Vermeiren Eclips+ AD User manual

VERMEIREN
INSTRUCTION MANUAL
MODE D’EMPLOI
G E B R U I K S A A N W I J Z I N G
GEBRAUCHSANWEISUNG
Eclips+AD

Instructions to the specialist dealer
This instruction manual is part and parcel of the product and must accompany every product sold.
Version: A, March 2011
All rights reserved, including translation.
No part of this manual may be reproduced in any form what so ever (print, photocopy, microfilm or any other process) without
written permission of the publisher, or processed, duplicated or distributed byusing electronic systems.
© N.V. Vermeiren N.V. 2011
Instructions pour les distributeurs
Ce manuel d'instructions fait partie du produit et doit accompagner chaque produit vendu.
Version : A, Mars 2011
Tous droits réservés, y compris la traduction.
Aucune partie de ce manuel ne peut être reproduite, sous quelque forme que ce soit (imprimée, photocopie, microfilm ou tout
autre procédé) sans l'autorisation écrite du publicateur, ni traitée, dupliquée ou distribuée à l'aide de systèmes électroniques.
© N.V. Vermeiren N.V. 2011
Instructies voor de vakhandelaar
Deze handleiding is deel van het product en dient bij iedere product te worden geleverd.
Versie: A, maart 2011
Alle rechten, inclusief vertaling, voorbehouden.
Niets uit deze handleiding mag geheel of gedeeltelijk in enige vorm (druk, fotokopie, microfilm of ieder ander procedé) zonder
de schriftelijke toelating van de uitgever worden gereproduceerd of met behulp van elektronische systemen worden verwerkt,
gekopieerd of verspreid.
© N.V. Vermeiren N.V. 2011
Hinweise für den Fachhändler
Diese Gebrauchsanweisung ist Bestandteil des Produkts und ist bei jeder Produkts auszuhändigen.
Version: A, März 2011
Alle Rechte, auch an der Übersetzung, vorbehalten.
Kein Teil der Gebrauchsanweisung darf in irgendeiner Form (Druck, Fotokopie, Mikrofilm oder einem anderen Verfahren) ohne
schriftliche Genehmigung des Herausgebers reproduziert oder unter Verwendung elektronischer Systeme verarbeitet,
vervielfältigt oder verbreitet werden.
© N.V. Vermeiren N.V. 2011

EN
Eclips+ AD
2011-03
!"#$%&%
Contents
Preface ...................................................................................................................................... 2!
1!Productdescription................................ ...................................................................... 3!
1.1!Intended Use................................................................................................................3!
1.2!Technical specifications ..............................................................................................4!
1.3!Components.................................................................................................................5!
1.4!Accessories..................................................................................................................5!
1.5!Location identification plate........................................................................................5!
1.6!Explanation of symbols...............................................................................................5!
1.7!Safety rules ..................................................................................................................6!
2!Use................................................................................................................................ 6!
2.1!Carrying the wheelchair ..............................................................................................6!
2.2!Mounting the rear wheels............................................................................................7!
2.3!Unfolding the wheelchair ............................................................................................7!
2.4!Mounting or removing of the footrests .......................................................................7!
2.5!Operating the brakes....................................................................................................7!
2.6!Mounting or removing of arm supports ......................................................................8!
2.7!Transfer in and out the wheelchair ..............................................................................9!
2.8!Correct position in the wheelchair ..............................................................................9!
2.9!Riding the wheelchair..................................................................................................9!
2.10!Moving on slopes ......................................................................................................10!
2.11!Negotiating steps or kerbs .........................................................................................10!
2.12!Fold up the wheelchair ..............................................................................................11!
2.13!Taking off the wheels ................................................................................................11!
2.14!Transport in the car....................................................................................................12!
2.15!Use of the wheelchair as seat in a motor vehicle ......................................................12!
3!Installation and adjustment .....................................................................................14!
3.1!Tools ..........................................................................................................................14!
3.2!Manner of delivery ....................................................................................................14!
3.3!Adjusting the seat height and seat angle ...................................................................15!
3.4!Seat width adjustment ...............................................................................................17!
3.5!Seat ............................................................................................................................18!
3.6!Back...........................................................................................................................19!
3.7!Adjust the brakes.......................................................................................................20!
3.8!Adjusting of the footrests ..........................................................................................20!
3.9!Adjusting of the pushing handles ..............................................................................21!
3.10!Adjusting of the tip cap .............................................................................................22!
3.11!Adjusting the stability and the maneuverability........................................................22!
4!Maintenance .............................................................................................................. 22!
4.1!Regular Maintenance.................................................................................................22!
4.2!Shipping and storage .................................................................................................23!
4.3!Care ...........................................................................................................................23!
4.4!Inspection ..................................................................................................................24!
4.5!Disinfection ...............................................................................................................24!
5!Guarantee .................................................................................................................. 26!
6!Disposal ...................................................................................................................... 26!
7!Declaration of conformity ........................................................................................26!
8!Maintenance plan......................................................................................................27!
9!Disinfection book ...................................................................................................... 27!

