Videotec PELCO MAXIMUS MPX Series User manual

EN
English - Instruction manual
ENGLISH
MAXIMUS MPX SERIES2 (MPXHD)
MAXIMUS MPXL SERIES2 (MPXL)
Flameproof PTZ camera

Instruction manual - English - EN
3MNLCMPXHDC_2222_EN
Contents
ENGLISH 1
1 About this manual....................................................................................................................5
1.1 Typographical conventions ................................................................................................................................................ 5
2 Notes on copyright and information on trademarks............................................................5
3 Safety rules ...............................................................................................................................6
4 Product description and type designation............................................................................9
4.1 Range of use............................................................................................................................................................................. 9
4.2 Specific use conditions ........................................................................................................................................................ 9
4.3 Gas Group, Dust Group and Temperatures.................................................................................................................. 9
4.4 Characteristics of installable devices.............................................................................................................................. 9
4.5 Cable entry............................................................................................................................................................................. 10
4.5.1 Stopping plug.........................................................................................................................................................................................10
4.6 Product marking................................................................................................................................................................... 11
4.7 For UL/CSA standard reference only............................................................................................................................. 12
4.8 Model identification............................................................................................................................................................14
4.8.1 Day/Night camera.................................................................................................................................................................................14
4.8.2 Day/Night camera with LED illuminator ......................................................................................................................................15
5 Preparing the product for use...............................................................................................16
5.1 Unpacking...............................................................................................................................................................................16
5.2 Contents ..................................................................................................................................................................................16
5.3 Safely disposing of packaging material.......................................................................................................................16
6 Installation..............................................................................................................................16
6.1 Installation options.............................................................................................................................................................. 16
6.1.1 Fixing to parapet or ceiling mount .................................................................................................................................................17
6.1.2 Fixing with wall mount bracket.......................................................................................................................................................17
6.1.3 Fixing with corner adaptor module or pole................................................................................................................................18
6.1.4 Sunshield mounting.............................................................................................................................................................................18
6.2 Opening of the connections compartment............................................................................................................... 19
6.3 Connector board description.......................................................................................................................................... 19
6.4 Ground connection.............................................................................................................................................................20
6.4.1 Earthing equipotential connection................................................................................................................................................20
6.4.2 Connection of the safety earthing.................................................................................................................................................20
6.5 Connecting the power supply ........................................................................................................................................20
6.6 Connecting alarms, remote reset and relays............................................................................................................. 21
6.6.1 Connecting an alarm with dry contact.........................................................................................................................................22
6.6.2 Remote Factory Default connection.............................................................................................................................................22
6.6.3 Relays connection.................................................................................................................................................................................22
6.7 Ethernet connection...........................................................................................................................................................22
6.7.1 Connection via RJ45 .............................................................................................................................................................................22
6.7.2 Connection via SFP...............................................................................................................................................................................22
6.8 Installations according to UL/CSA standards ............................................................................................................23
6.9 Connection compartment closing ................................................................................................................................24
7 Switching on ...........................................................................................................................25

