VEVOR 2125B User manual

STAIR CLIMBING CART
2125B
USR MANUAL
We continue to be committed to provide you tools with
competitive price.
"Save Half", "Half Price" or any other similar expressions
used by us only represents an estimate of savings you
might benefit from buying certain tools with us compared to
the major top brands and doses not necessarily mean to
cover all categories of tools offered by us. You are kindly
reminded to verify carefully when you are placing an order
with us if you are actually saving half in comparison with the
top major brands.

- 1 -
Have product questions? Need technical support? Please feel free to
contact us:
[e-mail]
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appear- ance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
STAIR CLIMBING
CART

This is the original instruction, please read all manual instructions carefully
before operating. VEVOR reserves clear interpretation of our user manual.
The appearance of the product shall be subject to the product you
received. Please forgive us that we won't inform you again if there is any
technology or software updates on our product.
SAFETY INSTRUCTIONS
WARNING:
1. Please do not put it near flammable materials.
2. It is forbidden to carry people at any condition.
3. Please pay attention to safety when going up and down stairs.
4. Overload is strictly prohibited.
5. Don't move too fast when passing potholes areas.
Model and Parameters
Model
2125B
Maximum Load(Flat Ground)
250kg
Maximum Load(Climb Stairs)
150kg
Overall Dimensions
152.8*45.8*52.3cm

Structure Diagram
1.Handle 1
2.Handle 2
3.Frame
4.Trim Strip
5.Climbing
Wheel
6.Wheel
Frame
7.Tray
1
2
3
5
4
6
7

COMPONENTS
A.Frame(x1)
B.Wheel Frame(x2)
C.Wheel Sets(x2)
D.Tray(x1)
E.Reinforcement(x2)
F.Axle(x1)
G.Handle 1(x1)
H.Handle 2(x1)
I.Trim Strip (x1)
J.Washer(x2)
K.Cotter Pin(x4)
L.Outer Hexagon
Bolt(x4)
N.Jam Nut(x8)
M.Crosshead
Bolt(x4)
O.Installation
Tools(x3)

Assembly and Use
1.Place the reinforcement(E) inside the frame(A) (below the hole), and
then insert the tray(D).
2.Place the wheel frame(B) on the outside of the frame as shown in the
figure, align it with the hole, and finally fix it with the outer hexagon bolt
(L+N).
3.Insert the axle (F) into the wheel frame, insert the cotter pin (K) inside
the wheel frame and bend it, and put the gasket (J) outside.
4.Install the wheel set (C), insert the cotter pin (K) and bend it.

Put in handle 2 (H), handle 1 (G) and trim strip (I) in turn, align them with
the holes and fix them with crosshead bolts (M+N).
Troubleshooting Instruction
Problem
Reasons
Solution
Wheel rolling is not
smooth
Insufficient
lubrication
Add oil to lubricate the
rotating parts
Velcro is not sticky
The Velcro has
sundries
Clean the hair, thread,
and other sundries on the
Velcro
Maintenance
1.Avoid prolonged exposure to the sun to avoid aging.
2.Avoid children taking the stair climbing cart to play.
Manufacturer:Jinhua Development Measuring Tools
Co.,Ltd.
ADD：Qiubin industrial park, Wucheng District, Jinhua,
Zhejiang province
MADE IN CHINA

E-mail: [e-mail]
