Viavi SPA06MA-O R005 User manual

SPA06MA-O User’s Guide
R005

SPA06MA-O User’s Guide
April 2021 22145360, R005 Page i
SPA06MA-O User’s Guide
Notice
Every effort was made to ensure that the information in this manual was accurate at the
time of printing. However, information is subject to change without notice, and VIAVI
reserves the right to provide an addendum to this manual with information not available
at the time that this manual was created.
Copyright/Trademarks
© Copyright 2021 Viavi Solutions Inc. All rights reserved. No part of this guide may be
reproduced or transmitted, electronically or otherwise, without written permission of the
publisher. VIAVI Solutions and the VIAVI logo are trademarks of Viavi Solutions Inc.
(“VIAVI”).
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth
SIG, Inc. and any use of such marks by Viavi is under license.
All other trademarks and registered trademarks are the property of their respective
owners.
Copyright release
Reproduction and distribution of this guide is authorized for US Government purposes
only.
Terms and conditions
Specifications, terms, and conditions are subject to change without notice. The provi-
sion of hardware, services, and/or software are subject to VIAVI’s standard terms and
conditions, available at www.viavisolutions.com/en/terms-and-conditions.

SPA06MA-O User’s Guide
Page ii 22145360, R005 April 2021
Open Source Disclaimer - IMPORTANT READ CAREFULLY
The ONA-800 includes third party software licensed under the terms of separate open
source software licenses. By using this software you agree to comply with the terms
and conditions of the applicable open source software licenses. Software originated by
VIAVI is not subject to third party licenses. Terms of the VIAVI Software License
different from applicable third party licenses are offered by VIAVI alone.

SPA06MA-O User’s Guide
April 2021 22145360, Released Page iii
Table of Contents
Table of Contents iii
About this User Guide ix
Purpose and scope . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Assumptions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Terminology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Related Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . x
Conventions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xi
Safety and compliance information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
Technical assistance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . xiii
Chapter 1 Overview 1
SPA06MA-O overview. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Exploring the module. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Module installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Chapter 2 Using Spectrum Analyzer 7
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Selecting mode and measure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Configuring spectrum measurements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Setting frequency. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Frequency and span . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Setting channel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Channel number, channel step, and channel standard . . . . . . . . . . . . . . . . . . . . . . 11
Setting amplitude . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Setting BW/AVG. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Selecting sweep. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Setting trigger . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Setting trace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Trace type. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Trace detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17

Table of Contents
SPA06MA-O User’s Guide
Page iv 22145360, Released April 2021
Trace math . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Setting limit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Using marker. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Using marker table. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Conducting spectrum measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Conducting RF measurements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Channel Power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Spectrum emission mask (SEM) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
Adjacent channel power (ACP) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Multi adjacent channel power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Spurious emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Field strength meter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Utility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Gate sweep spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Route map. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Chapter 3 Using Interference Analyzer 39
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Selecting mode and measure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Conducting spectrum measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Spectrum. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Spectrogram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Conducting interference measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
RSSI. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Interference finder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Radar chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Obtaining RSSI data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
Utility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
Spectrum Replayer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 55
PIM detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Chapter 4 Using Real-Time Spectrum Analyzer 59
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Selecting mode and measure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Conducting spectrum measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Persistent spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Persistent spectrogram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Conducting interference analysis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Persistent RSSI . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Persistent interference finder . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
Persistent radar chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Utility. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Real-time spectrum replayer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Chapter 5 Using LTE/LTE-A FDD Analyzer 83
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 84
Selecting mode and measure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85

Table of Contents
SPA06MA-O User’s Guide
April 2021 22145360, Released Page v
Conducting spectrum measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Conducting RF measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Channel power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
Occupied bandwidth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Spectrum emission mask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
ACLR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Multi-ACLR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
Spurious emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Power vs Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Power vs Time (Frame) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 94
Conducting modulation measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Constellation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Data channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Control channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
Subframe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 103
Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 106
Time alignment error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 109
Data allocation map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 111
Carrier aggregation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 112
Conducting OTA measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
OTA channel scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 114
OTA ID Scanner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 117
OTA multipath profile. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 118
OTA control channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
OTA datagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
OTA route map. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 123
Freq/Time/Power variation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 128
Miscellaneous. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 131
Power statistics CCDF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 132
Chapter 6 Using LTE/LTE-A TDD Analyzer 133
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 134
Selecting mode and measure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Conducting spectrum measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 135
Conducting RF measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Channel power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
Occupied bandwidth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 138
Spectrum emission mask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 140
ACLR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 142
Multi-ACLR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
Spurious emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
Power vs Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Power vs Time (Frame) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 146
Power vs Time (Slot). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Conducting modulation measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
Constellation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150