EN - English - Instruction manual
4 MNLCMPXHDC_2222_EN
8 Configuration..........................................................................................................................25
8.1 Default IP address ................................................................................................................................................................25
8.2 Web interface ........................................................................................................................................................................25
8.2.1 First access to the web pages...........................................................................................................................................................25
9 Instructions for normal operation........................................................................................26
9.1 Enabling the LED illuminator ...........................................................................................................................................26
10 Maintenance .........................................................................................................................26
10.1 Routine maintenance .......................................................................................................................................................26
10.1.1 Inspecting the cables.........................................................................................................................................................................26
10.1.2 Replacing the gasket..........................................................................................................................................................................26
10.1.3 Replacement of the wiper blade...................................................................................................................................................27
10.2 Extraordinary maintenance...........................................................................................................................................27
10.2.1 Fuse replacement................................................................................................................................................................................27
10.2.2 Factory Default....................................................................................................................................................................................28
11 Cleaning ................................................................................................................................28
11.1 Routine cleaning.................................................................................................................................................................28
11.1.1 Cleaning the glass window ..............................................................................................................................................................28
11.1.2 Cleaning the product.........................................................................................................................................................................28
12 Information on disposal and recycling ..............................................................................29
13 Troubleshooting...................................................................................................................29
14 Technical data.......................................................................................................................30
14.1 MAXIMUS MPX SERIES2 (MPXHD) ................................................................................................................................30
14.1.1 General ....................................................................................................................................................................................................30
14.1.2 Mechanical.............................................................................................................................................................................................30
14.1.3 Electrical..................................................................................................................................................................................................30
14.1.4 Network...................................................................................................................................................................................................30
14.1.5 I/O interface...........................................................................................................................................................................................30
14.1.6 Video ........................................................................................................................................................................................................31
14.1.7 Cameras...................................................................................................................................................................................................31
14.1.8 Environment..........................................................................................................................................................................................32
14.1.9 Certifications .........................................................................................................................................................................................32
14.1.10 Certifications - Explosion-proof applications.........................................................................................................................32
14.2 MAXIMUS MPXL SERIES2 (MPXL)..................................................................................................................................33
14.2.1 General....................................................................................................................................................................................................33
14.2.2 Mechanical............................................................................................................................................................................................33
14.2.3 Electrical.................................................................................................................................................................................................33
14.2.4 Network..................................................................................................................................................................................................33
14.2.5 I/O interface..........................................................................................................................................................................................33
14.2.6 Video........................................................................................................................................................................................................33
14.2.7 Cameras..................................................................................................................................................................................................34
14.2.8 Illuminators...........................................................................................................................................................................................34
14.2.9 Environment .........................................................................................................................................................................................34
14.2.10 Certifications ......................................................................................................................................................................................35
14.2.11 Certifications - Explosion-proof applications........................................................................................................................35
15 Technical drawings...............................................................................................................36

Instruction manual - English - EN
5MNLCMPXHDC_2222_EN
1 About this manual
Read all the documentation supplied carefully
before installing and using this product. Keep the
manual in a convenient place for future reference.
This document has been compiled and published
using product descriptions and specifications
available at the time of publication. The contents
of this document and the specifications of the
products discussed herein are subject to change
without notice. Pelco Inc. reserves the right to make
any such changes without notice. Neither Pelco Inc.
nor any of its affiliated companies: (1) guarantees
the completeness or accuracy of the information
contained in this document; or (2) is responsible for
your use of, or reliance on, the information. Pelco Inc.
shall not be responsible for any losses or damages
(including consequential damages) caused by
reliance on the information presented herein.
For greater certainty, the use of "manufacturer" in
this manual means "VIDEOTEC s.r.l.".
1.1 Typographical conventions
DANGER!
Explosion hazard.
Read carefully to avoid danger of
explosion.
DANGER!
High level hazard.
Risk of electric shock. Disconnect the
power supply before proceeding with any
operation, unless indicated otherwise.
DANGER!
Mechanical hazard.
Risk of crushing or shearing.
DANGER!
Hot surface.
Avoid contact. Surfaces are hot and may
cause personal injury if touched.
DANGER!
Emission of visible light or infrared.
Can be harmful for eyes. Pay attention to
the provided indications.
CAUTION!
Medium level hazard.
This operation is very important for the
system to function properly. Please read
the procedure described very carefully
and carry it out as instructed.
INFO
Description of system specifications.
We recommend reading this part carefully
in order to understand the subsequent
stages.
Underlined titles
Information is subject to certifications.
2 Notes on copyright and
information on trademarks
The mentioned names of products or companies are
trademarks or registered trademarks.
Pelco, the Pelco logo, and other trademarks
associated with Pelco products referred to in this
publication are trademarks of Pelco, Inc. or its
affiliates.
ONVIF® is a trademark of Onvif, Inc.
Other names or logos mentioned herein may be the
trademarks of their respective owners.
The absence of the symbols ™ and ® in proximity to
each trademark in this document or at all is not a
disclaimer of ownership of the related trademark.
Covered by one or more claims of the patents listed
at patentlist.hevcadvance.com.