EN
Eclips+ AD
2011-03
!"#$%'%
Preface
First of all we want to thank you for putting your trust in us by selecting one of our
wheelchairs.
The Vermeiren wheelchairs are the result of many years of research and experience. During
the development, special attention was given to the ease of use and the serviceability of the
wheelchair.
The expected lifetime of your wheelchair is strongly influenced by the care and maintenance
of the wheelchair.
This manual will help you get acquainted with the operation of your wheelchair.
Following the user instructions and the maintenance instructions are an essential part of the
warranty.
This manual reflects the latest product developments. Vermeiren has the right to introduce
changes without the obligation to adapt or replace previously delivered models.
For any further questions, please consult your specialist dealer.

EN
Eclips+ AD
2011-03
!"#$%(%
1 Productdescription
1.1 Intended Use
The wheelchair is intended for people with walking difficulties or no walking abilities.
The wheelchair is designed to transport 1 person.
The wheelchair is suited for indoor and outdoor use.
The user can propel the wheelchair by himself or have the wheelchair pushed by an
attendant.
The different types of fittings and accessories, and the modular construction allow full use by
persons disabled by:
paralysis
loss of limbs (leg amputation)
limb defects or deformations
stiff or damaged joints
heart insuffiencies and poor blood circulation
balance disturbances
cachexia (decrease in muscle)
and also for aged persons.
When providing for individual requirements:
body size and weight (max. 130kg (286.6 lb.))
physical and psychological condition
residential circumstances
environment
should be taken into consideration.
Your wheelchair should only be used on surfaces where all four wheels are touching the
ground and where there is sufficient contact to propel the wheels equally.
You should practice for use on uneven surfaces (cobblestones, etc.), slopes, curves and to
get past obstacles (kerbs, etc.).
The wheelchair should not be used as a ladder, nor is it a transport for heavy or hot objects.
When used on mats, carpeted floors or loose floor coverings, the floor covering can get
damaged.
Use only Vermeiren approved accessories.
The manufacturer is not liable for damage caused by the lack of or improper service or as a
result of not following instructions from this manual.
Compliance with the user and maintenance instructions are an essential part of the
guarantee conditions.

