Vertiv NetSure 731 A91 User manual

NetSure 731 A91 插框电源系统
用户手册
NetSure 731 A91 Subrack Power
System
User Manual
资料版本 V1.0
归档日期 2019-08-27
BOM 编码 31013961
Version V1.0
Revision date August 27, 2019
BOM 31013961
维谛技术有限公司为客户提供全方位的技术支
持，用户可与就近的维谛技术有限公司办事处
或客户服务中心联系，也可直接与公司总部联
系。
维谛技术有限公司
版权所有，保留一切权利。内容如有改动，恕
不另行通知。
维谛技术有限公司
地址：深圳市南山区学苑大道 1001 号南山智园
B2 栋
邮编：518055
公司网址：www.vertiv.com
客户服务热线：4008876510
E-mail：[e-mail]
Vertiv Tech provides customers with technical
support. Users may contact the nearest Vertiv
local sales office or service center.
Copyright © 2019 by Vertiv Tech Co., Ltd.
All rights reserved. The contents in this document
are subject to change without notice.
Vertiv Tech Co., Ltd.
Address: Block B2, Nanshan I Park, No.1001
Xueyuan Road, Nanshan District, Shenzhen,
518055, P.R.China
Homepage: www.vertiv.com
E-mail: [e-mail]

Safety Precautions
To reduce the chance of accident, please read the safety precautions very carefully before operation. The
"Caution, Notice, Warning, Danger" in this book do not represent all the safety points to be observed, and are
only supplement to various safety points. Therefore, the installation and operation personnel must be strictly
trained and master the correct operations and all the safety points before actual operation.
When operating Vertiv products, the safety rules in the industry, the general safety points and special safety
instructions specified in this book must be strictly observed.
Electrical Safety
I. Hazardous voltage
Danger
Some components of the power system carry hazardous voltage in operation. Direct contact or indirect contact through
moist objects with these components will result in fatal injury.
Safety rules in the industry must be observed when installing the power system. The installation personnel must
be licensed to operate high voltage and AC power.
In operation, the installation personnel are not allowed to wear conductive objects such as watches, bracelets,
bangles, rings.
When water or moisture is found on the Subrack, turn off the power immediately. In moist environment,
precautions must be taken to keep moisture out of the power system.
"Prohibit" warning label must be attached to the switches and buttons that are not permitted to operate during
installation.
Danger
High voltage operation may cause fire and electric shock. The connection and wiring of AC cables must be in compliance
with the local rules and regulations. Only those who are licensed to operate high voltage and AC power can perform high
voltage operations.
II. Tools
Warning
In high voltage and AC operation, special tools must be used. No common or self-carried tools should be used.
III. Thunderstorm
Danger
Never operate on high voltage,AC, iron tower or mast in the thunderstorm.
In thunderstorms, a strong electromagnetic field will be generated in the air. Therefore the equipment should be
well earthed in time to avoid damage by lightning strikes.

IV. ESD
Notice
The static electricity generated by the human body will damage the static sensitive elements on PCBs, such as large-scale
ICs. Before touching any plug-in board, PCB or IC chip, ESD wrist strap must be worn to prevent body static from
damaging the sensitive components. The other end of the ESD wrist strap must be well earthed.
V. Short circuit
Danger
During operation, never short the positive and negative poles of the DC distribution unit of the system or the non-grounding
pole and the earth. The power system is a constant voltage DC power equipment, short circuit will result in equipment
burning and endanger human safety.
Check carefully the polarity of the cable and connection terminal when performing DC live operations.
As the operation space in the DC distribution unit is very tight, please carefully select the operation space.
Never wear a watch, bracelet, bangle, ring, or other conductive objects during operation.
Insulated tools must be used.
In live operation, keep the arm muscle tense, so that when tool connection is loosened, the free movement of
the human body and tool is reduced to a minimum.
VI. Dangerous energy
Warning
More than 240VA system capacity, keep away from hazardous energy and avoid bridge connection.
Battery
Danger
Before any operation on battery, read carefully the safety precautions for battery transportation and the correct battery
connection method.
Non-standard operation on the battery will cause danger. In operation, precautions should be taken to prevent
battery short circuit and overflow of electrolyte. The overflow of electrolyte will erode the metal objects and PCBs,
thus causing equipment damage and short circuit of PCBs.
Before any operation on battery, pay attention to the following points:
Remove the watch, bracelet, bangle, ring, and other metal objects on the wrist.
Use special insulated tools.
Use eye protection device, and take preventive measures.
Wear rubber gloves and apron to guard against electrolyte overflow.
In battery transportation, the electrode of the battery should always be kept facing upward. Never put the battery
upside down or slanted.

