Vertiv NetSure F1011259 Operating and installation instructions

NetSure™
External Distribution Box (EDB)
Description and Installation Manual
Specification Number: F1011259, F1011265, F1011266

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
The information contained in this document is subject to change without
notice and may not be suitable for all applications. While every precaution has
been taken to ensure the accuracy and completeness of this document, Vertiv
assumes no responsibility and disclaims all liability for damages resulting from
use of this information or for any errors or omissions. Refer to other local
practices or building codes as applicable for the correct methods, tools, and
materials to be used in performing procedures not specifically described in
this document.
The products covered by this instruction manual are manufactured and/or
sold by Vertiv. This document is the property of Vertiv and contains
confidential and proprietary information owned by Vertiv. Any copying, use or
disclosure of it without the written permission of Vertiv is strictly prohibited.
Names of companies and products are trademarks or registered trademarks of
the respective companies. Any questions regarding usage of trademark
names should be directed to the original manufacturer.
Technical Support Site
If you encounter any installation or operational issues with your product, check the pertinent section of this
manual to see if the issue can be resolved by following outlined procedures.
Visit https://www.vertiv.com/en-us/support/ for additional assistance.

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
iii
TABLE OF CONTENTS
Admonishments Used in this Document..............................................................................................................................v
Important Safety Instructions.................................................................................................................................................vi
1 About this Document.............................................................................................................................................................1
2 Product Description ...............................................................................................................................................................1
2.1 General..................................................................................................................................................................................................................................................................................1
2.2 Part Numbers ..................................................................................................................................................................................................................................................................1
2.2.1 Enclosure.........................................................................................................................................................................................................................................................1
2.2.2 Circuit breakers........................................................................................................................................................................................................................................3
2.3 Application........................................................................................................................................................................................................................................................................3
2.4 Specifications.................................................................................................................................................................................................................................................................3
2.4.1 Electrical .........................................................................................................................................................................................................................................................3
2.4.2 Environmental............................................................................................................................................................................................................................................4
2.4.3 Compliance information ...................................................................................................................................................................................................................4
2.4.4 Safety listed AC and DC components.................................................................................................................................................................................4
2.4.5 Enclosure dimensions, weights, and physical specifications.........................................................................................................................4
2.5 Local DC Power Source........................................................................................................................................................................................................................................4
2.6 Enclosure Features and Options..................................................................................................................................................................................................................6
3 Sequence of Procedures....................................................................................................................................................10
3.1 General..............................................................................................................................................................................................................................................................................10
4 Front Doors and Locks........................................................................................................................................................11
4.1 Important Safety Instructions .......................................................................................................................................................................................................................11
4.2 Front Doors ....................................................................................................................................................................................................................................................................11
4.3 Opening and Closing the Enclosure Front Doors.......................................................................................................................................................................11
5 Installation Considerations...............................................................................................................................................14
5.1 Installation Overview ............................................................................................................................................................................................................................................14
5.2 Tools, Test Equipment, and Materials Recommended for Installation..................................................................................................................14
6 Transportation and Storage.............................................................................................................................................15
6.1 Important Safety Instructions .......................................................................................................................................................................................................................15
6.2 Transportation ............................................................................................................................................................................................................................................................15
6.3 Storage...............................................................................................................................................................................................................................................................................15
7 Mounting the Enclosure.....................................................................................................................................................15
7.1 Important Safety Instructions .......................................................................................................................................................................................................................15
7.2 Specific Safety Precautions ............................................................................................................................................................................................................................15
7.3 General...............................................................................................................................................................................................................................................................................15
7.4 Inspecting and Unpacking the Enclosure at the Installation Site ..............................................................................................................................16
7.5 Mounting the Enclosure on the Outside of a Companion Enclosure .....................................................................................................................16
7.6 Installing Field LVD Contactor Kit P/N F1011267.......................................................................................................................................................................16
8 Installing Bullet Nose Type Circuit Breakers.............................................................................................................16
9 Grounding the Enclosure...................................................................................................................................................18
9.1 Important Safety Instructions ......................................................................................................................................................................................................................18
9.2 General..............................................................................................................................................................................................................................................................................18
9.3 Enclosure Grounding Terminals................................................................................................................................................................................................................18

