Videotec ULISSE COMPACT User manual

ENGLISH ITALIANO FRANÇAIS DEUTSCH
РУССКИЙ
EN
English - Instructions manual
IT
Italiano - Manuale di istruzioni
FR
Français - Manuel d’instructions
DE
Deutsch - Bedienungslanleitung
RU
 - Руководство по эксплуатации
ULISSE COMPACT
Outdoor PTZ camera for highest precision Day/Night monitoring

EN
English - Instructions manual
ENGLISH
ULISSE COMPACT
Outdoor PTZ camera for highest precision Day/Night monitoring

Instructions manual - English - EN
3MNVCUCZ_1511_EN
Contents ENGLISH
1 About this manual ......................................................................................................... 7
1.1 Typographical conventions.................................................................................................................................. 7
2 Notes on copyright and information on trademarks.................................................. 7
3 Safety rules..................................................................................................................... 7
4 Identication................................................................................................................ 10
4.1 Product description and type designation...................................................................................................10
4.2 Product markings ..................................................................................................................................................10
4.2.1 Checking the markings .......................................................................................................................................................10
5 Versions ........................................................................................................................ 11
5.1 Integrated wiper ....................................................................................................................................................11
5.2 LED illuminator.......................................................................................................................................................11
5.3 IP video encoder ....................................................................................................................................................11
6 Preparing the product for use .................................................................................... 12
6.1 Safety precautions before use...........................................................................................................................12
6.2 Unpacking................................................................................................................................................................12
6.3 Contents....................................................................................................................................................................12
6.4 Safely disposing of packaging material.........................................................................................................12
6.5 Preparatory work before installation..............................................................................................................13
6.5.1 Attaching the bracket..........................................................................................................................................................13
6.5.2 Cables management ............................................................................................................................................................13
7 Installation ................................................................................................................... 13
7.1 Connecting the cables to the base..................................................................................................................13
7.2 Fixing the base to the support..........................................................................................................................14
7.3 Connection of the connector board...............................................................................................................14
7.3.1 Connector board description............................................................................................................................................14
7.3.2 Connection of the power supply line.............................................................................................................................15
7.3.3 Signal cable connection......................................................................................................................................................16
7.3.3.1 Video cable connection............................................................................................................................................................................16
7.3.3.2 Telemetry lines connections...................................................................................................................................................................16
7.4 Connection of the secondary connector board .........................................................................................17
7.4.1 Description of the secondary board...............................................................................................................................17
7.4.2 Connection of the alarm inputs .......................................................................................................................................17
7.4.3 Relay connection...................................................................................................................................................................18
7.4.4 Connecting the light sensitive switch for the LED illuminator .............................................................................18
7.4.5 Washing system connection..............................................................................................................................................19
7.4.6 Connection of the Ethernet cable ...................................................................................................................................19
7.5 Fixing the upper body..........................................................................................................................................20
7.6 Hardware conguration......................................................................................................................................20
7.6.1 Opening the conguration door .....................................................................................................................................20
7.6.2 Conguration of the dip-switches...................................................................................................................................20
7.6.3 Setting the conguration check mode (DIP 1) ...........................................................................................................21
7.6.4 Baud rate conguration......................................................................................................................................................21