EN - English - Instruction manual
6 MNLCMPXHDC_2222_EN
3 Safety rules
DANGER!
Explosion hazard.
Read carefully to avoid danger of
explosion.
• Installation and maintenance of the appliance
must be carried out by specialist technical staff
in compliance with the applicable reference
standard EN/IEC 60079-14, EN/IEC 60079-17 and
national standards.
• Do not open the device when powered and in
explosive atmosphere.
• Use appropriate tools for the installation. The
particular nature of the site where the device is to
be installed may mean special tools are required
for installation.
• Make all connections, installation and
maintenance work in a non-explosive
atmosphere.
• The equipotential connection is mandatory to
avoid the risk of ignition of products installed in
potentially explosive environments.
• This device must be connected to an earth
conductor (protective earth). This connection
must only be performed through the power
line connector. External equipotential bonding
connections must also be performed but only for
supplementary bonding connection to earth, and
required by local codes or authority.
• Before powering the product in an explosive
atmosphere, ensure the cover is closed correctly.
• The temperature of the surfaces of the device
is increased by exposure to direct sunlight.
The surface temperature class of the device
was determined only with ambient ambient
temperature, without taking into consideration
direct sunlight.
• Make sure that all the equipment are certified for
the application and for the environment in which
they will be installed.
• Any change that is not expressly approved by the
manufacturer will invalidate the warranty.
DANGER!
High level hazard.
Risk of electric shock. Disconnect the
power supply before proceeding with any
operation, unless indicated otherwise.
• Make sure that the power is off when installing or
carrying out maintenance, with the circuit-breaker
open.
• A power disconnect device must be included
in the electrical installation, and it must be very
quickly recognizable and operated if needed.
• The electrical system to which the unit is
connected must be equipped with a 16A max
automatic bipolar circuit breaker. The minimum
distance between the circuit breaker contacts
must be 3mm (0.1in). The circuit breaker must
be provided with protection against the fault
current towards the ground (differential) and the
overcurrent (magnetothermal).
• Be careful not to use cables that seem worn or old.
• The device can only be considered to be
switched off when the power supply has been
disconnected and the connection cables to other
devices have been removed.
• All the cables must comply with IEC60332-1-2, IEC
60332-1-3 and IEC/EN60079-14.
• When commencing installation make sure that
the specifications for the power supply for the
installation correspond with those required by the
device.
• For continued protection against risk of fire,
replace only with same type and rating of fuse.
Fuses must be replaced only by service personnel.
• This equipment is not suitable for use in locations
where children are likely to be present.
DANGER!
Mechanical hazard.
Risk of crushing or shearing.
• Hazardous moving parts. Keep fingers and other
body parts away.
DANGER!
Hot surface.
Avoid contact. Surfaces are hot and may
cause personal injury if touched.
• During normal operation the surface of the
illuminator can reach high temperatures. Do not
allow direct contact and position the appliance
where it is inaccessible to unauthorised persons.
Before touching, switch off the illuminator and
allow to cool for a minimum period of 10 minutes.

Instruction manual - English - EN
7MNLCMPXHDC_2222_EN
DANGER!
Emission of visible light or infrared.
Can be harmful for eyes. Pay attention to
the provided indications.
• Do not stare at the lamp when on. Can be harmful
for eyes.
• CAUTION! The infrared LED illuminator emits high-
intensity visible light. In compliance with standard
EN62471/IEC62471, the photobiological safety
assessment has classified the device in Risk Group
2, where it exceeds the values of the Exempt
Group. The risk linked to the observer depends on
how the product has been installed and is used.
For installation, follow the instructions in this
manual. Do not look directly at the illuminator
using optical lenses. Exposure hazard values
(EHV): 30.1s. Hazard distances (HD): 200mm.
• CAUTION! The white LED illuminator emits visible
high intensity light. In compliance with standard
EN62471/IEC62471, the photobiological safety
assessment has classified the device in Risk Group
2, where it exceeds the values of the Exempt
Group. The risk linked to the observer depends on
how the product has been installed and is used.
For installation, follow the instructions in this
manual. Do not look directly at the illuminator
using optical lenses. Exposure hazard values
(EHV): 33.3s. Hazard distances (HD): 200mm.
CAUTION!
Medium level hazard.
This operation is very important for the
system to function properly. Please read
the procedure described very carefully
and carry it out as instructed.
• Make sure that the installation complies with local
regulations and specifications.
• Make connections and tests in the laboratory
before carrying out installation on site.
• Check that the power supply socket and cable are
adequately dimensioned.
• Use suitable cables that can withstand the
operating temperatures.
• All disconnected cables must be electrically
isolated.
• The system can be installed only in a standard or
inverted position (ceiling mount).
• Make sure the product is to be secured to building
before operation.
• At start up the system makes some automatic
calibration movements: do not stand near the
device when it is powered.
• The manufacturer declines all liability for damage
to any of the apparatus mentioned in this
handbook, when resulting from tampering, use of
non-original spare parts, installation, maintenance
and repairs performed by non-authorised, non-
skilled personnel.
• For technical services, consult only and exclusively
authorized technicians.
• This product must only be repaired by suitably
trained personnel or under the supervision of
VIDEOTEC personnel in accordance with the
foreseen terms and conditions: IEC/EN60079-19.
• Only use original VIDEOTEC. Strictly adhere to
the maintenance instructions attached to each
replacement kit.