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
iv
9.4 Main Ground Bar ......................................................................................................................................................................................................................................................18
10 Cable Routing .......................................................................................................................................................................20
11 Making Electrical Connections .......................................................................................................................................21
11.1 Important Safety Instructions .......................................................................................................................................................................................................................21
11.2 General...............................................................................................................................................................................................................................................................................21
11.3 Cable Routing...............................................................................................................................................................................................................................................................21
11.4 Sealing Cable Entries ............................................................................................................................................................................................................................................21
11.5 Connecting RRH (Remote Radio Head) Cables..........................................................................................................................................................................21
11.5.1 General...........................................................................................................................................................................................................................................................21
11.5.2 Routing RRHs Cables into the Enclosure ......................................................................................................................................................................21
11.5.3 Connecting RRHs Cable Power Leads to the -48 VDC / -58 VDC Distribution Panels....................................................22
11.5.4 Connecting RRHs Cable Fiber Leads to the Fiber Termination Blocks ...........................................................................................22
11.6 Connecting Alarm and LVD (Low Voltage Disconnect) Cables ................................................................................................................................ 24
11.7 Connecting Fiber Cables to the Enclosure.......................................................................................................................................................................................31
11.7.1 Optical Fiber Cables Precautions..........................................................................................................................................................................................31
11.7.2 Installing Fiber Cables.....................................................................................................................................................................................................................32
11.8 Connecting -48 VDC / -58 VDC Input Power to the Enclosure...................................................................................................................................32
12 Sealing Enclosure Cable Entries.................................................................................................................................... 33
13 Initial Power Up....................................................................................................................................................................34
13.1 Important Safety Instructions .....................................................................................................................................................................................................................34
13.2 Prerequisite..................................................................................................................................................................................................................................................................34
13.3 Initial Power Up Sequence.............................................................................................................................................................................................................................34
14 Maintenance and Replacement Procedures..............................................................................................................34
14.1 Important Safety Instructions .....................................................................................................................................................................................................................34
14.2 Contact Information............................................................................................................................................................................................................................................. 34
14.3 Enclosure Identification....................................................................................................................................................................................................................................34
14.4 Routine Maintenance...........................................................................................................................................................................................................................................35
14.4.1 Freezing rain and ice........................................................................................................................................................................................................................35
15 Accessories and Replacement Parts ........................................................................................................................... 35
16 DC Power, Outdoor Enclosure & Service Contacts................................................................................................ 36

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
v
Admonishments Used in this Document
DANGER
! Warns of a hazard the reader will be exposed to that will likely result
in death or serious injury if not avoided
. (ANSI, OSHA)
WARNING
! Warns of a potential hazard the reader may be exposed to that could
result in
death or serious injury if not avoided
. This admonition is not used for situations that pose
a risk only to equipment, software, data, or service
. (ANSI)
CAUTION
! Warns of a potential hazard the reader may be exposed to that could
result in minor or moderate injury if not avoided
. (ANSI, OSHA) This admonition is not
used for situations that pose a risk only to equipment, data, or service, even if such use
appears to be permitted in some of the applicable standards
. (OSHA)
ALERT
! Alerts the reader to an action that must be avoided in order to protect
equipment, software, data, or service
. (ISO)
ALERT
! Alerts the reader to an action that must be performed in order to prevent
equipment damage, software corruption, data loss, or service interruption
. (ISO)
FIRE SAFETY
! Informs the reader of fire safety information, reminders, precautions,
or policies,
or of the locations of fire-fighting and fire-safety equipment. (ISO)
SAFETY
! Informs the reader of general safety information, reminders, precautions, or
policies not related to a particular source of hazard or to fire safety
. (ISO, ANSI, OSHA)