EN
Eclips+ AD
2011-03
!"#$%)%
1.2 Technical specifications
Technical terms below are valid for the wheelchair in standard settings.
If other footrest / arm support or other accessories are used, the tabulated values will change.
Make
Vermeiren
Address
Vermeirenplein 1/15, B-2920 Kalmthout
Type
Manual wheelchair
Model
Eclips+ AD
Maximum occupant mass
130 kg (286.6 lb.)
Description
Min.
Max.
Overall length with legrest
1040 mm (40.94 in.)
Effective seat width
390 mm
(15.35 in.)
420 mm
(16.54 in.)
440 mm
(17.32 in.)
460 mm
(18.11 in.)
480 mm
(18.90 in.)
500 mm
(19.69 in.)
Overall width (depends on the seat
width)
590 mm
(23.23 in.)
620 mm
(24.41 in.)
640 mm
(25.20 in.)
660 mm
(25.98 in.)
680 mm
(26.77 in.)
700 mm
(27.56 in)
Folded length
1040 mm (40.94 in.)
Folded width
300 mm (11.81 in.)
Folded height
910 mm (35.83 in.)
1015 mm (39.96 in.)
Total mass
± 17 kg (37.48 lb.)
Mass of heaviest part
9,55 kg (19.84 lb.)
Masses of parts that can be
dismantled or removed
Foot supports: 1,90 kg (4.19 lb); Arm supports: 1,40 kg (3.09 lb);
Rear wheels: 4,15 kg (8.82 lb)
Static stability downhill
7,5° (in standard configuration)
Static stability uphill
5° (in standard configuration)
Staticc stability sideways
>16° (in standard configuration)
Obstacle climbing
60 mm (2.36 in.)
Seat plane angle
0°
13°
Effective seat depth
420 mm (16.54 in.)
Seat surface height at front edge
430 mm (16.93 in.)
530 mm (20.87 in.)
Backrest angle
0°
13°
Backrest height
420 mm (16.54 in.)
460 mm (18.11 in.)
Distance between footrest and seat
390 mm (15.35 in.)
460 mm (18.11 in.)
Angle between seat and footrest
-3°
10°
Distance between armrest and seat
220 mm (8.66 in.)
Front location of armrest structure
380 mm (14.96 in)
Handrim diameter
535 mm (21.06 in.)
Horizontal location of axle
(deflection)
-47 mm (-1.85 in.)
19 mm (0.75 in.)
Minimum turning radius
1530 mm (60.24 in.)
Diameter Krypton PU Rear wheels
24"
Tyre pressure, rear (driving) wheels
Max. 3.5 bar
Diameter Krypton PU steering
wheels
200 mm (8 in.)
Tyre pressure, steering wheels
Max. 2.5 bar
Storage and use temperature
+ 5 °C (+41 °F)
+ 41 °C (+106 °F)
Storage and use humidity
30%
70%
We reserve the right to introduce technical changes. Measurement tolerance ± 15 mm / 1,5 kg / ° (0.59 in. / 3,3 lb. / 1,5°)
Table1: Technical specificationsEclips+ AD

EN
Eclips+ AD
2011-03
!"#$%*%
The wheelchair complies to the requirements set up in:
ISO 7176-8: Requirements and test methods for static, impact and fatigue strengths.
ISO 7176-16: Resistance to ignition of upholstered parts
ISO 7176-19: Wheeled mobility devices for use as seats in motor vehicles.
1.3 Components
1.4 Accessories
The following accessories are available for the Eclips+ AD:
Anterior pelvic belt (B58) for mounting on the tubes of the back
Anti-tipping device (B78) for mounting on the bottom frame
Drum brakes for the attendant (B74) for mounting on the push handles
1.5 Location identification plate
1.6 Explanation of symbols
Maximum mass
Indoor and outdoor use
Down slope
Up slope
CE conformity
1= Vermeiren name
2 = Taxi hooks
3 = Identification plate
4 = Name Eclips+ AD
1 = Cross
2 = Handles
3 = Back
4 = Arm pads
5 = Arm supports
6 = Driving wheels (rear wheels)
7 = Hand rims
8 = Brakes
9 = Tip cap
10 = Steering wheels (Front wheels)
11 = Footrests
12 = Seat