EN - English - Instruction manual
8 MNLCMPXHDC_2222_EN
INFO
Description of system specifications.
We recommend reading this part carefully
in order to understand the subsequent
stages.
• Given the considerable weight of the system, use
an appropriate transport and handling system.
The staff must carry out the handling of the
product in compliance with the common accident
prevention standards.
• Before proceeding with installation, check the
supplied material to make sure it corresponds
to the order specification by examining the
identification labels.
• Equipment is intended for installation in restricted
access area.
• The manufacturer declines all responsibility
for any damage caused by an improper use
of the appliances mentioned in this manual.
Furthermore, the manufacturer reserves the right
to modify its contents without any prior notice.
The documentation contained in this manual has
been collected and verified with great care. The
manufacturer, however, cannot take any liability
for its use. The same thing can be said for any
person or company involved in the creation and
production of this manual.
• Since the user is responsible for choosing the
surface to which the unit is to be anchored, we
do not supply the fixing devices for attaching the
unit firmly to the particular surface. The installer
is responsible for choosing fixing devices suitable
for the specific purpose on hand. Use methods
and materials capable of supporting at least 4
times the weight of the device.
• Contact the manufacturer for information on the
dimensions of the flameproof joint.
• For all maintenance interventions, we recommend
you return the product to the laboratory that will
perform all required operations.
• This device is remotely controlled and may change
position at any time. It should be installed so that
no one can be hit by moving parts. It should be
installed so that moving parts cannot hit other
objects and create hazardous situations.
• This is a Class A product. In a domestic
environment this product may cause radio
interference. In this case the user may be required
to take adequate measures.
• To comply with the main supply voltage dips and
short interruption requirements, use a suitable
Uninterruptible Power Supply (UPS) to power the
unit.
• This device was designed to be permanently
secured and connected on a building or
on a suitable structure. The device must be
permanently secured and connected before any
operation.

Instruction manual - English - EN
9MNLCMPXHDC_2222_EN
4 Product description and
type designation
The MAXIMUS MPX series is a range of
electropolished AISI316L steel PTZ cameras that can
be installed in potentially explosive environments.
The MAXIMUS MPX series is equipped with a NPT or
metric cables entry according to the model.
The MAXIMUS MPX series has an IP66/IP68/
IP69 degree of protection and can be installed in
environments with temperatures from -40°C to
+80°C (check the marking for each model available).
Versions are available with: visible camera, thermal
camera, visual and thermal camera, visible camera
with LED illuminator (IR or visible light).
4.1 Range of use
The unit is designed for use in a fixed location, for
surveillance of areas classified as zone 1-21 and zone
2-22 with potentially explosive atmospheres.
The unit has been built and certified in compliance
with directive 2014/34/UE and with the international
standards IECEX, which define its range of
application and minimum safety requirements.
4.2 Specific use conditions
Contact the manufacturer for information on the
dimensions of the flameproof joint.
Ambient temperature and Surface temperature – see
instructions.
Care shall be taken to prevent accumulation of
electrostatic charges. See installation instructions.
The unit can be only installed in standard or inverted
position.
4.3 Gas Group, Dust Group and
Temperatures
The device is certified for the IIC group (Gas) and the
IIIC group (dust).
The temperature class, the maximum surface
temperature and the temperature of the cables
entry depend on the characteristics of the installable
devices (dissipated power, Watt) and the ambient
temperature.
The features are specified for each model in its
specific chapters.
4.4 Characteristics of installable
devices
All the internal components must be installed inside
by the manufacturer.

