Victory Typhoon 28 Assembly instructions

VICTORY
Professional Built-In Range Hood
Model number: Typhoon
Available sizes: 28”, 34”, 40”, 46”, 52”, 58”
Rev. 3062u.3a
NOTICE:
For residential use only.
Installer: Leave this guide with the homeowner.
Homeowner: Keep this guide for future reference.
Installation Guide
and Users Manual

Important Safety Notice
Read all Instructions before Installing and operating this appliance
• The installation in this manual is intended for qualied installers, service technicians or persons with
similar qualied background. Installation and electrical wiring must be done by qualied profession-
als and in accordance with all applicable codes and standards, including re-rated construction.
• DO NOT attempt to install this appliance yourself. Injury could result from installing the unit due to
lack of appropriate electrical and technical background.
• Range hood may have very sharp edges; please wear protective gloves if it is necessary to remove any
parts for installing, cleaning or servicing.
• Activating any switch ON before completing installation may cause ignition or an explosion.
• Due to the size and weight of this range hood, two-person installation is recommended.
To reduce the risk of re, electric shock, or injury to persons:
• For general ventilating use only. DO NOT use to exhaust hazardous or explosive materials and va-
pors.
• The combustion air ow needed for safe operation of fuel-burning equipment may be aected by this
unit’s operation. Follow the heating equipment manufacturer’s guideline and safety standards such
as those published by the National Fire Protection Association (NFPA), and the American Society of
Heating, Refrigeration and Air Conditioning Engineers (ASHRAE), and the local code authorities.
• Before servicing or cleaning unit, switch power OFF at service panel and lock service panel to pre-
vent power from being switched ON accidentally.
• Clean grease laden surfaces frequently. To reduce the risk of re and to disperse air properly, make
sure to vent air outside. DO NOT vent exhaust into spaces between walls, crawl spaces, ceiling, attics
and/or garages.
• Ducted fans MUST always be vented to the outdoors.
• Use only metal ductwork and this unit MUST be grounded.
• Sucient air is needed for proper combustion and exhausting of gases through the duct to prevent
back drafting.
• When cutting or drilling into wall or ceiling, be careful not to damage electrical wiring or other hid-
den utilities.
• All electrical wiring must be properly installed, insulated and grounded.
• Old duct work should be cleaned or replaced if necessary to avoid the possibility of a grease re.
• Check all joints on duct work to insure proper connection and all joints should be properly taped.
• Use this unit only in the manner intended by the manufacturer. If you have questions, contact the
vendor.
To reduce the risk of a stove top grease re:
• Keep all fans, spacers, lters, grease tunnels, oil containers and grease-laden surfaces clean. Grease
should not be allowed to accumulate on fan, bae, spaces, lter, grease tunnel and oil container.
• Always turn range hood ON when cooking at high heat or when cooking foods that produce ames.
• Use high settings on cooking range only when necessary.
• Never leave surface units unattended at high settings. Boil overs cause smoking and greasy spillovers
that may ignite. Heat oils slowly on low or medium settings.