Battery installation requires reliable grounding. And battery is connected before accessing the battery protection
device.
Others
I. Sharp object
Warning
When moving equipment by hand, protective gloves should be worn to avoid injury by sharp object.
II. Cable connection
Notice
Please verify the compliance of the cable and cable label with the actual installation prior to cable connection.
III. Binding the signal lines
Notice
The signal lines should be bound separately from heavy current and high voltage lines, with binding interval of at least
150mm.

Contents
Chapter 1 Overview ............................................................................................................................................................1
1.1 Composition and Configuration.............................................................................................................................1
Chapter 2 Installation Instruction.........................................................................................................................................3
2.1 Safety Regulation..................................................................................................................................................3
2.2 Preparation...........................................................................................................................................................3
2.3 Mechanical Installation..........................................................................................................................................4
2.4 Electrical Installation.............................................................................................................................................5
2.4.1 Power System Cabling Method .................................................................................................................5
2.4.2 Connecting AC Input Cables .....................................................................................................................7
2.4.3 Connecting Load Cables ...........................................................................................................................7
2.4.4 Connecting Battery Cables........................................................................................................................8
2.4.5 Connecting Signal Cables .........................................................................................................................8
Chapter 3 Commissioning.................................................................................................................................................11
3.1 Installation Check and Startup............................................................................................................................11
3.2 Basic Settings.....................................................................................................................................................12
3.3 Alarm Check And System Operation Status Check............................................................................................12
3.4 Final Steps..........................................................................................................................................................13
Chapter 4 Troubleshooting................................................................................................................................................14
4.1 Controller Alarms And Fault Handling.................................................................................................................14
4.2 Rectifier Fault Handling.......................................................................................................................................16
4.2.1 Rectifier Fan Replacement......................................................................................................................18
Appendix 1 Technical And Engineering Data....................................................................................................................20
Appendix 2 Installation Instruction Of Battery Rack ..........................................................................................................23
1. Installation Instruction Of Two-Layer And Four-Layer Battery Rack .....................................................................23
2. Installation Instruction Of Three-Layer Battery Rack.............................................................................................25
3. Fixing The Battery Rack........................................................................................................................................26
Appendix 3 Wiring Diagram...............................................................................................................................................27
Appendix 4 Schematic Diagram........................................................................................................................................31

