VEVOR JS3401B User manual
Support and E-Warranty Certificate www.vevor.com/support
ELECTRIC CITRUS JUICER
INSTRUCTION MANUAL
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and dose not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
- 1 -
MODEL: JS3401B
Have product questions? Need technical support? Please feel free to
contact us:
Technical Support and E-Warranty Certificate
www.vevor.com/support
NEED HELP? CONTACT US!
This is the original instruction, please read all manual instructions
carefully before operating. VEVOR reserves a clear interpretation of our
user manual. The appearance of the product shall be subject to the
product you received. Please forgive us that we won't inform you again if
there are any technology or software updates on our product.
ELECTRIC CITRUS JUICER
- 2 -
IMPORTANT ASSURANCE
When using electrical appliances, basic safety precautions should always be
followed including the following:
1. Read all instructions.
2. To protect against the risk of electrical shock do not put the base in water or
other liquid.
3. This appliance is not intended for use by persons (including children) with
reduced physical, sensory, or mental capabilities or lack of experience and
knowledge unless they are closely supervised and instructed concerning the use
of the appliance by a person responsible for their safety. Close supervision is
necessary when any appliance is used by or near children. Children should be
supervised to ensure they do not play with the appliance.
4. The input voltage of this product is AC120V 60Hz and please confirm the
voltage before using.
5. Make sure to cut off the power supply before disassembling, assembling or
calibrating any part of the product.
6. This product adopts the Y connection. In case the power cord is damaged,
please contact the company's customer service department in case of any
danger or replace it at the designated repair point of the company directly, but
never disassemble and repair by yourself.
7. Please check whether the power cable, plug, and other parts are damaged
before use. In case of damage, please stop using it immediately and contact the
customer service department of the company time, but never disassemble and
repair by yourself so as to prevent possible dangers. If this product needs to be
repaired in the course of application, please get in touch with the Customer
Service Department of this company in order to avoid risks or come to the
appointed maintenance point of this company to change. Be sure not to take
apart or repair by yourself in order to avoid risks. Do not operate any appliance
with a damaged cord or plug or after the appliance malfunctions or is dropped or
damaged in any manner.
8. In the use process, in case the product needs to be repaired, please get in
touch with the customer service department of our company, or go to the repair
point designated by the company directly, but never disassemble by yourself, so
as to prevent possible dangers.
9. Before powering on, assemble the detachable parts of the juice plate and filter
mesh to their position.
10. The machine must be placed on a stable and firm working bench.
- 3 -
11. After juice making completion, do not remove the detachable parts until the
motor and the orange twisting head stops rotating and the power is cut off.
12. In case the product stops working in operation, it may result in the
temperature control protection of the motor, so please cut off the power supply
and cool for 20 to 30 minutes before using it again.
13. The spare parts of the product are forbidden to use hot water of more than
80℃and microwave oven for sterilization in case of deformation owing to heating.
The parts contacting with the food ingredients should conform to the certification
of food sanitation, and be clean, sanitary and reliable.
14. Please do not put the machine body into water or other liquids, or flush it
under the water or other liquids (it works to wipe it with a soft cloth).
15. Do not use steel wool, grinding detergent or corrosive liquids (such as
gasoline or acetone) to clean the product.
16. The product should be placed at places out of children’s reach; never let
those who are limb deformed, handicapped in sensor or mentality, or lack
relevant experience and knowledge (including children) use or play with this
product.
17. This product is only applicable for individual or family use.
18. To protect against the risk of electrical shock do not put the plug, power
supply cord and the driving body in water or other liquid.
19. Turn the appliance OFF, then unplug from the outlet when not in use, before
assembling or disassembling parts and before cleaning. To unplug, grasp the
plug and pull from the outlet. Never pull from the power cord.
20. The use of attachments not recommended or sold by the manufacturer may
cause fire, electric shock or injury.
21. Do not let the cord hang over the edge of the table or counter.
22. Avoid contacting moving parts.
23. Do not use outdoors.
24. Do not let the cord contact the hot surface, including the stove.
25. This appliance has a polarized plug (one blade is wider than the other). To
reduce the risk of electric shock, this plug will fit in a polarized outlet only one way.
If the plug does not fit fully in the outlet, reverse the plug. If it still does not fit,
contact a qualified electrician. Do not modify the plug in any way.
SAVE THESE INSTRUCTIONS
- 4 -
PARTS
S/N
Part name
Function introduction
1
Orange twisting head
Used for orange juicing
2
Lemon twisting head
Used for lemon juicing
3
Filtering mesh
Filer the juice and separate the pomace through
the mesh hole at the bottom of the filtering
mesh.
4
Juice plate
Hold and discharge the juice separated from the
filtering mesh.
5
Pressing cap
Fix and press the orange /lemon.
6
Machine body
It is the main part of the machine, including the
motor, etc. in it, the power source of the
machine, providing the power.
- 5 -
SPECIFICATIONS
OPERATION INSTRUCTIONS
This machine is applicable for processing the following fruits, such as orange,
lemon, grapefruit and other citrus fruits. Prior to the first time use of the product,
please completely clean the parts contacting with the food ingredients.
Attention: Please assemble the parts correctly before starting the product. Please
assemble and use the product as per the below steps:
Rated voltage
120V～
Rated frequency
60Hz
Rated power
150W
1
Assemble the pressing cap to the machine's body
handle well.
2
Place the juice plate on the machine body
3
Place the stainless steel filtering mesh into the juice
plate, and make sure that the stainless steel filtering
mesh is installed onto the juice plate correctly.
- 6 -
4
Assemble the lemon twisting head into the machine
body from the right above; in case of orange juicing,
then assemble the orange twisting head on the
lemon twisting juice.
5
Make the juice outlet downward.
6
Turn on the power supply, and prepare to work.
7
Wash the fruit clean, and cut each of the in halves.
8
Press the right middle of half of the orange on the
orange twisting head gently.
9
Press down the handle, and the machine starts to
work.
10
After completing all food ingredients processing, cut
off the power supply. Turn the juice outlet upward
after the motor and the orange twisting head stop
rotating completely and the no juice flows out from
the juice outlet in case of juice leakage.
- 7 -
CLEAN AND MAINTENANCE
1
Before cleaning the product, make sure to turn off the
switch and cut off the power supply.
2
Please clean the product timely after using it.
3
It works to wipe the external surface of the machine
with a wet cloth, but do not put the machine body into
water or other liquids or flush it under water or other
liquids.
4
The product should be placed at dry places free from
direct ultraviolet exposure.
5
Make sure to keep the product clean and dry before
storing it.
6
It works to clean each detachable part as per the
below steps.
1
Raise the handle, and remove the peels.
2
Take off the orange twisting head, lemon twisting
head, filtering mesh, juice plate, etc.
- 8 -
3
Remove the pressing cap, and clean it and assemble
it again.
TROUBLESHOOTING
If any irregularities are found during operation of the appliance, read the table
below to identify the cause and to find a solution to the problem.
Fault
phenomena
Cause analysis
Troubleshooting
After power on,
the product
fails to work.
1. The power cable is not
plugged well.
2. The parts are not assembled
to position.
1. Plug the power cable
again.
2. Assemble the spare
parts again as required.
Shutdown in
using.
1. Too powerful upon pressing
the handle.
2. Motor temperature control
protection.
1. Press the handle gently.
2. Use again after stopping
for 20 to 30 minutes.
Notes:
·The above are common faults analysis and troubleshooting methods. In case of
other faults, please contact the customer service department of our company or
go to the repair point designated by our company for repair directly, but never
disassemble and repair by yourself.
·The designated repair points of the company are shown on the warranty card.
