Vertiv NetSure 502NGFB Series User manual

NetSure™
502NGFB SERIES -48V DC Power System
Installation Manual (Section 6009), Revision Z
Specification Number: 582136700
Model Number: 502NGFB

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
2
This document may contain confidential and/or proprietary information of
Vertiv Group Corp., and its receipt or possession does not convey any right
to reproduce, disclose its contents, or to manufacture or sell anything that
it may describe. Reproduction, disclosure, or use without specific
authorization from Vertiv Group Corp. is strictly prohibited.
© 2020 Vertiv Group Corp. All rights reserved. Vertiv™ and the Vertiv
logo are trademarks or registered trademarks of Vertiv Group Corp. All
other names and logos referred to are trade names, trademarks or
registered trademarks of their respective owners. While every precaution
has been taken to ensure accuracy and completeness herein, Vertiv Group
Corp. assumes no responsibility, and disclaims all liability, for damages
resulting from use of this information or for any errors or omissions.
Specifications are subject to change without notice.

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
3
TABLE OF CONTENTS
Admonishments Used in this Document............................................................5
Important Safety Instructions ..............................................................................6
General Safety .......................................................................................................................................................... 6
Voltages..........................................................................................................................................................................6
AC Input Voltages........................................................................................................................................................6
DC Output and Battery Voltages ..................................................................................................................6
Battery ...............................................................................................................................................................................7
Personal Protective Equipment (PPE)............................................................................................. 8
Hazardous Voltage.............................................................................................................................................. 8
Handling Equipment Containing Static Sensitive Components............................. 8
Maintenance and Replacement Procedures.............................................................................. 8
Static Warning...........................................................................................................9
Customer Documentation Package....................................................................11
Installation Acceptance Checklist......................................................................11
Installing the System............................................................................................. 12
General Requirements.................................................................................................................................... 12
Securing the Relay Rack(s) to the Floor (if furnished)..................................................13
Securing the Power/Distribution Shelf to a Relay Rack or Cabinet..................16
Securing the Power/Distribution Shelf to a Wall with a Part No.
553203 Kit...................................................................................................................................................................16
Securing the System Horizontally to a Wall with P/N 552537 or P/N
552535 Kit (if furnished)...............................................................................................................................18
Installing Circuit Breakers and Fuses .............................................................................................. 21
Installing an Optional Battery Cabinet........................................................................................... 25
Making Electrical Connections.......................................................................... 26
Important Safety Instructions ................................................................................................................26
Wiring Considerations....................................................................................................................................26
Relay Rack Frame Grounding Connection................................................................................26
Power/Distribution Shelf Frame Grounding Connection............................................26
AC Input and AC Input Equipment Grounding Connections .................................26
External Interface Connections............................................................................................................30
IB2 (Controller Interface Board) Connections .............................................................................. 30
Ethernet Connection.......................................................................................................................................36
Load Connections..............................................................................................................................................38
To GMT Fuse Positions (List BF and NF)..........................................................................................38
To GMT Fuse Positions (List BA, NA, BC, LC and NC)........................................................40
To Bullet Nose-Type Load Distribution Circuit Breaker Positions (List
BC, LC, and NC)........................................................................................................................................................... 41
To Bullet Nose-Type Load Distribution Circuit Breaker Positions (List
BA and NA)......................................................................................................................................................................42
List KG GMT Load Distribution Fuse Panel.................................................................................... 43
CO Ground Connection................................................................................................................................44