EN - English - Instruction manual
10 MNLCMPXHDC_2222_EN
4.5 Cable entry
The product is supplied with plastic caps for
cable entry protection. They cannot be used for
installation.
Unused cable entries must be closed using
appropriate Ex certified locking devices with "db"
and "tb” explosion protection, suitable for the use
conditions and installed correctly.
All cable glands shall be Ex certified, as appropriate,
with protection type "db" and "tb", suitable for the
conditions of use and installed correctly.
When conduit is used, a suitable Ex certified
stopping box shall be used, as appropriate, with
protection type "db" and "tb", suitable for the
conditions of use and installed correctly.
The stopping box must be fitted within 50mm
(1.97in) from the enclosure entry.
The cable entry temperatures are specified in the
marking.
To maintain the IP level of product use cable glands
with appropriate IP level and apply to threads a
sealant compliant with standard IEC/EN60079-14.
4.5.1 Stopping plug
The stopping plug supplied is not KCs
certified.
With the product, an Ex certified stopping plug
is supplied with “db” and “tb” explosion-proof
type protection. Thread sealant is also supplied, in
compliance with IEC/EN60079-14, the use ensure the
IP degree.
The stopping plug installation instructions are
available on https://peppers.co.uk.
Fig. 1

Instruction manual - English - EN
11MNLCMPXHDC_2222_EN
4.6 Product marking
1
7
9
11
52 3
10 86
4
14
12
13
13
12
Fig. 2
1. Manufacturer’s name and address.
2. Model.
3. The serial number consists in 12 numeric
characters, the second and third digits
define the last two numbers of the year of
manufacture.
4. Electrical characteristics (voltage V, frequency
Hz, current A, power W).
5. Number, dimension and type of cable entries.
6. Cable entry temperature.
7. Warnings.
8. The number of the accredited body that
provides the quality assessment.
9. ATEX marking. The Class temperature depends
on the electronics installed inside and the
ambient temperature.
10. IECEx marking. The Class temperature depends
on the electronics installed inside and the
ambient temperature.
11. IP protection degree.
12. T Class (Tx or Tx...Tx).
13. Maximum surface temperature (Tx°C or Tx°C...
Tx°C).
14. Ambient temperature (-40°C ≤ Ta ≤+TX°C, -40°C
≤ Ta ≤ TX°C or TX°C, -40°C ≤ Ta ≤ TX°C or TX°C
or TX°C).
Example of marking:
EXAMPLE DATA
Dissipated power in
housing (W)
T Class Maximum surface tem-
perature
Cable entry temperature Ambient temperature
7T4 T135°C 90°C -40°C ≤ Ta ≤ 80°C
T6…T5 T85°C…T100°C 80°C -40°C ≤ Ta ≤ 60°C or 70°C
T6…T4 T85°C...T135°C 90°C -40°C ≤ Ta ≤ 60°C or 70°C
or 80°C
Tab. 1

EN - English - Instruction manual
12 MNLCMPXHDC_2222_EN
4.7 For UL/CSA standard reference only.
The flameproof joints are not intended to be repaired.
CAUTION! Hazardous moving parts. Keep fingers and other body parts away.
The appliance includes moving parts. Make sure that the unit is positioned where it is
inaccessible under normal operating conditions. Attach the warning label supplied with the
appliance, placing it near the unit so that it can be seen easily.
Fig. 3
In the USA, the National Electrical Code (NEC) and in Canada the Canadian Electrical Code (CEC)
apply to electrical equipment used on hazardous industrial premises.
Important safety instructions
WARNING: DO NOT OPEN WHEN AN EXPLOSIVE ATMOSPHERE IS PRESENT.
AVERTISSEMENT: NE PAS OUVRIR EN PRÈSENCE D'UNE ATMOSPHÉRE EXPLOSIVE.
WARNING: POTENTIAL ELECTROSTATIC CHARGING HAZARD - SEE INSTRUCTIONS.
AVERTISSEMENT: DANGER POTENTIEL DE CHARGES ÈLECTROSTATIQUES - VOIR INSTRUCTIONS.
WARNING: A SEAL SHALL BE INSTALLED WITHIN 50MM OF THE ENCLOSURE.
AVERTISSEMENT: UN SCELLEMENT DOIT ÊTRE INSTALLÉ À MOINS DE 50MM DU BOÎTIER.
In installations according to UL/CSA standards, installation is compulsory of the separator provided as
indicated in the relevant chapter (6.8 Installations according to UL/CSA standards, page 23).
Fig. 4

