Vertiv NetSure IPE Series User manual

NetSure™ IPE Series
-48 VDC Outdoor Rectifier
Installation and User Manual
Specification Number: 1R482000C2-1, 1R482000C2-2, 1R482000C2-3
Model Number: R48-2000C2
BOM: 31014424

Vertiv™ NetSure™ IPE Series -48 VDC Outdoor Rectifier Installation and User Manual
Vertiv™ NetSure™ IPE Series -48 VDC Outdoor Rectifier Installation and User Manual
The information contained in this document is subject to change without
notice and may not be suitable for all applications. While every precaution
has been taken to ensure the accuracy and completeness of this
document, Vertiv assumes no responsibility and disclaims all liability for
damages resulting from use of this information or for any errors or
omissions. Refer to other local practices or building codes as applicable
for the correct methods, tools, and materials to be used in performing
procedures not specifically described in this document.
The products covered by this instruction manual are manufactured
and/or sold by Vertiv. This document is the property of Vertiv and
contains confidential and proprietary information owned by Vertiv. Any
copying, use or disclosure of it without the written permission of Vertiv is
strictly prohibited.
Names of companies and products are trademarks or registered
trademarks of the respective companies. Any questions regarding usage
of trademark names should be directed to the original manufacturer.
Technical Support Site
If you encounter any installation or operational issues with your product, check the pertinent section of this
manual to see if the issue can be resolved by following outlined procedures.
Visit Vertiv.com for local additional assistance.

Vertiv™ NetSure™ IPE Series -48 VDC Outdoor Rectifier Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
iii
TABLE OF CONTENTS
Admonishments Used in this Document.............................................................................................................................vi
Important Safety Instructions............................................................................................................................................... vii
Static Warning ...............................................................................................................................................................................x
1Introduction...............................................................................................................................................................................1
1.1 General ...................................................................................................................................................................................................................................................................................1
1.2 Packing List.........................................................................................................................................................................................................................................................................1
1.2.1 1R482000C2-1 Packing List ..........................................................................................................................................................................................................1
1.2.2 1R482000C2-2 Packing List ........................................................................................................................................................................................................2
1.2.3 1R482000C2-3 Packing List ........................................................................................................................................................................................................2
1.2.4 Battery Packing List.............................................................................................................................................................................................................................3
1.3 Accessories.........................................................................................................................................................................................................................................................................3
1.3.1 Mounting Kits.............................................................................................................................................................................................................................................3
1.3.2 Customer Wiring Selection............................................................................................................................................................................................................4
1.4 Rectifier Overview.........................................................................................................................................................................................................................................................5
1.5 Rectifier Specifications ............................................................................................................................................................................................................................................5
1.5.1 DC Output Ratings................................................................................................................................................................................................................................5
1.5.2 AC Input Ratings.....................................................................................................................................................................................................................................7
1.5.3 Environmental Ratings ...................................................................................................................................................................................................................10
1.5.4 Digital Output (DO) Dry Relay Contacts ........................................................................................................................................................................12
1.5.5 Compliance I nforma t ion................................................................................................................................................................................................................13
1.5.6 Standard Features ...............................................................................................................................................................................................................................13
1.5.7 Mechanical Specifications........................................................................................................................................................................................................... 14
1.6 Battery ................................................................................................................................................................................................................................................................................15
1.6.1 Battery Appearance ...........................................................................................................................................................................................................................15
1.6.2 Battery Specifications.......................................................................................................................................................................................................................17
1.6.3 Battery Storage Environment ..................................................................................................................................................................................................18
1.6.4 Battery Maintenance........................................................................................................................................................................................................................ 18
1.6.5 Precautions for Battery Use ......................................................................................................................................................................................................18
2Installation ..............................................................................................................................................................................19
2.1 General ...............................................................................................................................................................................................................................................................................19
2.2 Tools Required for Installation....................................................................................................................................................................................................................... 19
2.3 Mounting Kits ...............................................................................................................................................................................................................................................................20
2.3.1 Standard Mounting Kit for Single Rectifier Installation...................................................................................................................................20
2.3.2 Optional Mounting Kit P/N 02236200 for One (1) Rectifier and One (1) Battery Flag Installation........................20
2.3.3 Optional Mounting Kit P/N 02236201 for One (1) Rectifier and One (1) Battery Flat Installation.............................21
2.4 Mounting the Rectifier to a Pole or Wall Using the Standard Rectifier Mounting Kit................................................................................22
2.4.1 General..........................................................................................................................................................................................................................................................22
2.4.2 Pole Mounting Procedure............................................................................................................................................................................................................22
2.4.3 Wall Mounting Procedure............................................................................................................................................................................................................26
2.5 Mounting the Rectifier with a Lithium-Ion Battery to a Pole or Wall Using Optional Rectifier/Battery
Mounting Kit P/N 02236200 (Flag Installation)............................................................................................................................................................................29
2.5.1 General ..........................................................................................................................................................................................................................................................29
2.5.2 Pole Mounting Procedure............................................................................................................................................................................................................29
2.5.3 Wall Mounted Procedure..............................................................................................................................................................................................................33
2.6 Mounting the Rectifier with a Lithium-Ion Battery to a Pole or Wall Using Optional Rectifier/Battery
Mounting Kit P/N 02236201 (Flat Installation).............................................................................................................................................................................. 36