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
4
Battery Connections........................................................................................................................................44
To Battery Busbars................................................................................................................................................. 44
To Bullet Nose-Type Circuit Breaker Positions (Lists BA and NA)......................... 44
Installing and Connecting Batteries in an Optional Battery Tray (If
Furnished)........................................................................................................................................................................ 46
Optional External Battery Disconnect Unit ..............................................................................49
Connecting to an Optional Battery Cabinet ............................................................................53
Installing the Rectifier Modules............................................................................................................54
Initially Starting the System............................................................................... 55
Initially Starting, Configuring, and Checking System Operation when
e/w NCU.......................................................................................................................................................................55
Initial Startup Preparation .................................................................................................................................55
Initially Starting the System.............................................................................................................................55
NCU Controller Initialization............................................................................................................................55
NCU Start Wizard ...................................................................................................................................................... 57
Verifying the Configuration File................................................................................................................... 57
Checking Basic System Settings................................................................................................................ 57
Checking System Status.....................................................................................................................................58
Configuring the NCU Identification of Rectifiers and Assigning Which
Input Feed Is Connected to the Rectifiers........................................................................................ 59
NCU Alarm Relay Check.................................................................................................................................... 59
Final Steps....................................................................................................................................................................... 64
Initially Starting, Configuring, and Checking System Operation when
e/w ACU+...................................................................................................................................................................65
Initial Startup Preparation ................................................................................................................................ 65
Initially Starting the System............................................................................................................................ 65
ACU+ Initialization................................................................................................................................................... 65
Verifying the Configuration File...................................................................................................................67
Checking Basic System Settings................................................................................................................67
Checking System Status.................................................................................................................................... 68
Configuring the ACU+ Identification of Rectifiers and Assigning Which
Input Phase Is Connected to Each Rectifier................................................................................... 68
ACU+ Alarm Relay Check................................................................................................................................. 69
Final Steps........................................................................................................................................................................ 75
Initially Starting, Configuring, and Checking System Operation when
e/w SCU+.................................................................................................................................................................... 76
Initial Startup Preparation .................................................................................................................................76
Initially Starting the System.............................................................................................................................76
SCU+ Initialization.....................................................................................................................................................76
Verifying the Configuration File...................................................................................................................78
Checking System Status.....................................................................................................................................78
Configuring the SCU+ Identification of Rectifier Modules ................................................78
SCU+ Alarm Relay Check..................................................................................................................................79
Final Steps....................................................................................................................................................................... 84

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
5
ADMONISHMENTS USED IN THIS DOCUMENT
DANGER!
Warns of a hazard the reader will be exposed to that will likely result
in death or serious injury if not avoided. (ANSI, OSHA)
WARNING!
Warns of a potential hazard the reader may be exposed to that could
result in
death or serious injury if not
avoided. This admonition is not used for situations that pose
a
risk only to equipment, software, data, or service. (ANSI)
CAUTION!
Warns of a potential hazard the reader may be exposed to that could
result in minor or moderate injury if not avoided. (
ANSI, OSHA) This admonition is not
used for situations that po
se a risk only to equipment, data, or service, even if such use
appears to be permitted in some of the applicable standards. (OSHA)
ALERT!
Alerts the reader to an action that must be avoided in order to protect
equipment, software, data, or service. (I
SO)
ALERT!
Alerts the reader to an action that must be performed in order to prevent
equipment damage, software corruption, data loss, or s
ervice interruption. (ISO)
FIRE SAFETY!
Informs the reader of fire safety information, reminders, precautions,
or policies, or of the locations of fire
-fighting and fire-safety equipment. (ISO)
SAFETY!
Informs the reader of general safety information, reminders, precautions, or
policies not related to a particular source of hazard or to fire safety. (ISO, ANS
I, OSHA)