Chapter 1 Overview 1
NetSure 731 A91 Subrack Power System User Manual
Chapter 1 Overview
This chapter introduces model composition and configuration and features of NetSure 731 A91-S1, NetSure 731
A91-S2 and NerSure 731 A91-S3 (abbreviated as 'power system' hereinafter).
1.1 Composition and Configuration
Composition
The power system is composed of power distribution、rectifier modules and controller module.
Take NetSure731 A91-S1 for example, the internal structure is shown as Figure 1-1.
Earthing screw
AC input terminal N
AC input terminal L3
AC input terminal L2
AC input terminal L1
Positive terminal
Battery MCB
Controller
Rectifier
Non- prority load Prority load
Figure 1-1 NetSure 731 A91- S1 system instruction
Configuration
The configuration of the power system is listed in Table 1-1.
Table 1-1 Configuration of power system
Item
NetSure 731 A91-S1
NetSure 731 A91-S2
NetSure 731 A91-S3
Controller
Mode: M830B
Mode: M530B
Mode: M830B
Rectifier
Model:
R48-3500e3
Maximum configuration：9 pieces
Model：
R48-3000e3/R48-3500e3
Maximum configuration：9 pieces
Note: R48-3000e3 moudle and
R48-3500e3 moudle are not mixed
Model：
R48-3000e3
Maximum configuration：9 pieces
AC power
distribution
3P＋N＋PE/380-415Vac
3P＋N＋PE/380-415Vac
3P＋N＋PE/380-415Vac
DC power
distribution
PL:
63A/1P×2 MCB
32A/1P×2 MCB
16A/1P×2 MCB
NPL:
63A/1P×3 MCB
32A/1P×3 MCB
16A/1P×2 MCB
PL:
63A/1P×2 MCB
32A/1P×2 MCB
16A/1P×2 MCB
NPL:
63A/1P×3 MCB
32A/1P×3 MCB
16A/1P×2 MCB
PL:
63A/1P×2 MCB
32A/1P×2 MCB
16A/1P×2 MCB
NPL:
63A/1P×3 MCB
32A/1P×3 MCB
16A/1P×2 MCB
AC output MCB
/
/
/
Battery MCB
4×125A/1P
4×125A/1P
4×125A/1P
AC SPD
1 piece
1 piece
1 piece
DC SPD
1 piece
1 piece
1 piece

2 Chapter 1 Overview
NetSure 731 A91 Subrack Power System User Manual
Item
NetSure 731 A91-S1
NetSure 731 A91-S2
NetSure 731 A91-S3
Cover
Standard
Standard
Standard
BLVD controller
control mode
Controller without power-losing
mode
Controller without power-losing mode
Controller without power-losing
mode
Main Features
⚫The rectifier uses the active Power Factor Compensation(PFC) technology and the power factor is up to 0.99.
⚫The power system has wide AC input voltage: 85Vac～300Vac.（Module single phase input voltage）。
⚫The rectifier uses soft switching technology, raising the efficiency above 95.3％.
⚫The rectifier has Ultra-low radiation. With advanced EMC design, the rectifier meets international standards such
as CE、NEBS and YD/T983.Both the conducted and radiated interference reach Class B.（R48-3500e3 moudle
reach Class B，R48-3000e3 moudle reach Class A）
⚫The rectifier safety design complies UL, CE and NEBS.
⚫The rectifier is of high power density.
⚫The rectifier is hot pluggable. It takes less than1 min to replace a rectifier.
⚫The rectifier has input over-voltage protection. The overvoltage protection point is set to 307.5V, which can be
automatically restored.
⚫The rectifier has two optional over-voltage protection methods: hardware protection and software protection. The
latter one also has two optional modes: lock-out at the first over-voltage and lock-out at the second
over-voltage.
⚫The controller module has perfect battery management. The management functions includes BLVD,
temperature compensation, auto voltage regulation , stepless current limiting ,battery capacity calculation and
on-line battery test, etc.
⚫History alarm records：M530B controller supports 200 history alarms and 5000 history data records, M830B
controller supports 4000 history alarms and 60000 history data records.
⚫Battery test data: M530B controller can record up to 5 sets of battery test data. M830B controller can record up
to 10 sets of battery test data.
⚫The power system is of network design. Providing multiple communication ports (such as RS232, RS485, USB,
Ethernet and CAN), which enables flexible networking and remote monitoring.
⚫The power system has perfect lighting protection at both AC side and DC side.
⚫The power system has complete fault protection and fault alarm functions.