EN
Eclips+ AD
2011-03
!"#$%+%
1.7 Safety rules
!" To prevent injury and/or damage to your wheelchair, make sure that no objects
and/or body parts are caught in the spokes of the driving wheels.
!" The parking brakes should be applied before getting into and out of the wheelchair.
!" When getting into and out of the wheelchair, do not stand on the footplates. These
should be folded up beforehand, or the leg supports should be swung completely
outwards out of the way.
!" Investigate the effects of shifting the centre of gravity on the behavior of the wheelchair,
for example on up or down gradients, on laterally sloping ground, or when overcoming
obstacles. Obtain support from an attendant.
!" If you want to pick up something (lying in front of, on the side, or to the rear of the
wheelchair), you should not lean too far out to avoid tipping over.
!" When moving through doors, arches, etc. ensure that there is enough room at the sides
so that you do not get your hands or arms caught or crushed and that there is no
damage to the wheelchair.
!" Only use your wheelchair according to regulations. For example, avoid uncontrolled
rolling against obstacles (steps, kerbs, doorframes, etc) or dropping down from ledges.
The manufacturer cannot assume liability for damage caused by overloading, collision
or other improper use.
!" Stairs may only be negotiated when aided by another person. If furnishings like drive-on,
ramps or lifts are available, use them.
!" When moving on the public highway, you are subject to the rules of the road.
!" When driving your wheelchair, you should not be under the influence of alcohol or
medicine as in the case of driving other vehicles. This also applies to indoor driving.
!" When travelling outdoors, adapt your driving to weather and traffic conditions.
!" When transporting the wheelchair, never pick it up by grasping movable parts (armrests,
leg supports, etc.)
!" To be better visible when driving in the dark, wear the brightest possible clothing or
clothes with reflectors, and check that the reflectors mounted on the sides and rear of
the wheelchair are clearly visible.
!" Be careful when using possible causes of fire such as cigarettes since they may set the
seat and back covers alight.
!" Never exceed the maximum load of 130 kg (286.6 lb.).
2 Use
This chapter describes the everyday use. These instructions are for the user and the
specialist dealer.
The wheelchair is delivered fully assembled by your specialist dealer. The instructions
intended for the specialist dealer on how to set up the wheelchair are given in § 3.
2.1 Carrying the wheelchair
The best way to carry the wheelchair is to make use of the wheels and roll the wheelchair.
If this is not possible (e.g. when the rear wheels are taken off for transportation in a car),
firmly grasp the frame on the front and the grips. Do not use the foot or arm rests or the
wheels to grasp the wheelchair.

EN
Eclips+ AD
2011-03
!"#$%,%
2.2 Mounting the rear wheels
1. Take the rear wheel and push on button !.
2. Keep the button pushed in and mount the rear
wheels axle till it stops.
3. Release the button.
4. Check that the wheel is secured.
2.3 Unfolding the wheelchair
!"CAUTION: Risk of clamping !Keep fingers away from moving parts of the
wheelchair.
1. Position yourself behind the wheelchair.
2. Use the hand-grips to open the wheelchair as much as possible.
3. Position yourself at the front of the wheelchair.
4. Push both seating tubes down till they are fixed in their position.
2.4 Mounting or removing of the footrests
The mounting of the footrests is done as follows:
1. Hold the footrest sideways at the outside of the
wheelchair frame and mount the tube hood !
into the frame.
2. Swing the footrest inwards till it clicks in
position.
3. Swing the foot plate downwards.
To take off the footrests:
1. Pull handle ".
2. Swing the footrest to the outside of the
wheelchair till it comes loose from the guidance.
3. Pull the footrest from tube hood !.
2.5 Operating the brakes
!"WARNING: The brakes are not used to slow down the wheelchair during
movements !Use the brake only to prevent the wheelchair from unintended
movements.
!"WARNING: Good operation of the brakes is influenced by wear and
"#$%&'($&%(#$)#*)%+,)%(-,.)/0&%,-1)#(21)'341)56)! Check the condition of the tires
before each use.
!"WARNING: The brakes are adjustable and can wear !Check the operation of the
brakes before each use.

