Vertiv NetSure IPE Series User manual

NetSure™ IPE Series
Rectifier
Installation and User Manual
Specification Number: 02131111
Model Number: R48-2000C

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
The information contained in this document is subject to change without
notice and may not be suitable for all applications. While every precaution has
been taken to ensure the accuracy and completeness of this document, Vertiv
assumes no responsibility and disclaims all liability for damages resulting from
use of this information or for any errors or omissions. Refer to other local
practices or building codes as applicable for the correct methods, tools, and
materials to be used in performing procedures not specifically described in
this document.
The products covered by this instruction manual are manufactured and/or
sold by Vertiv. This document is the property of Vertiv and contains
confidential and proprietary information owned by Vertiv. Any copying, use or
disclosure of it without the written permission of Vertiv is strictly prohibited.
Names of companies and products are trademarks or registered trademarks of
the respective companies. Any questions regarding usage of trademark
names should be directed to the original manufacturer.
Technical Support Site
If you encounter any installation or operational issues with your product, check the pertinent section of this
manual to see if the issue can be resolved by following outlined procedures.
Visit https://www.vertiv.com/en-us/support/ for additional assistance.

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
iii
TABLE OF CONTENTS
Admonishments Used in this Document.......................................................................................................................... v
Important Safety Instructions ............................................................................................................................................ vi
Static Warning ....................................................................................................................................................................... viii
1 Introduction ......................................................................................................................................................................... 1
1.1 General.....................................................................................................................................................................................................................................................................................1
1.2 What is in the Box..........................................................................................................................................................................................................................................................1
1.3 Rectifier Overview .........................................................................................................................................................................................................................................................1
1.4 Rectifier Specifications.............................................................................................................................................................................................................................................1
1.4.1 DC Output Ratings.................................................................................................................................................................................................................................1
1.4.2 AC Input Ratings.....................................................................................................................................................................................................................................3
1.4.3 Environmental Ratings ......................................................................................................................................................................................................................6
1.4.4 Compliance I nforma t ion ..................................................................................................................................................................................................................7
1.4.5 Standard Features.................................................................................................................................................................................................................................7
1.4.6 Mechanical Specifications..............................................................................................................................................................................................................9
2 Installing the Rectifier ................................................................................................................................................... 10
2.1 General.................................................................................................................................................................................................................................................................................10
2.2 Pole Installation P ro c edure ..............................................................................................................................................................................................................................10
2.3 Wall Installation P ro c edure ...............................................................................................................................................................................................................................13
3 Making Electrical Connections ....................................................................................................................................15
3.1 Important Safety Instructions..........................................................................................................................................................................................................................15
3.2 Wiring Considerations.............................................................................................................................................................................................................................................15
3.3 Frame Ground Connection.................................................................................................................................................................................................................................15
3.4 Customer Wiring to Terminal Blocks Located Inside Rectifier Case.........................................................................................................................16
3.4.1 General..........................................................................................................................................................................................................................................................16
3.4.2 Procedure ...................................................................................................................................................................................................................................................16
3.5 External Alarm and Control Connections.............................................................................................................................................................................................21
3.5.1 General...........................................................................................................................................................................................................................................................21
3.5.2 Contact Ratings (UL / CSA Rating): ...................................................................................................................................................................................21
3.5.3 Rectifier Fail Alarm.............................................................................................................................................................................................................................22
3.5.4 AC Fail Alarm...........................................................................................................................................................................................................................................22
3.5.5 Fuse Alarm.................................................................................................................................................................................................................................................22
3.5.6 CAN..................................................................................................................................................................................................................................................................22
3.6 Nominal 120 VAC / 208 VAC / 220 VAC / 230 VAC / 240 VAC Input and AC Input Equipment Grounding
Connections....................................................................................................................................................................................................................................................................22
3.7 -48 VDC Output Connections........................................................................................................................................................................................................................22
3.8 Battery Connections ...............................................................................................................................................................................................................................................23
3.9 Paralleling Rectifiers for Redundancy.....................................................................................................................................................................................................23
4 Initially Starting the Rectifier......................................................................................................................................24
5 Operation...........................................................................................................................................................................24
5.1 Rectifier High Voltage Shutdown and Lockout Restart .......................................................................................................................................................24
6 Troubleshooting and Repair........................................................................................................................................24
6.1 Contact Information................................................................................................................................................................................................................................................24

