Vermeiren V100 User manual

VERMEIREN
V100
INSTRUCTION MANUAL
MODE D’EMPLOI
GEBRUIKSAANWIJZING
GEBRAUCHSANWEISUNG
ISTRUZIONI PER L'USO
MANUAL DE INSTRUCCIONES
INSTRUKCJA OBSŁUGI

EN
Instructionsto thespecialist dealer
This instruction manual is part and parcel of the product and must accompany every wheelchair sold.
Version: A, November 2010
All rights reserved, including translation.
No part of this manual may be reproduced in any form what so ever (print, photocopy, microfilm or
any other process) without written permission of the publisher, or processed, duplicated or distributed
by using electronic systems.
© N.V. Vermeiren N.V. 2010

EN
V100
2010-11
Page%1%
Contents
Preface .................................................................................................. 2!
1!Productdescription ................................................................... 3!
1.1!Intended Use................................................................................................................3!
1.2!Technical specifications ..............................................................................................4!
1.3!Drawing.......................................................................................................................5!
1.4!Accessories..................................................................................................................6!
1.5!Location identification plate........................................................................................6!
1.6!Explanation of symbols...............................................................................................6!
2!Use.............................................................................................. 7!
2.1!Carrying the wheelchair ..............................................................................................7!
2.2!Mounting the rear wheels............................................................................................7!
2.3!Unfolding the wheelchair ............................................................................................7!
2.4!Mounting or removing of the footrests .......................................................................8!
2.5!Operating the brakes....................................................................................................8!
2.6!Mounting or removing of arm supports ......................................................................9!
2.7!Transfer in and out the wheelchair ............................................................................ 11!
2.8!Correct position in the wheelchair ............................................................................11!
2.9!Riding the wheelchair................................................................................................11!
2.10!Moving on slopes ......................................................................................................12!
2.11!Negotiating steps or kerbs .........................................................................................12!
2.12!Fold up the wheelchair ..............................................................................................15!
2.13!Taking off the wheels ................................................................................................15!
2.14!Transport in the car....................................................................................................15!
2.15!Use of the wheelchair as seat in a motor vehicle ......................................................16!
3!Installation and adjustment ................................................... 18!
3.1!Tools ..........................................................................................................................18!
3.2!Manner of delivery....................................................................................................19!
3.3!Adjusting the seat height...........................................................................................19!
3.4!Adjusting the seat depth ............................................................................................20!
3.5!Adjust the brakes.......................................................................................................21!
3.6!Adjusting of the footrests ..........................................................................................22!
3.7!Adjusting the arm support.........................................................................................23!
4!Maintenance ............................................................................ 24!
4.1!Regular Maintenance.................................................................................................24!
4.2!Shipping and storage .................................................................................................24!
4.3!Care ...........................................................................................................................25!
4.4!Inspection ..................................................................................................................26!
4.5!Disinfection ...............................................................................................................27!
5!Guarantee ................................................................................ 30!
6!Disposal .................................................................................... 30!
7!Declaration of conformity ...................................................... 31!
8!Maintenance plan ................................................................ ... 32!
9!Disinfection book .................................................................... 33!

EN
V100
2010-11
Page%2%
Preface
First of all we want to thank you for putting your trust in us by selecting one of our
wheelchairs.
The Vermeiren wheelchairs are the result of many years of research and experience. During
the development, special attention was given to the ease of use and the serviceability of the
wheelchair.
The expected lifetime of 8 years for your wheelchair is strongly influenced by the care and
maintenance of the wheelchair.
This manual will help you get acquainted with the operation of your wheelchair.
Following the user instructions and the maintenance instructions are an essential part of the
warranty.
This manual reflects the latest product developments. Vermeiren has the right to introduce
changes without the obligation to adapt or replace previously delivered models.
For any further questions, please consult your specialist dealer.