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
vi
Important Safety Instructions
Safety Admonishments Definitions
Definitions of the safety admonishments used in this document are listed under “Admonishments Used in this Document” on page v.
You Must Follow Approved Safety Procedures
DANGER! Performing the following procedures may expose you to hazards. These procedures should be performed by
qualified technicians familiar with the hazards associated with this type of equipment. These hazards may include shock,
energy, and/or burns. To avoid these hazards:
a) The tasks should be performed in the order indicated.
b) Remove watches, rings, and other metal objects.
c) Prior to contacting any uninsulated surface or termination, use a voltmeter to verify that no voltage or the expected
voltage is present. Check for voltage with both AC and DC voltmeters prior to making contact.
d) Wear eye protection.
e) Use certified and well maintained insulated tools. Use double insulated tools appropriately rated for the work to be
performed.
DC Input/Output Voltages
DANGER! This system has a DC source connected to it and provides DC distribution. Although the DC voltage is not
hazardously high, the DC source can deliver large amounts of current. Exercise extreme caution not to inadvertently contact
or have any tool inadvertently contact an input or output terminal or exposed wire connected to an input or output terminal.
NEVER allow a metal object, such as a tool, to contact more than one termination at a time, or to simultaneously contact a
termination and a grounded object. Even a momentary short circuit can cause sparking, explosion, and injury.
DANGER! Follow local lockout/tagout procedures to ensure DC branch circuit protection devices remain de-energized
during installation at loads, as required.
Buried Utilities
CAUTION! When installing the enclosure, ensure the site is free of any buried utilities. Call 811 before installation. Severe
damage, serious injury, or death can occur if buried utilities are not identified prior to installation.
Personal Protective Equipment (PPE)
DANGER! ARC FLASH AND SHOCK HAZARD.
Appropriate PPE and tools required when working on this equipment. An appropriate flash protection boundary analysis
should be done to determine the “hazard/risk” category, and to select proper PPE.
Only authorized and properly trained personnel should be allowed to install, inspect, operate, or maintain the equipment.
Do not work on LIVE parts. If required to work or operate live parts, obtain appropriate Energized Work Permits as required
by the local authority, per NFPA 70E “Standard for Electrical Safety in the Workplace”.

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
vii
General Safety Precautions
The following precautions shall be observed at all time when handling and installing the enclosure:
•Observe all safety precautions against personal injury and equipment damage.
•The procedures outlined in this manual are only recommended guidelines. Ensure that all NEC (National Electric Code) and
local codes for safety and wiring are followed.
-Use listed two-hole compression connectors (lugs) to terminate all ground connections. Selected lug shall match wire
and type, and crimped applied as specified by the lug manufacturer.
-Apply NO-OX-ID-A to all ground connections.
-Insulation of field-wire conductors should be rated no less than 90 °C and sized in a manner that is consistent with the
NEC and local codes.
•Always use an approved voltage detector, when approaching an enclosure, to verify no leaks or shorts are presents on the
external body.
•Read “Specific Safety Precautions” starting on page viii in its entirety prior to attempting to handle or secure the enclosure.
•A minimum of two persons are required to safely install the enclosure.
•Hard hats and steel-toed boots should be worn while maneuvering the enclosure.
•Safety glasses should always be on while on-site.
•Safety gloves should be on when working in temperature extremes, with batteries, or with sharp objects.
•All electricians, operators, and technicians have been trained for the task at hand.
•Keep bystanders away.
•Ensure that all personnel on site are familiar with the first-aid kit location and emergency procedures in the event of an injury.