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
iv
6.2 Troubleshooting.........................................................................................................................................................................................................................................................24
6.2.1 Rectifier Current Sharing I m b alance ..............................................................................................................................................................................24
6.3 Repair...................................................................................................................................................................................................................................................................................24
7 DC Power, Outdoor Enclosure & Service Contacts..............................................................................................26

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
v
Admonishments Used in this Document
DANGER
! Warns of a hazard the reader will be exposed to that will likely result
in death or serious injury if not avoided
. (ANSI, OSHA)
WARNING
! Warns of a potential hazard the reader may be exposed to that could
result in
death or serious injury if not avoided
. This admonition is not used for situations that pose
a risk
only to equipment, software, data, or service. (ANSI)
CAUTION
! Warns of a potential hazard the reader may be exposed to that could
result in minor or moderate injury if not avoided
. (ANSI, OSHA) This admonition is not
used for situations that pose a
risk only to equipment, data, or service, even if such use
appears to be permitted in some of the applicable standards
. (OSHA)
ALERT
! Alerts the reader to an action that must be avoided in order to protect
equipment, software, data, or service
. (ISO)
ALERT
! Alerts the reader to an action that must be performed in order to prevent
equipment damage, software corruption, data loss, or service interruption
. (ISO)
FIRE SAFETY
! Informs the reader of fire safety information, reminders, precautions,
or policies, or of the locations of fire
-fighting and fire-safety equipment. (ISO)
SAFETY
! Informs the reader of general safety information, reminders, precautions, or
policies not related to a particular source of hazard or to fire safet
y. (ISO, ANSI, OSHA)

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
vi
Important Safety Instructions
Safety Admonishments Definitions
Definitions of the safety admonishments used in this document are listed under “Admonishments Used in this Document” on page v.
General Safety
DANGER! YOU MUST FOLLOW APPROVED SAFETY PROCEDURES.
Performing the following procedures may expose you to hazards. These procedures should be performed by qualified
technicians familiar with the hazards associated with this type of equipment. These hazards may include shock, energy,
and/or burns. To avoid these hazards:
a) The tasks should be performed in the order indicated.
b) Remove watches, rings, and other metal objects.
c) Prior to contacting any uninsulated surface or termination, use a voltmeter to verify that no voltage or the expected
voltage is present. Check for voltage with both AC and DC voltmeters prior to making contact.
d) Wear eye protection.
e) Use certified and well maintained insulated tools. Use double insulated tools appropriately rated for the work to be
performed.
Voltages
AC Input Voltages
DANGER! This system may operate from AC input voltage capable of producing fatal electrical shock. AC input power must
be completely disconnected from the branch circuits wiring used to provide power to the system before any AC electrical
connections are made. Follow local lockout/tagout procedures to ensure upstream branch circuit breakers remain de-
energized during installation. DO NOT apply AC input power to the system until all electrical connections have been
completed and checked.
DC Output and Battery Voltages
DANGER! This system may produce DC power and may have a battery source connected to it. Although the DC voltage is
not hazardously high, the rectifiers and/or battery can deliver large amounts of current. Exercise extreme caution not to
inadvertently contact or have any tool inadvertently contact an output terminal or battery terminal or exposed wire
connected to an output terminal or battery terminal. NEVER allow a metal object, such as a tool, to contact more than one
termination or battery terminal at a time, or to simultaneously contact a termination or battery terminal and a grounded
object. Even a momentary short circuit can cause sparking, explosion, and injury.