Chapter 2 Installation Instruction 3
NetSure 731 A91 Subrack Power System User Manual
Chapter 2 Installation Instruction
2.1 Safety Regulation
Certain components in this power system carry hazardous voltage and current. Always following the instructions
below：
1. Only the adequately trained personnel with satisfactory knowledge of the power system can carry out the
installation. The most recent revision of these safety rules and local safety rules in force shall be adhered to during
the installation.
2. All external circuits that are below 48V and connected to the power system must comply with the requirements of
SELV as defined in IEC 60950-1.
3. Make sure that the power (mains and battery) to the system is cut off before any operations can be carried out
within the system cabinet.
4. The power cabinets shall be kept locked and placed in a locked room. The key keeper should be the one
responsible for the power system.
5. The wiring of the power distribution cables should be arranged carefully so that the cables are kept away from the
maintenance personnel.
2.2 Preparation
Unpacking inspection
The equipment should be unpacked and inspected after it arrives at the installation site. The inspection shall be done
by representatives of both the user and Vertiv Tech Co., Ltd.
To inspect the equipment, you should open the packing case, take out the packing list and check against the packing
list that the equipment is correct and complete. Make sure that the equipment is delivered intact.
Cables
The cable should be selected in accordance with relevant industry standards.
It is recommended to use the RVVZ cables as AC cables. The cable should reach at least +70°C temperature
durability. With cable length shorter than 30 meters, the Cross-Sectional Area (CSA) calculation should be based on
the current density of 3.5A/mm2. The suggested CSA value is no less than the Table 2-1.
Table 2-1 AC cable CSA selection
AC MCB rated current
Max. AC input current
Min cable CSA
Max cable CSA
100A
64A
25mm2
50mm2
The CSA of DC cable depends on the current flowing through the cable and the allowable voltage drop. To select the
battery cable CSA, see Table 2-2,select the DC load cable CSA according to the Table 2-3.
Table 2-2 Battery cable CSA selection
Battery MCB rated current
Max. battery current
Min cable CSA
Max cable length( volt drop:
0.35V with max. CSA)
125A
100A
35mm2
7m
Note:
1. The specs are applicable at ambient temperature of 25°C.
2. The battery cable should reach at least +90°C heat durability. It is recommended to use double-insulated copper-core flame
retardant cable as battery cable.

4 Chapter 2 Installation Instruction
NetSure 731 A91 Subrack Power System User Manual
Table 2-3 DC load cable CSA selection
Load route
rated current
Max. output
current
Min. cable
CSA
Max cable length ( volt drop:
0.35V with min. CSA)
Max. cable
CSA
Max cable length ( volt drop: 0.35V
with max. CSA)
63A
63A
16mm2
5m
25mm2
8m
32A
32A
10mm2
6m
25mm2
15m
16A
16A
6mm2
8m
25mm2
31m
Note: The specs are applicable at ambient temperature of 25°C. If the temperature is higher than this, the CSA of the cable should
be increased.
To prevent the air switching capacity is too large, the load doesn't work when overload. Recommended the capacity
of the air switching is up to 1.5~2 times of the load peak.
The CSA of the system grounding cables should be consistent with the largest power distribution cables. The CSA
value is no less than 25mm2.
AC distribution、DC distribution interface definition see Table 2-4.
Table 2-4 AC distribution 、 DC distribution interface definition
Connector name
Connector specifications
Wiring instruction
AC power
distribution
AC input MCB
H type terminal, max. cable CSA 50mm2
AC power line
Grounding busbar
One M8 bolt, OT type wiring terminal, max. cable
CSA 35mm2
Connected to the grounding bar of
the building
DC power
distribution
Battery output MCB
H type terminal, max. cable CSA 50mm2
Connected to the battery port
Negative output MCB
H type terminal, max. cable CSA 25mm2
Connected to the users negative
load port
Positive busbar
Terminal subrack terminal：cable CSA ≤ 50mm2
Connected to the users positive
load port
2.3 Mechanical Installation
Note
1. The cabinet or rack that installed in the subrack must provide fireproof and electric protection casing, or install in cement or
other difficult to burn, at the same time keep enough distance to other combustible material.
2. For the convenience of maintenance, users should maintain a clearance of 800mm at the front of the power system.
3. Subrack cannot be installed against the wall, it must leave enough space for heat dissipation.
Installed on the battery rack
Fix the subrack power system to the battery rack through the connectors with M6 bolts, as show in Figure 2-1.
Power system
M6 screw
Connector
Battery rack
M6 screw
Connector
Figure 2-1 Cabinet and rack installation