Important Safety Notice
Read all Instructions before Installing and operating this appliance
WARNING
Your safety and the safety of others is very important. We have provided many important safety mes-
sages in this manual and on your appliance. Always read and obey all safety messages. All safety mes-
sages will tell you what the potential hazard is, tell you how to reduce the chance of injury, and tell you
what can happen if the instructions are not followed.
This is the safety alert symbol. This symbol alerts you to potential hazards that can hurt you and others.
All safety messages will follow the safety alert symbol and the word “WARNING”.
The manufacturer and/or distributor/reseller declines all responsibility in the event of failure to ob-
serve the instructions given here for installation, maintenance and suitable use of the product.
The manufacturer and/or distributor/reseller further declines all responsibility for injury due to neg-
ligence and the warranty of the unit automatically expires due to improper maintenance.
The manufacturer and/or distributor/reseller will not be held responsible for any damages to per-
sonal property or real estate or any bodily injuries whether caused directly or indirectly by the range
hood.
• Clean ventilating fan frequently.
• Always use appropriate cookware and utensils size.
• Always use cookware appropriate for the size of the surface element.
To reduce the risk of injury to persons in the event of a stove top grease re:
• Smother ames with a close-tting lid, cookie sheet, or metal tray, then turn OFF the burner. Be
careful to PREVENT BURNS. Never pick up a pan that has ames—you may be burned. Keep am-
mable and/or combustible material away from ames. If the ames DO NOT go out immediately,
EVACUATE and CALL the FIRE DEPARTMENT or dial your local emergency service immediately.
• DO NOT use WATER, including wet dishcloths or towels — it will result in a violent steam explosion
• Use an extinguisher ONLY if:
• You know you have a Class A, B, C extinguisher, and you already know how to operate it.
• The re is small and contained in the area where it has started.
• The re department is on the way.
• You can ght the re while having access to a safe exit.
To reduce the risk of injury to persons in the event of a gas leaks:
• Extinguish any open ame.
• DO NOT turn on the range hood fan or any type of ventilator.
• DO NOT turn on the lights or any type of appliance.
• Open all doors and windows to disperse the gas. If you still smell gas, call the gas company and re
department or dial your local emergency service immediately.

Venting Requirements
• Vent system must terminate to the out-
side (roof or side wall), unless using a
recirculating kit.
• Do not terminate the vent system in an
attic or other enclosed area.
• Do not use 4” (10.2 cm) laundry-type
wall caps.
• Use metal/aluminum vent only. Rigid
metal/aluminum vent is recommended.
• Do not use plastic vent.
• Always keep the duct clean to ensure
proper airow.
• Calculate the following gures before
installation:
1. Distance from the oor to the ceil-
ing.
2. Distance between the oor to the
counter top/stove (recommend 24”
to 30”).
3. Distance between the counter top/
stove to the range hood.
4. Height of hood and duct cover.
For the most ecient and quiet
operation:
• It is recommended that the range hood
be vented vertically through the roof
through 8” or 10” round metal/ alumi-
num vent work.
• The size of the vent should be uniform.
• Use no more than three 90° elbows.
• Make sure there is a minimum of 24”
(61 cm) of straight vent between the
elbows if more than one elbow is used.
• Do Not install two elbows together.
• The length of vent system and number
of elbows should be kept to a mini-
mum to provide ecient performance.
• The vent system must have a damper.
If roof or wall cap has a damper, Do
Not use damper supplied with the
range hood.
• Use aluminum tape to seal all joints in
the vent system.
• Use caulking to seal exterior wall or
roof opening around the cap.
Height & Clearance
Cabinet
Range hood
Venting 8”
or 10”Duct
36” base
Min: 24”
Max: 30”

IMPORTANT:
• A minimum of a 8” round duct (standard for this range hood) must be used to maintain maximum airow
eciency. There is also an optio to use an 10” round duct size for this unit.
• Always use rigid type metal/aluminum ducts if available to maximize airow when connecting to provided
duct.
• Please use Duct Run Calculation below to compute total available duct run when using elbows, transitions
and caps.
• ALWAYS, when possible, reduce the number or transitions and turns in the duct run. If a long duct run is re-
quired, increase the duct size from 8” to 10”. If a reducer is used, install a long reducer instead of a pancake
reducer. Reducing the duct size will restrict airow and decrease eciency.
• If turns or transitions are required: Install as far away from opening and as far apart, between 2, as possible.
• Minimum mount height between stove top to hood bottom should be no less than 24-inch*.
• Maximum mount height between stove top to hood bottom should be no higher than 30-inch*.
• It is important to install the hood at the proper mounting height. Hoods mounted too low could result in heat
damage and re hazard; while hoods mounted too high will be hard to reach and will loose its performance
and eciency.
• If available, also refer to stove top manufacturer’s height clearance requirements and recommended hood
mounting height above range.
* Due to dierent ceiling height congurations, recommended height may not be applicable.
Minimum Duct Size:
• Round - 8” minimum
• Round - 10” recommended/optional
Duct Run Calculation:
Recommended maximum run
8” or 10” round duct 50 ft
Vent piece deduction
Each 90º elbow used 9 ft
Each 45º elbow used 5 ft
Each round to rectangle transition used 7 ft
Side wall cap with damper 7 ft
Roof cap 7 ft
Duct Run Calcuation example:
One roof cap, two 90º elbows, and one 45º elbow used:
7ft + 9ft + 9ft + 5ft = 30ft used.
The above vent pieces used are equivalent to 30ft of a
straight duct run. Subtract 30ft from the allowable 50ft.
The remaining distance of 20ft is the longest that the
straight ducting (in addition to the vent pieces) can be.
Calculating Vent System Length
To calculate the length of the duct system you require, subtract the equivalent feet for each “Vent piece” (Table
Below) used in the system from the “Recommended maximum run” (Table Below). The longest duct run that is
acceptable (if completely straight) is 50 feet. The number of vent pieces (elbow, transition, etc.) installed in your
duct run will determine the maximum length the duct run can be. Please refer to the example below:

Venting Methods
• This range hood is factory set for venting through the roof or wall.
• Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed.
IMPORTANT:
• NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, attics or
garages. All exhaust must be ducted to the outside.
• Use metal/aluminum duct work only.
• Fasten all connections with sheet metal screws and tape all joints with certied Aluminum Foil Tape.
• Use caulking to seal exterior wall or roof opening around the cap.

IMPORTANT: Observe all governing codes and ordinances.
It is the customer’s responsibility:
• To contact a qualied electrician
• To assure that the electrical installation is adequate and in conformance with National Electrical Code, ANSI/
NFPA 70 — latest edition*, or CSA Standards C22. 1-94, Canadian Electrical Code, Part 1 and C22. 2 No.
0-M91 - latest edition** and all local codes and ordinances.
If codes permit and a separate ground wire is used, it is recommended that a qualied electrician determine that
the ground path is adequate.
A 120-Volt, 60 Hz, AC-only, fused electrical supply is required on a separate 15-amp circuit, fused on both sides
of the line.
DO NOT ground to a gas pipe.
Check with a qualied electrician if you are not sure that the range hood is properly grounded.
DO NOT have a fuse in the neutral or ground circuit.
IMPORTANT: Save this Installation Guide for electrical inspector’s use.
The range hood must be connected with copper wire/plug only.
The range hood should be connected directly to the fused disconnect (or circuit breaker) box through exible
armored or non-metallic sheathed copper cable. A U.L. - or C.S.A. - listed strain relief must be provided at each
end of the power supply cable.
Wire sizes (copper wire only) and connections must conform with the rating of the appliance as specied on
the model/serial rating label. Wire sizes must conform to the requirements of the National Electrical Code
ANSI/NFPA 70 — latest edition*, or CSA Standards C22. 1-94, Canadian Electrical Code Part 1 and C22.
2 No. 0-M91 - latest edition** and all local codes and ordinances. A U.L. - or C.S.A. - listed conduit con-
nector must be provided at each end of the power supply cable (at the range hood and at the junction box).
Copies of the standards listed may be obtained from:
* National Fire Protection Association
Batterymarch Park
Quincy, Massachusetts 02269
** CSA International
8501 East Pleasant Valley Road
Cleveland, Ohio 44131-5575
Electrical Requirements

Installation
Excessive Weight
Require two or more person to move and
install this range hood. Spinal or other bodi-
ly injuries could occur if it is not followed.
INSTALL THE HOOD
Due to excessive weight, two or more person is recommended for this step.
TEST THE RANGE HOOD PRIOR INSTALLATION
NOTE: the hood has to be installed, inside the cabinet, at
minimum 1/2” from the rear wall cabinet and at 1/2” from the front wall cabinet.
The internal height of cabinet has to be minimum 28”.
The hood should be mounted centered over the cook top burners.
1. Cut a hole in the bottom of the cabinet, using the dimensions shown in the table below (ref. to Fig. A).
2. Insert the hood in the cabinet and secure with the mounting screws from the inner side of the range hood (Fig.
B). Note: Wood blocking might need to be built if it’s not available in order to secure the mounting screws.
3. Attach the 8” or 10” top vent duct
4. Connect the hood the a power supply
Wood Blocking
Fig. B
Fig. A
Cut a hole in the bottom of the
cabinet
X
Y
Model X Y
Typhoon 28 28-3/8” 19-11/16”
Typhoon 34 34-3/8” 19-11/16”
Typhoon 40 40-3/8” 19-11/16”
Typhoon 46 46-3/8” 19-11/16”
Model X Y
Typhoon 52 52-3/8” 19-11/16”
Typhoon 58 58-3/8” 19-11/16”