EN
Eclips+ AD
2011-03
!"#$%-%
To apply the brakes:
1. Push the brake handles !forward till you feel a
distinctive click.
!"CAUTION: Risk of unintended movement !
Make sure the wheelchair is on a flat
horizontal surface before releasing the
brakes. Never release both brakes
simultaneously.
To release the brakes:
1. Release one brake by pulling the handle !
backwards.
2. Hold the hand-rim of the release wheel with
your hand.
3. Release the second brake by pulling the handle
backwards.
2.6 Mounting or removing of arm supports
!"CAUTION: Risk of clamping !Keep fingers, buckles and clothes away from the
bottom side of the arm support.
The arm supports of the wheelchair can be mounted by following instructions.
1. Mount the rear tube of the arm rest in tube hood !. (Fig A)
2. Make sure the arm support is mounted very well.
3. Fold the arm rest forward.
4. Pull the lever "#on tube hood $#upwards. (Fig B)
5. Click the front tube of the arm rest %in tube hood $. (Fig B)
To open and remove the arm rest:
1. Pull lever "and pull the front of the arm rest !upwards. (Fig C)
2. Fold the arm rest backwards.
3. To remove the arm rest, pull the rear of the arm support from tube hood $. (Fig D)
A
B

EN
Eclips+ AD
2011-03
!"#$%.%
2.7 Transfer in and out the wheelchair
!"CAUTION: In case you can not perform the transfer in a safe manner, ask
someone to assist you.
!"CAUTION: Risk of tipping over of the wheelchair !Do not stand on the foot
plates.
1. Position the wheelchair as close as possible to
the chair, couch or bed to/from you wish to
transfer.
2. Check both brakes from the wheelchair are in
the on position.
3. Fold the foot plates upwards to prevent
standing on them.
4. If the transfer is on the side of the wheelchair,
fold the arm support on that side upwards.
(see § 2.6)
5. Transfer to/from the wheelchair.
2.8 Correct position in the wheelchair
Some recommendations for a comfortable use of the wheelchair:
Position your backside as close as possible to the back rest.
Make sure your upper legs are horizontal !If needed adjust the length of the foot
rests. (see § 3.9.1)
2.9 Riding the wheelchair
!"WARNING: Risk of clamping !Prevent your fingers from being caught by the
wheels spokes.
!"WARNING: Risk of clamping !Be careful passing through restricted passages
(e.g. doors).
!"WARNING: Risk of burns !Be careful when driving in hot or cold environments
(sunshine, extreme cold, saunas, etc.) for a sufficient amount of time and when
touching - Surfaces can assume the environment temperatures.
1. Release the brakes.
2. Take both hand rims at their highest position.
3. Lean forward and push the hand rims forward until straight arms.
4. Swing your arms loosely back to the hand rims topside and repeat the movement.
C
D

EN
Eclips+ AD
2011-03
!"#$%&/%
2.10 Moving on slopes
!"WARNING: Control your speed !Moving on slopes as slow as possible.
!"WARNING: Consider the capacities of your attendant !If your attendant does not
have enough force to control the wheelchair, put on the brakes.
!"WARNING: Risk of tipping over !Lean forward to move your centre of gravity
forward. To improve a better stability.
1. If available on the wheelchair, wear the safety belt.
2. Do not attempt moving on too high slopes. The maximum
slope angles (upwards and downwards) are mentioned in
table 1.
3. Ask an attendant to help you moving on the slope.
4. Lean forward to move your centre of gravity forward.
2.11 Negotiating steps or kerbs
2.11.1 Getting down steps or kerbs
Riding down low kerbs can be done moving forwards. Make sure that the foot rests do not
touch the ground.
A practiced user can negotiate small steps or kerbs by himself:
!" WARNING: Risk of tipping over !If you do not have
enough experience with your wheelchair, ask
assistance of an attendant.
1. Bring balance on the rear wheels to reduce the pressure on
the front wheels.
2. Negotiate the kerbs.
Higher kerbs can be taken forward with an attendant:
1. Ask the attendant to tip the wheelchair slightly backwards.
2. Get past the kerbs while moving on the rear wheels.
3. Put the wheelchair back on the four wheels.
An experienced user can negotiate higher kerbs by himself. This is
best done backwards.
1. Turn the wheelchair to have the rear wheels facing the
kerb.
2. Lean forward to move your centre of gravity forward.
3. Move the wheelchair close to the kerbs.
4. Use the hand rim to roll-off wheelchair from the kerb in a
controlled manner.
2.11.2 Moving up steps or kerbs
Moving up steps or kerbs with attendant as follows:
1. Prevent the foot rests from touching the kerb.
2. Ask the attendant to tip the wheelchair backwards, just
enough to move the front wheels over the kerb.
3. Lean backwards to move your centre of gravity above the rear
wheel.
4. Place the front wheels on the kerb.
5. Roll rear wheels of the wheelchair over the kerb.