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
vii
Personal Protective Equipment (PPE)
DANGER! ARC FLASH AND SHOCK HAZARD.
Appropriate PPE and tools required when working on this equipment. An appropriate flash protection boundary analysis
should be done to determine the “hazard/risk” category, and to select proper PPE.
Only authorized and properly trained personnel should be allowed to install, inspect, operate, or maintain the equipment.
Do not work on LIVE parts. If required to work or operate live parts, obtain appropriate Energized Work Permits as required
by the local authority, per NFPA 70E “Standard for Electrical Safety in the Workplace”.
Hazardous Voltage
DANGER! HAZARD OF ELECTRICAL SHOCK.
More than one disconnect may be required to de-energize the system before servicing.
Handling Equipment Containing Static Sensitive Components
ALERT! Installation or removal of equipment containing static sensitive components requires careful handling. Before
handling any equipment containing static sensitive components, read and follow the instructions contained on the Static
Warning Page.

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
viii
Static Warning
This equipment contains static sensitive components. The warnings listed below must be observed to prevent damage to
these components. Disregarding any of these warnings may result in personal injury or damage to the equipment.
1. Strictly adhere to the procedures provided in this document.
2. Before touching any equipment containing static sensitive components, discharge all static electricity from yourself by
wearing a wrist strap grounded through a one megohm resistor. Some wrist straps have a built-in one megohm resistor;
no external resistor is necessary. Read and follow wrist strap manufacturer’s instructions outlining use of a specific wrist
strap.
3. Do not touch traces or components on equipment containing static sensitive components. Handle equipment
containing static sensitive components only by the edges that do not have connector pads.
4. After removing equipment containing static sensitive components, place the equipment only on static dissipative
surfaces such as conductive foam or ESD bag. Do not use ordinary Styrofoam or ordinary plastic.
5. Store and ship equipment containing static sensitive components only in static shielding containers.
6. If necessary to repair equipment containing static sensitive components, wear an appropriately grounded wrist strap,
work on a conductive surface, use a grounded soldering iron, and use grounded test equipment.

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
1
1Introduction
1.1 General
The NetSure IPE Series provides a rectifier mounted inside an environmentally protective enclosure. The NetSure IPE Series rectifier
can be wall or pole mounted.
1.2 What is in the Box
Refer to Table 1.
Table 1:
Part Number Description Qty.
02131111 NetSure IPE Series Rectifier 1
21505943 Pole/Wall Mount Kit 1
63126330 Pole Mount Band 2
6312017Y Security Screw Wrench 1
UM02131111 Installation and User Manual 1
1.3 Rectifier Overview
The rectifier provides load power during normal operating conditions. The rectifier is a constant power design. The rectifier is rated
at its maximum output power. This means that, within the normal operating ambient temperature range and input voltage range, the
maximum available output power is a constant 2000 W. Within these ranges, the rectifier operates in one of three modes, depending
upon load demands. Transition between modes is completely automatic. If ambient temperature rises above or input voltage falls
below acceptable values, the rectifier continues to operate but at derated output power levels.
•Constant Voltage Mode: For any initial output voltage setting from -42 VDC to -58 VDC (factory set at -54 VDC), output
voltage remains constant regardless of load. This is the normal operating condition, in which loads are being supplied. The
rectifier operates in the Constant Voltage Mode unless load increases to the point where the product of load current and
output voltage is approximately 2000 W.
•Constant Power Mode: As load increases above approximately 2000 W (non-adjustable), output current continues to
increase, but output voltage decreases as required to maintain constant output power. The rectifier operates in the Constant
Power Mode unless load continues to increase to the point where the current limit setting is reached.
•Constant Current Mode: If load increases to the current limit setting, output voltage decreases linearly to maintain output
current at the current limit setting.
1.4 Rectifier Specifications
The specifications are for a single unit only, unless otherwise noted.
1.4.1 DC Output Ratings
1. Voltage: -42 VDC to -58 VDC, positive ground. Output voltage is factory set at -54 VDC.
2. Output Power and Current: 2000 W (41.7 A) @ 200 VAC to 250 VAC input and -48 VDC output.
3. Output Characteristics: Refer to Figure 1for a graph of output voltage vs. output current.