Dimensions
Filter Installation
Figure 7
Figure 6
Figure 5
Figure 8
To install bae lters and stainless spacer(s)
Refer to Figure 7 & 8 and follow the following
ve steps:
- Angle bae lter toward back of hood.
- Push bae lter up until almost level.
- Slide forward into recess behind the front of
hood.
- Lower bae lter.
- Slide back until it ts into resting positions.

Typical rotary switch
Range Hood Operations
Wiring Diagram (4 Speed Blower)
Wiring Diagram
This range hood is equipped with 2 rotary switches. Left
switch control the blower, right switch controls the lights.
BLOWER SWITCH:
Rotate the switches clockwise to switch the blower ON. The
switch has 5 positions , OFF, SPEED 1,2,3,4.
LIGHT SWITCH:
Rotate the switches clockwise to switch the lights ON. The
light switch allows you to control the

Troubleshooting
1. If the range hood or lights do not operate after in-
stallation:
• Check if the range hood has been plugged in, make
sure that all power has been turned back ON, fused
not blown and all electrical wiring are properly con-
nected.
• Swap out light assembly to working ones to deter-
mine whether it is caused by defective bulbs. See
Replacing the light bulbs on Page17.
2. The range hood vibrates when the blower is on: • The range hood might not have been secured prop-
erly on to the ceiling or wall.
3. The blower or fan seems weak: • Check that the duct sized used is at least 8” . Range
hood WILL NOT function eciently with insu-
cient duct size. For example: Connecting this hood
to 4”, 5’ or 6” duct will reduce the suction and
create extra noise and vibrations. Check if duct is
clogged or if damper unit is not installed correctly
or opening properly. A tight mesh on a side wall cap
unit might also cause restriction to the air ow.
4. The lights work but the blower is not spinning at all,
is stuck or is rattling.
• The blower might be jammed or scraping the bot-
tom due to shipping damage. Please contact us im-
mediately.
5. The hood is not venting out properly: • Make sure the distance between the stove top and
the bottom of the hood is within* 24” and 30” in
distance. *Due to dierent ceiling height congura-
tions, recommended height may not be applicable.
• Reduce the number of elbows and length of duct
work. Check if all joints are properly connected,
sealed, and taped.
• Make sure the power is on high speed for heavy
cooking.
NOTE: For all other inquiries, please contact Victory Range Hoods.

Specications*:
Body Heavy Duty Stainless Steel
Power Rating 120V/60Hz (USA & Canada standard)
General Input Power 370 W (300W + 2x35W)
Motor Input Power 300 W
Motor Revolution 800 RPM (±10%) to 1300 RPM (±10%)
Levels Of Speed Control 4 Levels
Maximum Airow 1000 CFM / 1150 CFM (when 10” duct is used)
Air Pressure 150 Pa (200 Pa Maximum)
Noise Level (sone) Approximately 1.5 to 6.8 (Lowest to highest Speed)
Motor Type Single Chamber Ultra Quiet
Fan Type Centrifugal
Control Type Mechanical, Rotary Switches
Illumination Dimmable: 35W GU10 Bulbs (LED Optional)
Venting Size Top or Back 8” or 10” round exhaust
Specications
* Subject to change without notice, please contact your local authorized reseller for details.
Use and Care Information
Operations:
• Read and understand all instructions and warnings in this manual before operating the appliance. Save these
instructions for future reference.
• Always leave safety grills and lters in place. Without these components, operating blowers could catch on to
hair, ngers and loose clothing.
• NEVER dispose cigarette ashes, ignitable substances, or any foreign objects into blowers.
• NEVER leave cooking unattended. When frying, oil in the pan can easily overheat and catch re. The risk of
self combustion is higher when the oil has been used several times.
• NEVER cook on “open” ames under the range hood. Check deep-fryers during use: Superheated oil may be
ammable.
Cleaning:
• The saturation of greasy residue in the blower and lters may cause increased inammability. Keep unit clean
and free of grease and residue build-up at all times to prevent possible res.
• Filters must be cleaned periodically and free from accumulation of cooking residue (see cleaning instructions
on Page 17). Old and worn lters must be replaced immediately.
• DO NOT operate blowers when lters are removed. Never disassemble parts to clean without proper instruc-
tions. Disassembly is recommended to be performed by qualied personnel only. Read and understand all
instructions and warnings in this manual before proceeding.