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
6
IMPORTANT SAFETY INSTRUCTIONS
General Safety
DANGER! YOU MUST FOLLOW APPROVED SAFETY PROCEDURES.
Performing the following procedures may expose you to hazards. These procedures should be
performed by qualified technicians familiar with the hazards associated with this type of equipment.
These hazards may include shock, energy, and/or burns. To avoid these hazards:
a) The tasks should be performed in the order indicated.
b) Remove watches, rings, and other metal objects.
c) Prior to contacting any uninsulated surface or termination, use a voltmeter to verify that no voltage
or the expected voltage is present. Check for voltage with both AC and DC voltmeters prior to
making contact.
d) Wear eye protection.
e) Use certified and well maintained insulated tools. Use double insulated tools appropriately rated for
the work to be performed.
Voltages
AC Input Voltages
DANGER! This system operates from AC input voltage capable of producing fatal electrical shock. AC
input power must be completely disconnected from the branch circuits wiring used to provide power to
the system before any AC electrical connections are made. Follow local lockout/tagout procedures to
ensure upstream branch circuit breakers remain de-energized during installation. DO NOT apply AC
input power to the system until all electrical connections have been completed and checked.
DC Output and Battery Voltages
DANGER! This system produces DC power and may have a battery source connected to it. Although
the DC voltage is not hazardously high, the rectifiers and/or battery can deliver large amounts of current.
Exercise extreme caution not to inadvertently contact or have any tool inadvertently contact an output
terminal or battery terminal or exposed wire connected to an output terminal or battery terminal.
NEVER allow a metal object, such as a tool, to contact more than one termination or battery terminal at a
time, or to simultaneously contact a termination or battery terminal and a grounded object. Even a
momentary short circuit can cause sparking, explosion, and injury.
DANGER! Follow local lockout/tagout procedures to ensure DC branch circuit protection devices
remain de-energized during installation at loads, as required.

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
7
Battery
Refer to the battery manufacturer documentation for specific battery safety instructions. The following are
general guidelines.
WARNING! Correct polarity must be observed when connecting battery leads.
WARNING! Special safety precautions are required for procedures involving handling, installing, and
servicing batteries. Observe all battery safety precautions in this manual and in the battery instruction
manual. These precautions should be followed implicitly at all times.
WARNING! A battery can present a risk of electrical shock and high short circuit current. Servicing of
batteries should be performed or supervised only by properly trained and qualified personnel
knowledgeable about batteries and the required precautions.
The following precautions should be observed when working on batteries:
•Remove watches, rings, and other metal objects.
•Eye protection should be worn to prevent injury from accidental electrical arcs.
•Use certified and well maintained insulated tools. Use double insulated tools appropriately rated for
the work to be performed. Ensure that wrenches with more than one working end have only one
end exposed.
•Do not lay tools or metal parts on top of batteries.
•Disconnect charging source prior to connecting or disconnecting battery terminals.
•Risk of explosion if battery is replaced with an incorrect type or if polarity is reversed.
Recommended to replace batteries with the same manufacturer and type, or equivalent.
•Dispose of used batteries according to the instructions provided with the batteries. Do not dispose
of batteries in a fire. They may explode.
•ALWAYS FOLLOW THE BATTERY MANUFACTURER’S RECOMMENDATIONS AND SAFETY
INSTRUCTIONS.
DANGER! This equipment may be used in conjunction with lead-acid batteries. Working near lead-acid
batteries is dangerous!
In addition to the hazard of electric shock, gas produced by batteries can be explosive and sulfuric acid
can cause severe burns.
•Do not open or mutilate batteries. Released electrolyte is harmful to the skin and eyes, and is toxic.
•Batteries contain sulfuric acid.
•Batteries generate explosive gases during normal operation. Systems containing batteries should
never be installed in an airtight room or space. Only install in a ventilated environment.
•Batteries are an energy source that can produce high amounts of electrical current.

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
8
FOR THESE REASONS, IT IS OF CRITICAL IMPORTANCE THAT YOU READ THESE INSTRUCTIONS
AND FOLLOW THEM EXACTLY.
WHEN WORKING WITH LEAD-ACID BATTERIES:
•Follow the recommended PPE requirements per the SDS for the battery to be used.
•If battery acid enters your eye, immediately flush your eye with running cold water for at least 15
minutes. Get medical attention immediately.
•If battery acid contacts skin or clothing, wash immediately with soap and water.
ALERT! Performing maintenance and/or troubleshooting procedures may interrupt power to the loads,
if battery reserve is not sufficient.
Personal Protective Equipment (PPE)
DANGER! ARC FLASH AND SHOCK HAZARD.
Appropriate PPE and tools required when working on this equipment. An appropriate flash protection
boundary analysis should be done determine the “hazard/risk” category, and to select proper PPE.
This product is intended only for installation in a Restricted Access Location.
Only authorized and properly trained personnel should be allowed to install, inspect, operate, or maintain
the equipment.
Do not work on LIVE parts. If required to work or operate live parts, obtain appropriate Energized Work
Permits as required by the local authority, per NFPA 70E “Standard for Electrical Safety in the
Workplace”.
Hazardous Voltage
DANGER! HAZARD OF ELECTRICAL SHOCK.
More than one disconnect may be required to de-energize the system before servicing.
Handling Equipment Containing Static Sensitive Components
ALERT! Installation or removal of equipment containing static sensitive components requires careful
handling. Before handling any equipment containing static sensitive components, read and follow the
instructions contained on the Static Warning Page.
Maintenance and Replacement Procedures
CAUTION! When performing any step in procedures that requires removal or installation of hardware,
use caution to ensure no hardware is dropped and left inside the unit; otherwise service interruption or
equipment damage may occur.
NOTE! When performing any step in procedures that requires removal of existing hardware, retain all
hardware for use in subsequent steps, unless otherwise directed.