EN - English - Instructions manual
4 MNVCUCZ_1511_EN
7.6.5 Setting of the serial communication lines....................................................................................................................21
7.6.5.1 Two-way RS-485 TX/RX line.....................................................................................................................................................................22
7.6.5.2 Line RS-485-1 reception, line RS-485-2 repetition..........................................................................................................................22
7.6.5.3 Two-way RS-422 line..................................................................................................................................................................................22
7.6.5.4 One-way RS-485 line..................................................................................................................................................................................22
7.6.6 Serial line terminations........................................................................................................................................................23
7.6.7 Protocol conguration.........................................................................................................................................................23
7.6.8 Address conguration .........................................................................................................................................................23
8 Switching on ................................................................................................................ 24
8.1 First start-up.............................................................................................................................................................24
8.2 Checks list.................................................................................................................................................................24
9 Conguration............................................................................................................... 25
9.1 OSM interface (On Screen Menu).....................................................................................................................25
9.1.1 Using the OSM........................................................................................................................................................................25
9.1.1.1 How to use the joystick.............................................................................................................................................................................25
9.1.2 How to move around the menus.....................................................................................................................................26
9.1.3 How to modify the parameters ........................................................................................................................................26
9.1.4 How to change the numeric elds..................................................................................................................................27
9.1.5 How to change text ..............................................................................................................................................................27
9.1.6 Conguration via OSM.........................................................................................................................................................29
9.1.7 Main Menu...............................................................................................................................................................................29
9.1.8 Language Selection Menu .................................................................................................................................................29
9.1.9 Camera menu..........................................................................................................................................................................29
9.1.9.1 Zone Titling Menu ......................................................................................................................................................................................30
9.1.9.2 Zone Titling Menu (Edit Area).................................................................................................................................................................30
9.1.9.3 Masking Menu .............................................................................................................................................................................................31
9.1.9.4 Masking Menu (Edit Masks) ....................................................................................................................................................................31
9.1.9.5 How to create a new mask ......................................................................................................................................................................31
9.1.9.6 How to modify a mask ..............................................................................................................................................................................32
9.1.9.7 Advanced Setting Menu...........................................................................................................................................................................33
9.1.9.8 Advanced Setting Menu (Zoom)...........................................................................................................................................................33
9.1.9.9 Advanced Setting Menu (Focus)...........................................................................................................................................................33
9.1.9.10 Advanced Setting Menu (Exposure)..................................................................................................................................................34
9.1.9.11 Advanced Setting Menu (Infrared) ....................................................................................................................................................35
9.1.9.12 Advanced Setting Menu (White Balance)........................................................................................................................................36
9.1.9.13 Advanced Setting Menu (Other).........................................................................................................................................................36
9.1.10 Movement Menu.................................................................................................................................................................37
9.1.10.1 Manual Control Menu.............................................................................................................................................................................37
9.1.10.2 Manual Control Menu (Limits).............................................................................................................................................................38
9.1.10.3 Preset Menu ...............................................................................................................................................................................................38
9.1.10.4 Preset Menu (Edit Preset) ......................................................................................................................................................................38
9.1.10.5 Preset Menu (Utility Preset)..................................................................................................................................................................39
9.1.10.6 Patrol Menu................................................................................................................................................................................................39
9.1.10.7 Autopan Menu ..........................................................................................................................................................................................39
9.1.10.8 Motion Recall Menu ................................................................................................................................................................................40
9.1.10.9 Advanced Menu........................................................................................................................................................................................40
9.1.11 Display Menu........................................................................................................................................................................41
9.1.12 Options Menu.......................................................................................................................................................................41
9.1.12.1 Alarms Menu..............................................................................................................................................................................................42
9.1.13 Washer Menu........................................................................................................................................................................43
9.1.14 Default Menu........................................................................................................................................................................43

Instructions manual - English - EN
5MNVCUCZ_1511_EN
9.1.15 Info Menu...............................................................................................................................................................................43
9.2 Sofware interface...................................................................................................................................................44
9.2.1 Minimum system requirements.......................................................................................................................................44
9.2.2 Conguration procedure through software................................................................................................................44
9.2.3 Installing the software.........................................................................................................................................................44
9.3 Web interface ..........................................................................................................................................................46
9.3.1 Home..........................................................................................................................................................................................46
9.3.2 User Controls...........................................................................................................................................................................47
9.3.3 Device Parameters.................................................................................................................................................................48
9.3.4 Device Statistics .....................................................................................................................................................................48
9.3.5 Network Conguration........................................................................................................................................................48
9.3.6 User Conguration................................................................................................................................................................49
9.3.7 Movement Parameters........................................................................................................................................................49
9.3.7.1 Autopan .........................................................................................................................................................................................................50
9.3.7.2 Patrol ...............................................................................................................................................................................................................50
9.3.7.3 Motions Recall..............................................................................................................................................................................................50
9.3.8 Preset Parameters..................................................................................................................................................................51
9.3.9 Preset Parameters (Advanced)..........................................................................................................................................51
9.3.10 Digital I/O...............................................................................................................................................................................52
9.3.11 Wiper........................................................................................................................................................................................52
9.3.12 Washer.....................................................................................................................................................................................52
9.3.13 Encoder Parameters...........................................................................................................................................................53
9.3.14 Tools.........................................................................................................................................................................................53
10 Accessories................................................................................................................. 54
10.1 Washer.....................................................................................................................................................................54
10.2 Wall mount.............................................................................................................................................................54
10.3 Parapet bracket....................................................................................................................................................54
10.4 Ceiling mounting ................................................................................................................................................54
11 Instructions for normal operation ........................................................................... 55
11.1 Visualizing the state of the pan & tilt............................................................................................................55
11.2 Saving a Preset .....................................................................................................................................................55
11.2.1 Quick save..............................................................................................................................................................................55
11.2.2 Saving from the Menu.......................................................................................................................................................55
11.3 Restore a Preset position (Scan).....................................................................................................................56
11.4 Patrol enabling.....................................................................................................................................................56
11.5 Autopan enabling...............................................................................................................................................56
11.6 Recalling a pattern (Tour).................................................................................................................................56
11.7 Recalling the Home position...........................................................................................................................57
11.8 Enabling the wiper (Wiper)..............................................................................................................................57
11.9 Enabling the washer (Washer)........................................................................................................................57
11.10 Enabling the LED illuminator........................................................................................................................57
11.11 Unit Reboot.........................................................................................................................................................57
11.12 Manual correction of a preset focusing....................................................................................................57
11.13 Special controls .................................................................................................................................................58
12 Maintaining and cleaning......................................................................................... 61
12.1 Maintaining ...........................................................................................................................................................61