WARNING
Hazard of Burns!
Light bulb become extremely hot when turned on.
DO NOT touch bulb until switched o󰀨 and cooled.
Touching hot bulbs could cause serious burns.
Maintenance
SAFETY WARNING: Never put your hand into area housing the fan while the fan is operating!
For optimal operation, clean range hood and all bae/spacer/lter/grease tunnel/oil container regularly. Regular care will
help preserve the appearance of the range hood.
Cleaning Exterior surfaces:
• Clean periodically with hot soapy water and clean cotton cloth. Do not use corrosive or abrasive detergent (e.g. Comet
Power Scruv®, EZ-O® oven cleaner), or steel wool/scoring pads, which will scratch and damage the stainless steel
surface. For heavier oil use liquid degrease such as “Forumla 409®” or “Fantastic®” brand cleaner.
• If the hood looks splotchy (stainless steel hood), use a stainless steel cleaner to clean the surface of the hood. Avoid
getting cleaning solution onto or into the control panel. Follow directions of the stainless steel cleaner. CAUTION: Do
not leave on too long as this may cause damage to the hood nish. Use a soft towel to wipe o the cleaning solution,
gently rub o any stubborn spots. Use a dry soft towel to dry the hood.
• After cleaning, you may use non abrasive stainless steel polish such as 3M® or ZEP®, to polish and bu out the stainless
luster and grain. Always scrub lightly, a with clean cotton cloth, and with the grain.
• DO NOT allow deposits to accumulate or remain on the hood.
• DO NOT use ordinary steel wool or steel brushes. Small bits of steel may adhere to the surface and cause rusting.
• DO NOT allow salt solutions, disinfectants, bleaches, or cleaning compounds to remain in contact with stainless steel
for extended periods. Many of these compounds contain chemicals, which may be harmful. Rinse with water after ex-
posure and wipe dry with a clean cloth.
Cleaning Aluminum Grease Filter / Stainless Steel Filterless Grill:
IMPORTANT: Drain oil from grease tunnel and lters before oil and residue overow!
• The stainless steel lters are intended to lter out residue and grease from cooking. It need not be replaced on a regular
basis, but are required to be kept clean.
• Filters should be cleaned after every 30 hours of use.
• Remove and clean by hand. Spray “Formula 409®” or equivalent degreasing detergent and leave to soak if very dirty.
Dry the lters and re-install before using the hood.
Replacing Filters:
• Should lters wear out due to age and prolonged use, please contact Victory Range Hoods for replacement lters.
Replacing the light bulb:
• Please contact Victory Range Hoods if you require a replacement Light.
• Make sure the range hood is unplugged or turn OFF breaker.
• Make sure the lights are cool to touch, carefully remove the old light xture and replace it with the new one.
• Turn ON breaker and range hood to test for operation.