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
9
STATIC WARNING
This equipment contains static sensitive components. The warnings listed below must be observed to
prevent damage to these components. Disregarding any of these warnings may result in personal injury
or damage to the equipment.
1. Strictly adhere to the procedures provided in this document.
2. Before touching any equipment containing static sensitive components, discharge all static
electricity from yourself by wearing a wrist strap grounded through a one megohm resistor. Some
wrist straps have a built-in one megohm resistor; no external resistor is necessary. Read and follow
wrist strap manufacturer’s instructions outlining use of a specific wrist strap.
3. Do not touch traces or components on equipment containing static sensitive components. Handle
equipment containing static sensitive components only by the edges that do not have connector
pads.
4. After removing equipment containing static sensitive components, place the equipment only on
conductive or anti-static material such as conductive foam, conductive plastic, or aluminum foil. Do
not use ordinary Styrofoam™or ordinary plastic.
5. Store and ship equipment containing static sensitive components only in static shielding containers.
6. If necessary to repair equipment containing static sensitive components, wear an appropriately
grounded wrist strap, work on a conductive surface, use a grounded soldering iron, and use
grounded test equipment.

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
10
This page is intentionally blank.

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
11
CUSTOMER DOCUMENTATION PACKAGE
This document (Section 6009) provides Installation Instructions for NetSure™ -48 VDC Power System Model
502NGFB, Spec. No. 582136700.
•The complete Customer Documentation Package consists of…
System Installation Manual
•Power System Installation Instructions: Section 6009
System User Manual
•Power System User Instructions: Section 6010
•Rectifier Instructions: UM1R482000e
•Power System “System Application Guide”: SAG582136700
•Engineering Drawings
Controller User Manual
•NCU Controller User Instructions: UM1M830BNA
•ACU+ Controller User Instructions: UM1M820BNA
•SCU+ Controller User Instructions: UM1M521BNA
•For factory settings of all configurable Controller parameters, refer to the Configuration Drawing (C-
drawing) supplied with your Power System.
INSTALLATION ACCEPTANCE CHECKLIST
Provided below is an Installation Acceptance Checklist. This checklist helps ensure proper installation and
initial operation of the system. As the procedures presented in this document are completed, check the
appropriate box on this list. If the procedure is not required to be performed for your installation site, also
check the box in this list to indicate that the procedure was read. When installation is done, ensure that each
block in this list has been checked. Some of these procedures may have been factory performed for you.
NOTE! The system is not powered up until the end of this checklist.
NOTE! Some of these procedures may have been performed at the factory for you.
Installing the System
Relay Racks (if required) Secured to Floor
Power/Distribution Shelf Secured to Relay Rack or Cabinet
Circuit Breakers Installed
Fuses Installed