Chapter 2 Installation Instruction 5
NetSure 731 A91 Subrack Power System User Manual
Installed in cabinet
Insert the subrack power system to the matching cabinet, as shown in Figure 2-2.
Power subrack
Figure 2-2 Installed in the cabinet system
The engineering graphics of the subrack power system as shown in Figure 2-3.
101.676.2101.6
37.7 355.2
465.1
482.6
10
7
R3.5
Figure 2-3 Installation size of 731 A91-S1/S2/S3 （ unit: ： mm ）
Note
1. Tighten the captive screw of the MFU Panel by the cross head screwdriver when there is no operation.
2. Also tighten the handle by the cross head screwdriver.
3. Please plug in the new modules or installing a new panel after removing the rectifier module.
2.4 Electrical Installation
2.4.1 Power System Cabling Method
Cabling from the top of the power system
The top cover is rubber ring top cover.

6 Chapter 2 Installation Instruction
NetSure 731 A91 Subrack Power System User Manual
Rubber ring top cover for MFU unit cabling :
Use the electrician knife incise the "十" mark on the rubber unit. As shown in Figure 2-4. Cabling from the cable outlet
area and then fixed to the cable--bunding plate and the top edge by using cable ties.
Lates unit
Cable outlet area
Figure 2-4 Cable entry illustration of the MFU unit
Cabling from the side of the power system
Use a cross head screwdriver to remove two screws which fix the cabling panel at side of cabling area, then the cable
can be led out from the cabling area, as shown in Figure 2-5.
警告
Warning
When the subrack is installed independently on the outside (not installed in the rack). Using system side outlet. The clearance of
the outlet hole must be sealed after connecting the cable to prevent it from touching the live part of the frame.
Screw Screw
Cable hole
Cable hole
Figure 2-5 Side cabling

Chapter 2 Installation Instruction 7
NetSure 731 A91 Subrack Power System User Manual
2.4.2 Connecting AC Input Cables
Danger
Danger
1. Switch off all MCBs before the electrical connection.
2. Only the qualified personnel can do the mains cable connection.
For NetSure 731 A91-S1 power system, the position of the connection terminals are shown in Figure 2-6.After
connecting AC cables, fixing cables on top or side cable banding area by using cable ties.
Earthing screw
AC input terminal N
AC input terminal L3
AC input terminal L2
AC input terminal L1
Figure 2-6 Illustration of NetSure 731 A91-S1 connection terminal
Note
1. Recommended tightening torque of user grounding screw is 11N*M.
2. In case system earthing cable lessen, please add another fixing point except for the earthing screw.
2.4.3 Connecting Load Cables
Connect the negative load cable to the upper terminal of load MCB and then connect the positive load cable to
positive terminal. As shown in Figure 2-7.
Non- prority load Prority load
Positive terminal
Figure 2-7 Illustration of the load cable connection terminal

8 Chapter 2 Installation Instruction
NetSure 731 A91 Subrack Power System User Manual
2.4.4 Connecting Battery Cables
Note
1. The batteries may have dangerous current. Before connecting battery cables, make sure that the battery MCBs at the battery
side are switched off.
2. If there are no battery MCBs at the battery side, users should disconnect any one of the connectors between battery cells to
avoid live state of the system after installation.
3.Be careful not to reversely connect the battery. Otherwise, both the battery and the system will be damaged.
4.It's forbidden to disassemble battery cables in the up of the battery MCB when the battery input port is still connected.
1. Connect one end of the negative battery cable to the upper terminal of battery MCBs. Connect one end of the
positive battery cable to the DC positive bus bar.
2. Connect copper lugs to the other end of the battery cables. Bind the connecting parts with insulating tape, and put
them beside the battery. Connect the cables to the battery when the DC distribution unit is to be tested. As shown in
Figure 2-8.
Positive terminal
Battery MCB
Figure 2-8 Illustration of the battery connection terminal
2.4.5 Connecting Signal Cables
Connecting NetSure 731 A91-S1/S3 Signal Cables
The standard configuration of the system is M830B controller. The MA4C5U31 user interface board is used for
M830B. M830B controller and MA4C5U31 user interface board cable connection is show in the following:

Chapter 2 Installation Instruction 9
NetSure 731 A91 Subrack Power System User Manual
Terminal block
User interface board
（DI/ DO board）
Signal cable
Figure 2-9 Netsure 731 A91-S1 user interface board illustration
MA4C5U31 User Interface Board can provide 8 DI and 8 DO. For alarm type and corresponding relay, users can set
it by background software according to the actual situation.
Connecting Communication Signal Cable
The communication port of M830B controller is shown in Figure 2-10.
USB口
以太网口
Ethernet port
USB
Figure 2-10 M830B controller communication port
Connecting NetSure 731 A91-S2 Signal Cables
The standard configuration of the system is M530B controller. Netsure 731 A91-S2 user interface board position as
shown in Figure 2-11.
Signal cable
User interface terminal
（DI/ DO board）
Figure 2-11 Netsure 731 A91-S2 user interface board illustration

10 Chapter 2 Installation Instruction
NetSure 731 A91 Subrack Power System User Manual
Connecting Communication Signal Cable
The communication port of M530B controller is shown in Figure 2-12.
USB口
以太网口
Ethernet port
USB
Figure 2-12 M530B controller communication port

Chapter 3 Commissioning 11
NetSure 731 A91 Subrack Power System User Manual
Chapter 3 Commissioning
The controllers can be used in the power system are M830B、M530B. This section introduces commissioning after
installation. During installation test, the corresponding safety rules should be adhered to. The system has been tested
before out of the factory, user doesn't need to test on site.
3.1 Installation Check and Startup
Before the test, inform the chief manufacturer representative. Only trained electrical engineer can maintain and
operate this equipment. In operation, the installation personnel are not allowed to wear conductive objects such as
watches, bracelets, bangles and rings.
During operation, parts of this equipment carry hazardous voltage. Misoperation may result in severe or fatal injuries
and property damage. Before the test, check the equipment to ensure the proper earthing. Installation check must be
done before testing. Then the batteries can be charged for the first time.
Make sure that the AC input MCBs, battery MCBs and load MCBs are switched off. Make sure that all the devices are
properly installed.
Installation check
OK
Comments
Check all the fuse and cables. Are the models correct?

Check the busbar connections, input and output cable connection, and connection between the power
system and the system grounding.

Check if the number and connections of the batteries are correct. Check the polarity of the battery string
with a voltmeter.

Make sure all the communication cables and alarm cables are connected to the controller module. Check
that the temperature sensor, if any, has been installed.

Startup preparations
OK
Comments
Make sure that all the MCB are switched off and all the fuses are removed.

Measure the AC input voltage. Make sure the input voltage is within the allowable range.

Umin＝V
Check that communication and alarm cables are connected to the signal transfer board.

Check that the temperature sensor, if any, has been installed.

Check that the battery string circuit is not closed.

Connect the disconnected batteries to the battery string circuit.

Make sure that the MCB disconnected to the battery cables are switched off. Check the battery signal
cables connection and MCB cables connection.

Measure with a voltmeter across the connection points of each battery and make sure that the polarity is
right. For a lead-acid battery with 24 cells, the voltmeter should read 2.0 ~ 2.1V/cell or 48 ~ 51V/battery. If
the voltage of certain cell is lower than 2.0V, that cell must be replaced.

Umin＝V
Check with an ohmmeter that there is no short circuit between the positive & negative distribution bus bars,
or between the positive & negative battery poles (Note: Pull out all modules before the check and restore
them after the check).

