CENTRIFUGAL JUICER & BLENDER
INSTRUCTION MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and doses not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
MODEL:JB-70D
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
CENTRIFUGAL JUICER
& BLENDER
- 2 -
IMPORTANT ASSURANCE
WARNING: Before operating this device, please read this instruction
manual completely and keep it handy for future reference. Always follow
basic safety precautions when using these devices. These include:
This appliance may not be used by children. Store the appliance and its cord out
of the reach of children.
The appliance may be used by persons with limited physical, sensory, or mental
abilities or persons with no experience and knowledge if they remain under
supervision or use the appliance safely per the user manual and understand the
hazards.
Children may not play with the appliance.
Never use the juicer if the filter is damaged.
Clean all parts of the appliance in contact with food in accordance with the
description in section CLEANING AND MAINTENANCE.
Switch off the appliance and unplug it before replacing accessories or coming into
contact with moving parts of the appliance.
The appliance must always be used according to the recommended operating
time. The maximum duration of continuous operation is 1 minute. After this time
the appliance must be switched off for 2 minutes. After 3 cycles, before restarting
it is recommended to stop using the appliance for 15-20 minutes until it cools
down. The method adopted shall prolong the service life.
Do not use other accessories apart from those sold with the appliance.
WARNING: There is a risk of injury if the appliance is used contrary to its
intended use. Care must be taken when handling the filter blades,
emptying the filter and cleaning.
Always unplug the appliance when left unattended before assembly/disassembly
and cleaning.
If the power supply cord is damaged, it must be replaced by the manufacturer, an
authorized service, or qualified persons to avoid any hazard.
This appliance is intended for private indoor use only.
Before using it, always ensure that the supply voltage specified on the appliance
label corresponds to the voltage in the power supply grid.
Do not use the unit if the appliance's power cord, plug, or other parts are
damaged.
- 3 -
Do not immerse the drive base in water or other liquids. Do not wash it under
running water. Clean the motor housing with a damp cloth only.
Observe the basic safety rules to avoid fire or electric shock risks when using
electrical appliances, especially if children are present.
Do not immerse the plug, the power cord or the appliance in water or other liquids
in order to avoid electric shock.
Do not hang the power cord over the edge of table or sink .
Do not use the appliance near flammable fabric (curtains, carpets); do not place it
close to heat sources: gas cookers, electric cookers.
Do not cover the appliance during operation.
Do not put any items (cutlery, tools, etc.) inside the device during its operation.
Do not leave the appliance unattended while connected to the power supply.
Do not use the appliance if it is damaged or works incorrectly.
Do not use the appliance if it falls or has clear damage signs.
Do not attempt to open the body or disassemble any parts of the appliance.
Do not place the drive base on wet surfaces.
Never immerse the drive base in any liquid and prevent the liquid from
penetrating the inside of the drive base housing.
Protect the appliance from moisture. Indoor use only.
If liquid enters the drive base housing, disconnect the appliance from the power
supply and have it repaired by a service center.
Do not hold the appliance, the power cord, or the plug with wet hands.
Do not exceed the maximum appliance operation time.
Do not combine with elements or parts of other manufacturers.
Before inserting the plug into a wall socket, assemble the appliance in
accordance with the manual.
Please cut off the power before dismantling, assembling or tuning any parts of the
product.
If repairs are required during operation, please contact our customer service
department or an authorised service centre. Never try to repair the juicer on your
own.
- 4 -
Before starting the juicer, ensure the accessories, e.g., filter and lid, are correctly
installed.
In operation, putting your hands or sharp objects into the feed port and any
objects instead of the push rod is forbidden. In case of any accidents, please
keep your eyes away from the feed port.
To avoid any personal injury or product damage, keeping your body or other
complex objects away from the filter or motor wheel when starting up the product
is required.
If the appliance stops working when in operation, it may be caused by the
motor overheat protection. In such a case, before starting the appliance again,
it is necessary to unplug it and wait for 20-30 minutes until the appliance cools
down.
To prevent any damage caused by thermal strain, it is forbidden to disinfect the
parts of the product with hot-water and microwave oven more than 80°C. Parts
contacting the food are clean, sanitary and reliable, and have passed the
necessary certificate.
The juicer body shall not be washed in water or other liquid (soft cloth available).
The product shall not be cleaned with the steel wool, abrasive cleaners or
corrosive fluids (e.g. gasoline or acetone) .
Before processing, fruits, and vegetables with kernels, hard seeds, thick skin, or
hard shells shall be removed.
This appliance is intended for home use only and may not be used for
professional purposes . Any other use is considered to be inappropriate, and
therefore, dangerous .
The manufacturer is not responsible for any damage resulting from improper use
of the appliance.
This juicer is intended for squeezing citrus fruits such as orange, grapefruit,
mandarin, lemon, and lime.