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
2
Figure 1: Output Voltage vs. Output Current
4. Power Derating Based on Input Voltage: The rectifier power varies with changes in input voltage. It uses an advanced power
limitation method. The lower input threshold is 85 VAC. The rectifier can provide its maximum rated power (2000 W) as
long as the input voltage is within the range of 176 VAC to 300 VAC. Below 176 VAC, and down to 85 VAC, the rectifier will
continue to operate normally but will be in a power derating mode. The relationship between the output power and input
voltage is illustrated in Figure 2.
Figure 2: Power Derating Based on Input Voltage
5. Power Derating Based on Temperature: The rectifier delivers full power when operating at an ambient temperature of +50 °C
(+122 °F) or below. The rectifier continuously monitors the ambient temperature surrounding the power conversion circuit. If
this temperature for any reason (such as a high ambient temperature) increases above approximately +50 °C (+122 °F), the
rectifier will not shut down. Rather, the rectifier limits its maximum output power to maintain the temperature of the power
conversion circuit within design parameters. Operation between +50 °C (+122 °C) and +75 °C (+167 °F) will result in output
power being decreased. Full power capability is restored when the temperature decreases to below approximately +50 °C
(+122 °F). Refer to Figure 3to view the relationship between the output power and the ambient temperature.
0
10
20
30
40
50
60
0 5 10 15 20 25 30 35 40 45
Output Voltage (V)
Output Current (A
)
Output voltage v.s. Output current at max. Power
0.0%
20.0%
40.0%
60.0%
80.0%
100.0%
120.0%
050 100 150 200 250 300 350
% of output power
Input voltage (Vac)
Output power vs. Input voltage and Vo>48V at Temp≤50℃

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
3
WARNING! The module is rated for continuous operation at full output power up to +50 °C (+122 °F). Operation between
+50 °C (+122 °F) and +75 °C (+167 °F) will result in output power decrease. Operation above +75 °C (+167 °F) is considered
abnormal and should be used on a temporary1basis only.
1Temporary Operation at Abnormal Temperature: Temporary operation is defined as a period of not more than eight
consecutive hours per day, and a total of not more than 15 days in a year. (This refers to a total of 120 hours in any
given year, but no more than 15 occurrences in that one-year period.)
Other power rating values are as follows (refer to Figure 3):
a) At an ambient temperature of +65 °C (+149 °F), the power delivered by the rectifier is 800 W.
b) At an ambient temperature of +75 °C (+167 °F), the power delivered by the rectifier is 0 W.
Figure 3: Power Derating Based on Temperature
6. Regulation:
a) Static: Steady state regulation is ±0.6% as controlled within the rectifier for any and all combinations of load from 5% to
100% load, input voltage, and input frequency at a constant ambient temperature.
b) Dynamic: Response time ≤200 us and overshoot ≤5% for load changes at 50% - 25% - 50%
and 50% - 75% - 50% at rated output current.
For any step load change within the range of 10% to 90% of full load within 50 microseconds, per Telcordia
GR-947-CORE, the maximum voltage transient will not exceed 5% of the initial steady state voltage within 50±10
microseconds. Recovery to within 1% of the initial steady state voltage does not exceed 4 milliseconds.
7. Filtering:
a) Voice Band Noise: Peak-peak voltage is ≤200 mV at 0 MHZ to 20 MHZ and normal output voltage.
b) Wide Band Noise: Wideband noise voltage is ≤50 mV at 3.4 kHz to 150 kHz and ≤20 mV at 0.15 MHz to 30 MHz.
1.4.2 AC Input Ratings
1. Voltage: Nominal 120 VAC / 208 VAC / 220 VAC / 230 VAC / 240 VAC, single phase, 3-wire, 50 Hz / 60 Hz, with an operating
range of 85 VAC to 300 VAC. Acceptable input frequency range is 45 Hz to 65 Hz.
Permitted Variation: 85 VAC to 300 VAC.

