Verykool I123 User manual

verykool
I123
UserGuide
Document Name I123
Document No. UM-GW-AL-128(E) Department for
Editing
Technology
Management
Department
Version V1.0 Prepared By Xi Wang
Security Class Confidential Effective Date 2012-04-13
verykool USA INC.

I
Proprietary & Confidential -0-
Revision History
Date Editor Revision Items Version Verified by Approved by
2012-04-13 Xi Wang Initial version 1.0

I
Proprietary & Confidential -I-
Any Changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
This device complies with part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.

I
Proprietary & Confidential -II-
Table of Contents
1PHONE APPEARANCE AND KEYS................................................................................................................. 1
1.1 Physical Impression................................................................................................................................................. 1
1.2 Keys specification .................................................................................................................................................... 1
1.3 Icons.......................................................................................................................................................................... 2
2USER GUIDE ................................................................................................................................................... 2
2.1 Installing the battery............................................................................................................................................... 2
2.2 Charging the battery............................................................................................................................................... 2
2.3 Inserting the SIM card............................................................................................................................................ 2
2.4 Installing T-Flash card............................................................................................................................................. 3
2.5 Power On or Off....................................................................................................................................................... 3
3CALL FUNCTIONS........................................................................................................................................... 3
3.1 Making a Call............................................................................................................................................................ 3
3.2 Answering a Call ...................................................................................................................................................... 3
4PHONEBOOK................................................................................................................................................... 3
4.1 Add new contact...................................................................................................................................................... 4
4.2 Searching for a contact........................................................................................................................................... 4
5MESSAGES....................................................................................................................................................... 4
5.1 Write message.......................................................................................................................................................... 4
6CALL LOGS ...................................................................................................................................................... 4
7FILE MANAGER............................................................................................................................................... 4
8MULTIMEDIA.................................................................................................................................................. 4
8.1 Audio player.............................................................................................................................................................. 4
8.2 Camera...................................................................................................................................................................... 5
8.3 Video recorder.......................................................................................................................................................... 5
8.4 Video player.............................................................................................................................................................. 5
9FM RADIO........................................................................................................................................................ 5
10TEXT INPUT SETTINGS................................................................................................................................. 6
10.1 Key functions for Input Mode................................................................................................................................. 6
10.2 Multitap ABC mode.................................................................................................................................................. 6
11SAFETY AND GENERAL INFORMATION...................................................................................................... 6
11.1 Brief Introduction..................................................................................................................................................... 6
11.2 Important Safety Precautions ................................................................................................................................ 6
11.3 Phone Precautions................................................................................................................................................... 6
11.4 Battery Safety Precautions ..................................................................................................................................... 7
11.5 Disposing of Used Battery ...................................................................................................................................... 7
11.6 Charger Precautions................................................................................................................................................ 8
11.7 SAR Information......................................................................................................................错误！未定义书签。
11.8 Clean and Maintenance........................................................................................................................................... 8

I
Proprietary & Confidential -1-
1 Phone Appearance and Keys
1.1 Physical Impression
1.2 Keys specification
Keys Specification
Dial SIM1 Key Make a call by SIM1 card.
Answer an incoming call.
View SIM1 card Call Logs in standby mode.
Confirm selected items.
Dial SIM2 Key Make a call by SIM2 card.
Answer an incoming call.
View SIM2 card Call Logs in standby mode.
Right soft key Display Phonebook list in standby mode.
Return to the previous menu.
END key Power on or power off the phone (by pressing and holding it
for about 3s).
End a call, or reject an incoming call.
Return to standby mode.
Navigation keys
Indicates 【↑】【↓】【←】【→】four directions.
In standby mode, press【↑】to access Write message;
In standby mode, press【↓】to access Inbox;
In standby mode, press【←】to access Alarm;
In standby mode, press【→】to access Profiles;
Middle key In standby mode, press middle key to display Main menu.
Press middle key to confirm a selection
*Key To display “*”, “+”, “P” and “W” by pressing it a few times in
standby.
Keypad
Enter numbers, letter, and characters
Call the voice mail center in standby mode (by pressing and
holding the 1 key for about 3s)
Speed-dial phone numbers in standby mode (by pressing and
holding the 2-9keys for about 3s)
Select a submenu item labeled with the corresponding digit
number.
To activate or deactivate silent profile in standby mode (by
pressing and holding 0 key for 3 seconds).
# Key
Press Right soft key then press # key to lock/unlock keypad.
To activate or deactivate Led flashlight in standby mode (by
pressing and holding # key for 3 seconds).
※Note: In standby mode means that your phone is switched on but not being used for any

