ANNULAR CUTTER
USER MANUAL
MODEL: 10190010215/10190010216/10190010146
10190010213/10190010214
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.

- 1 -
MODEL: 10190010215/10190010216/10190010146
10190010213/10190010214
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
ANNULAR CUTTER

- 2 -
SAFETY INSTRUCTION AND PRECAUTIONS
WARNING:
Read this material before using this product. Failure to do so can result in
serious injury.
Safety Caution
For your safety please wear goggles and helmet. Do not wear loose
clothes or yarn gloves.
1. Please use hook to remove the chip to prevent injuries of hand.
2. Before using, make sure the cutter is sound and securely. Do not use the
cutter with damage.
3. Turn off the machine immediately if the cutter gets stuck.
4. Turn off the power before replace and disassemble cutter.
5. Do not touch the cutter when it is working.
6. Cutter’s tip is hard but also fragile. Please protect the cutter to prevent it
tipping.
[The usage of annular cutter]
Annular cutter（Core drill）.It can cutting all kinds of steel, steel pipe, cast
iron, stainless steel, aluminum, copper and various non-metallic materials.
[The type]
Shank
Suitable types of magnetic drill
Weldon shank
Applicable to all kinds of Magnetic core drill machine. Like: CHTOOLS、
ALFRA、RUKO、HOUGEN、Rotabroach、BDS etc.
Universal
shank
(Nitto shank)
Applicable to all kinds of Magnetic core drill machine, unless Fein
machine .Like：CHTOOLS、ALFRA、RUKO、HOUGEN、Rotabroach、
BDS etc.
Fein shank
Applicable to Fein machine from Germany

- 3 -
[Method of application]
1．Installation method：
• Weldon shank （1）：The handle of two planes aim at the two screw holes
on the drill spindle，With a hex wrench to tighten and leaving a gap of
0.2-0.3mm, Back and forth with your hand to confirm socket head screw
perpendicular to the two planes, then screw down the screws.
• Universal shank（2）: The handle of two planes aim at steel ball within the
drill chuck, then loaded into chuck.
Universal shank can also be used socket head screws，As long as socket
head screw perpendicular to the two planes.
• Fein shank（3）: Turn on insurance ring of the main shaft clockwise to the
right way, let the handle end insert into directly, rotate in small range until
steel ball enter into the hole.

- 4 -
2. Recommended cutting speed for high speed steel annular cutter:
Dia
Material
12-18
19-25
26-32
33-39
40-46
47-53
54-60
61-65
carbon steel
447-318
301-229
220-179
173-146
143-124
121-108
106-95
93-88
alloy steel
371-247
234-178
171-139
135-114
111-96
94-84
82-74
73-68
stainless steel
345-230
217-165
159-129
125-106
103-90
88-78
76-69
67-63
Aluminum
1857-1238
1173-891
857-696
675-571
557-484
474-420
412-371
365-342
cast iron
796-530
502-382
367-298
289-244
238-207
203-180
176-159
156-146
cast copper
1194-796
754-573
551-447
434-367
358-311
304-270
265-238
234-220
3. Feed speed: The recommended feed speed is 0.08-0.12mm/R or
0.6-1.0mm/sec.Different feed speed will cause different chip and affect the
performance of removal of chips.
4. Positioning: Chisel a positioning point in the center of the position to be
drilled or mark a "cross" line with an alloy needle to ensure the accuracy of
the drilled position. Note that when using the center chisel to hit the
positioning point, please make sure that the center chisel is perpendicular
to the surface of the workpiece to avoid affecting the smooth discharge of
the cutting core
5. Start to drill: Make sure the button of magnetic drill machine is clean
before power on. Turn on the switch of coolant liquid when start to drill.
First feed slowly and feed in the normal speed after drill 1-2mm.
6. Finish drill: Turn off the power and use hook to remove the chips on the
cutter after it stops.
[Notice]
The following actions will help to reduce or slow wearing and fracturing of
cutter.
1. When drilling steel parts, please make sure enough amount of cooling
and use metal cutting fluid.
2. Good rigidity of drill pipe and the guide rail gap can improve the
precision of drilling and the life of the bit.
3. Please make sure flat and clean between the magnetic holder and
artifacts.
4. Before cutting, make sure all parts to be locked surely.

- 5 -
5. Drillling in the start and at the end, the drilling feed should reduce 1/3.
6. For a large amount of fine powder material which occurs in the drilling,
such as cast iron, cast copper, etc., can use compressed air instead of
coolant liquid to help chip removal.
7. Please remove the chips on the cutter, to ensure smooth chip removal.
[The solutions of common problem]
The solutions of chip core stuck:
Use nonmetallic material lightly slaping drill, or lightly pressure core
material repeatedly,in order to make it loose to pop up, also can remove
the bit, tap the thimble, so that it is out.
The wearing of tools:
Under the normal cooling, when chip appear blue-black color, it need to
check the drill bit blade, when the most big wear width is 0.5 mm, it needs
grinding.
Items
Description
1
Name
Annular Cutter
2
Model
10190010215
3
Parameter
Shank：Weldon shank
D.O.C：2"
Cutter Dia.：1"、1-1/8"、1-1/4"、1-1/2"、1-3/4"、2"
Items
Description
1
Name
Annular Cutter
2
Model
10190010216
3
Parameter
Shank：Universal shank
D.O.C：2"
Cutter Dia.：1"、1-1/8"、1-1/4"、1-1/2"、1-3/4"、2"

- 6 -
Items
Description
1
Name
Annular Cutter
2
Model
10190010146
3
Parameter
Shank：Weldon shank
D.O.C：1"
Cutter Dia.：1/2"、9/16"、11/16"、13/16"、15/16"、1-1/16"
Items
Description
1
Name
Annular Cutter
2
Model
10190010213
3
Parameter
Shank：Weldon shank
D.O.C：1"
Cutter Dia.：7/16"、1/2"、9/16"、11/16"、5/8"、3/4"、13/16"、7/8"、
15/16"、1"、1-1/16"
Items
Description
1
Name
Annular Cutter
2
Model
10190010214
3
Parameter
Shank：Weldon shank
D.O.C：2"
Cutter Dia.：7/16"、1/2"、9/16"、11/16"、5/8"、3/4"、13/16"、7/8"、
15/16"、1"、1-1/16"