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
4
2. Harmonic Content (THD): Meets EN61000-3-2. ≤5% from 50% to 100% of rated output current at 230 VAC.
3. Inrush Current: Peak does not exceed 1.5 times of the peak value of the maximum steady-state input current at full load, 230
VAC input voltage, and for any duration of AC input interrupts. Under the above conditions, standard AC distribution circuit
breakers will not trip.
4. Typical Input Data: 50 Hz input.
a) Refer to Table 2.
b) Maximum Input Current: Refer to Table 3.
c) Efficiency Curve: Refer to Figure 4.
5. Typical Input Data: 60 Hz input.
a) Refer to Table 4.
b) Maximum Input Current: Refer to Table 5.
c) Efficiency Curve: Refer to Figure 5and Figure 6.
Table 2: Typical Input Data with 50 Hz Input
Nominal
Input Voltage
Percent
of Full Load
Input Current
(Amperes)
Input
VA
Input
Watts
Power
Factor
Efficiency
%
Heat Dissipation
BTU/Hr
208
0
0.747
156.234
13.4
0.080
--
45.654
25
2.559
534.2
514.9
0.960
90.901
159.854
50
4.850
1012.9
992.3
0.979
93.979
203.849
75
7.130
1485.3
1475.8
0.993
94.642
269.828
100
9.503
1973.8
1962.1
0.994
94.736
352.417
110
10.457
2170.5
2159.9
0.995
94.543
402.201
240
0
0.861
207.6
12.9
0.060
--
44.017
25
2.311
557.9
513.8
0.923
91.524
148.579
50
4.206
1012
989.1
0.977
94.318
191.752
75
6.180
1485.7
1471.1
0.990
94.944
253.791
100
8.195
1967.1
1955.3
0.994
94.907
339.803
110
9.010
2162
2152.0
0.995
94.872
376.540
Note: System output is initially adjusted to 54 volts DC as measured at the system sense point at 50% of full load
and nominal input. “Percent of Full Load” refers to percent of 34.48 amperes.
Table 3: Maximum Input Current with 50 Hz Input
Nominal Input
Voltage
Input
Voltage
Input Current
(Amperes)
208/240 176 11.98
Note: At 100% of full load with output adjusted to 58 volts DC as
measured at the output terminals.

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
5
Table 4: Typical Input Data with 60 Hz Input
Nominal
Input Voltage
Percent
of Full Load
Input Current
(Amperes)
Input
VA
Input
Watts
Power
Factor
Efficiency
%
Heat Dissipation
BTU/Hr
120
0
0.533
64.1
18.7
0.283
0
63.602
25
4.403
528.6
524.8
0.994
90.028
178.566
50
8.438
1006.9
1005.8
0.999
92.735
249.324
75
12.66
1503
1501.9
0.999
92.945
361.533
100
--
--
--
--
--
--
110
--
--
--
--
--
--
208
0
0.896
187.4
13.4
0.070
0.000
45.586
25
2.615
545.9
517
0.947
90.968
159.338
50
4.840
1010.4
991.9
0.982
94.052
201.306
75
7.150
1487.7
1475.7
0.992
94.648
269.487
100
9.506
1974.8
1961.7
0.994
94.720
353.405
110
10.460
2171.1
2159.6
0.995
94.679
392.108
240
0
1.031
248.9
13.0
0.050
0.000
44.494
25
2.376
575.8
517.3
0.907
91.333
152.975
50
4.241
1020.7
989.2
0.969
94.309
192.093
75
6.198
1489.7
1471.3
0.987
94.931
254.473
100
8.203
1969.9
1955.1
0.993
95.040
330.885
110
9.018
2163.5
2152.1
0.995
95.009
366.517
Note: System output is initially adjusted to 54 volts DC as measured at the system sense point at 50% of full load
and nominal input. “Percent of Full Load” refers to percent of 34.48 amperes.
Table 5: Maximum Input Current with 60 Hz Input
Nominal Input
Voltage
Input
Voltage
Input Current
(Amperes)
208/240 176 11.98
Note: At 100% of full load with output adjusted to 58 volts DC as
measured at the output terminals.
Figure 4: Efficiency Curve (@ 230 VAC, 50 Hz)