I
Proprietary & Confidential -2-
function.※
1.3 Icons
Icon Specification
Network signal strength
Straight stripe is more, the network signal is stronger.
Message
Receive new SMS message.
Keypad lock
The keypad is locked.
Earphone
The phone is inserted earphone.
Alarm
Set the alarm time and activate the function.
Incoming call alert type:
That is “Ring”.
That is “Vib. only”.
That is “Vib. And ring”.
That is “Vib. then ring”.
Battery
Straight stripe is more, the battery is more.
2 User Guide
2.1 Installing the battery
1) Place the metal contact points of the battery downward and flush
with metal contact points in the battery bay, then insert the bottom
of battery into battery bay.
2) Place the back cover of the battery onto the phone squarely, and
push upward till it clicks into place.
※Note: Do install the battery as the diagram so as prevent the battery
contact patch being damaged. ※
2.2 Charging the battery
Your phone is powered by a rechargeable battery. When the battery is
weak, the battery sensor informs you. At this time, you need charge the
battery. When the battery becomes too weak for the phone to operate, it
switches off automatically.
1) Connect the charger to a power socket.
2) Connect the charger to the charger jack on the phone.
3) Wait until the battery is completely charged. During charging, the
charging icon is displayed in animation. When the charging icon
becomes static, the battery is fully charged.
4) Disconnect the charger from the phone. Disconnect the charger from the power socket.
2.3 Inserting the SIM card

I
Proprietary & Confidential -3-
The mobile support two SIM cards on-line at one time. The method of the two SIM cards of
inserting or removing is the same.
1) Power off the phone; remove battery and other external power
connection, as shown in the image.
2) Insert SIM card into SIM card socket.
3) When you need to remove SIM card, please power off the
phone first, remove battery, then remove the card.
2.4 Installing T-Flash card
T-Flash card slot locate at the right top of the SIM card. Insert
memory card into card slot as shown in the image.
※Note: No micro SD card is delivered in the product package. The micro
SD card is sold separately. ※
2.5 Power On or Off
Make sure the battery is already inserted:
1) Power On: Hold down end key until the phone-on image display. After power on, the
phone searches for your network automatically.Some SIM card is protected by the PIN
number, if you are asker for inputting the PIN number, please enter it, then press
middle key.
2) Power Off: Hold down end key until the power-off image display.
※Note:
(a) PIN is provided by your service provider. If the PIN is entered incorrectly three times, the
SIM card is barred.
(b) If the phone asks for an unlock code when switched on, enter the unlock code and press
middle key. ※
3 Call Functions
3.1 Making a Call
When you want a call, press the phone keypad to input the area code and phone number.
Click middle key to save.
Pressing * key a few times until character “+” appears, and then you can dial an international
number. (The ‘+’ stands for international dial code.) Press dial key to dial the number. If the
number is stored with a name, it appears on the display when you dial the number.
You can also make a call through call logs, phonebook and messages.
3.2 Answering a Call
When somebody calls you, the phone rings, and displays the incoming call area. If the caller
can be identified, the caller’s phone number (or name if stored in your phonebook) is displayed.
When a call is coming, answer the call by pressing dial keys. The missed incoming calls
appear on the display. Press dial SIM1/2 key to check the details of the missed calls or press dial
key to call the number. Press end key to end the call.
4 Phonebook
This feature allows you to store phone numbers and their corresponding names in the
memory of your SIM card and phone’s memories, at the same time, provides browsing, adding,
managing functions. Your phone can store up to 300 contacts, while SIM card memory depends
on various SIM card. There is “1”or “2”icon displayed on the left side of some contacts, it
means this contact is stored in SIM1 or SIM2.

I
Proprietary & Confidential -4-
4.1 Add new contact
Add new entry and related information to phonebook.
First, press navigation key to move the cursor to “Preferred storage”, select to save to SIM1,
SIM2 or Phone.
Then, press navigation key to move the cursor to “Add new contact”, input Name and
Number.
4.2 Searching for a contact
Press corresponding alphanumeric keys to search for a number by name. Enter the first
letter of the name that you want to find. The phonebook entries are listed, starting with the first
entry matching your input. For example, you want to find the number named “zhang san”, then
press 9 key four times, the display will show the name list starting with “z”.
You can finish the following operations with the find number:
5 Messages
User can send text messages.
5.1 Write message
Each text message has limitation in length, that is 1224 English characters. If exceed the
limitation, the message will be cut to many messages for sending.
Screen icon that displays in standby mode refers to any new message just received and
unviewed. You can set the message tone to remind you of receiving any new message. No more
messages can be received when the Inbox is full. You can receive the new message after you
have deleted some old ones to release memory space.
Write new message for sending. During editing the message, press dial SIM1 key to operate:
Send: enter number or add from phonebook or call logs. You can add many numbers.
Save: save the message to draft of SIM1 or SIM2.
After editing the message, select “Send”and select the number, press middle key to
access:
Send: send the message to the selected numbers.
Edit: edit the number.
6 Call logs
In this menu, you can view all the calls, or the call you missed, dialed and received.
There is “1”or “2”icon displayed on the left side of every call logs, it means this call is
dialed or received by SIM1 or SIM2. Select the call log, press SIM1 or SIM2 to dial the number
with SIM1 or SIM2.
7 File manager
For saving more information, the phone support memory card. The card can be installed at
any time. The menu can manage the files on the phone.
8 Multimedia
8.1 Audio player
Through the menu, you can play music or ring tone file. Press dial SIM1 key to access music
list, press dial SIM1 key to operate.
During playing the music, press left or right navigation key to next music file; long press left