EN - English - Instructions manual
6 MNVCUCZ_1511_EN
12.1.1 Firmware updating.............................................................................................................................................................61
12.1.2 Replacing the fuses ............................................................................................................................................................61
12.1.3 Fuses replacement..............................................................................................................................................................61
12.2 Cleaning..................................................................................................................................................................61
12.2.1 Window and plastic cover cleaning..............................................................................................................................61
13 Disposal of waste materials...................................................................................... 62
14 Troubleshooting ........................................................................................................ 62
15 Technical data ............................................................................................................ 65
15.1 General....................................................................................................................................................................65
15.2 Mechanical.............................................................................................................................................................65
15.3 Electrical/Video....................................................................................................................................................65
15.4 Communications.................................................................................................................................................66
15.5 Protocols.................................................................................................................................................................66
15.6 Environment..........................................................................................................................................................66
15.7 Certications.........................................................................................................................................................66
16 Technical drawings .................................................................................................... 67
A Appendix - Address table ........................................................................................... 69

Instructions manual - English - EN
7MNVCUCZ_1511_EN
1 About this manual
Before installing and using this unit, please read this
manual carefully. Be sure to keep it handy for later
reference.
1.1 Typographical conventions
DANGER!
High level hazard.
Risk of electric shock. Disconnect the
power supply before proceeding with any
operation, unless indicated otherwise.
DANGER!
Mechanical hazard.
Risk of crushing or shearing.
DANGER!
Hot surface.
Avoid contact. Surfaces are hot and may
cause personal injury if touched.
CAUTION!
Medium level hazard.
This operation is very important for the
system to function properly. Please read
the procedure described very carefully and
carry it out as instructed.
INFO
Description of system specications.
We recommend reading this part carefully
in order to understand the subsequent
stages.
2 Notes on copyright and
information on trademarks
The quoted names of products or companies are
trademarks or registered trademarks.
Microsoft Internet Explorer®, Windows XP®, Windows
Vista® are the property of Microsoft Corporation.
INTEL® Core™ 2 Duo, INTEL® Core™ 2 Quad, INTEL®
Xeon® are the property of Intel Corporation.
3 Safety rules
Infrared LED radiation. Do not look directly
at the illuminator using optical lenses. Class
1M LED device. Emitted optical power at
0.1m: 2.2mW @ 875nm, in compliance with
standard EN60825-1/IEC60825-1.
The white light LED illuminator emits
high-intensity visible light. In compliance
with standard EN62471/IEC62471, the
photobiological safety assessment has
classied the device in Risk Group 2, where
it exceeds the values of the Exempt Group.
The risk linked to the observer depends
on how the product has been installed
and is used. For installation, follow the
instructions in this manual. Do not open
the illuminator for whatever reason. Do not
look directly at the illuminator using optical
lenses. Exposure hazard values (EHV):
20.8s. Hazard distance (HD): 200mm.
Fig. 1 White light illuminator.
CAUTION! The electrical system to which
the unit is connected must be equipped
with a 20A max automatic bipolar circuit
breaker. This circuit breaker must be of
the Listed type. The minimum distance
between the contacts must be 3mm (0.1in).
The circuit breaker must be provided
with protection against the fault current
towards the ground (dierential) and the
overcurrent (magnetothermal).
CAUTION! The device must be installed
only and exclusively by qualied technical
personnel.
RISK GROUP 2
CAUTION: Possibly
hazardous optical radiation
emitted from this product.
Do not stare at operating
lamp. May be harmful to
the eye.
ATTENTION:
Des
rayonnements optiques
dangereux peuvent être émis
par ce produit. Ne pas regarder
la lampe directement. Peut
être dangereux pour les yeux.
GROUPE DE RISQUE 2