Instruction manual - English - EN
13MNLCMPXHDC_2222_EN
1
6
78
11
5
2 3
10
9
9 89 8
4
Fig. 5
1. Manufacturer’s name and address.
2. Model.
3. The serial number consists in 12 numeric
characters, the second and third digits
define the last two numbers of the year of
manufacture.
4. Electrical characteristics (voltage V, frequency
Hz, current A, power W).
5. Number, dimension and type of cable entries.
6. Warnings.
7. Ambient temperature (-40°C ≤ Ta ≤+TX°C, -40°C
≤ Ta ≤ TX°C or TX°C, -40°C ≤ Ta ≤ TX°C or TX°C
or TX°C).
8. T Class (Tx or Tx...Tx).
9. Maximum surface temperature (Tx°C or Tx°C...
Tx°C).
10. Cable entry temperature.
11. Level of protection Type.
Connections
The choice of connection must comply with local legislation in force.
Cable glands: select a cable gland in compliance with UL2225 with the following protection AEx db IIC and/or
AEx tb IIIC and C22.2 with the following protection Ex db IIC and/or Ex tb IIIC in compliance with the marking
of the product.
Conduit: it is necessary to install a sealing device within 50mm of the product input when the conduit is used.
Regulation references:
UL 60079-0, 7th Edition, Explosive Atmospheres - Part 0: Equipment – General requirements
UL 60079-1, 7th Edition, Explosive Atmospheres - Part 1: Equipment Protection by Flameproof Enclosures “d”
UL 60079-31, 2nd Edition, Explosive Atmospheres - Part 31: Equipment Dust Ignition Protection by Enclosure
“t”
CSA C22.2 No. 60079-0:19, Explosive Atmospheres - Part 0: Equipment - General requirements
CSA C22.2 No. 60079-1:16, Explosive Atmospheres - Part 1: Equipment Protection by Flameproof Enclosures “d”
CSA C22.2 No. 60079-31:15, Explosive Atmospheres - Part 31: Equipment Dust Ignition Protection by Enclosure
“t”

EN - English - Instruction manual
14 MNLCMPXHDC_2222_EN
4.8 Model identification
4.8.1 Day/Night camera
MAXIMUS MPX SERIES2  CONFIGURATION OPTIONS
Voltage Camera Temperature class and ambient tempe-
rature
Options
MPXHD 1230Vac 5Pelco® Day/Night 30X zoom, Full HD camera ET6...T5 -40°C/+55°C or +70°C 0Without accessories 00C
224Vac SWith SD CARD
3120Vac
5220Vac
6100Vac
Tab. 2MAXIMUS MPX SERIES2 (MPXHD)
MAXIMUS MPX SERIES2  CERTIFICATIONS AND MARKINGS
Part number Certification Marking Ambient temperature Cable entry temperature
MPXHD*5E0**C ATEX II 2 G Ex db IIC T6...T5 Gb
II 2D Ex tb IIIC T85°C...T100°C Db
-40°C ≤ Ta ≤ +55°C or +70°C 80°C
IECEx Ex db IIC T6...T5 Gb
Ex tb IIIC T85°C...T100°C Db
EAC Ex 1Ex db IIC T6...T5 Gb X
Ex tb IIIC T85°C...T100°C Db X
INMETRO Ex db IIC T6...T5 Gb
Ex tb IIIC T85°C...T100°C Db
KCsEx db IIC T6...T5 Gb
Ex tb IIIC T85°C...T100°C Db
UK Ex II 2 G Ex db IIC T6...T5 Gb
II 2D Ex tb IIIC T85°C...T100°C Db
Hazardous Location America Class I, Zone 1, AEx db IIC T6...T5 Gb
Zone 21, AEx tb IIIC T85°C...T100°C Db
Class I, Div 2, Group A, B, C, D T6...T5
Class II, Div 2, Group F and G T6...T5
80°C with Ta = 69°C
81°C with Ta = 70°C
Hazardous Location Canada Ex db IIC T6...T5 Gb X
Ex tb IIIC T85°C...T100°C Db X
Class I, Div 2, Group A, B, C, D T6...T5
Class II, Div 2, Group F and G T6...T5
Tab. 3MAXIMUS MPX SERIES2 (MPXHD)