Table of Contents
SPA06MA-O User’s Guide
Page vi 22145360, Released April 2021
Data channel. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 153
Control channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 156
Subframe. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 159
Time alignment error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 163
Data allocation map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 164
Carrier aggregation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 166
Conducting OTA measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
OTA channel scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 168
OTA ID Scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
OTA multipath profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 172
OTA control channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 173
OTA datagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
OTA route map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Freq/Time/Power variation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 182
Miscellaneous . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 185
Power statistics CCDF . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 186
Chapter 7 Using 5G NR Signal Analyzer 187
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
Selecting mode and measure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189
Conducting spectrum measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189
Trigger spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189
Conducting RF measurements. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
Channel power . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 193
Occupied bandwidth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 197
Spectrum emission mask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 200
ACLR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 204
Multi-ACLR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 207
Spurious emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 209
Conducting OTA measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211
Beam analyzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 211
Carrier scanner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 215
Route map. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
Beam availability Index . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 227
Freq/Time/Power variation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 231
Multipath profile . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 234
Conducting modulation measurement. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237
Constellation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 237
Power vs Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 241
Power vs Time (Slot) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 241
Power vs Time (Frame). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 244
Conducting PDSCH measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 247
PDSCH constellation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 248
EVM vs subcarrier . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 254
Allocation mapper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 260

Table of Contents
SPA06MA-O User’s Guide
April 2021 22145360, Released Page vii
Chapter 8 Using NSA Signal Analyzer 267
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
Selecting mode and measure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
Conducting OTA measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
NSA analyzer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 268
NSA scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 274
Route map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 279
Chapter 9 Using 5G DSS Signal Analyzer 289
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290
Selecting mode and measure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 290
Conducting spectrum measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291
Spectrum . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 291
Conducting RF measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292
Channel power. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 292
Occupied bandwidth . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 294
Spectrum emission mask . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 295
ACLR. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 296
Multi-ACLR . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 297
Spurious emissions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 299
Conducting Power vs Time measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300
Power vs Time (Frame) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 300
Power vs Time (Slot). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 302
Conducting modulation measurements . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 304
Constellation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 304
Channel mapper . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 308
Control channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 310
Subframe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 315
Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 321
Time alignment error . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 325
Conducting OTA measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 327
OTA channel scanner . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 328
OTA ID Scanner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 331
OTA multipath profile. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 334
OTA Control Channel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 337
OTA Route Map . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 341
Freq/Time/Power Variation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 348
Chapter 10 Using RFoCIPRI Analyzer 353
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 354
Selecting mode and measure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 354
Connecting cables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 355
Selecting port . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 355
Configuring test parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 356
Setting frequency. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 356
Setting reference level . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 356
Setting scale per division . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 357

Table of Contents
SPA06MA-O User’s Guide
Page viii 22145360, Released April 2021
Setting external offset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 357
Enabling auto leveling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 358
Setting RBW . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 359
Setting average . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 360
Setting sweep mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 360
Setting trace . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 361
Selecting network technology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 362
Configuring Rx parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 362
Configuring Tx parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 365
Setting measure setup. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 366
Conducting spectrum measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 368
Conducting spectrogram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 371
Using the spectrum replayer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 371
Setting display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 372
Chapter 11 Using EMF Analyzer 375
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 376
Connecting antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 376
Selecting mode and measure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 378
Conducting spectrum measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 378
Spectrum. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 379
Conducting signal measurement . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 384
5G NR beam analysis . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 384
Appendix A Physical specifications 393

SPA06MA-O User’s Guide
April 2021 22145360, R005 Page ix
About this User Guide
This prefix explains how to use this User Guide.
•“Purpose and scope” on page x
•“Assumptions” on page x
•“Terminology” on page x
•“Related Information” on page x
•“Conventions” on page xi
•“Safety and compliance information” on page xiii
•“Technical assistance” on page xiii