EN
V100
2010-11
Page%3%
1 Productdescription
1.1 Intended Use
The wheelchair is intended for people with walking difficulties or no walking abilities.
The wheelchair is designed to transport 1 person.
The wheelchair is suited for indoor and outdoor use.
The user can propel the wheelchair by himself or have the wheelchair pushed by an
attendant.
The different types of fittings and accessories, and the modular construction allow full use by
persons disabled by:
paralysis
loss of limbs (leg amputation)
limb defects or deformations
stiff or damaged joints
heart insuffiencies and poor blood circulation
balance disturbances
cachexia (decrease in muscle)
and also for aged persons.
When providing for individual requirements:
body size and weight (max. 130kg (286.6 lb.))
physical and psychological condition
residential circumstances
environment
should be taken into consideration.
Your wheelchair should only be used on surfaces where all four wheels are touching the
ground and where there is sufficient contact to propel the wheels equally.
You should practice for use on uneven surfaces (cobblestones, etc.), slopes, curves and to
get past obstacles (kerbs, etc.).
The wheelchair should not be used as a ladder, nor is it a transport for heavy or hot objects.
When used on mats, carpeted floors or loose floor coverings, the floor covering can get
damaged.
Use only Vermeiren approved accessories.
The manufacturer is not liable for damage caused by the lack of or improper service or as a
result of not following instructions from this manual.
Compliance with the user and maintenance instructions are an essential part of the
guarantee conditions.

EN
V100
2010-11
Page%4%
1.2 Technical specifications
Technical terms below are valid for the wheelchair in standard settings.
If other footrest / arm support or other accessories are used, the tabulated values will
change.
Make
Vermeiren
Address
Vermeirenplein 1/15, B-2920 Kalmthout
Type
Manual wheelchair
Model
V100
Maximum occupant mass
130 kg (286.6 lb.)
Description
Min.
Max.
Overall length with legrest
1010 mm (39.76 in.)
Effective seat width
390 mm
(15.35 in.)
420 mm
(16.54 in.)
440 mm
(17.32 in.)
460 mm
(18.11 in.)
480 mm
(18.90 in.)
500 mm
(19.69 in.)
Overall width (depends on the seat
width)
570 mm
(22.44 in.)
600 mm
(23.62 in.)
620 mm
(24.41 in.)
640 mm
(25.20 in.)
660 mm
(25.98 in.)
680 mm
(26.77 in.)
Folded length
1010 mm (39.76 in.)
Folded width
300 mm (11.81 in.)
Folded height
880 mm (34.65 in.)
940 mm (37.01 in.)
Total mass
18 kg (39.7 lb.)
Mass of heaviest part
10,5 kg (22.05 lb.)
Static stability downhill
10° (in standard configuration)
Static stability uphill
7° (in standard configuration)
Static stability sideways
18° (in standard configuration)
Obstacle climbing
60 mm (2.36 in.)
Seat plane angle
5°
Effective seat depth
430 mm (16.93 in.)
450 mm (17.72 in.)
Seat surface height at front edge
480 mm (18.90 in.)
540 mm (21.26 in.)
Backrest angle
90°
Backrest height
420 mm (16.54 in.)
Distance between footrest and seat
410 mm (16.14 in.)
Angle between seat and footrest
8°
Distance between armrest and seat
220 mm (8.66 in.)
240 mm (9.45 in.)
Front location of armrest structure
410 mm (16.14 in.)
Handrim diameter
535 mm (21.06 in.)
Horizontal location of axle (deflection)
50 mm (1.97 in.)
Minimum turning radius
1500 mm (59.06 in.)
Diameter Krypton PU Rear wheels
22"
24"
Tyre pressure, rear (driving) wheels
Max. 3.5 bar
Diameter Krypton PU steering wheels
200 mm (7.87 in.)
Tyre pressure, steering wheels
Max. 2.5 bar
Storage and use temperature
+ 5 °C (+41 °F)
+ 41 °C (+106 °F)
Storage and use humidity
30%
70%
We reserve the right to introduce technical changes. Measurement tolerance ± 15 mm / kg / ° (0.59 in. / 3,3 lb. / 1,5°)
Table1: Technical specifications

EN
V100
2010-11
Page%5%
The wheelchair complies to the requirements set up in:
ISO 7176-8: Requirements and test methods for static, impact and fatigue strengths.
ISO 7176-16: Resistance to ignition of upholstered parts
ISO 7176-19: Wheeled mobility devices for use as seats in motor vehicles.
1.3 Drawing
1 = Armrests
2 = Arm supports
3 = Footrests
4 = Brakes
5 = Steering wheels (front wheels)
6 = Driving wheels (rear wheels)
7 = Seat
8 = Back
9 = Tip cap
10 = Cross
11 = Handles