Vertiv™ NetSure™ IPE Series -48 VDC Outdoor Rectifier Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
iv
2.6.1 General ......................................................................................................................................................................................................................................................... 36
2.6.2 Pole Mounting Procedure........................................................................................................................................................................................................... 36
2.6.3 Wall Mounted Procedure............................................................................................................................................................................................................. 43
2.6.4 Lashing of Cords and Cables...................................................................................................................................................................................................49
3Making Electrical Connections ......................................................................................................................................50
3.1 Important Safety Instructions........................................................................................................................................................................................................................50
3.2 Wiring Considerations...........................................................................................................................................................................................................................................50
3.3Rectifier Interface Overview Diagrams .................................................................................................................................................................................................50
3.4 Rectifier Ground Connection ..........................................................................................................................................................................................................................52
3.4.1 General..........................................................................................................................................................................................................................................................52
3.4.2 Positive Grounding.............................................................................................................................................................................................................................52
3.4.3 Chassis Grounding .............................................................................................................................................................................................................................52
3.5 Terminal List...................................................................................................................................................................................................................................................................53
3.5.1 PG Version .................................................................................................................................................................................................................................................53
3.5.2 Quick Connect Version..................................................................................................................................................................................................................53
3.6 Customer Wiring Selection ...............................................................................................................................................................................................................................53
3.7 Digital Output (DO) Relay Functions ..................................................................................................................................................................................................... 54
3.8 Changing the Alarm Relay Configuration for the Digital Output (DO) Relay Functions........................................................................ 54
3.9 Wire Preparation .........................................................................................................................................................................................................................................................55
3.10 Customer Wiring Connection Procedure.............................................................................................................................................................................................57
3.10.1 Customer Wiring Connection Procedure for PG Terminal ...........................................................................................................................57
3.10.2 Customer Wiring Connection Procedure for Quick Connect Terminal ........................................................................................... 59
3.11 Battery Connections ...............................................................................................................................................................................................................................................67
3.11.1 General ..........................................................................................................................................................................................................................................................67
3.11.2 Battery DB9 Pin Definition..........................................................................................................................................................................................................67
3.11.3 Rectifier and Battery Wire Diagram...................................................................................................................................................................................68
3.12 Battery DIP Switch and Power Switch...................................................................................................................................................................................................69
3.12.1 DIP Switch .................................................................................................................................................................................................................................................69
3.12.2 Power Switch ..........................................................................................................................................................................................................................................69
4Micro SIM Card Installation, Bluetooth Jumper Setup, and Antenna Installation ...................................... 70
4.1 Installing the Micro SIM Card (if required)........................................................................................................................................................................................70
4.2 Setting Bluetooth Jumper Position (if required) ...........................................................................................................................................................................71
4.3 Antenna Installation (For R48-2000C2-1 Only)............................................................................................................................................................................72
5Initially Starting and Checking Rectifier Operation ................................................................................................73
5.1 Initially Starting the Rectifier...........................................................................................................................................................................................................................73
5.2 Checking Rectifier Status...................................................................................................................................................................................................................................73
5.3 Checking Battery Status .....................................................................................................................................................................................................................................73
6Operation ...............................................................................................................................................................................74
6.1 Local Indicators ...........................................................................................................................................................................................................................................................74
6.2 Battery Local Indicators.......................................................................................................................................................................................................................................74
6.3 Opening / Closing the Front Access Panel........................................................................................................................................................................................75
6.3.1 Opening the Front Access Panel..........................................................................................................................................................................................75
6.3.2 Closing the Front Access Panel.............................................................................................................................................................................................75
7Controller and Controller Interface...............................................................................................................................77
7.1 General ...............................................................................................................................................................................................................................................................................77
7.2 Specifications.................................................................................................................................................................................................................................................................77
7.3 Accessing the Rectifier via Bluetooth.....................................................................................................................................................................................................78