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
viii
Specific Safety Precautions
DANGER! ELECTRICAL HAZARD
The equipment shall be installed and serviced by trained service personnel in accordance with the applicable requirements of
the current edition of the American National Standards Institute (ANSI) approved National Fire Protection Association's
(NFPA) National Electrical Code (NEC) (NFPA 70) or Canadian Electrical Code; and the applicable sections of the National
Electrical Safety Code (NESC) (ANSI C2). For operation in countries where the NEC or NESC is not recognized, follow
applicable codes.
All electrical procedures should be performed by a licensed electrician.
Observe all safety precautions as specified by local building codes. If local building codes specify procedures different from
those in this section, follow local codes.
DANGER! RISK OF ELECTRICAL SHOCK, GENERAL
All enclosure grounding must be installed and verified prior to connecting any power cables and turning-up of enclosure.
When connecting any discrete power connection, make the connection first with the ground/return and break last with
ground/return.
Do not install equipment showing any physical damage.
If packaging is damaged, do not accept receipt from the shipper.
DANGER! RISK OF ELECTRICAL SHOCK, AC
Proper actions, include, but not limited to:
a) Verify before contacting the enclosure that no current leakage or ground fault condition is present.
b) Verify a proper ground is in place.
DANGER! RISK OF ELECTRICAL SHOCK, DC
An OFF battery switch / breaker does not isolate the batteries, nor do the batteries have a protective fuse. Thus, handle
accordingly and use only insulated tools when working around batteries or any DC potential.
In addition, be sure that all connection points have been de-energized.
DANGER! RISK OF ELECTRICAL SHOCK, OSP CABLES
If joint buried cables are used, check the cable sheath for voltage in accordance with local standards. If voltage is detected,
do not proceed with the installation. Contact the supervisor and do not proceed until the voltage hazard is eliminated.
DANGER! RISK OF ELECTRIC SHOCK
The DC bus may be powered by DUAL power sources – rectifiers and DC batteries.
To properly work on the system, de-energize by disconnecting BOTH power sources. Even with the batteries turned off by
using a local battery (circuit breaker) disconnect, batteries are still “LIVE” and hazardous, including a voltage >50 VDC, and a
source of high short circuit current.
Use extreme caution around the batteries and terminals.
WARNING! RISK OF INJURY TO EYES AND SKIN, FROM OPTIC DEVICES
Do not look into a fiber cable or device, nor hold such cable or device against body, fabric or other material.

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
ix
WARNING! RISK OF HAZARDOUS SUBSTANCES
After handling of the enclosure or any such component, such as batteries, cables, busbars, etc., always wash hands
immediately after.
DANGER! RISK OF CHEMICAL EXPOSURE
A battery can present harmful chemicals. Refer to the battery installation manuals and MSDS supplied with the batteries.
Work in a ventilated area and follow all safety procedures.
At a minimum, wear safety glasses and gloves when working with batteries.
Do not smoke.
CAUTION! PREVENT EQUIPMENT DAMAGE, OPERATING TEMPERATURE
The enclosure is approved for operation in an environment with an expected temperature range of -40 °Fto +115 °F (–40 °C
to +46 °C) and 0% to 95% relative humidity range, non-condensing. Do not use at temperatures or humidity exceeding these
ranges.

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
x
This page intentionally left blank.

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
1
1About this Document
This document provides description and installation instructions for Vertiv™ NetSure™ External Distribution Box (EDB); Spec. Nos.
F1011259, F1011265, and F1011266.
Procedures related to the provisioning, start-up, and acceptance of associated telecom equipment are not covered in this document.
Documents that supplement the information in this document are referenced in “Sequence of Procedures” on page 10.
2Product Description
2.1 General
The Vertiv™ NetSure™ External Distribution Box (EDB) provides an enclosure housing two (2) DC distribution panels and alarm cards,
a fiber termination and storage chamber, and a cable entry chamber. Spec. No. F1011259 contains no Low Voltage Disconnect (LVD).
Spec. No. F1011265 contains a Low Voltage Disconnect (LVD) contactor on the left side DC distribution panel’s DC input. Spec. No.
F1011266 contains Low Voltage Disconnect (LVD) contactors on the left side and right side DC distribution panels’ DC input. See
Figure 2.1 for overall views of the enclosure.
The Vertiv™ NetSure™ External Distribution Box (EDB) is to be mounted on the side of a companion enclosure made of a minimum of
0.125-inch aluminum or 14-gauge galvanized steel.A companion enclosure is a Vertiv™ XTE series enclosure equipped with a Vertiv™
NetSure™ series power system.
2.2 Part Numbers
2.2.1 Enclosure
Refer to Table 2.1 for applicable product part numbers.
Table 2.1 Vertiv™ NetSure™ External Distribution Box (EDB) Part Numbers and Descriptions
Part Number Description
F1011259 External Distribution Box (EDB) Providing DC Distribution and Fiber
Termination, No LVD.
F1011265 External Distribution Box (EDB) Providing DC Distribution and Fiber
Termination, One (1) LVD.
F1011266 External Distribution Box (EDB) Providing DC Distribution and Fiber
Termination, Two (2) LVDs.
F1011267 LVD Contactors Kit (Field Installed)

