793)
"Logging In" provides you with access to the
features of the LCD keypad. To log in:
Open the keypad
cover, and press in
your user ID number
and/or PIN number
as indicated on the
display.
When finished viewing or entering items, you can
use the key to exit (press multiple times as
needed--until the "login" screen appears).
Tip: You will also be logged out automatically if you
do not press any keys for approximately one (1)
minute.
Overview of Screens (Topics)
When logged in, you will see only the topics
that you have the authority to use. Some or all
of the following topics will be available:
Selecting a Topic: Press the "►" key until your
desired topic appears on-screen. Then press the
key directly under your topic to select it.
Off // Stay // On:
The first screen that
you'll see allows you
to arm or disarm the area(s) as desired, or to
access other topics.
Only two of arm/disarm selections will appear
at a time—depending on the present arming-
state of the area(s).
Off: all intrusion protection fully off.
Stay: partial protection. Internal motion
detectors disabled. Only perimeter protection
on. For users to remain inside the protected
area.
On: all protection fully on. No one remaining in
the protected area.
Status: This allows checking the status of
various items in the system, or commanding
items into different states.
Please ignore uncommon status screens that may
show up like “Comms, Modem, Licns”. They are for a
service technician’s purposes.
Bypass: This allows bypassing faulty
sensor(s) so the system ignores them, and/or
to allow arming the system.
History: This allows viewing a record of the
tasks that users have performed (disarm
areas, bypass sensors, etc.)
My PIN: This allows the person who is logged
in to change their password.
Users: This allows adding or deleting 'users'
from the system, or viewing or editing settings
for specific users.
A "User" is a person who has the authority to login to
system keypads, and/or to gain entry at access-
controlled doors.
Welcome
Enter ID: _ __
Your Name Appears
Enter PIN: ____
Push ►for Menus
↓Stay ↓On

4 Monitor xL™ LCD Keypad User's Guide 21-3600E rev1.2
Test: This allows testing different aspects of
the system.
Verify: This allows a person to prove they are
present. This lets a monitoring facility know
that you are present after accidentally tripping
a sensor, and/or silencing a false alarm.
Schdule: This allows extending the scheduled
closing time for an area (the "work-late"
feature), or suspending a schedule altogether.
Arm/Disarm: Re-enters the screen for turning
the system to Off, Stay or On.
Time: This allows changing the time and/or
date for a system panel.
Keypad Entry Basics
Use the buttons directly under the display
screen when the arrow “È“ beside desired
subjects on the screen is pointing down to the
corresponding keypad buttons.
The ◄and ►buttons allow you to view
additional topics--when available.
("◄"and/or "►" will appear on the display
screen to indicate these keys can be used).
Use the “” escape key when finished with
your present menu / topic to return to the main
screen or back out of inner screens.
Entering Letters (e.g., for a user's name)
The numeric keypad allows entering numbers--
and letters as well--for items that support this.
When required, press the specific key multiple
times until the desired letter appears:
Pressing "2" multiple times produces: 2 A B
C on the screen.
Pressing "3" multiple times produces: 3 D E
F on the screen.
...etc. (look for the letters on each key).
Tip: The "_" on the 0 key (zero) represents a space.

21-3600E rev1.2 Welcome Alarm Status Admin Reference 5
Alarms, Turning
Protection On
and Off