EN
V100
2010-11
Page%6%
1.4 Accessories
The following accessories are available for the V100:
Anterior pelvic belt (B20) for mounting on the tubes of the back (see according
manual)
Anti-tipping device (B78) for mounting on the bottom frame (see according manual)
1.5 Location identification plate
1.6 Explanation of symbols
Maximum mass
Indoor and outdoor use
Down slope
Up slope
CE conformity

EN
V100
2010-11
Page%7%
2 Use
This chapter describes the everyday use. These instructions are for the user and the
specialist dealer.
The wheelchair is delivered fully assembled by your specialist dealer. The instructions
intended for the specialist dealer on how to set up the wheelchair are given in § 3.
2.1 Carrying the wheelchair
The best way to carry the wheelchair is to make use of the wheels and roll the wheelchair.
If this is not possible (e.g. when the rear wheels are taken off for transportation in a car),
firmly grasp the frame on the front and the grips. Do not use the foot or arm rests or the
wheels to grasp the wheelchair.
2.2 Mounting the rear wheels
1. Take the rear wheel and push on button .
2. Keep the button pushed in and mount the rear
wheels axle till it stops.
3. Release the button.
4. Check that the wheels is secured.
2.3 Unfolding the wheelchair
L CAUTION: Risk of clamping !Keep fingers away from moving parts of the
wheelchair.
1. Position yourself behind the wheelchair.
2. Use the hand-grips to open the wheelchair as much as possible.
3. Position yourself at the front of the wheelchair.
4. Push both seating tubes down till they are fixed in their position.
1

EN
V100
2010-11
Page%8%
2.4 Mounting or removing of the footrests
The mounting of the footrests is done as follows:
1. Hold the footrest sideways at the outside of the
wheelchairs frame and mount the tube hood into
the frame.
2. Swing the footrest inwards till it clicks in position.
3. Swing the foot plate downwards.
To take off the footrests:
1. Pull handle .
2. Swing the footrest to the outside of the wheelchair till
it comes loose from the guidance.
3. Pull the footrest from tube hood .
2.5 Operating the brakes
L WARNING: The brakes aren't used to slow down the wheelchair during
movements !Use the brake only to prevent the wheelchair from unintended
movements.
L WARNING: Good operation of the brakes is influenced by wear and
"#$%&'($&%(#$)#*)%+,)%(-,.)/0&%,-1)#(21)'341)56)! Check the condition of the tires
before each use.
L WARNING: The brakes are adjustable and can wear !Check the operation of the
brakes before each use.
To apply the brakes:
1. Push the brake handles forward till you feel a distinctive click.
L CAUTION: Risk of unintended movement !Make sure the wheelchair is on a
flat horizontal surface before releasing the brakes. Never release both brakes
simultaneously.
To release the brakes:
1. Release one brake by pulling the handle backwards.
2. Hold the hand-rim of the release wheel with your hand.
3. Release the second brake by pulling the handle backwards.

EN
V100
2010-11
Page%9%
2.6 Mounting or removing of arm supports
The arm supports of the wheelchair can be fold away or taken off.
L CAUTION: Risk of clamping !Keep fingers, buckles and clothes away from the
bottom side of the arm support.
1. Mount the rear tube of the arm rest in tube
hood .
2. Make sure the arm support clicks in the
locking mechanism.
3. Fold the arm rest forward.
4. Click the front tube of the arm rest in tube
hood .

EN
V100
2010-11
Page%10%
To open and remove the arm rest:
1. Press lever and pull the front of the arm rest
upwards.
2. Fold the arm rest backwards.
3. To remove the arm rest, press button and pull the rear of the arm support from
tube hood .

EN
V100
2010-11
Page%11%
2.7 Transfer in and out the wheelchair
L CAUTION: In case you can't perform the transfer in a safe manner, ask someone
to assist you.
L CAUTION: Risk of tipping over of the wheelchair !Don't stand on the foot plates.
1. Position the wheelchair as close as
possible to the chair, couch or bed to/from
you wish to transfer.
2. Check both brakes from the wheelchair
are in the on position.
3. Fold the foot plates upwards to prevent
standing on them.
4. If the transfer is on the side of the
wheelchair, fold the arm support on that
side upwards. (see § 2.6)
5. Transfer to/from the wheelchair.
2.8 Correct position in the wheelchair
Some recommendations for a comfortable use of the wheelchair:
Position your backside as close as possible to the back rest.
Make sure your upper legs are horizontal –If needed adjust the length of the foot
rests. (see § 3.6)
2.9 Riding the wheelchair
L WARNING: Risk of clamping !Prevent your fingers from being caught by the
wheels spokes.
L WARNING: Risk of clamping !Be careful passing through restricted passages
(e.g. doors).
L WARNING: Risk of burns !Be careful when driving in hot or cold environments
(sunshine, extreme cold, saunas, etc.) for a sufficient amount of time and when
touching - Surfaces can assume the environment temperatures.
1. Release the brakes.
2. Take both hand rims at their highest position.
3. Lean forward and push the hand rims forward until straight arms.
4. Swing your arms loosely back to the hand rims topside and repeat the movement.