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
2
Figure 2.1 Vertiv™ NetSure™ External Distribution Box (EDB) Overall Views
Front Front
Rear Rear

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
3
2.2.2 Circuit breakers
Refer to Table 2.2 for the part numbers of compatible circuit breakers to be used in the enclosure’s distribution panels. Each
distribution panel holds up to twenty-six (26) single-pole bullet nose-type load distribution circuit breakers.
Circuit Breaker Derating: 1A to 60A circuit breakers shall be loaded up to 80% of rated value.
Table 2.2 Circuit Breaker Part Numbers
Ampere
Rating
Number
of Poles
Number of
Mounting
Positions
Required
Part Number
Electrical Trip1
(White Handle)
Electrical /
Mechanical Trip2
(Black Handle)
1 1 1 102272 101596
3 1 1 102273 101597
5 1 1 102274 101598
10 1 1 102275 101599
15 1 1 102276 101600
20 1 1 102277 101601
25 1 1 102278 101602
30 1 1 102279 101603
35 1 1 102280 101604
40 1 1 102281 101605
45 1 1 121998 121997
50 1 1 102282 101606
60 1 1 102283 101607
Circuit Breaker Alarm Operation:
1Provides an alarm during an electrical trip condition only.
2 Provides an alarm during an electrical or manual trip condition.
2.3 Application
The Vertiv™ NetSure™ External Distribution Box (EDB)...
•provides a stable, secure, and water-tight environment for DC distribution and fiber management supporting both wireline
and wireless telecommunications applications.
•depends upon a proven structural system, integrated mechanical components, and a sealing system that withstands rain,
dust, and snow.
•can be mounted to the side of a companion enclosure.
2.4 Specifications
2.4.1 Electrical
•Input / Output Voltage: -48 VDC / -58 VDC, ±0%
•Maximum Input Current: 480 A.
•Input / Output Bus A Maximum Current:240 A.
•Input / Output Bus B Maximum Current:240 A.

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
4
•Short Circuit Current: 10000 ADC.
•Maximum Load Distribution Circuit Breaker Size: 60 A.
•Circuit Breaker Alarm (CBA) Circuit: A set of Form-C alarm relay contacts and resistive battery are provided for connection
to external CBA alarms. Relay contacts rated for 2 A @ 30 VDC, 0.6 A @ 110 VDC, and 0.6A @ 125 VAC.
2.4.2 Environmental
•Operating Ambient Temperature Range: -40 °Fto +115 °F (–40 °Cto +46 °C).
•Storage Ambient Temperature Range: –40 °F to +185 °F (–40 °C to +85°C).
•Relative Humidity: Capable of operating in an ambient relative humidity range of 0 % to 95 %, non-condensing.
•Altitude: Capable of operating in an altitude range of 0 feet to 10,000 feet.
2.4.3 Compliance information
The Vertiv™ NetSure™ External Distribution Box (EDB) complies with the following standards:
•UL Listed to UL 62368-1 (2nd Edition), UL Subject 1801, and CAN/CSA C22.2 No. 62368-1-14 (2nd Edition) under Vertiv file
no. E97066 (QPQY/QPQY7 categories).
•UL-50E Rain Test.
2.4.4 Safety listed AC and DC components
A typical Vertiv™ NetSure™ External Distribution Box (EDB) includes listed or recognized components for the United States.
2.4.5 Enclosure dimensions, weights, and physical specifications
Dimensions
•See Figure 2.2 for overall dimensions.
•See Figure 2.3 for mounting hole dimensions.
Physical Specifications and Weight
•Height: 60.82 inches.
•Width: 40.00 inches.
•Depth: 9.12 inches.
•Weight: 135 lbs.
•Color: Cool White.
2.5 Local DC Power Source
DC power to be provided by customer via an upstream power source, typically from an adjacent enclosure.