Instruction manual - English - EN
15MNLCMPXHDC_2222_EN
4.8.2 Day/Night camera with LED illuminator
MAXIMUS MPXL SERIES2  CONFIGURATION OPTIONS
Voltage Day/Night camera Illuminator Lens Temperature class and ambient temperature Accessories
MPXL 1from 220Vac up to
230Vac
5Pelco® camera,
Day/Night 30X
zoom, FullHD
8850nm 2Spot,
Wide
FATEX - IECEx - INMETRO - EAC Ex - KCs - UK Ex
T6...T4 -40°C/+50°C or +60°C or +70°C
cULus
T5...T4 -40°C/+40°C or +60°C
0Without accessories 00C
224Vac Wwhite
light
SWith SD CARD
3120Vac
6100Vac
Tab. 4MAXIMUS MPXL SERIES2 (MPXL)
MAXIMUS MPXL SERIES2  CERTIFICATIONS AND MARKINGS
Part number Certification Marking Ambient temperature Cable entry temperature
MPXL1582F0**C, MPXL2582F
0**C, MPXL3582F0**C
ATEX II 2G Ex db IIC T6...T4 Gb
II 2D Ex tb IIIC T85°C...T135°C Db
-40°C ≤ Ta ≤ +50°C or +60°C
or +70°C
(T6/T85°C with Ta ≤ +50°C)
(T5/T100°C with Ta ≤ +60°C)
(T4/T135°C with Ta ≤ +70°C)
+80°C with Ta ≤ +60°C
+90°C with Ta ≤ +70°C
IECEx Ex db IIC T6...T4 Gb
Ex tb IIIC T85°C...T135°C Db
EAC Ex 1Ex db IIC T6...T4 Gb X
Ex tb IIIC T85°C...T135°C Db X
INMETRO Ex db IIC T6...T4 Gb
Ex tb IIIC T85°C...T135°C Db
KCsEx db IIC T6...T4 Gb
Ex tb IIIC T85°C...T135°C Db
UK Ex II 2G Ex db IIC T6...T4 Gb
II 2D Ex tb IIIC T85°C...T135°C Db
UL Hazardous Location
America
Class I, Zone 1, AEx db IIC T5...T4 Gb
Zone 21, AEx tb IIIC T100°C...T135°C Db
Class I, Div 2, Group A, B, C, D T5...T4
Class II, Div 2, Group F, G T5...T4
-40°C ≤ Ta ≤ +40°C or +60°C
(T5/T100°C with Ta ≤ +40°C)
(T4/T135°C with Ta ≤ +60°C)
+80°C
UL Hazardous Location
Canada
Ex db IIC T5...T4 Gb X
Ex tb IIIC T100°C...T135°C Db X
Class I, Div 2, Group A, B, C, D T5...T4
Class II, Div 2, Group F, G T5...T4
Tab. 5MAXIMUS MPXL SERIES2 (MPXL)

EN - English - Instruction manual
16 MNLCMPXHDC_2222_EN
5 Preparing the product for
use
Before carrying out any type of
maintenance, read the "Safety rules"
chapter carefully in the product manual.
5.1 Unpacking
When the product is delivered, make sure that the
package is intact and that there are no signs that it
has been dropped or scratched.
If there are obvious signs of damage, contact the
supplier immediately.
When returning a faulty product we recommend
using the original packaging for shipping.
Keep the packaging in case you need to send the
product for repairs.
5.2 Contents
Check the contents to make sure they correspond
with the list of materials as below:
• Flameproof PTZ camera
• Sunshield (2 for MAXIMUS MPXL SERIES2)
• Silicone sheath
• O-ring replacement part kit, hexagon socket set
screws
• Stopping plug
• Sealant
• Cable ties
• Separation barrier for installations according to
UL/CSA standards
• Instruction manual
5.3 Safely disposing of packaging
material
The packaging material can all be recycled. The
installer technician will be responsible for separating
the material for disposal, and in any case for
compliance with the legislation in force where the
device is to be used.
6 Installation
Before carrying out any type of
maintenance, read the "Safety rules"
chapter carefully in the product manual.
PELCO strongly recommend to test the device
configuration and performance before putting it in
the final installation site.
6.1 Installation options
It is possible to install the unit with several brackets.
We strongly recommend using only approved
brackets and accessories during installation.
The system can be installed only in a standard or
inverted position (ceiling mount). When installed
for inverted operation, the camera orientation and
controller functions are reconfigured for normal
operation through the system’s software.
Hardware adjustment is not required for inverted
operation.
Fig. 6