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
6
Figure 5: Efficiency Curve (@ 240 VAC, 60 Hz)
Figure 6: Efficiency Curve (@ 120 VAC, 60 Hz)
1.4.3 Environmental Ratings
1. Operating Ambient Temperature Range:
a) -20 °C (-4 °F) to +50 °C (+122 °F) with full power performance.
b) +50 °C (+122 °F) to +75 °C (+167 °F) with derating output.
c) Temperature Coefficient: 0.02% per degrees Celsius.
2. Storage Ambient Temperature Range: -40 °C (-40 °F) to +70 °C (+158 °F).
3. Relative Humidity: This rectifier is capable of operating in an ambient relative humidity range of 0% to 95%.
4. Altitude: 3048 m (9842 feet).
75.0
80.0
85.0
90.0
95.0
020 40 60 80 100
Efficiency(%)
Load(% of rated load)
Efficiency Curve
75.0
80.0
85.0
90.0
95.0
020 40 60 80 100
Efficiency(%)
Load(% of rated load)
Efficiency Curve

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
7
5. Surge Protection: EN61000-4-5 up to level 4, Telcordia GR-1089-Core, IEEE C62.41-2002, YD/T 731-2002.
Performance Criteria B.
AC Power Terminals
Test Level Source
Impedance
Performance
Criteria
Line to Line Line to Ground
± 4 kV ± 4 kV 2 ohms B
NA ± 6 kV 12 ohms B
DC Power Terminals:
Test Level Source
Impedance
Performance
Criteria
Line to Line Line to Ground
± 500 V ± 500 V 2 ohms B
± 800 V ± 800 V 2 ohms B
The test method is described in EN 61000-4-5. In this test the DC-cables shall
be 5 m long.
6. Single Rectifier Audible Noise: At 25 °C ≤45 dB(A). Measurement made at 0.6 m distance in front of rectifier and at same
horizontal line of the middle of rectifier.
7. High Voltage Category (per UL60950): III
8. Power Distribution System: TN/TT/IT
9. EMI/RFI Suppression:
a) The rectifier conforms to the requirements of FCC rules Part 15, Class B for radiated and conducted emissions limits.
b) The rectifier conforms to the requirements of European Norm, EN55022, Class B for radiated and conducted emissions
limits.
10. Pollution Degree: Degree 3.
1.4.4 Compliance I nforma t ion
1. EMC: ETSI EN 300 386, FCC CFR 47 Part 15 class B, Telcordia GR-1089-CORE.
2. EMI Load Range: 10% to 100%.
3. Safety: UL 60950-1, UL 60950-22, EN 60950-1, IEC 60950-1.
4. NEBS.
1.4.5 Standard Features
1. Type of Power Conversion Circuit: High frequency.
2. Input Protection:
a) Input Over/Under Voltage Protection: The rectifier will shut down at low or high voltage input; based on the following
voltage levels:
Low Voltage Disable Point: 80 VAC, ±5 V; hysteresis is at least 15 VAC for restart.

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
8
High Voltage Disable Point: 305 VAC, ±5 V; hysteresis is at least 10 VAC for restart.
b) Between85 VAC and 176VAC the output power will be derated linearlybased on the input voltage as follows:
At input voltage of 85 VAC with output >48 VDC, maximum output power is 1275 W.
At input voltage of 176 VAC with output >48 VDC, maximum output power is 2000 W.
3. Output Protection:
a) Overload / Reverse Current: The rectifier has a fuse wire in the negative output DC bus. This fuse is not customer
replaceable.
b) Current Limiting: The rectifier has a current limit function. The current limit point is factory set at 41.7 A. The current
limit accuracy is ±1.5 A when the output voltage ranges from 42 VDC to 58 VDC.
c) Advanced Current Limit Function: The rectifier has an advanced Current Limit Function. When a short circuit occurs
at the rectifier output terminals, the rectifier will keep its output current at a constant value (factory set at 34.5 A). This
function effectively protects the rectifier and the equipment connected to the rectifier. When the short circuit fault is
cleared, the rectifier will automatically restore back to normal operation.
d) High Voltage Shutdown:
•Fixed Control: If rectifier output voltage exceeds a factory set value of 59.5 VDC and the rectifier is delivering more
than 10% of its rated current, the rectifier shuts down. (The restart hysteresis is 0.5 V ±0.2 V.)
The rectifier then restarts and a HVSD restart timer starts (factory set at 5 minutes). If output voltage again
exceeds the high voltage shutdown value before the HVSD restart timer expires, the rectifier shuts down and locks
out. Manual restart is then required (by turning power to the rectifier off, waiting 30 seconds or more, then turning
power to the rectifier on). If the rectifier does not experience a high voltage condition before the HVSD restart
timer expires, the restart circuit is reset.
If two or more rectifiers are paralleled, only the rectifier causing the high voltage condition shuts down.
•Backup: If rectifier output voltage exceeds 59.5 VDC ±0.5 V (non-adjustable), the rectifier shuts down. The
rectifier then restarts and a HVSD restart timer starts (factory set at 5 minutes). If output voltage again exceeds
the high voltage shutdown value before the HVSD restart timer expires, the rectifier shuts down and locks out.
Manual restart is then required (by turning power to the rectifier off, waiting 30 seconds or more, then turning
power to the rectifier on).
4. Over-Temperature Protection: The rectifier provides over temperature protection by derating output power and recovers
automatically.
5. Active Load Sharing: The rectifier uses advanced digital active load sharing technology that maintains balancing to within 5%
of rated current.
6. Paralleling: Up to three (3) rectifiers can be connected in parallel in one system. Do not exceed the load rating of a single
rectifier.
7. Monitoring Function: The rectifier has a built-in advanced DSP that monitors and controls the operation of the rectifier.
CAUTION! Double pole/neutral fusing.