EN - English - Instructions manual
8 MNVCUCZ_1511_EN
CAUTION! TNV-1 installation type. The
installation is type TNV-1, do not connect it
to SELV circuits.
CAUTION! For continued protection against
risk of re, replace only with same type and
rating of fuse. Fuses must be replaced only
by service personnel.
CAUTION! In order to reduce the risk of re,
only use UL Listed or CSA certied cables
sizes greater than or equal to 0.13mm² (26
AWG).
• The manufacturer declines all responsibility
for any damage caused by an improper use
of the appliances mentioned in this manual.
Furthermore, the manufacturer reserves the right
to modify its contents without any prior notice.
The documentation contained in this manual has
been collected with great care. The manufacturer,
however, cannot take any liability for its use. The
same thing can be said for any person or company
involved in the creation and production of this
manual.
• Before starting any operation, make sure the
power supply is disconnected.
• Do not use cables that seem worn or old.
• Never, under any circumstances, make any
changes or connections that are not shown in
this handbook. Improper use of the appliance
can cause serious hazards, risking the safety of
personnel and of the installation.
• Use only original spare parts. Non-original spare
parts could cause re, electrical discharge or other
hazards.
• Before proceeding with installation, check the
supplied material to make sure it corresponds
to the order specication by examining the
identication labels (4.2 Product markings, page
10).
• This device was designed to be permanently
installed on a building or on a suitable structure.
The device must be installed permanently before
any operation.
• Installation category (also called Overvoltage
Category) species the level of mains voltage
surges that the equipment will be subjected to.
The category depends upon the location of the
equipment, and on any external surge protection
provided. Equipment in an industrial environment,
directly connected to major feeders/short branch
circuits, is subjected to Installation Category III. If
this is the case, a reduction to Installation Category
II is required. This can be achieved by use of an
insulating transformer with an earthed screen
between primary and secondary, or by tting
listed Surge Protective Devices (SPDs) from live
to neutral and from neutral to earth. Listed SPDs
shall be designed for repeated limiting of transient
voltage surges, suitable rated for operating voltage
and designated as follows: Type 2 (Permanently
connected SPDs intended for installation on the
load side of the service equipment overcurrent
device); Nominal Discharge Current (In) 20kA min.
For example: FERRAZ SHAWMUT, STT2240SPG-
CN, STT2BL240SPG-CN rated 120Vac/240Vac,
(In=20kA). Maximum distance between installation
and reduction is 5m.
• Use a Class 2 listed UL tranformer, compliant with
the Standards in force, only for products marked
UL, powered at 24Vac.
• A disconnecting device, readily and easily
accessible, must be incorporated in the electrical
system of the building for rapid intervention.
• The separate protective earthing terminal provided
on this product shall be permanently connected
to earth.
• Hazardous moving parts. Keep ngers and other
body parts away.

Instructions manual - English - EN
9MNVCUCZ_1511_EN
• Connect the device to a power source
corresponding to the indications given on the
marking label. Before proceeding with installation
make sure that the power line is properly isolated.
The supply voltage should never exceed the limit
(±10%).
• If it is necessary to transport the device, this should
be done with great care. Abrupt stops, bumps and
violent impact could damage the unit or injure the
user.
• To comply with the main supply voltage dips and
short interruption requirements, use a suitable
Uninterruptable Power Supply (UPS) to power the
unit.
• The device should be mounted so that it is
accessible only to the technician/installer because
the moving parts constitute a residual risk of injury
caused by movement of said parts.
• Attach the Dangerous Moving Parts label near the
device. (Fig. 6, page12).
• Do not use the appliance in the presence of
inammable substances.
• Do not allow children or unauthorised people to
use the appliance.
• The appliance should only be considered switched
o when the power supply has been disconnected
and the connecting cables to other devices have
been removed.
• Only skilled personnel should carry out
maintenance on the device. When carrying out
maintenance, the operator is exposed to the risk of
electrocution and other hazards.
• Use only the accessories indicated by the
manufacturer. Any change that is not expressly
approved by the manufacturer will invalidate the
guarantee.
• Connect the coaxial cable to earth.
• Before connecting all the cables make sure the
device is properly connected to the earth circuit.
• If the device has to be removed from the
installation, always disconnect the earth cable last.
• Take all necessary precautions to prevent the
apparatus from being damaged by electrostatic
discharge.
• The unit has been made for connection using a
3-pole cable. To make a correct connection to
the earth circuit, follow the instructions in this
handbook.
• Handle the unit with great care, high mechanical
stress could damage it.
• Make especially sure that the power supply line is
insulated at a sucient distance from all the other
cables, including lightning protection devices.