EN
Eclips+ AD
2011-03
!"#$%&&%
Higher kerbs are negotiated backwards:
1. Turn the wheelchair to have the rear wheels facing the kerb.
2. Lean backwards and move your centre of gravity above the rear wheels.
3. Ask the attendant to pull the wheelchair on the kerb.
4. Take back the normal position in the wheelchair.
An experienced user can negotiate kerbs by himself:
!"WARNING: Risk of tipping over !If you have not enough experience to control
the wheelchair, get help from an attendant.
1. Drive until the kerbs.
2. Ensure that the footrest do not touch the kerbs.
3. Lean backwards so you are balancing on the rear wheels.
4. Role the frontwheels balancing over the kerbs.
5. Bend forward for more stability.
6. Role the rear wheels over the kerbs.
2.11.3 Taking of stairs
Taking of stairs while you staying in the wheelchair shall be according following rules:
!"WARNING: Risk of tipping over !Taking of stairs shall always with 2 attendants.
1. Remove the footrests.
2. One attendant tip the wheelchair slightly backwards.
3. The second attendant take the front of the frame.
4. Stay calm, avoid sudden movements and keep your arms inside the wheelchair.
5. Take the steps on the rear wheels of the wheelchair.
6. Mounting the footrests back after taking the stair.
2.12 Fold up the wheelchair
!" CAUTION: Chance of pinching !Do not place fingers between the components
of the wheelchair.
1. Fold or remove the footplates (see § 2.4).
2. Take the seat on the front side and backside and pull it up.
2.13 Taking off the wheels
To facilitate the transport off the wheelchair the rear wheels can be taken off:
1. Make sure the brakes standing in the off
position.
2. Take the wheelchair to the side frame where
you want to remove the wheel.
3. Press the button !in the center of the wheel
hub.
4. Pull the wheel away from the frame.

EN
Eclips+ AD
2011-03
!"#$%&'%
2.14 Transport in the car
!"WARNING: Risk of injury !See that the wheelchair is attached properly. So you
can avoid injury from the passengers during collision or sudden braking.
!"WARNING: Risk of injury !Use for attaching the wheelchair and passenger
NEVER the same seatbelt.
1. Remove footrests and accessories.
2. Store footrests and accessories safely.
3. If possible, fold the wheelchair and remove the wheels.
4. Place the wheelchair in the luggage place.
5. If the wheelchair and the passenger compartment is NOT separated, attach the
frame of the wheelchair securely to the vehicle. You can use the available safety
belts in the vehicle.
2.15 Use of the wheelchair as seat in a motor vehicle
!"WARNING: The wheelchair has passed the crash of ISO 7176-19: 2008 and, as
such, has been designed and tested for use only as forward-facing seat in a
motor vehicle.
!"WARNING: The wheelchair's pelvic belt alone is not suited as an occupant
restraint belt.
The wheelchair is tested using the four-point strap-tie system and a 3-point occupant-
restraint system.
Whenever feasable, use the seat of the vehicle and store the wheelchair in the cargo area.
Steps to secure the wheelchair in a motor vehicle:
1. Check that the vehicle is equipped with a suitable wheelchair tie down and occupant-
restraint system, conform ISO 10542.
2. Check that the components of the wheelchair tie down and occupant restraint system
are not frayed, contaminated, damaged or broken.
3. If equipped with an adjustable seat and/or back tilt, make sure that the wheelchair
user is sitting as upright as possible. If the user's condition prevents this, a risk
assessment should be done to evaluate the user's safety during transit.
4. Remove all mounted accessories such as trays and respiratory equipment, and
secure them in a safe place.
5. Position the wheelchair facing forward in the travelling direction, centrally between
the tie-down rails mounted in the floor of the vehicle.
6. Make sure that the indicated zones around the wheelchair user are clear from rigid
vehicle parts.