I
Proprietary & Confidential -5-
or right navigation key to fast forward or Rewind; press up and down navigation key to adjust
volume; press middle key to pause/play the playing file; press dial SIM2 key to stop playing.
8.2 Camera
With the phone camera feature, you can take picture at any time without carrying digital
camera. Enter the menu, the display shows the preview image.
Keys Functions
Dial SIM1 key To open Options menu
Right Soft Key (RSK) Back to main menu
OK key To take a picture
8.3 Video recorder
Through the menu, you can record video by yourself. Press middle key to start recording.
During scanning, press dial SIM1 key to operate.
Press middle key to start recording. During recording, press right soft key to stop, select
whether to save. The file is saved as *.avi file.
8.4 Video player
The menu supports play video file. When the file list is null, select the storage path first, and
then select the video folder. There will update the video file list, select one file from the list, press
dial SIM1 key to play. Press end key to exit and return list. The phone supports the AVI, 3GP and
MP4 video files.
9 FM radio
Before starting FM radio, insert the earphone into left side of the phone. The earphone line
equates in FM radio antenna. Open the FM radio, the phone will show the channel frequency.
Press left/right navigation keys to change the channel frequency. Press dial SIM1 key to operate:
Power on/off, Tune, Channel list, Volume, Preset auto search, Loudspeaker, Record, Append,
File list.
10 Bluetooth
The phone support Bluetooth communication mode. In idle mode, press middle key, select
“Menu-Bluetooth”.
Turn on/off: set the function on or off.
Visibility: Select On or Off. If disable the feature, the phone will not be used as a BT
device.
My device: show my BT device list. If the list is null, press OK key to search the new
device. Select one device, press left soft key to pair, if the device has passcode, input
the passcode and press OK.
Search audio device: Before search Bluetooth device, power on Bluetooth function.
After searching new device, connect the new device in pairs according to the display
information. When successfully connected, the devices can communicate.
My name: edit the device name.
Advanced: set Bluetooth parameter。
¾Storage: select storage location of transfer file from Bluetooth.
¾My address: show the device address.

I
Proprietary & Confidential -6-
11 Text input settings
11.1 Key functions for Input Mode
1) Digital key 1~9: show different character with different input mode.
2) Navigation key: move cursor.
3) 1 key: in ABC, abc Mode, input “.,-?!’@:#$/_1” in turn.
4) 0 key: in Input Mode, press to enter space. In Number Mode, press to enter 0; In
ABC/abc Mode, press one time to enter space, press 2 times continuous to 0.
5) * key: open punctuation mark list.
6) # key: change input mode.
11.2 Multitap ABC mode
When typing in Multitap ABC or abc mode, press the key which corresponds to the desired
letter several times until the letter you want appears.
Example: input “how”, in Multitap abc mode, you press numeric key 4 two times to show “h”;
press numeric key 6 three times to show “o”; press numeric key 9 once to show “w”.
ABC means to enter uppercase letters; abc means to enter lowercase letters.
12 Safety and General Information
12.1 Brief Introduction
This part will be edited by the client.
12.2 Important Safety Precautions
Read these guidelines before using your wireless phone. Failure to comply with them may
be dangerous or illegal.
12.3 Phone Precautions
1) Switch off your phone in aircraft, hospital and any facility where posted notices instruct you
to do so. Wireless phone can cause interference to electronic instruments and medical
equipment, when using your phone in such kind of area, meet any special regulations in
force. Your phone features automatically power on function, check your power settings and
make sure your mobile phone will not automatically switch on when on board an aircraft.
Turn off your phone whenever on board an air craft, so as not to interfere with electronic
system and result in aircraft accidents.
2) To avoid electromagnetic interference and/or compatibility conflicts, turn off your mobile
phone in any facility where posted notices instruct you to do so. Hospitals or health care
facilities may be using equipment that is sensitive to external RF energy. Especially when
near the below devices: hearing aid, pacemaker and other medical devices, fire detector,
automatic door and other automatic control devices. In the event of mobile phone interfering
with pacemaker and other medical electronic devices, consult the manufacturer of the device
or local salesman. Mobile phone may interfere with appliances like television, radio, or PC
3) Do not hit the LCD display with extreme force or use it to hit other things. Doing so may
break the glass and cause the LCD liquid to leak. If the liquid enters into eyes, it may blind
you. In such case, rinse with a large quantity of water immediately (do not rub your eyes)
and consult a doctor.
4) Do not disassemble or remodel your phone. Doing this may damage your phone or result in
the leakage of electricity and circuit fault.
5) In a very few cases, the use of mobile phone may interfere with the electronic equipments in
some cars. In such case, for safety, do not use mobile phone.