SAVE THESE INSTRUCTIONS
PARTS
Parts list
- 5 -
1.Pusher 2.Feed tube and Lid 3.Filter Basket 4.Juice Collector
5.Juice Spout 6.Pulp Container 7.Blender Stiring Stick 8.Blender
Cover 9. Blender Jug 10.Blender Cutting Blade Base 11.Milling
Container
12.Mill Cutting Blade Base 13.Mincer Stiring Stick 14.Mincer Cover
15.Mincer Container 16.Mincer Cutting Blade Base 17.Locking
Arm
18.Driving Shaft 19. Motor Unit 20.Digital Control Panel
SPECIFICATIONS
Model: JB-70D
Power Supply Voltage: 120V~ 60Hz
Power: 850 W
Rotation Speed:11000~18000PRM
Material: PP, stainless steel
- 6 -
OPERATION INSTRUCTIONS
NOTE: Before using the appliance for the first time, clean it according to the
instruction specified in Chapter CLEANING AND MAINTENENANCE.
LED Monitor Description
1.On/Off
2.Select Function (SEL)
3.Start (START)
4.Pulse(P)
How to use LED digital control function
1.Plug in and Press"
"button, speed displaying number'3".
2.Press "SEL" to select the desired speed according to different fruit or vegetable.
3.After selecting the desired speed, press" START" to start process, After
finishing food process, press"
"button to power it off.
4.For precision operation, press"P" continuously. It stops when release the press
finger.
How to Dismantle and Assemble
DISMANTLE:
1. Unplug the appliances from the power supply.
2. Release the lock arm.
3.Remove the pulp container, transparent lid, and
pusher, and pull the filter basket upwards and juice
collector separately.
ASSEMBLE:
- 7 -
1.Place juice collector on the motor unit, and insert filter basket.
2.Mount transparent lid onto the juice collector, and fasten the lock arm upwards
unit it clicks into place.
3.Place the pulp container under pulp spout and put the juice jug under the juice
spout.
4.Plug in and ready for operation.
Preparing for use
1.After unpacking the unit and before use, ensure all mechanical parts and
attachments are not damaged.
2.Wash and dry all parts of the appliances, which will come into contact with
food(figure 1). Clean the body of unit with a soft dry cloth.
3. Practice assembling and dismantling the unit a few times before making juice.
4. Wash fruit and/or vegetables and cut them into pieces that fit into the feeding
tube(figure 2).
Using Juice Extractor
The appliance will only function if all parts have been properly assembled and the
lid has been properly locked in place with the locking arm.
Place the juice collector onto motor unit and
put the filter basket in the juice collector.
Make sure the filter basket is fitted securely
onto the driving shaft.
- 8 -
Place the lid, ad lift the lock arm upwards to
lock in position on either side of the lid.
Place the pulp container into the appliance by
tilting it forward slightly.
Slide the pusher into the feeding tube by aligning
the groove in the pusher with small protrusion
towards the inside of the feeding tube.
Using Blender
Screw the jug tight into base, and put the pre-cut
fruit or vegetable in 1~2 cm size to jug.
- 9 -
Add some drinkable water or other liquid and cover
it. Then put it onto the motor shaft and fasten it.
Plug in, select speed 5, or press“P” to start mixing.
After sufficient mixing, press“ ”to power off, then
unplug, unscrew the jug counterclockwise.
CAUTION:
·Ensure the switch is off and the blender cover is on before operation. Do not run
the appliance unloaded.
·Reduce 1/3 blending capacity for sticky food or food with less moisture content
and add some more drinkable water or liquid before blending.
·Maximum blending capacity:1500ml.
·Do not operate the blender longer than 2 minutes at a time.
·Care shall be taken when handling the sharp cutting blades, emptying the bowl,
and cleaning.
·Be careful not to pour hot liquid into a glass jar as it can be ejected from the
appliance due to a sudden steaming.
- 10 -
Using Mincer
Screw the mincer container into the base
and take about 250g of meat peeled and cut
the meat into pieces of about 1cm.
Cover the prepared meat with half a spoon of
edible oil in the container.Then put the mincer onto
the motor shaft and fasten it.
Plug in, select speed 5, or press “P” to start
chopping. Use the stirring sticker to stir food or
meat while choppingg.
After sufficient chopping, press“ ” to power off,
then unplug, unscrew the container
counterclockwise.
CAUTION:
·Ensure the switch is off and the cover is put in place before the operation, do not
run the appliance unloaded.
·Stop operation immediately when it suddenly slows down due to sinew or
peeling tied to the blade. Switch off and unplug.Remove the sinew or peeling with
stirring sticker and start again.
·Maximum mincing capacity:250g.
·Do not operate the mincer longer than 60 seconds at a time.
Using Mill
- 11 -
Reverse the milling container, then put
Ingredient, then screw the container tight to base.
Put the mill onto the motor housing, plugin and select
speed 5 or press P to start grinding, support the
container with hand when grinding.
