LIFTING FLAT TABLE
USER MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.

1
MODEL NO.: ZWE-DDJ-SS-11, ZWE-DDJ-SS-12
Have product questions? Need technical support? Please feel free to
contact us:
[e-mail]
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
Lifting Flat Table

2
WARNING:
Please read this manual carefully before using the product. Failure to
do so may result in serious injury. SAVE THIS MANUAL
ASSEMBLY PRECAUTIONS
1. Assemble only according to these instructions. Improper assembly can
create hazards.
2. Wear ANSI-approved safety goggles and heavy-duty work gloves
during assembly.
3. Keep the assembly area clean and well-lit.
4. Keep bystanders out of the area during assembly.
5. Do not assemble when tired or when under the influence of alcohol,
drugs, or medication.
6. The product capabilities apply to properly and completely assembled
products only.
7. Assemble on a flat, level, hard, and smooth surface capable of safely
supporting the Lifting Flat Table.
8. For additional information regarding the parts listed in the following
pages, please refer to the Assembly Diagram of this manual. Unwrap
and separate all parts on a clear work area.
USE PRECAUTIONS
TO PREVENT SERIOUS INJURY AND DEATH FROM TIPPING:
1. This product is not a toy. Do not allow children to play with or approach
this item.
2. Use as intended only. Do not sit or stand on the table.
3. Inspect before every use. Do not use it if parts are loose or damaged.
4. Use only on flat, level, and hard surfaces.

3
TECHNICAL SPECIFICATIONS
Model ZWE-DDJ-SS-11
ZWE-DDJ-SS-12
Adapter Rating(s) 100-240V~, 50/60Hz, 1.5A
Main Material Steel + Board
Color Brown + Black
Product
Dimensions
(LxWxH)
1200 x 600 x 1270 mm
Packing Size
(LxWxH) 1285 x 380 x 150 mm
Net Weight (kg) 29.2
Gross Weight (kg) 31.2
PACKAGE CONTENTS
A×2 B×1 C×1
D×2 E×2
替代版本
审核
工艺
比例质量
第 张
共 张
阶 段 标 记
批准
标准化
主管设计
年 月 日
签名
更改文件号
分区处数标记
设计
校核
零件代号
借(通)用件登记
旧底图总号
底 图 总 号
日 期
Q235A
折弯横梁
0.888
11
1:5
1
B
A
D
C
B
A
签 字
2 543
6
6
42 51 3
常州市泽维尔
办公设备有限公司

4
H×1 I ×1
J×3 K×4 L×1
M×1 N
×38 O×2
P×2 Q×8 R×1
S×1 T×4 U×1
X×22
V×2 W ×4
Y×22
M4*40
M6*13
ST4*12
M6*35

5
①×2②×2
③×1④×1
⑤×1⑥×1
⑦×2

6
ASSEMBLY STEPS
STEP1 Foot installation
STEP2 Motor installation

7
STEP3 Drive rod installation
STEP4 Beam installation

8
STEP5 Side wing installation
STEP6 Panel splicing（1）

9
STEP6 Panel splicing（2）

10
STEP7 Bookshelf installation

11
STEP8 Panel installation
STEP9
N

12
STEP10 Line connection
STEP11 Drawer installation

13
7
7
Insert the cloth drawer into the bookcase
!

14
Detailed introduction of key functions
Set Key
Memory Key 3
Memory Key 2
Memory Key 1
UP Key
LED Display
Down Key
Height Adjustment Controller Operation
Press the S key once, and the height value will start flashing. At this time, press the 1, 2, and 3
keys to save the current height to the corresponding position.
Set memory height
In normal state, press the number key to call up its corresponding height, and the lifting table
will automatically run to the corresponding position.
Execute memory height
After running to the lowest height position, press and hold for 7 seconds. When the LED screen
"rst" and "E-1" flash alternately, release the ↓ key, and press and hold the key again. After the
desktop runs down to the lowest mechanical zero point, go back 5mm, the LED screen displays
the lowest height value, and the reset is completed.
Reset
LED Display:
Press any key once to wake up the LED display.
Press and hold the UP key to raise the desk.
UP Key:
Press and hold the DOWN key to lower the desk.
Down Key:
Memory Key:
You must complete the Initialization Process to reset your desk before using it for
the first time.

15
Error Code
Error Code Instructions
Reason Solution
E-1
When the system does not
save the current position, the
LED screen flashes alternately
to display "E-1"
Reset by pressing the long key until the
LED screen displays the minimum height
and the alarm is released
1. Check the connection lines between all
motors and the controller to ensure that
they are firm, and then reset by long
pressing the down key until the LED screen
displays the minimum height, and remove
the alarm
1. Normal load shall be controlled below
120KG
2. When the current exceeds 4A, the
overload protection function will be
triggered
Err
Err is displayed when the
communication line sequence
between the manual control-
ler and the control box is
wrong
E-2
When the motor is locked, the
LED displays E-2
/
/
E-5
When the motor appears: the
connecting line is disconnect-
ed/loosened, the LED screen
flashes alternately to display
"E-5"
ovr
When the load exceeds the set
value, the LED screen flashes to
display ovr. At this time, it is
necessary to remove the weight
of the desktop and power on
the controller after powering
off. This alarm can be relieved
hot
When the internal tempera-
ture of the controller exceeds
60 ± 5 degrees, the LED
displays hot /
Press and hold the S key for 9 seconds, release the S key when the LED screen displays "FAC",
and operate the S key again to restore the factory settings.
Restore factory settings
Press and hold the S key for 3 seconds. When the LED screen displays "SET", learn to open the S
key. Press the number key 3 to enter the lock screen state. At this time, the LED screen flashes
and displays "OFF".
When the screen is locked, press and hold the S key for 3s, and the LED screen displays the height
value. At this time, release the S key to complete the unlocking.
Lock key

16
1. When the voltage exceeds 32V, the
controller is powered off and the LED
screen is black;
2. When the voltage drops to 32V, the
system will automatically reply and LDE
will display the real-time height
1. Uninterrupted operation means that the
operation interval is within 3s
2. This alarm can also be removed when
the control system is powered on again
It shall be ensured that the table will not
vibrate significantly, bump into obstacles
or tilt during operation
voL
When the input voltage of the
controller exceeds 34V, the
LED displays voL
hot
After the motor runs continu-
ously for 5min, the LED screen
displays hot, and it can work
normally after waiting for
10min
E-3
During the operation, when
suddenly blocked, the LED
screen flashes "E-3", stops the
action and runs 30mm in the
opposite direction, then the
LED screen displays the
real-time height

17