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
5
Figure 2.2 Enclosure Dimensions
(2) 3/4-inch trade-size knockouts
(1.125-inch actual diameter).
(4) 2-inch trade-size knockouts
(2.5-inch actual diameter).
(10) 2.50-inch cable grommets.
(8) 1.77-inch cable grommets.
Notes:
1. All dimensions are in inches.
Top
Right SideLeft Side
Bottom
Front
40.00
60.82
9.12

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
6
Figure 2.3 Enclosure Mounting Dimensions
2.6 Enclosure Features and Options
Perspective Views: Refer to Figure 2.4 for enclosure perspective views with major features identified.
Mounting Options: The enclosure is designed to be mounted to the side of a companion enclosure.
Exterior Finish:The enclosure is finished in multistage dry powder polyester paint (cool white) for maximum durability and
performance against corrosion.
Sealed DC Distribution Chamber / Sealed Fiber Termination and Storage Chamber / Cable Entry Chamber:The enclosure
provides three chambers. A sealed DC distribution chamber, a sealed fiber termination and storage chamber, and a cable entry
chamber.
Notes:
1. All dimensions are in inches.
Front
40.00
6.00 6.00 6.00 6.00 6.00 6.00
2.00
59.82
60.82
1 x 0.438 (14-places)

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
7
Front Doors: The enclosure has two (2) front environmentally sealed doors that provide access to the DC distribution chamber, fiber
termination and storage chamber, and cable entry chamber.
•The front doors securing mechanism is a swing handle with multi-point rod-latch mechanism.
•The swing handle locking mechanism is equipped with a padlock hasp that supports a lock.
•The front doors require a hex/pin security tool (T-handle tool) to open.
•The front doors have a self-locking wind latch that secures the door open during installation or maintenance activities. Door
wind latch secures at 90° and 120°.
•The front doors have EPDM rubber environmental seals.
DC Distribution Chamber:The DC distribution chamber is equipped with…
•DC Distribution Panels: Two (2) 26-position DC distribution panels are provided inside the enclosure.
•Alarm Cards:Two (2) alarm cards are provided to connect circuit breaker alarms into the alarm circuits of the companion
enclosure.The alarm cards are factory wired to the enclosure’s alarm blocks.
•Alarm Blocks:Two (2) alarm blocks are provided for connecting alarm circuits and LVD control wiring to the enclosure.
•Main Ground Bar:A five (5) position main ground bar is located inside of the enclosure.
-The main ground bar is mounted on isolators.
-The default ground lug geometry is two hole with 1/4 inch post and 5/8 inch spacing.
•Low Voltage Disconnect (LVD):
-Spec. No. F1011259 contains no Low Voltage Disconnect (LVD).
-Spec. No. F1011265 contains a Low Voltage Disconnect (LVD) contactor on the left side DC distribution panel’s DC input.
-Spec. No. F1011266 contains Low Voltage Disconnect (LVD) contactors on the left side and right side DC distribution
panels’ DC input.
Fiber Termination and Storage Chamber:The fiber termination and storage chamber is equipped with…
•Fiber Termination:Forty-Eight (48) LC Duplex fiber connectors are provided.
•Fiber Storage:Two (2) fiber storage spools are provided.
Cable Entry Chamber:The cable entry chamber is equipped with…
•Tower Cable Ground Bars:Two (2) tower cable ground bars are provided.
•Cable Tie Bar:A cable tie bar is provided.
Grounding: Two 1/4-20 studs on 5/8” centers are located on the outside side panel of the enclosure for connecting the enclosure
into the site grounding network.
Cable Entry/Exit:Cable entry/exit is made into a dedicated chamber (splash zone) at the bottom of the enclosure. Ten (10) 2.50-
inch cable grommets and eight (8) 1.77-inch cable grommets are provided on the bottom of the enclosure for cable entry.There are
four (4) 2-inch trade size knockouts provided for power cable entry and fiber exit, along with two (2) 3/4-inch trade size knockouts for
alarm wiring. See Figure 2.2.