Startup
OK
Comments
Switch on the system AC input MCB. Insert one rectifier. The green LED on the rectifier will be on and the
fan will start running after a certain delay. The controller module will show that the power supply voltage is
53.5V.

Check the system voltage and busbar polarity with a voltmeter. The voltage difference between the
measured value and displayed value should be less than±0.2V.

Start and stop each rectifier of the system by inserting and unplugging the rectifier. Check their output
voltages.


12 Chapter 3 Commissioning
NetSure 731 A91 Subrack Power System User Manual
3.2 Basic Settings
When the system is put into service for the first time, the parameters of controller module must be set based on the
actual system configuration, such as battery number, capacity, user’s charge current limit and other functional
requirements. Only after that can the controller module display system operation information and control the output.
M830B controller password is 640275. System parameter settings are shown in Table 3-1.
Table 3-1 M830B controller paremeter settings
Parameter
Path
Default settings
Capacity
NCU home page—Settings—Battery charge—Battery 1 capacity
300Ah
LVD1 enabled
LCD—Settings—LVD Settings—LVD1 enabled
Enabled
LVD2 enabled
LCD—Settings—LVD Settings—LVD2 enabled
Enabled
LVD1
LCD—Settings—LVD Settings—LVD1 Volt
44.0V
LVD2
LCD—Settings—LVD Settings—LVD2 Volt
43.2V
AC Fail Required
Web—Advanced Settings—System—LVD Group—AC Fail Required
Y
Num Batt Shunts
LCD—Settings—Bat. Settings—Basic Settings—Num Batt Shunts
1
Batt shunts settings
LCD—Settings—Bat. Settings—Basic Settings—Battery 1—Shunt
Current/Shunt Voltage
600A/25mV
Contactor type
Web—Settings—LVD—Contactor type
Monstabillity
Walk-in
LCD→Settings→Rect Settings→Walk-in on
Y
Walk-in T
LCD→Settings→Rect Settings→Walk-in T
128S
Note: The above battery protection voltage should be set according to the battery manufacturer's requirements. The battery
capacity should be set according to the actual configuration.
M530B controller password is 640275. System parameter settings are shown in Table 3-2.
Table 3-2 M530B controller main paremeter settings
Parameter
Path
Default settings
System Type
Quick Settings →System Type
48V/SET
Capacity
Quick Settings →Capacity
150Ah
LVD2
Settings→Bat. Settings→LVD Settings →LVD2 Volt
43.2V
LVD1
Settings→Bat. Settings→LVD Settings →LVD1 Volt
44.0V
Batt shunts settings
Settings →Basic Settings →Batt Shunts 1
N
Batt shunts settings
Settings →Basic Settings →Batt Shunts 2
Y
BLVD contactor
Bat. Settings →LVD Settings →BLVD Volt
43.2V
AC Phase
Settings→Input Settings→AC PH
3-PH
Walk-in
Settings→Rect Settings→Walk-in on
N
Walk-in T
Settings→Rect Settings→Walk-in T
8S
Note: The above parameters need to be adjusted according to the actual situation.
3.3 Alarm Check And System Operation Status Check
Alarm check
Check that all functional unit can trigger alarms that can be displayed on the controller.
OK
Comment
Pull out one rectifier. The ‘Rect N Com Failure’ alarm should be triggered. Insert the rectifier in. The alarm
should disappear. Repeat the same procedures on other rectifiers

Switch off battery MCB 1. The ‘Batt1 Failure’ alarm should be triggered. Switch on the MCB. The alarm
should be cleared. Repeat the same on battery MCB 2, MCB 3 and MCB 4.

Switch off a load MCB connected to a load route. The alarm ‘Load Fuse N Failure’ should be triggered.
Switch on the MCB, and the alarm should be cleared. Repeat the same on the other load MCBs

Remove all the battery MCBs. Keep only one rectifier in operation. Through the controller module, adjust
the rectifier FC voltage to make it lower than the alarm point. The alarm ‘DC Voltage Low’ should be
triggered