Vertiv™ NetSure™ IPE Series -48 VDC Outdoor Rectifier Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
v
7.3.1 Mobile Device and Mobile Device Operating System Version Requirements............................................................................78
7.3.2 Bluetooth APP........................................................................................................................................................................................................................................78
8Troubleshooting and Repair ...........................................................................................................................................89
8.1 General ..............................................................................................................................................................................................................................................................................89
8.2 Alarm Conditions Identified by the Controller ...............................................................................................................................................................................89
8.3 Alarm Conditions Identified by the Battery .......................................................................................................................................................................................91
8.4 Replacement Information................................................................................................................................................................................................................................... 91
8.4.1 General..........................................................................................................................................................................................................................................................91
8.4.2 Rectifier Fuses........................................................................................................................................................................................................................................ 91
8.5 Replacement Procedures................................................................................................................................................................................................................................... 91
8.5.1 Replacing a DC Load Fuse or Battery Fuse................................................................................................................................................................91

Vertiv™ NetSure™ IPE Series -48 VDC Outdoor Rectifier Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
vi
Admonishments Used in this Document
DANGER!
Warns of a hazard the reader will be exposed to that will likely result
in death or serious injury if not avoided. (ANSI, OSHA)
WARNING!
Warns of a potential hazard the reader may be exposed to that could result
in death or
serious injury if not avoided. This admonition is not used for situations that
pose a risk only to equipment, software, data, or service. (ANSI)
CAUTION!
Warns of a potential hazard the reader may be exposed to that could
result in minor or moderate injury if not avoided. (ANSI, OSHA) This admonition is not
used for situations that pose a risk only to equipment, data, or service, even if such
use appears to be permitted in some of the applicable standards. (OSHA)
ALERT!
Alerts the reader to an action that must be avoided in order to protect
equipment, software, data, or service. (ISO)
ALERT!
Alerts the reader to an action that must be performed in order to prevent
equipment damage, software corruption, data loss, or service interruption. (ISO)
FIRE SAFETY!
Informs the reader of fire safety information, reminders,
precautions, or policies, or of the locations of fire
-fighting and fire-safety
equipment. (ISO)
SAFETY!
Informs the reader of general safety information, reminders, precautions, or
policies not
related to a particular source of hazard or to fire safety. (ISO, ANSI, OSHA)

Vertiv™ NetSure™ IPE Series -48 VDC Outdoor Rectifier Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
vii
Important Safety Instructions
Safety Admonishments Definitions
Definitions of the safety admonishments used in this document are listed under “Admonishments Used in this Document” on
page vi.
General Safety
DANGER! YOU MUST FOLLOW APPROVED SAFETY PROCEDURES.
Performing the following procedures may expose you to hazards. These procedures should be performed by qualified
technicians familiar with the hazards associated with this type of equipment. These hazards may include shock, energy,
and/or burns. To avoid these hazards:
a) The tasks should be performed in the order indicated.
b) Remove watches, rings, and other metal objects.
c) Prior to contacting any uninsulated surface or termination, use a voltmeter to verify that no voltage or the expected
voltage is present. Check for voltage with both AC and DC voltmeters prior to making contact.
d) Wear eye protection.
e) Use certified and well maintained insulated tools. Use double insulated tools appropriately rated for the work to be
performed.
Voltages
AC Input Voltages
DANGER! This system operates from AC input voltage capable of producing fatal electrical shock. AC input power must
be completely disconnected from the branch circuits wiring used to provide power to the system before any AC electrical
connections are made. Follow local lockout/tagout procedures to ensure upstream branch circuit breakers remain de-
energized during installation. DO NOT apply AC input power to the system until all electrical connections have been
completed and checked.
DC Output and Battery Voltages
DANGER! This system produces DC power and may have a battery source connected to it. Although the DC voltage is
not hazardously high, the rectifiers and/or battery can deliver large amounts of current. Exercise extreme caution not to
inadvertently contact or have any tool inadvertently contact an output terminal or battery terminal or exposed wire
connected to an output terminal or battery terminal. NEVER allow a metal object, such as a tool, to contact more than
one termination or battery terminal at a time, or to simultaneously contact a termination or battery terminal and a
grounded object. Even a momentary short circuit can cause sparking, explosion, and injury.
Battery
Refer to the battery manufacturer documentation for specific battery safety instructions. The following are general guidelines.
WARNING! Correct polarity must be observed when connecting battery leads.
WARNING! Special safety precautions are required for procedures involving handling, installing, and servicing batteries.
Observe all battery safety precautions in this manual and in the battery instruction manual. These precautions should be
followed implicitly at all times.