About this User Guide
Purpose and scope
SPA06MA-O User’s Guide
Page x 22145360, R005 April 2021
Purpose and scope
This manual is intended to help you use the capabilities of the SPA06MA-O/SPA06MA,
and used in conjunction with the ONA-800 Getting Started Guide.
These manuals includes task-based instructions that describe how to configure, use,
and troubleshoot the test capabilities available on your instrument, assuming it is
configured and optioned to support the capabilities.
Assumptions
This manual is intended for novice, intermediate, and experienced users who want to
use their instrument effectively and efficiently. We are assuming that you have basic
computer experience and are familiar with basic telecommunication concepts, termi-
nology, and safety.
Terminology
The following items are used throughout this manual and appear on the user interface
when performing testing. Some terms are also used to label the ports (connectors) on
instrument connector panels.
• 5G — Fifth Generation
• CPRI — Common Public Radio Interface
• FDD — Frequency Division Duplex
• LTE — Long Term Evolution
• LTE Line — Termination Equipment
• RF — Radio Frequency
• RFoCPRI — Radio Frequency over Common Public Radio Interface
• RTSA — Real Time Spectrum Analyzer
• SPA06MA — Spectrum Analysis module without RFoCPRI
• SPA06MA-O — Spectrum Analysis module with RFoCPRI
• TDD — Time Division Duplex
Related Information
This is the This manual is application-oriented and contains information about using
these instruments to test service carried on each of the listed networks. It includes an
overview of testing features, instructions for using the instruments to generate and
transmit traffic over a circuit, and detailed test result descriptions. This manual also
provides contact information for VIAVI’s Technical Assistance Center (TAC).

About this User Guide
Conventions
SPA06MA-O User’s Guide
April 2021 22145360, R005 Page xi
Conventions
This manual uses conventions and symbols, as described in the following tables.
Table 1 Text formatting and other typographical conventions
Item(s) Example(s)
Buttons, keys, or switches that
you press or flip on a physical
device.
Press the On button.
– Press the Enter key.
– Flip the Power switch to the on position.
Buttons, links, menus, menu
options, tabs, or fields on a PC-
based or Web-based user inter-
face that you click, select, or
type information into.
Click Start
– Click File > Properties.
– Click the Properties tab.
– Type the name of the probe in the Probe
Name field.
Directory names, file names,
and code and output messages
that appear in a command line
interface or in some graphical
user interfaces (GUIs).
$NANGT_DATA_DIR/results (directory)
–test_products/users/
defaultUser.xml (file name)
–All results okay. (output message)
Text you must type exactly as
shown into a command line
interface, text file, or a GUI text
field.
– Restart the applications on the server using
the following command:
$BASEDIR/startup/npiu_init
restart
Type: a:\set.exe in the dialog box.
References to guides, books,
and other publications appear in
this typeface.
Refer to Newton’s Telecom Dictionary.
Command line option separa-
tors.
platform [a|b|e]
Optional arguments (text vari-
ables in code).
login [platform name]
Required arguments (text vari-
ables in code).
<password>
Table 2 Symbol conventions
This symbol indicates a note that includes important supplemental infor-
mation or tips related to the main text.
This symbol represents a general hazard. It may be associated with either a
DANGER, WARNING, CAUTION, or ALERT message. See Table 3 for
more information.
This symbol represents an alert. It indicates that there is an action that must
be performed in order to protect equipment and data or to avoid software
damage and service interruption.

About this User Guide
Conventions
SPA06MA-O User’s Guide
Page xii 22145360, R005 April 2021
This symbol represents hazardous voltages. It may be associated with
either a DANGER, WARNING, CAUTION, or ALERT message. See Table 3
for more information.
This symbol represents a risk of explosion. It may be associated with either
a DANGER, WARNING, CAUTION or ALERT message. See Table 3 for
more information.
This symbol represents a risk of a hot surface. It may be associated with
either a DANGER, WARNING, CAUTION, or ALERT message. See Table 3
for more information.
This symbol represents a risk associated with fiber optic lasers. It may be
associated with either a DANGER, WARNING, CAUTION or ALERT mes-
sage. See Table 3 for more information.
This symbol, located on the equipment, battery, or the packaging indicates
that the equipment or battery must not be disposed of in a land-fill site or
as municipal waste, and should be disposed of according to your national
regulations.
Table 3 Safety definitions
Term Definition
DANGER Indicates a potentially hazardous situation that, if not avoided, will
result in death or serious injury. It may be associated with either a
general hazard, high voltage, or other symbol. See Table 2 for
more information.
WARNING Indicates a potentially hazardous situation that, if not avoided,
could result in death or serious injury. It may be associated with
either a general hazard, high voltage, or other symbol. See Table 2
for more information.
CAUTION Indicates a potentially hazardous situation that, if not avoided,
could result in minor or moderate injury and/or damage to equip-
ment.
It may be associated with either a general hazard, high voltage, or
risk of explosion symbol. See Table 2 for more information.
When applied to software actions, indicates a situation that, if not
avoided, could result in loss of data or a disruption of software
operation.
ALERT Indicates that there is an action that must be performed in order to
protect equipment and data or to avoid software damage and ser-
vice interruption.
Table 2 Symbol conventions (Continued)