6 Monitor xL™ LCD Keypad User's Guide 21-3600E rev1.2
Alarm Monitoring Features
Depending on how the system is set up,
specific alarms may be indicated by any of the
following items:
•An alarm message will appear on specific
keypad(s);
•Keypad 'sonalerts' (beepers) may sound;
•A local siren may be triggered;
UL Listed Systems:For UL listed systems, a local
siren must be triggered.
•An alarm message may be transmitted to a
monitoring station (and/or to a management
PC running the Director software);
UL Listed Systems:For UL listed systems, an
alarm message must be transmitted.
•A programmable "output" may be triggered
(this can cause a horn to sound, or perform
any other type of automated 'switching'
function);
•A numeric pager may be called to let the
wearer know that a specific type of alarm has
occurred.
These actions can be fully customized for each type
of event--for each arming level that the system can
be in at any time (Off, Stay or fully ON).
Audible Keypad Tones
•The following audible keypad tones
accompany keypad visual indications like
lights and screen messages.
•There are 2 versions for some of the tones to
operate:
Standard: regular tone operation.
Alternative: opposite to regular operation.
New systems will use Standard Tone Operation.
Alternative tone operation must be especially
programmed by a security representative.
These tones also apply to the ones emitting
from an Arming Station. See the section on
the Arming Station Reference in this manual.
Pressing Keypad Keys/Buttons
Single short beep
Error Tones for Wrong Keys Pressed
6 short beeps
Fire Alarm
Standard and Alternative Operation:
A quick on and off tone.
Burglary Alarm, Trouble Condition
Standard Operation:
Steady continuous tone.
Alternative Operation:
Slow on off tones
Entry and Exit Delay (tones generated when the
protected area is entered or protection is turned on
before leaving)
Standard Operation:
Slow on off tones until the last 15 seconds of
the delay when the tones speed up and become
more immediate to indicate that protection
should be turned off or exiting should be done
to prevent a false alarm.
Alternative Operation:
Continuous tone.
Entry Delay after the System has been in Alarm
or during an Alarm Condition
Standard and Alternative Operation:
Very fast on and off beeps.
Exit Delay with a Protection Point Insecure
Standard and Alternative Operation:
Fast on and off beeps
Confirm Exit Delay (the exit delay is shortened
when the exit door is exited before the end of the exit
delay)
Standard and Alternative Operation:
Fast on and off beeps
Closing Time Soon (a system that has a schedule
will sound a warning when the time for the protection
to turn on is approaching)
Standard and Alternative Operation:
30 minutes before the scheduled protected
area’s protection should turn on, the keypad will
make 3 short beeps. In the final 15 minutes, the
tones will gradually get faster.
Chime (see “Function Key Reference” in this manual)
When the chime feature is turned on and a door
is opened.
Standard and alternative operation:
Three short low sounding beeps.

21-3600E rev1.2 Welcome Alarm Status Admin Reference 7
Sirens
Conventional Siren
Fire Alarm: Intermittent Tone
(the same as a Fire Alarm in the previous
keypad tone details).
Burglar Alarm: Steady Tone.
Voice Siren (optional)
Fire Alarm: Steady tone, followed by
optional voice Fire Alarm Message.
(e.g. “FIRE! FIRE! ... Leave Immediately!”)
Burglar Alarm: On and off tone, followed
by optional voice Burglar Alarm Message.
(e.g. “Intrusion! Intrusion! ... The police have
been called, leave immediately”).
Dealing with Alarms (what to do if
the keypad is beeping)
If an alarm occurs, you must first decide if it is
a valid alarm (break-in, battery failure, etc.), or
a false alarm. If a valid alarm occurs, be sure
to notify the appropriate persons, and/or take
steps to either deal with the item yourself--if
appropriate, or get yourself and others to
safety.
Silencing a False Alarm
An authorized user can Cancel a false alarm,
disarm the system and inform the monitoring
station not to dispatch the respective
emergency service.
This feature may not be available in all areas.
Consult your local security representative / installer
for more information.
However, fire alarms can not be cancelled.
The following steps assume that you have
accidentally triggered a false alarm. If an
alarm has been generated, the LCD display
will show the alarm, and the keypad 'sounder'
will probably also be making a steady tone.
Steps:
1. Enter your user ID
and/or password to
log into the
keypad.
2. Select Yes to
silence the alarm.
3. Select Yes again
to verify who you
are.
4. Enter your PIN
when prompted.
This will signal the
monitoring facility that you want to cancel the
false alarm.
5. To disarm area(s),
select "Off".
6. Select Yes to turn
all areas off, if
desired.
7. If there was a
false alarm, the
following screen
will appear.
8. Select Ack to
acknowledge the
alarm and disarm
the system.
XXX: refers to the number for the monitored sensor
(input point) that was in alarm.
9. Press this key to
perform another
function.
To return to the main screen (log out), press
the ““ escape key a few times, or let the
system time-out (1 minute).
The entry tones will now stop sounding and the
selected areas are now fully disarmed.
If the Verify option is used, it must be done within 1
minute of the false alarm occurring, for the station to
acknowledge the signal.
!! In Alarm !!
Enter ID: _ __
Silence System?
↓Yes ↓No View↓
Verify User?
↓Yes ↓No
To Verify User
Enter PIN: _ ___
Push ►for menus
↓Off ↓Stay
All Areas Off?
↓Yes ↓No
Area XX
Had an Alarm
xxx: Sensor Name
Status ↓Ack
Disarming...
↓Next Function