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
8
Figure 2.4 Perspective Views with Major Features Identified (cont’d on next page)
Drain Holes
Cable Entry Grommets
Cable Entry Grommets
Front Door Front Door Cable Entry (Splash Zone)
Fiber Termination
Fiber Storage
DC Distribution

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
9
Figure 2.4 Perspective Views with Major Features Identified (cont’d from previous page)
Spec. No. F1011265 contains a
Low Voltage Disconnect (LVD)
contactor on the left side DC
distribution panel’s DC input.
Spec. No. F1011266 contains
Low Voltage Disconnect (LVD)
contactors on the left side and
right side DC distribution
panels’ DC input.
Spec. No. F1011259 contains no
Low Voltage Disconnect (LVD).
Enclosure
Grounding
Terminals
Tower Cable
Ground Bars
Cable Tie Bar
Fiber Termination
Fiber Storage
Lances
Alarm Block (X2) 26-Position DC Distribution Panel (X2)
Distribution Return Bar (X2)
-48 VDC / -58 VDC Input Bar (X2)
LVD Contactor or Bypass Busbar
Input Return Bar (X2)
Ground Bar
Lances Front
Front

Vertiv™ NetSure™ External Distribution Box (EDB) Description and Installation Manual
Proprietary and Confidential © 2022 Vertiv Group Corp.
10
3Sequence of Procedures
3.1 General
Perform the procedures in Table 3.1 (in the order listed) to fully install the enclosure.
Other documents and manufacturer’s documents may be required to complete the installation of the system. This includes, but is not
limited to:
•OSP cable fishing, sealing, grounding, splicing, and termination.
•Equipment manufacturer’s drawings and documentation.
•Refer also to…
-SD-1011259-01 (enclosure schematic drawings).
-SD-1011265-01 (enclosure schematic drawings).
-SD-1011266-01 (enclosure schematic drawings).
Table 3.1 Sequence of Procedures
Section in this Document Starting on Page Description
Product Description 1 Provides information that will help the project engineer determine
an appropriate use and location for the enclosure.
Front Doors and Locks 11 Describes how to access the inside of the enclosure.
Installation Considerations 14 Provides installation overview and recommended tools and test
equipment.
Transportation and Storage 15 Describes the transportation and storage requirements.
Mounting the Enclosure 15 Describes the safe handling of the enclosure and the procedures to
install the enclosure.
Installing Bullet Nose Type
Circuit Breakers 16 Provides a procedure to install the circuit breakers into the enclosure.
Grounding the Enclosure 18 Describes the grounding requirements for the enclosure.
Cable Routing 20 Provides cable routing information.
Making Electrical Connections 21
Provides the following wiring information.
RRH (Remote Radio Head) Cables
Alarm and LVD (Low Voltage Disconnect) Cables
Fiber Cables
DC Input Power Cables
Sealing Enclosure Cable Entries 33 Provides methods for sealing the cable entries.
Initial Power Up 34 Describes the power up sequence for the enclosure.
Maintenance and Replacement
Procedures 34 Provides maintenance and replacement information.