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
12
Making Electrical Connections
Relay Rack Frame Grounding Connection Made
Power/Distribution Shelf Frame Grounding Connection Made
AC Input and AC Input Equipment Grounding Connections Made
External Interface Connections Made
Digital Inputs
Relay Outputs
Temperature Probes
Load Connections Made
CO Ground Connection Made
Battery Connections Made
Batteries Installed and Connected in an optional Battery Tray (if furnished)
Optional External Battery Disconnect Unit Connections Made
Ethernet Connection Made (if required)
Installing Rectifier Modules
Rectifier Modules Installed
Initially Starting the System
System Started, Configured, and Checked
INSTALLING THE SYSTEM
General Requirements
•This product is intended only for installation in a Restricted Access Location on or above a non-
combustible surface.
•This product must be located in a Controlled Environment with access to Crafts persons only.
•This product is intended for installation in Network Telecommunication Facilities (CO, vault, hut, or other
environmentally controlled electronic equipment enclosure).
•This product is intended to be connected to the common bonding network in a Network
Telecommunication Facility (CO, vault, hut, or other environmentally controlled electronic equipment
enclosure).
•The installer should be familiar with the installation requirements and techniques to be used in securing
the relay rack(s) to the floor.
•Typical industry standards recommend minimum aisle space clearance of 2'6" for the front of the relay
rack(s) and 2' for the rear of the relay rack(s).

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
13
•The installer should be familiar with the installation requirements and techniques to be used in securing
the Power/Distribution Shelf to a relay rack or cabinet.
•Rectifier and mounting shelf ventilating openings must not be blocked and temperature of air entering
rectifiers must not exceed rated Operating Ambient Temperature Range found in SAG582136700.
•Units with the side mounted Molex AC input connectors ‘End Use Application’ MUST be within an
electronic equipment enclosure.
Securing the Relay Rack(s) to the Floor (if furnished)
Secure the relay rack(s) to the floor per site requirements. Refer to the General Requirements section at the
beginning of this section.
Ventilation Requirements
Refer to the General Requirements section at the beginning of this section.
Relay Rack Floor Mounting Dimensions
Refer to Figure 1and Figure 2for relay rack floor mounting dimensions.

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
14
Figure 1: Relay Rack Floor Mounting Dimensions - 23” (dimensions are in inches)
Part No. 525004
Part No. 525111
Part No. 524913
17.50
20.13
24.38
2.13
3.44
9.88
12.53
15.00
1.24
2.56
0.875 Dia.
(8 Places)
Masked for Frame Ground Lug
0.281 Dia. Holes on 0.625 Centers
(Top of Rack, 2 Places)
22.500
24.750
1.125
15.000
17.500
20.125
25.000
2.437
3.750
9.871
12.531
15.031
1.250
2.580
2.00
1.00
1.00
2.00
2.00
2.00
5.00
0.437 Dia.
(12 Places)
Masked for Frame Ground Lug
0.281 Dia. Holes on 0.625 Centers
(Top of Rack, 2 Places)
0.875 Dia.
(8 Places)
Masked for Frame Ground Lug
0.281 Dia. Holes on 0.625 Centers
(Top of Rack, 1 Place)

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
15
Figure 2: Relay Rack Floor Mounting Dimensions - 19” (dimensions are in inches)
Part No. 525003
Part No. 528183
Part No. 524988
13.50
16.13
20.38
2.13
3.44
9.88
12.53
15.00
1.24
2.56
0.875 Dia.
(8 Places)
Masked for Frame Ground Lug
0.281 Dia. Holes on 0.625 Centers
(Top of Rack, 2 Places)
18.500
20.750
1.125
15.000
14.13
16.75
21.00
2.13
3.44
9.38
12.03
15.00
1.49
2.81
2.00
1.00
1.00
2.00
2.00
2.00
5.00
0.437 Dia.
(12 Places)
Masked for Frame Ground Lug
0.281 Dia. Holes on 0.625 Centers
(Top of Rack, 2 Places)
0.875 Dia.
(8 Places)
Masked for Frame Ground Lug
0.281 Dia. Holes on 0.625 Centers
(Top of Rack, 2 Places)