Vertiv™ NetSure™ IPE Series -48 VDC Outdoor Rectifier Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
viii
WARNING! A battery can present a risk of electrical shock and high short circuit current. Servicing of batteries should
be performed or supervised only by properly trained and qualified personnel knowledgeable about batteries and the
required precautions.
The following precautions should be observed when working on batteries:
•Follow the recommended PPE requirements per the SDS for the battery to be used.
•Batteries are an energy source that can produce high amounts of electrical current.
•Remove watches, rings, and other metal objects.
•Eye protection should be worn to prevent injury from accidental electrical arcs.
•Use certified and well maintained insulated tools. Use double insulated tools appropriately rated for the work to be
performed. Ensure that wrenches with more than one working end have only one end exposed.
•Verify that no current will flow when the battery is connected or disconnected by opening battery disconnects (if
available) or adjusting the system to match battery voltage.
•Dispose of used batteries according to the instructions provided with the batteries. Do not dispose of batteries in a
fire. They may explode.
•Do not open or mutilate batteries.
•ALWAYS FOLLOW THE BATTERY MANUFACTURER’S RECOMMENDATIONS AND SAFETY INSTRUCTIONS.
Specific Precautions for the Batteries Described in this Document
•Batteries have an ON/OFF switch. Before making any electrical connection, disconnect power at battery by placing
the ON/OFF switch to the OFF position.
•Do not immerse the battery in water.
•Do not approach a heat source.
•Do not short-circuit the positive and negative poles of the battery.
•Do not reverse charge.
•Do not use the battery in an extremely hot environment, such as a closed environment. Care must be taken to keep
operational temperature within -40 °C to +55 °C rating of battery. Otherwise, the battery will overheat which will
affect the performance of the battery and shorten the service life of the battery and may catch fire (ignite).
•DO NOT OPEN THE BATTERY ENCLOSURE due to high hazard inside. Battery is only intended to be replaced, not
repaired if faulty.
•If needing replacement, battery must be returned in HAZ MAT approved Class 9 packaging.
•It is recommended to store the battery under the conditions in “Battery Storage Environment” on page 18, otherwise
battery performance will be reduced or battery life will be shortened.
•Do not DROP the battery during installation.
•Battery maximum elevation – 3k Meters.
ALERT! Performing maintenance and/or troubleshooting procedures may interrupt power to the loads, if battery reserve
is not sufficient.

Vertiv™ NetSure™ IPE Series -48 VDC Outdoor Rectifier Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
ix
Personal Protective Equipment (PPE)
DANGER! ARC FLASH AND SHOCK HAZARD.
Appropriate PPE and tools required when working on this equipment. An appropriate flash protection boundary analysis
should be done to determine the “shock hazard and arc flash hazard” category, and to select proper PPE.
Only authorized and properly trained personnel should be allowed to install, inspect, operate, or maintain the equipment.
Do not work on LIVE parts. If required to work or operate live parts, obtain appropriate Energized Work Permits as
required by the local authority, such as NFPA 70E “Standard for Electrical Safety in the Workplace”.
Hazardous Voltage
DANGER! HAZARD OF ELECTRICAL SHOCK.
More than one disconnect may be required to de-energize the system before servicing.
Handling Equipment Containing Static Sensitive Components
ALERT! Installation or removal of equipment containing static sensitive components requires careful handling. Before
handling any equipment containing static sensitive components, read and follow the instructions under “Static Warning”
on page x.
Maintenance and Replacement Procedures
CAUTION! When performing any step in the procedures that requires removal or installation of hardware, use caution to
ensure no hardware is dropped and left inside the unit; otherwise service interruption or equipment damage may occur.
NOTE! When performing any step in the procedures that requires removal of existing hardware, retain all hardware for
use in subsequent steps, unless otherwise directed.

Vertiv™ NetSure™ IPE Series -48 VDC Outdoor Rectifier Installation and User Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
x
Static Warning
This equipment contains static sensitive components. The warnings listed below must be observed to prevent damage
to these components. Disregarding any of these warnings may result in personal injury or damage to the equipment.
1. Strictly adhere to the procedures provided in this document.
2. Before touching any equipment containing static sensitive components, discharge all static electricity from yourself
by wearing a wrist strap grounded through a one megohm resistor. Some wrist straps have a built-in one megohm
resistor; no external resistor is necessary. Read and follow wrist strap manufacturer’s instructions outlining use of a
specific wrist strap.
3. Do not touch traces or components on equipment containing static sensitive components. Handle equipment
containing static sensitive components only by the edges that do not have connector pads.
4. After removing equipment containing static sensitive components, place the equipment only on static dissipative
surfaces such as conductive foam or ESD bag. Do not use ordinary Styrofoam or ordinary plastic.
5. Store and ship equipment containing static sensitive components only in static shielding containers.
6. If necessary to repair equipment containing static sensitive components, wear an appropriately grounded wrist
strap, work on a conductive surface, use a grounded soldering iron, and use grounded test equipment.