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
9
1.4.6 Mechanical Specifications
Dimensions and Weight
Refer to Figure 7 .
Figure 7: Overall Dimensions and Weight
Front View
Bottom View
Top View
Left Side View Right Side View
Rear View
Notes:
1. Dimensions are in inches.
2. Finish: Aluminum with powder paint.
3. Net Weight: 24.25 lbs.
19.0 16.5 15.7
3.5 4.5
15.0

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
10
2Installing the Rectifier
2.1 General
The rectifier can be pole mounted or secured to a suitable wall.
For mounting; use a corrosion inhibiting compound (CIC) inside the tapped mounting holes to keep water away, or use organically
plated stainless steel bolts. See Figure 9and Figure 14.
2.2 Pole Installation P ro c edure
NOTE! Torque all hardware to the values shown in the illustrations.
1. Unpack the rectifier and mounting accessories.
2. Install the mounting bracket (big) in the appropriate top position on the pole with the supplied pole mount band. Securely
tighten the pole mount band to the pole. The pole mount band accommodates poles from 6” to 12” in diameter. Refer to
Figure 8.
3. Install mounting brackets to the rear panel of the rectifier with the supplied hardware. Refer to Figure 9.
4. Secure the connect bend bracket to the rear of rectifier with the supplied M6 bolts (optional). Refer to Figure 10.
5. Secure the top of the rectifier to the pole by securing the mounting bracket (small) to the mounting bracket (big) with the
supplied M8 bolts. Refer to Figure 11.
6. Secure the bottom of the rectifier to the pole by securing the mounting bracket (big) to the pole with the supplied pole
mount band. Refer to Figure 12.
Figure 8: Installing the Mounting Bracket to the Pole with the Pole Mount Band
Pole
Pole Mount Band
P/N 63126330
Mounting Bracket (Big)
P/N 63240BPY
Torque to 5.0 Nm (44.3 in-lbs).

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
11
Figure 9: Installing the Mounting Brackets to the Rectifier
Figure 10: Installing the Connect Bend Bracket to the Rectifier (Optional)
M6 X 20 Bolts (4)
GB9074_13-88_M6X20_SL
Torque to 2.8 to 4.8 Nm (24.78 to 42.48 in-Ibs).
M6 X 12 Bolts (4)
P/N 26011367
Torque to 2.8 to 4.8 Nm (24.78 to 42.48 in-lbs).
Connect Bend Bracket (4)
P/N 63240CKK

Vertiv™ NetSure™ IPE Series Rectifier Installation and User Manual
12
Figure 11: Securing the Rectifier to the Pole at the Top
Figure 12: Securing the Rectifier to the Pole at the Bottom
M8 Bolts (2 places)
P/N 26011153
Torque to 13 to 16 Nm
(115 to 141 in-lbs).
Pole Mount Band
P/N 63126330
Torque to 5.0 Nm (44.3 in-lbs).
Mounting Bracket (Big)
P/N 63240BPY