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
16
Securing the Power/Distribution Shelf to a Relay Rack or Cabinet
The shelf is designed to mount in a standard 19” or 23” wide relay rack or cabinet frame having 1” or 1-3/4”
multiple drillings. Refer to SAG582136700 for overall dimensions and a list of available relay racks.
NOTE! Refer to the General Requirements section at the beginning of this section for Ventilation
Requirements.
NOTE! Multiple Power/Distribution Shelves may be stacked one above the other with no space between
the shelves.
Mounting the Shelf
1. Secure shelf mounting angles to relay rack or cabinet at two (2) locations per side. Use grounding
washers at one (1) location per side. Proper orientation of grounding washers enables teeth to dig into
paint for a secure ground connection. Torque connections to 70 in-lbs.
NOTE! Compliance with Telcordia GR-1089-CORE requires that prior to mounting the
Power/Distribution Shelf to the equipment rack:
•All paint must be removed from the front surface of each equipment rack rail where it mates with a
shelf-mounting bracket, so that good metal-to-metal contact can be established between the shelf
and rack.
•The shelf-to-rack mating surfaces must be cleaned.
•Electrical anti-oxidizing compound must be applied to the shelf-to-rack mating surfaces.
Securing the Power/Distribution Shelf to a Wall with a Part No. 553203 Kit
An optional Wall Mount Bracket Kit (Part No. 553203) is available for vertical wall mounting of any List 2 or 6
Power/Distribution Shelf.
NOTE! Refer to the General Requirements section at the beginning of this section for Ventilation
Requirements.
Procedure
1. Refer to Figure 3when performing this procedure.
2. The installer must provide fasteners for securing the shelf to a wall or other vertical surface. Ensure that
the wall and fastening technique are suitable for supporting the weight of the shelf and rectifiers.
Suggested anchors are listed in the illustrations. Refer to System Application Guide SAG582136700 for
shelf weight and additional dimensions.
3. Attach the brackets to the shelf mounting angles using kit-furnished screws. Torque to 60 in-lbs.
4. Use drill guide dimensions in the illustration to prepare the wall for customer-furnished fasteners.
Secure the shelf assembly to the wall.

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
17
Figure 3: Vertical Wall Mounting, List 2 or 6
Front
Installer to furnish hardware
for fastening brackets to wall.
Use (2) wall anchors per bracket.
For solid concrete block, hard
natural stone or solid brick, use
Hilti HLC H 5/16 X 1-5/8 or similar.
Bottom
of Shelf
19” shelf shown.
23” shelf similar.
Wall Mount Drilling Guide (Not to scale)
All dimensions are in inches.
3-1/8
18-15/16 (19” Shelf)
22-29/32 (23” Shelf)
3/8 Dia.
Clearance
Hole in
Bracket
for Wall
Fastener
(Front)

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
18
Securing the System Horizontally to a Wall with P/N 552537 or P/N 552535 Kit (if
furnished)
An optional wall mount bracket kit (P/N 552537 for 19” system and P/N 552535 for 23” system) is available for
horizontal wall mounting of the system.
NOTE! Refer to “General Requirements” on page 12 for mounting restrictions and ventilation
requirements.
NOTE! Refer to Figure 4 or Figure 5 when performing this procedure.
Procedure
1. The installer must provide fasteners for securing the system to a wall or other horizontal surface.
Ensure that the wall and fastening technique are suitable for supporting the weight of the system. Refer
to System Application Guide SAG582136700 for system weight and additional dimensions.
2. Prepare the wall for customer-furnished fasteners. Secure the wall bracket to the wall.
3. Attach the system to the wall bracket using the standard mounting technique. See “Securing the
Power/Distribution Shelf to a Relay Rack or Cabinet” on page 16.

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
19
Figure 4: Horizontal Wall Mounting with P/N 552537
Notes:
1. All dimensions are in inches,
unless otherwise specified.
2. Installer to furnish hardware
for fastening bracket to wall.
552537
Frame Grounding Point
(1/4-20Studson5/8”Centers)

Vertiv |NetSure 502NGFB Installation Manual (Section 6009) |Rev. Z
20
Figure 5: Horizontal Wall Mounting with P/N 552535
Notes:
1. All dimensions are in inches,
unless otherwise specified.
2. Installer to furnish hardware
for fastening bracket to wall.
552535
Frame Grounding Point
(1/4-20 Studs on 5/8” Centers)