Unplug after completing grinding, unscrew
mill and remove it off motor housing.
Reverse the container and tap off the adhered
ingredients, then unscrew the container and pour the
ingredients.
CAUTION:
·Make sure switch is off before operation.
·Do not run the appliance unloaded.
·Maximum grinding capacity:50g.
·Do not operate the mill longer than60 seconds at a time.
·Grind dry food only.
Processing Foods
Capacity
Nutlet(Hulled)
20-25g
- 12 -
Cheese
20-25g
Coffee bean
20-25g
Pepper corn
10-25g
Black sesame seed
20-50g
Dry rice, dry wheat
20-50g
Soybean
20-50g
Operating Instructions
·This appliances is equipped with a safety lock system. If the transparent lid is not
correctly placed or the lock arms are unfastened. The appliance will not function.
·Before starting, ensure the appliance is switched off and the transparent lid and
locking arm are fastened properly.
·Wash fruits and vegetables thoroughly. Cut fruits into small pieces to fit into the
feed tube. Remove the stone or peel from that citrus and fruits: prunes, apricots,
cherries or oranges, lemons, melons, etc.
·Plug in, switch on the appliance, and choose the desired speed according to
different fruits and vegetables.
·Speed 1:Soft fruits:grape, tomato and melon.
·Speed 2:Celery, citrus and cucumber
·Speed 3:Apple, pear,peach.
·Speed 4:Carrot, garlic, beet.
·Speed 5:Hard fruits and vegetables: pomegranate and potato.
·Put the pre-prepared fruits and vegetables into the feed tube and press the
pusher down gently.
·NEVER USE FINGERS OR OTHER OBJECTS AS PUSHER.
·When pulp container or juice jug is full, switch it off and empty the containers
before continuing the process.
ATTENTION:
·Do not run the juice extractor continuously for longer than 2 minutes. Should
more time is required, occasionally switch it off to allow the appliance to cool
down.
- 13 -
CAUTION:
·Remove large seeds or pits from fruits like apricot, peach, plum, cherry, etc., and
peel off if the fruits with thick seedcase or seedcase are inedible.
·Unsuitable fruits and vegetables: banana, mango, papaya, and coconut or other
hard foods.
·When the process is completed, switch it off and unplug the unit.
CLEAN AND MAINTENANCE
Switch off the appliance and unplug before cleaning.
The appliance is easier to clean if you clean it immediately after use.
Do not use abrasive cleaning agents, scourers, acetone, alcohol etc. to clean the
appliance. All detachable parts are dishwasher-safe.
Clean these parts with the cleaning brush in warm water with some washing-up
liquid and rinse them under the tap.
Wipe off the motor unit with a soft dry cloth, and keep it away from water. Blade is
sharp,take special care when cleaning.
Check the filter basket regularly for signs of damage. Do not use it if the filter
basket is damaged. Never immerse the motor unit in water nor rinse it under the
tap.
After cleaning, allow all the parts to dry completely before reassembling the
appliance. The filter may be cleaned with the cleaning brush attached.
TROUBLESHOOTING
If any irregularities are found during operation of the appliance, read the table
below to identify the cause and to ind a solution to the problem .
Problem
Possible cause
Solution
The appliance does
not turn on .
1. Incorrect installation of the
central ring .
2 . Head cover installed in
wrong place.
1. Install the central ring in a
proper place.
2 . Install head cover in place .
3 . Replace the lid .
- 14 -
During the first start
of the appliance,
unpleasant smell
may
be released .
It is normal.
Please send the product to our
company’s maintenance point
nearby if the product still gives
off unpleasant smell after
repeated use.
T he product stops
while in operation.
1. Under voltage
2 . Excessive ingredients
3 . Push the rod with
excessive force
4 . Motor thermal control
protection
1. Check if under voltage
2 . Disconnect power, take out
the surplus ingredients .
3 . Push the rod gently.
4 . Restart it after stopping 20-
30 minutes .
T he juice contains
a lot of pulp .
1. Juice extraction net
damaged .
2 . Too much pomace in the
central ring .
1. Replace the net .
2 . Clean the central ring .
Abnormal vibration
or
big noise .
1. Improper installation of
juice extraction net and poor
running balance.
2 . Unstable placement of
product or come off of foot
pad .
3 . Over voltage
4 . Excessive ingredients
1. Install juice extraction net in
proper place.
2 . Place product stably or
install the foot pad in proper
place .
3 . Check if any over voltage .
4 . Disconnect power, take out
the surplus ingredients .
Small amount of
juice.
1. Much pomace in the
central ring .
2 . Press the push rod with
excessive force.
1. Clean central ring .
2 . Press the push rod with
proper force.
Filter
Filter is clogged.
Unplug the appliance and
remove any clogging pieces of
food material from
the filter.
Table of contents
Other VEVOR Juicer manuals