8 Monitor xL™ LCD Keypad User's Guide 21-3600E rev1.2
Using the Emergency Keys
There are three emergency keys that will
cause an emergency alarm. This will be
transmitted to the monitoring station, and may
also turn on a local alarm, a programmable
output, and/or cause a numeric pager
message to be sent (depending on how the
system is set up).
To transmit an emergency alarm, press the
button on both sides of the specific symbol at
the same time.
1,- # 2ABC 3DEF
45
JKL 6MNOGHI
78
TUV 9WXYPRS
0Z_Q
X
X
WELCOME
Enter ID:
Alert Keys
Fire,press the “F” function key
(discussed in “Using the Function Keys”) and
the left arrow key ◄at the same time.
Panic/Police Alarm, press the left and
right arrow keys ◄►at the same time.
Emergency (Non medical), press the
left arrow key ►and the ““ Escape key at
the same time.
Alert Keys are only available if they have been
ordered by you and supplied by your Security
Representative.
Worklate: Extending the
Scheduled Closing Time
A Schedule represents when e.g. a
commercial system is open for normal
business hours. If the scheduled closing time
is approaching when the protection is turned
on, and you wish to remain in the area, you
can extend the 'closing' time.
Steps:
1. Enter your user ID
and/or PIN to log
into the keypad.
2. Press the
◄►arrow keys
until you see
"Schdule". Then select Schdule.
3. Select Schd to
change the
Schedule for the
selected area (e.g. Office) or select Next
Area to select a different area.
4. Select WorkLate
to change the
closing time for
your selected area.
5. Select "+"or "-"
to adjust (Adj)
the closing time
as desired.
The "+" and "-" (Adj) keys adjust the closing time by
increments of 30 minutes.
6. Once the
scheduled closing
time is correct,
select Ok.
To return to the main screen (log out), press
the ““ escape key a few times, or let the
system time-out (1 minute).
An authorized user may only change the WorkLate
Schedule for the current day. 15 minutes before a
Schedule ends, the system will chime indicating that
a scheduled closing is pending. At this stage, an
authorized user may change the WorkLate time to
suspend the system closing until a specified time.
Welcome
Enter ID: _ __
Menu Options
◄Schdule ►↓Ok
AreaName.....Off
↓Schd ↓Next Area
Close -> 09:30pMo
↓Worklate Susp↓
..until 17:30pFr
↓Ok ↓+Adj -↓
..Until 17:30pFr
↓Ok ↓+ Adj -↓

21-3600E rev1.2 Welcome Alarm Status Admin Reference 9
Suspending Schedules for an
Area or Areas
A schedule can be blocked altogether if you do
not want a scheduled closing to occur.
Steps:
1. Enter your user
ID and/or PIN to
log into the
keypad.
2. Press the ►keys
until you see
"Schedule". Then
press the key under "Schedule" to select it.
3. Select Schd to
suspend the
Schedule for the
selected area (e.g. Office) or select Next
Area to select a different area.
4. Select Susp to
suspend the
Schedule for the
selected area.
5. Select Ok to
suspend the
schedule and
return to the main screen. Select Resume to
reinstate the schedule.
To return to the main screen (log out), press
the ““ escape key a few times, or let the
system time-out (1 minute).
WARNING: A Schedule will remain
suspended indefinitely until “Resume” is
selected .
Turning Protection ON, STAY, or
Viewing the Present Arming-Level
With the appropriate authority, you can arm
and disarm the system, or specific area(s)
using an LCD keypad.
Steps:
1. Enter your user ID
and/or PIN to log
into the keypad.
2. Select the button
for your desired
protection level.
If all areas are currently OFF, only STAY and ON are
shown. If STAY is not an authorized function, only
ON will be shown.
The "Stay" arming-level refers to the perimeter
sensors being monitored, but not the interior ones.
This is typically used when someone is inside the
facility or protected area.
3. Select No to
choose an Area to
view or change (or
Yes for all areas ON).
4. Press the left
button to set the
arming-level.
Select Nxt to choose a different area, or
select Done to exit.
5. Select OK to
confirm. (Review
allows you to
change your mind.)
6. If points are currently bypassed, in tamper,
in alarm, or not Ok, the following screen will
appear when you are attempting to arm an
area (to Stay or ON).
7. Select Ok? to arm
the system, or
View to list points
that are currently not Ok.
WARNING: Selecting OK will arm the
system with point(s) not secure.
Welcome
Enter ID: _ __
Menu Options
◄Schdule ►↓Ok
Area..........Off
↓Schd ↓Next Area
Close by 17:30pMo
↓Worklate Susp↓
Suspended
↓Ok Resume↓
Welcome
Enter ID: _ __
Push ►for menus
↓Stay ↓On
All Areas ON?
↓Yes ↓No
AreaName.....Off
↓On ↓Nxt Done↓
Area(s) to....ON
↓OK ↓Review
Pts in Bypass!
↓Ok? ↓View