EN
V100
2010-11
Page%12%
2.10 Moving on slopes
L WARNING: Control your speed !Moving on slopes as slow as possible.
L WARNING: Consider the capacities of your attendant !If your attendant doesn't
have enough force to control the wheelchair, put on the brakes.
L WARNING: Risk of tipping over !Lean forward to move your centre of gravity
forward. To improve a better stability.
1. If available on the wheelchair, wear the safety belt.
2. Do not attempt moving on too high slopes. The maximum
slope angles (upwards and downwards) are mentioned in
table 1.
3. Ask an attendant to help you moving on the slope.
4. Lean forward to move your centre of gravity forward.
2.11 Negotiating steps or kerbs
2.11.1 Getting down steps or kerbs
Riding down low kerbs can be done moving forwards. Make sure that the foot rests don't
touch the ground.
A practiced user can negotiate small steps or kerbs by himself:
L WARNING: Risk of tipping over !If you don't have
enough experience with your wheelchair, ask
assistance of an attendant.
1. Bring balance on the rear wheels to reduce the pressure
on the front wheels.
2. Negotiate the kerbs.
Higher kerbs can be taken forward with an attendant:
1. Ask the attendant to tip the wheelchair slightly backwards.
2. Get past the kerbs while moving on the rear wheels.
3. Put the wheelchair back on the four wheels.

EN
V100
2010-11
Page%13%
An experienced user can negotiate higher kerbs by himself.
This is best done backwards.
1. Turn the wheelchair to have the rear wheels facing the
kerb.
2. Lean forward to move your centre of gravity forward.
3. Move the wheelchair close to the kerbs.
4. Use the hand rim to roll-off wheelchair from the kerb
in a controlled manner.
2.11.2 Moving up steps or kerbs
Moving up steps or kerbs with attendant as follows:
1. Prevent the foot rests from touching the kerb.
2. Ask the attendant to tip the wheelchair backwards, just
enough to move the front wheels over the kerb.
3. Lean backwards to move your centre of gravity above
the rear wheel.
4. Place the front wheels on the kerb.
5. Roll rear wheels of the wheelchair over the kerb.
Higher kerbs are negotiated backwards:
1. Turn the wheelchair to have the rear wheels facing the kerb.
2. Lean backwards and move your centre of gravity above the rear wheels.
3. Ask the attendant to pull the wheelchair on the kerb.
4. Take back the normal position in the wheelchair.

EN
V100
2010-11
Page%14%
An experienced user can negotiate kerbs by himself:
L W A RN IN G: Risk of tipping over !If you haven't enough experience to control the
wheelchair, get help from an attendant.
1. Drive until the kerbs.
2. Ensure that the footrest don't touch the kerbs.
3. Lean backwards so you are balancing on the rear
wheels.
4. Role the frontwheels balancing over the kerbs.
5. Bend forwards for more stability.
6. Role the rear wheels over the kerbs.
2.11.3 Taking of stairs
Taking of stairs while you staying in the wheelchair shall be according following rules:
L WARNING: Risk of tipping over !Taking of stairs shall always with 2 attendants.
1. Remove the footrests.
2. One attendant tip the wheelchair slightly backwards.
3. The second attendant take the front of the frame.
4. Stay calm, avoid sudden movements and keep your arms inside the wheelchair.
5. Take the steps on the rear wheels of the wheelchair.
6. Mounting the footrests back after taking the stair.