EN - English - Instructions manual
10 MNVCUCZ_1511_EN
4 Identication
4.1 Product description and type
designation
ULISSE COMPACT is a robust and ecient PTZ camera
unit designed to ensure dynamic and non-stop
surveillance of large outdoor areas and withstand
harsh weather conditions, reducing maintenance to
zero.
Optimal operation is ensured in very hot
environments up to 60°C or in very cold
environments up to -40°, thanks to optional
enhanced heating.
The accurate top-mount construction ensures vision
beyond the horizon and the continuous rotation on
the horizontal axis, combining high speed to absolute
tracking accuracy, both in manual mode and in patrol
mode.
The integrated camera ensures superior image
quality, even in poorly lit environments.
To ensure detailed images even during the night
hours, versions are available with LED illuminators,
with infrared light or white light.
The ULISSE COMPACT PTZ camera can be equipped
with a wiper for removing rain and dust from the
front glass; there is a wide selection of jerry cans with
washer pump, dierent capacities and heads.
The IP-based PTZ camera versions can be integrated
into a network system, with network control of all
PTZ functions.
H.264/AVC compression allows high denition
images to be transmitted via Ethernet with
optimisation of bandwidth and video storage space.
The compliance with ONVIF Prole S provides an
open architecture for maximum integration with IP
systems of the major brands in the industry.
4.2 Product markings
Pan & tilt devices have a label complying
with CE markings.
Fig. 2
The label shows:
• Model identication code (Extended 3/9 bar code).
• Power supply (Volt).
• Frequency (Hertz).
• Current consumption (Amps).
• Weatherproof standard (IP).
• Serial number.
4.2.1 Checking the markings
Before proceeding further with installation, make
sure the material supplied corresponds to the order
specication by examining the marking labels.
Never, under any circumstances, make any changes
or connections that are not shown in this handbook.
Improper use of the appliance can cause serious
hazards, risking the safety of personnel and of the
installation.

Instructions manual - English - EN
11MNVCUCZ_1511_EN
5 Versions
5.1 Integrated wiper
The product can be tted with a wiper.
Fig. 3
For further information refer to the relative
chapter (9.3.2 User Controls, page47).
5.2 LED illuminator
The pan & tilt can be tted with a LED illuminator.
Fig. 4
For further information refer to the relative
chapter (9.3.2 User Controls, page47).
5.3 IP video encoder
The product can be tted with a board for video
output through Ethernet.
Fig. 5
For further information refer to the relative
chapter (7.4.6 Connection of the Ethernet
cable, page19).

EN - English - Instructions manual
12 MNVCUCZ_1511_EN
6 Preparing the product for
use
Any change that is not expressly approved
by the manufacturer will invalidate the
guarantee.
6.1 Safety precautions before use
The appliance includes moving parts. Make
sure that the unit is positioned where it
is inaccessible under normal operating
conditions. Attach the warning label
supplied with the appliance, placing it near
the unit so that it can be seen easily.
Fig. 6
6.2 Unpacking
When the product is delivered, make sure that the
package is intact and that there are no signs that it
has been dropped or scratched.
If there are obvious signs of damage, contact the
supplier immediately.
Keep the packaging in case you need to send the
product for repairs.
6.3 Contents
Check the contents to make sure they correspond
with the list of materials as below:
• Positioning unit
• Accessories box
• Serial extension cable
• Label
• Silicon sheath
• Ties
• CD-ROM with installation software (for IP version
only)
• Instructions manual
6.4 Safely disposing of packaging
material
The packaging material can all be recycled. The
installer technician will be responsible for separating
the material for disposal, and in any case for
compliance with the legislation in force where the
device is to be used.
When returning a faulty product we recommend
using the original packaging for shipping.