10 Monitor xL™ LCD Keypad User's Guide 21-3600E rev1.2
Select View to view
points that are
currently bypassed or
not Ok. At this time the system will indicate
points that are not OK and force you to either
bypass or secure
these points in order
to arm the system.
Select the desired topic:
•Pts: Bypassable points (sensors) in the
displayed area;
•Next: Show the
next area;
•All: All bypassable
points regardless of area.
When a point/sensor is displayed, you'll have
these options:
•"◄►": Press the arrow keys to scan through
the sensors (points) in the system (or the
selected area);
•Bypass: Select this
for the system to
ignore (bypass) the
selected sensor.
•"?" jumps to the next point that is not OK.
Once all points have
been bypassed or
secured, the system will automatically arm.
After arming (On), leave immediately by the
designated exit route!
The tone you will hear is a reminder for you to
quickly leave the area or premises. During the
last 15 seconds this intermittent tone will
speed up. The exit tones will now stop
sounding and the selected areas are now fully
armed.
Turning Protection OFF
1. When you have entered the area with THE
protection ON, the keypad will beep and
the screen will
display:
2. Enter your user ID and/or PIN to log into
the keypad.
3. This screen will display, to choose turning
the area fully off
or put in Stay for
partial protection.
4. After making your
selection, this
screen will ask if
the protection for all areas should be
changed, if there is more then one area. If
“No” is selected,
this screen will
display the
current condition of the available areas
e.g. “On” and selections for that area.
Selections for other areas are displayed by
pressing ”Nxt” or just change the
protection level for the area you are in.
Pressing the button below “Done” will
process the selections you made.
Turning Protection On by Area
Groups, a Group of Areas or
Individual Areas.
Check with your Security Representative / Installer
to have this feature added to your system. You must
have the proper Authority to control additional
protected areas.
1. Enter your user ID
and/or PIN to log
into the keypad.
2. Select the button
for your desired
protection level.
Selecting “Stay” will supply selections for the
areas separately. Selecting “On” will supply
the special way to turn area protection on.
3. Select Yes if an
authorized user
has been
assigned with the authority level to turn on a
certain group or groups of areas at the same
time.
4. If authorized,
select No to
choose individual
Area Groups or Areas to turn on.
AreaName.....Off
↓Pts ↓Next All↓
xxx:►Sensor Name
Status ↓Bypass ↓?
Arming...Bypass
↓Next Function
Area(s) arming
Please Leave
To Disarm
Enter ID: _ __
Push ►for menus
↓Off ↓Stay
Points not Ok!
↓View
All Areas Off?
↓Yes ↓No
Area 1.........On
↓Off ↓Nxt Done↓
Welcome
Enter ID: _ __
Push ►for menus
↓Stay ↓On
All Areas ON?
↓Yes ↓No
Choose Area by?
↓Group ↓Area