EN
Eclips+ AD
2011-03
!"#$%&(%
7. Mount the front securement straps according to the instructions of the strap-system
manufacturer at the indicated place. (figure 3)
This place is marked on the wheelchair with a symbol. (figure 4)
8. Roll back the wheelchair until the front straps are tight.
9. Apply the wheelchair brake.
10. Mount the back securement straps according to the instructions of the strap-system
manufacturer at the indicated place. (figure 3)
11. This place is marked on the wheelchair with a symbol. (figure 4)
figure 3
Steps to secure the wheelchair user:
1. Remove both arm rests.
2. If present, attach the wheelchair's pelvic belt.
3. Attach the occupant restraint belts according to the instructions of the strap-system
manufacturer.
4. Wear the pelvic belt low across the front of the pelvis, so that the angle of the pelvic
belt is within the preferred zone of 30° to 75° to the horizontal, similar to that shown
below.
5. A steeper (greater) angle within the preferred zone is desirable.
6. Adjust the belt tightly according to the instructions of the strap-system manufacturer,
consistent with the user's comfort.
7. Ensure that the restraint belt connects in a straight line to the anchor point in the
vehicle and that no bends in the belt are visible, for instance at the axle of the rear
wheel.
8. Install the arm rests, if desired. make sure that belts are not twisted or held away
from the body by wheelchair components such as arm rests or wheels.

EN
Eclips+ AD
2011-03
!"#$%&)%
3 Installation and adjustment
The instructions in this chapter are for the specialist dealer.
The Vermeiren Lightweight wheelchairs Eclips+ AD has been designed entirely for your
comfort. This wheelchair can be adjusted to individual requirements as explained below.
To find a service facility or specialist dealer near you, contact the nearest Vermeiren facility.
A list of Vermeiren facilities can be found on the last page.
!"WARNING: Risk of unsafe settings - Use only the settings described in this
manual.
!"WARNING: Variation of allowed adjustments can still change the stability of your
wheelchair (tilt back or sideways).
3.1 Tools
To set up the wheelchair the following tools are needed.
Wrench set n° 10 to n° 19
Allen key set n° 4 to n° 5
Screwdriver Phillips head
3.2 Manner of delivery
The Vermeiren Eclips+ AD shall be delivered with:
1 frame with arm supports, rear and front wheels (seat height of 500 mm - 19.69 in.,
seat angle of 7°)
1 pair footrests
Tools
Manual
Accessories

EN
Eclips+ AD
2011-03
!"#$%&*%
3.3 Adjusting the seat height and seat angle
!"WARNING: Risk of injury - Make sure that all screws are properly tightened with
the appropriate tool.
!"WARNING: Risk of tipping over - When the driving wheels are adjusted, the
position of the wheels are altered.
When adjusting the height of the seat the wheel may not touch the armrest. Maximum height
adjustment is when the wheel do not touch the armrest.
The Vermeiren Eclips+ AD is adjustable in 4 seat heights and different seat angles by
changing the wheels position. At each height there is a different setting of the front and rear
wheels.
The summary of the different seat heights by a standard seat angle 7° is tabulated below.
Seat height
Rear wheel
Front wheel
Ø
Holes
Ø
Adapter !/
fork
Holes
430 mm (16.93 in.)
22"
Hole 9 and 11
200 mm
Short
Hole 2 and 3
470 mm (18.50 in.)
24"
Hole 8 and 10
140 mm
Standard
Hole 2 and 3
500 mm (19.69 in.)
(Standard)
24"
Hole 6 and 8
200 mm
Standard
Hole 2 and 3
530 mm (20.87 in.)
24"
Hole 4 and 6
200 mm
Standard
Hole 1 and 2
Table 3: Seat heights Eclips+ AD
Change the seat height and seat angle according the following steps (refer to the figure on
the next page):
* Front wheel:
1. Loosen the screws "from the steering wheel adapter !.
2. Choose correct size for the adapter !and fork.
3. Place the steering wheel adapter in the desired position.
4. Tighten the screws "properly.
5. Change diameter of the steering wheel if necessary (only for seat height 470 mm(18.5
in.)).
* Rear wheel:
6. Remove the rear wheels (see § 2.13).
7. Loosen the fixing screws "from the rear axle block !.
8. Push the axle block !upwards or downwards to the desired height.
9. Tighten the screws "properly.
10. Mount the rear wheels.
11. Adjust the brakes according § 3.8.