Instructions manual - English - EN
13MNVCUCZ_1511_EN
6.5 Preparatory work before
installation
6.5.1 Attaching the bracket
Dierent types of supports are available (10
Accessories, page54). Choose a suitable bracket for
the installation and follow all the instructions in the
suggested chapter.
Take special care when attaching and
fastening down the apparatus. If it is to be
attached to a concrete surface you must
use dowel pins with a traction torque rating
of at least 300dN each. For a metal surface
use screws with a diameter of at least 8mm
and of an appropriate length. The clamping
system must be able to support at least 4
times the weight of the entire equipment,
including P&T, lenses and camera.
The device should be assembled vertically.
Any other position could impair the
performance of the appliance.
6.5.2 Cables management
The connection cables should not be
accessible from the outside. It is necessary
to fasten the cables securely to the support
in order to prevent excessive weight pulling
them out accidentaly.
You must use cables suited to the type of
installation.
Insert the cables into the support so that they
protrude by about 50cm.
50cm50cm
Fig. 7
7 Installation
Never, under any circumstances, make
any changes or connections that are not
shown in this handbook. Failure to follow
the connection instructions that are given
in the handbook may create serious safety
hazards for people and for the installation.
Do not change the wiring in the product
as it is supplied to you. Failure to follow
this instruction may create serious safety
hazards for people and for the installation,
and will also invalidate the guarantee.
Keep a connection diagram for future
reference.
7.1 Connecting the cables to the
base
Insert the cables into the cable glands holding the
base at about 20cm from the support. Tighten the
cable glands. The cable glands are suitable for cables
with a diameter between 5mm and 10 mm.
Fig. 8

EN - English - Instructions manual
14 MNVCUCZ_1511_EN
7.2 Fixing the base to the support
Use the screws and the washers supplied
with the base.
After having positioned gasket (01), fasten base (02)
on support (03) using screws (04), toothed spring
washers and the at washers (05). Insert the screw-
sealing OR (06).
01
06
05
04
02
03
Fig. 9
03
01
06
05
04
02
Fig. 10
Align the 3 notches on the base with those on the
support as shown in the following gure.
Fig. 11
Apply a thread-locker on the holes of the
screws (Loctite 243®).
Pay attention to the xing. Tightening
torque: 4Nm.
7.3 Connection of the connector
board
7.3.1 Connector board description
BOARD DESCRIPTION
Connector Function
J2 Power supply line
J5/J7 Video output
J10 Telemetry lines
Tab. 1
J2 J7 J5 J10
Fig. 12

Instructions manual - English - EN
15MNVCUCZ_1511_EN
7.3.2 Connection of the power supply
line
Electrical connections must be performed
with the power supply disconnected and
the circuit-breaker open.
When commencing installation make sure
that the specications for the power supply
for the installation correspond with those
required by the device.
Earth cable should be about 10mm longer
than the other two, so that it will not be
disconnected accidentally if pulled.
Make sure that the power source and
connecting cables are suitable for the
power consumption of the system.
The power supply cable should also be
covered by the silicone sheath (01) supplied
for this purpose. The silicone sheath must
be fastened with the corresponding tie (02).
Depending on the version, the device can be
provided with dierent power supply voltages. Their
value is shown on the product identication label (4.2
Product markings, page10).
01
02
N
La
J2
J2
Fig. 13
Connect the power supply cables to the J2 terminal
as described in the table.
CONNECTION OF THE POWER SUPPLY LINE
Colour Terminals
Power supply 24Vac
Dened by the installer N (Neutral)
Dened by the installer L (Phase)
Yellow/Green GND
Power supply 230Vac
Blue N (Neutral)
Brown L (Phase)
Yellow/Green GND
Power supply 120Vac
Blue N (Neutral)
Brown L (Phase)
Yellow/Green GND
Tab. 2
Use a Class 2 listed UL tranformer,
compliant with the Standards in force, only
for products marked UL, powered at 24Vac.
To connect the power supply line use the
appropriate junction-box (UPTJBUL). For
further information, refer to the product
use and installation manual.