EN
V100
2010-11
Page%15%
2.12 Fold up the wheelchair
L CAUTION: Chance of pinching !Don't place fingers between the components of
the wheelchair.
1. Fold or remove the footplates (see § 2.4).
2. Take the seat on the front side and backside and pull it up.
2.13 Taking off the wheels
To facilitate the transport off the wheelchair the rear
wheels can be taken off:
1. Make sure the brakes standing in the off
position.
2. Take the wheelchair to the side frame where you
want to remove the wheel.
3. Press the button in the center of the wheel
hub.
4. Pull the wheel away from the frame.
2.14 Transport in the car
L WARNING: Risk of injury !See that the wheelchair is attached properly. So you
can avoid injury from the passengers during collision or sudden braking.
L WARNING: Risk of injury !Use for attaching the wheelchair and passenger
NEVER the same seatbelt.
1. Remove footrests and accessories.
2. Store footrests and accessories safely.
3. If possible, fold the wheelchair and remove the wheels.
4. Place the wheelchair in the luggage place.
5. If the wheelchair and the passenger compartment is NOT separated, attach the
frame of the wheelchair securely to the vehicle. You can use the available safety
belts in the vehicle .
1

EN
V100
2010-11
Page%16%
2.15 Use of the wheelchair as seat in a motor vehicle
L WARNING: The wheelchair has passed the crash of ISO 7176-19: 2008 and, as
such, has been designed and tested for use only as forward-facing seat in a
motor vehicle.
L WARNING: The wheelchair's pelvic belt alone is not suited as an occupant
restraint belt.
The wheelchair is tested using the four-point strap-tie system and a 3-point occupant-
restraint system.
Whenever feasable, use the seat of the vehicle and store the wheelchair in the cargo area.
Steps to secure the wheelchair in a motor vehicle:
1. Check that the vehicle is equipped with a suitable wheelchair tie down and occupant-
restraint system, conform ISO 10542.
2. Check that the components of the wheelchair tie down and occupant restraint system
are not frayed, contaminated, damaged or broken.
3. If equipped with an adjustable seat and/or back tilt, make sure that the wheelchair
user is sitting as upright as possible. If the user's condition prevents this, a risk
assessment should be done to evaluate the user's safety during transit.
4. Remove all mounted accessories such as trays and respiratory equipment, and
secure them in a safe place.
5. Position the wheelchair facing forward in the travelling direction, centrally between
the tie-down rails mounted in the floor of the vehicle.
6. Make sure that the indicated zones around the wheelchair user are clear from rigid
vehicle parts.

EN
V100
2010-11
Page%17%
7. Mount the front securement straps according to the instructions of the strap-system
manufacturer at the indicated place. (figure 3)
This place is marked on the wheelchair with a symbol. (figure 4)
8. Roll back the wheelchair until the front straps are tight.
9. Apply the wheelchair brake.
10. Mount the back securement straps according to the instructions of the strap-system
manufacturer at the indicated place. (figure 3)
11. This place is marked on the wheelchair with a symbol. (figure 4)
figure 3
Steps to secure the wheelchair user:
1. Remove both arm rests.
2. If present, attach the wheelchair's pelvic belt.
3. Attach the occupant restraint belts according to the instructions of the strap-system
manufacturer.
4. Wear the pelvic belt low across the front of the pelvis, so that the angle of the pelvic
belt is within the preferred zone of 30° to 75° to the horizontal, similar to that shown
below.

EN
V100
2010-11
Page%18%
5. A steeper (greater) angle within the preferred zone is desirable.
6. Adjust the belt tightly according to the instructions of the strap-system manufacturer,
consistent with the user's comfort.
7. Ensure that the restraint belt connects in a straight line to the anchor point in the
vehicle and that no bends in the belt are visible, for instance at the axle of the rear
wheel.
8. Install the arm rests, if desired. make sure that belts are not twisted or held away
from the body by wheelchair components such as arm rests or wheels.
3 Installation and adjustment
The instructions in this chapter are for the specialist dealer.
The Vermeiren V100 has been designed to be adjust with a minimum of replacements parts.
There is no need for extra stock of spare parts.
To find a service facility or specialist dealer near you, contact the nearest Vermeiren facility.
A list of Vermeiren facilities can be found on the last page.
L WARNING: Risk of unsafe settings - Use only the settings described in this
manual.
L WARNING: Variation of allowed adjustments can still change the stability of your
wheelchair (tilt back or sideways).
3.1 Tools
To set up the wheelchair the following tools are needed.
Wrench set n° 7 to n° 22
Allen key set n° 3 to n° 8
Screwdriver n° 4 to n° 5
Screwdriver Phillips head