EN
Eclips+ AD
2011-03
!"#$%&+%
Front wheel
Axle plate rear wheels
Seat height 430 mm (16.93 in)
Seat height 500 mm (19.69 in) (standard)
Seat height 530 mm (20.87 in)
Seat height 470 mm (18.50 in)

EN
Eclips+ AD
2011-03
!"#$%&,%
Adjustment of the slope nuts #from the steering wheels.
!"WARNING: Risk of injury - Make sure that all screws are properly tightened with
the appropriate tool.
!"WARNING: Risk of injury - Make sure that the eccentric screw settings are
identical on both front-wheel adapters and, before using the wheelchair.
This figure illustrates the principle. The position of the screw thread is indicated by a number.
AShows the frame when the seat is horizontal and the
adapter is perpendicular to the ground.
BShows the frame when the seat is tilted slightly and the
adapter is not perpendicular.
3.4 Seat width adjustment
The wheelcair can be adjusted to seat widths of 390 mm to 500 mm (15.35 lb. to 19.69 lb.).
The straps on the seat and rear covers must be loosened completely beforehand. (see the
"#$%&'()*+,'$&-*$./*+0$12-34
Loosen the 4 locking screws on the spacer guide (these are located on the two top
and bottom ends of the cross-hinged tubing) with an appropriate Allen key.
Loosen the four Phillips screws alongside the locking screws on the brackets for the
hinged tubing. These are located on the top and bottom end of the cross-hinged
tubing.
Turn the disc screws on the two boomerangs so that they can telescope freely.
Pull the hinged tubing at each end to the required seat width. The cross-hinge
components have been drawn out to the required width when the required lengths
can be precisely seen in all four fields on the cross-hinged tubing and the Phillips
screws (B) engage on their own.
A
B
D
!
C
4 x
4 x
B
D
C
A

EN
Eclips+ AD
2011-03
!"#$%&-%
The screws (A) and (B) must then be retightened properly.
To secure the boomerangs properly, notches have been put on the side of the inner
telescope rail (1) that indicate the seat width settings 390 mm, 420 mm, 440 mm, 460 mm,
480 mm and 500 mm. When the boomerangs are pushed together, these notches must fit
exactly to the edge of the outer telescope rail (2). Then secure the disc screws (3) in such a
way that they can be tightened fully. If the disc screws (3) cannot be tightened sothey are
flush, it will be because they are not settled in their intended recesses, so they cannot be
secured properly.
If the disc screws are not tightened so they are flush, and if they are not settled in the
recesses in the inner telescope rail, they can get damaged and restrict seat width
adjustments in the future.
3.5 Seat
!"WARNING: Risk of injury - Make sure that all screws are properly tightened with
the appropriate tool.
!"WARNING: Risk of injury !Ensure that all the securing straps are sufficiently
tightened and do not hang through.
The seat can be used for a seat width of 390
mm to 500 mm. Loosen the Velcro fastening
on all 5 straps (A) and pull the straps to the
length you require by pulling them through
the flaps (B).
When you have adjusted the straps to the
required length, fasten them back up. The
cushions can now be added to the seat by
fitting the cushion straps to the side-straps on
the adjustable seat.
The seat frame is available in one of three seat depths 42 cm, 44 cm, 46 cm (16.54 in.,
17.32 in. and 18.11 in.).
The standard seat depth of the cover is 42 cm (16.54 in.). To close the gap between the
back frame and the seat, fold the flap of the backrest under the seat ( Velcro fastening).
A
B
C
C
2
1
3
39 cm
42 cm
44 cm
46 cm
48 cm
50 cm
39 cm
42 cm
44 cm
46 cm
48 cm
50 cm
2
3