About this User Guide
Safety and compliance information
SPA06MA-O User’s Guide
April 2021 22145360, R005 Page xiii
Safety and compliance information
Safety and compliance information for the instrument are provided in printed form and
ship with your instrument.
Technical assistance
If you require technical assistance, call 1-844-GO-VIAVI. For the latest TAC informa-
tion, go to http://www.viavisolutions.com/en/services-and-support/support/technical-
assistance.

About this User Guide
Technical assistance
SPA06MA-O User’s Guide
Page xiv 22145360, R005 April 2021

SPA06MA-O User’s Guide
April 2021 22145360, R005 Page 1
1
Chapter 1 Overview
This chapter provides a description of the SPA06MA-O. Topics covered in this chapter
include:
•“SPA06MA-O overview” on page 2
•“Exploring the module” on page 2
•“Module installation” on page 3

Chapter 1 Overview
SPA06MA-O overview
SPA06MA-O User’s Guide
Page 2 22145360, R005 April 2021
SPA06MA-O overview
The SPA06MA-O module is equipped with 6 GHz RF and 25 Gbps Optical hardware.
SPA06MA is a variant that has 6 GHz RF hardware only.
6 Ghz RF hardware allows:
•Spectrum Analysis from 9 kHz to 6 GHz
•Real-time Spectrum Analysis with up to 100MHz persistent display
•LTE-FDD/TDD and 5G NR OTA Signal Analysis
25 Gbps optical hardware allows:
•RFoCPRI Interference Analysis up to 10.1 Gbps.
Exploring the module
Figure 1 SPA06MA-O module
1 RF Input port Used as the input signal port for spectrum analysis, signal
analysis, and RF power measurement.
2 Ext Ref. SMA type female connector to receive 10 MHz, 13 MHz, or 15
MHz reference clock signals from an external frequency
source.
3 Trigger Out SMB connector to send 1 PPS clock or 10 ms synchronization
signals from an internal timing reference.
Digital CMOS Input DC Coupled
Input signal requirements: Minimum logic high. 2.4V, Maxi-
mum logic high ≥ 3.3V.

Chapter 1 Overview
Module installation
SPA06MA-O User’s Guide
April 2021 22145360, R005 Page 3
Module installation
The following procedure describes how to install the module to the base.
To connect the module to the ONA-800
1Verify that the power is OFF on your ONA-800 and the power adapter is
unplugged.
2Remove the back termination cover or CAA/OTDR modules.
3Remove the screen from the ONA-800 base:
aSet the unit so you have access to the back. Using the hex key located in the
groove on the back of the ONA-800, loosen the four fasteners, as shown in
Figure 2.
4 Trigger In SMB connector to receive 1PPS clock or 10 ms synchroniza-
tion signals.
Digital CMOS Input DC Coupled
Input signal requirements: Minimum logic high. 2.4V, Maxi-
mum logic high ≥ 3.3V.
5 GNSS Antenna SMA connector for GNSS antenna.
61SFP+/SFP28 You can use these ports to connect SFP modules to test CPRI
protocols, detect an error or alarm, perform interference analy-
sis, and transmit test pattern over fiber link.
71
81QSFP+/QSFP28 You can use these ports to connect QSFP modules to test
CPRI protocols, detect an error or alarm, perform interference
analysis, and transmit test pattern over fiber link.
1. Not supported on SPA06MA.

Chapter 1 Overview
Module installation
SPA06MA-O User’s Guide
Page 4 22145360, R005 April 2021
Figure 2 Fastener locations
bLift the ONA-800 base off of the screen.
4Set the module onto the screen, ensuring the mating connectors between the two
pieces are aligned, as shown in Figure 3.
Figure 3 Module to screen alignment
5Insert the hex key in the brass fittings on the rear of the module and tighten the
internal captive fasteners to secure the module to the display.
6Set the ONA-800 base to the module, ensuring the mating connectors are
aligned, as shown in Figure 4.