Five Year Parts Warranty:
For ve years from the date of original purchase, your Victory Range Hoods will provide free of charge, non-consum-
able replacement parts or components that failed due to manufacturing defects. Subject to the conditions and limita-
tions set forth below, Victory Range Hoods will, at its option, either repair or replace any part of its products that prove
defective by reason of improper workmanship or materials. Repaired parts or replacement products will be provided by
Victory Range Hoods on an exchange basis, and will be either new or refurbished to be functionally equivalent to new.
Who is Covered:
This warranty is extended to the original purchaser for products purchased for ordinary home use.
This Warranty Will Be Voided When:
Product is damaged through negligence, improper installation, accident, abuse, misuse, natural disaster, insucient or
excessive electrical supply, abnormal mechanical or environmental conditions, or any unauthorized disassembly, repair,
modication, or failure to follow installation instructions. When product is used commercially or other than its intended
purpose. Damaged because of improper connection with equipment of other manufacturers. Repaired or modied by
anyone other than Victory Range Hoods. This limited warranty also does not apply to any product on which the original
identication information has been altered, obliterated or removed, has not been handled or packaged correctly or has
been sold as second-hand.
What is Not Covered:
Consumable parts such as light bulbs, metal and charcoal lters. The natural wear of nish, and wear due to improper
maintenance, use of corrosive and abrasive cleaning products, pads, and oven cleaner products. Chips, dents or cracks
due to abuse, misuse, freight damage, or improper installation. Damage of product caused by accident, re, oods or
acts of God. The manufacturer and/or distributor/reseller is not liable for, and does not cover under warranty, any loss
of properties or any costs associated with removing, servicing, installing, or determining the source of problems with
this product.
This warranty is valid in Canada and the United States of America. It is non-transferable and applies only to the original
purchaser and does not extend to subsequent owners of this product. Any applicable implied warranties, including the war-
ranty of merchantability, are limited in duration to a period of express warranty as provided herein beginning with the date
of original purchase and, no warranties, whether expressed or implied, shall apply to this product thereafter.
To obtain warranty service, you may contact Victory Range Hoods. Please conrm the terms of Victory Range Hood’s poli-
cies prior to contacting us. Typically, you must include product identication information, such as the model number/name
with a detailed description of the problem you are experiencing. You must also include proof of the date of original purchase
as evidence that the product is within the applicable warranty period, and that it is a genuine range hood from Victory Range
Hoods.
TO OBTAIN SERVICE UNDER WARRANTY:
You must present proof of original purchase date.
Please provide an original dated proof of purchase (sales receipt / invoice) in order to obtain service under warranty.
The information in this document is subject to change without notice, please contact Victory Range Hoods for updated details.
Warranty

Carefully inspect all items for damages before accepting delivery. note any damages on the freight bill or
express receipt. request name and signature of the carrier’s agent and keep a copy to support your claim. Upon
acceptance of items, owner assumes responsibility for its safe arrival. Report damages to the carrier and le
a claim immediately. Failure to do so may result in the denial of your claim. The carrier will furnish you with
necessary forms for ling a claim.
Damages on any returns or exchanges caused during transit are not covered under our warranty (the customer
must insure the return with the shipping company). If your range hood is damaged in transit, please contact us
within 14 days of receiving your new order to report the damages. Victory Range Hoods will, to the best of its
ability, le a damage claim and investigate the matter.
Please inspect contents of package(s) carefully upon receiving! We must be notied of any damages and/or
missing parts within fourteen (14) days upon your receipt of the package(s). Claims will not be accepted after
fourteen (14) days. NOTE: Items are thoroughly tested and carefully packed in our facility before shipping.
Products must be returned in good working condition with ALL original parts and documentation packed in all
original cartons, llers and shipping cartons. A restocking fee of 10% will be charged for all approved return(s).
Exchanges or returns will not be accepted if the unit has been installed, and may be rejected if parts are missing.
Make sure to inspect the hood for damages and defects before installation. Appearance aws of the hood found
after installation and not aecting hood performance are not covered under our warranty for returns or exchang-
es. Service visits are not covered under warranty and will carry a service charge.
If you require assistance, please contact Victory Range Hoods. Please have your order number and model of the
range hood ready. You must have this information in order to receive a response to your request.
If you need replacement parts, we recommend using only genuine parts. Our accessories and parts are engineered
and designed specically for VICTORY range hoods. Each part is rigorously tested assuring the utmost in dura-
bility and reliability, providing a factory match, factory-installed appearance and functionality tailored to each
individual range hood model.
Contact Us
Disclaimer
The information in this document is subject to change without notice, please contact Victory Range Hoods for updated details.

583 Nicola Ave
Port Coquitlam, BC
V3B 0M3
Canada
VICTORY
Range Hoods for Professionals