EN - English - Instructions manual
16 MNVCUCZ_1511_EN
7.3.3 Signal cable connection
All signal cables must be grouped together
by means of a strap.
Fig. 14
7.3.3.1 Video cable connection
CDS installation type (Cable Distribution
System). The installation is type TNV-1, do
not connect it to SELV circuits.
CAUTION! In order to reduce the risk of re,
only use cable with sections greater than or
equal to 0.13mm² (AWG 26).
The content of this chapter does not apply
to the versions with digital video encoder.
The video signal is present on connectors J5 and J7 of
the board. Only use one connector.
Connector J5: Connect the screen and the central
cable to terminals GND and CVBS respectively.
Connector J7: Connect the coaxial cable to the BNC
connector (not supplied) and then connect it to
connector J7.
The terminals accept cables with sections between
1.5mm² (AWG16) and 0,5mm² (AWG30).
VIDEO OUT
J7
CVBS
J5
GND
RS485-1
SGND
AB
RS485-2
SGND
AB
Fig. 15
7.3.3.2 Telemetry lines connections
CDS installation type (Cable Distribution
System). The installation is type TNV-1, do
not connect it to SELV circuits.
CAUTION! In order to reduce the risk of re,
only use cable with sections greater than or
equal to 0.13mm² (AWG 26).
The content of this chapter does not apply
to the versions with digital video encoder.
The product is supplied with 2 RS-485 serial
communication lines.
TELEMETRY LINES CONNECTIONS
Serial line Terminal Description
RS-485-1 A (+) RS-485 line (1)
B (-) RS-485 line (1)
SGND RS-485-1 line
reference
RS-485-2 A (+) RS-485 line (2)
B (-) RS-485 line (2)
SGND RS-485-2 line
reference
Tab. 3
The lines can be congured in various ways according
to the positions of dip-switches 5 and 6 on the Serial
(DIP 1) of the CPU board (7.6.5 Setting of the serial
communication lines, page21).
VIDEO OUT
J7
CVBS
J5
GND
RS485-1
SGND
AB
RS485-2
SGND
AB
Fig. 16

Instructions manual - English - EN
17MNVCUCZ_1511_EN
7.4 Connection of the secondary
connector board
All signal cables must be grouped together
by means of a strap.
7.4.1 Description of the secondary
board
BOARD DESCRIPTION
Connector Function
J3 Ethernet Connector
J4-J5 Alarms and relay connector
Tab. 4
J4
J5
Fig. 17 Alarms and relay board.
J4
J5
J3
Fig. 18 Alarms, relay and IP video output board.
7.4.2 Connection of the alarm inputs
In case of free contact alarm make the connection as
shown in the gure.
The alarm contacts are present on connector (J4-J5).
A G
Dry contact
Fig. 19
The dry contact alarm can be NO (normally open) or
NC (normally closed).
For further details on conguring and using the
alarms, refer to the related chapter (9.1.12.1 Alarms
Menu, page42).
CONNECTION OF THE ALARM INPUTS, OF THE
TWILIGHT SWITCH AND OF THE RELAYS
Terminal Description
W, G Voltage-controlled liquid level alarm,
referred to G
A1, A2, A3,
A4, A5* e G
Self-powered alarm inputs referred to G
Tab. 5* It can be used as input for the light sensitive switch
(not supplied) used to switch on the LED illuminator.
All alarms have an approximate reach of 200m, which
can be obtained using an unshielded cable with a
minimum section of 0.25mm² (AWG 24).

EN - English - Instructions manual
18 MNVCUCZ_1511_EN
7.4.3 Relay connection
Relays can be used for low working
voltages only (up to 30Vac or 60Vdc) and
with a maximum current of 1A. Use cables
with a section suitable for the load to be
controlled and use cables with a minimum
section of 0.25mm² (AWG 24) and maximum
section of 1.5mm² (AWG 16).
The R1A, R1B, R2A and R2B relay clamps are located
in the J4 connector. Relays do not have polarity and
therefore both terminals A or B of the same relay
can be used, for alternating or continuous current
voltages.
RELAY CONNECTION
Terminal Description
R1A Relay 1, Terminal A
R1B Relay 1, Terminal B
R2A Relay 2, Terminal A
R2B Relay 2, Terminal B
Tab. 6
For further information refer to the relative
chapter (9.1.12.1 Alarms Menu, page42).
7.4.4 Connecting the light sensitive
switch for the LED illuminator
During installation do not look directly at
the illuminator while it is on.
To guarantee correct vision during the day
and the night, it is necessary to correctly set
the sensor.
The light sensitive switch must be
positioned so that it is not hit by the light
beam coming from the illuminator or by
articial lights (such as road lights, car
headlights, etc.).
Fig. 20