21-3600E rev1.2 Welcome Alarm Status Admin Reference 11
Area Priority Protection On/Off
Priority Arming requires that areas are armed
and disarmed in order of their priority. If
protection for Area 1 is turned on first, then
area 2 and then 3, disarming the areas would
then require area 3 to be turned off first, then
area 2 and then 1. This sequence can vary
and it is necessary to learn the order from your
Security Representative / Installer or System
Administrator.
•If protection for
areas is not turned
on, off in their
proper sequence, this error screen will appear
and the process will not occur. It will have to be
repeated properly.
Common Area Protection On/Off
A common entrance used by e.g. a user who
has authority for only certain areas in a
multiple area system, must be able to enter the
entrance to reach their areas. At the same
time, a user who only has authority for their
particular areas beyond the same entrance
must also be able to enter. This can make this
main entrance a “common area”. Both users
can have authority for this common area to
reach their particular areas. This allows them
to be able to turn the protection on and off to
this common area when their authorized areas
are in use. Check with your Security
Representative / Installer or System
Administrator for information and authority for
a Common Area.
Turning ON an Area’s Protection
using an Access TOKEN
Check with your
Security
Representative /
Installer to have this
feature added to your
system. You must have
the proper Authority to
control additional
protected areas.
1. Place and hold
the token in
front of the
keypad within 2 -3 inches (78mm).
2. The exit delay
will start and the
keypad will
sound its exit delay beeps.
Turning OFF an Area’s Protection
using an Access TOKEN
1. If you have entered the area with protection
on, the keypad
will beep and
the screen will
display:
2. Repeat holding the token in front of the
keypad within 2 -3 inches (78mm).
3. The screen will
display:
Protection will be off.
AREA 1
Priority Fail
Welcome
Enter ID: _ __
Arming...
↓Next Function
To Disarm
Enter ID: _ __
Disarming...
↓Next Function

12 Monitor xL™ LCD Keypad User's Guide 21-3600E rev1.2
UK System Operation
The following is required to ensure conformity
with the ACPO, DD243:2002 Standard.
UL Listed Systems:Not to be used for UL listed
systems.
If this screen displays
after disarming …
the system has had a
Confirmed Alarm and the following procedure
must be done:
Resetting Confirmed Alarms
Once a confirmed alarm occurs at a site, the
user will be able to disarm and silence the
system. The confirmed alarm strobe display, if
it is part of the system’s equipment, will also
turn off. However, arming will be blocked until
reset by an Engineer during a service call in
the following manner:
1. The main panel cabinet must be opened to
activate the ‘tamper sensor’
2. The system will generate a tamper alarm; the
authorized user must first silence this.
3. Next, the Service user ID and Pin must be
entered followed by the ID and Pin of the
authorized user.
(Master end user ID and PIN default: e.g. ID: 01
or 001, PIN: 7793)
4. Select “Reset Confirmed Alarm”.
5. Close the main panel cabinet to secure the
tamper sensor.
If there is an attempt made to arm the system
and this reset procedure has not been done, this
screen will appear
momentarily…
External Arming Button
When attempting to arm the system and exiting
the protected area the “external arming button”
must be pressed. Failure to do so will result in a
“Failed to Exit” condition. The protection will
disarm at the end of the arming delay and a failed
to exit report will be logged in the system’s
History log.
UK and European System
Operation
UL Listed Systems:Not to be used for UL listed
systems.
Restoring Tampers
Once a tamper condition occurs it will be
logged in the system’s History log. Any
authorized users can silence tampers
however; the following system message will
scroll on the LCD display to indicate that a
tamper condition had occurred…
This message will only appear when the
tamper condition has been restored. The
yellow “trouble” light on the keypad will also
turn off.
1. This message can only be cleared during a
service call in the following manner.
2. The main panel cabinet must be opened to
activate the ‘tamper sensor’
3. The system will generate a tamper alarm; the
authorized user must first silence this.
4. Next, the Service user ID and Pin must be
entered followed by the ID and Pin of the
authorized user.
(Master end user ID and PIN default: e.g. ID: 01
or 001, PIN: 7793)
This screen message
will display to prompt
for the master
authority user to enter their ID and Pin.
After the reset procedure has been completed,
the system Status can be checked to ensure that
the only tamper condition still displaying is the
open main panel cabinet.
5. Close the main panel cabinet to secure the
tamper sensor.
Arming / Disarming Conditions
If at the time of arming, certain system faults are
present, arming will be blocked.
The red armed light on the keypad will only stay
on for 30 seconds from the time of any arming.
This is to prevent the condition of the system
from being easily visible.
Confirmed Alarm!
Enter ID: _ __
Was in Tamper!
Enter ID: _ __
!! Cannot Arm !!
Confirmed Alarm!
2nd Service User
Enter ID: _ __