Instruction manual - English - EN
17MNLCMPXHDC_2222_EN
6.1.1 Fixing to parapet or ceiling mount
Fix the adaptor (01) to the bottom of the unit using
the 4 flat countersunk screws (02) with hexagonal
socket M10x20mm in stainless steel (A4 class 70)
supplied.
Make sure the thread are free of dirt and debris.
Apply a generous amount of thread locking
compound (Loctite 270) into the threaded holes in
the base of the device.
Pay attention to the fixing. Tightening
torque: 35Nm.
The thread compound must cure for one hour, allow
for this period prior to completing the installation.
01
02
Fig. 7
Use the external holes in the adapter to fix the
assembled unit to the parapet or to the ceiling. Use
screws that can bear at least 4 times the weight of
the unit.
Ø 11
8
Ø 238
Ø 200
35°
35°
35°
35°
Fig. 8
6.1.2 Fixing with wall mount bracket
The bracket can be fixed to the vertical wall. Use
screws and wall fixing devices that can bear at least
four times the weight of the unit.
Then, fix the device to the bracket using the 4 flat
washers, the 4 spring washers in stainless steel and
the 4 hexagonal head screws in stainless steel (A4
class 70) supplied (M10x20mm).
Fig. 9
Make sure the thread are free of dirt and debris.
Apply a generous amount of thread locking
compound (Loctite 270) on the 4 screws.
Tighten the screws.
Pay attention to the fixing. Tightening
torque: 35Nm.
The thread compound must cure for one hour, allow
for this period prior to completing the installation.

EN - English - Instruction manual
18 MNLCMPXHDC_2222_EN
6.1.3 Fixing with corner adaptor
module or pole
To install the product on the corner adaptor module
or pole, first of all fasten the support bracket.
Fig. 10
To fasten the support bracket, use the 4 flat washers,
the 4 elastic washers in stainless steel and the 4
hexagonal head screws in stainless steel (A4 class 70)
M10x30mm supplied.
Make sure the thread are free of dirt and debris.
Apply a generous amount of threadlocker (Loctite
270) on the 4 threaded holes on the adaptor module.
Tighten the screws.
Pay attention to the fixing. Tightening
torque: 35Nm.
The thread compound must cure for one hour, allow
for this period prior to completing the installation.
To fix the device to the bracket, consult the relevant
chapter (6.1.2 Fixing with wall mount bracket, page
17).
6.1.4 Sunshield mounting
Remove the protective film before the
sunshield installation (if present).
Apply a generous amount of thread locking
compound (Loctite 270) into the threaded holes in
the base of the device.
Fix the sunshield to the housing using the screws
and washers screwed into the upper body of the
housing.
The thread compound must cure for one hour, allow
for this period prior to completing the installation.
Fig. 11
Pay attention to the fixing. Tightening
torque: 2Nm.

Instruction manual - English - EN
19MNLCMPXHDC_2222_EN
6.2 Opening of the connections
compartment
The safety grub screw is used to prevent
the unscrewing of the threaded cover from
the connection compartment. Remove the
security grub screw before unscrewing the
threaded cover.
The bottom of the unit has no.2 3/4” NPT cable
entries (or M25 special version).
To install the connections, remove the safety grub
screw (01) using a male 1.5mm hex key, the threaded
cover (02) (30mm hex nut) and the plastic plugs (03).
The plastic plugs are only used for shipping
purposes and should not be used during operation.
02 01
03
03
Fig. 12
By unscrewing the threaded lid, the connectors are
accessed.
6.3 Connector board description
BOARD DESCRIPTION
Connector Function Terminals - Nomi-
nal section of the
cables used
J1 Power supply line from 0.2mm²
(24AWG) up to
2.5mm² (13AWG)
J6 Alarms, Remote
reset and serial line
from 0.2mm²
(24AWG) up to
1.0mm² (17AWG)
J8 Relay from 0.2mm²
(24AWG) up to
1.0mm² (17AWG)
F1 Fuse –
F2 Fuse –
P1 Reset push-button –
RJ45 Ethernet Connector –
SFP SFP connector –
Tab. 6
P1 F2
RJ45
SFP
J6
J1
F1
J8
Fig. 13

EN - English - Instruction manual
20 MNLCMPXHDC_2222_EN
6.4 Ground connection
6.4.1 Earthing equipotential connection
The equipotential connection must be carried out
using an external cable with a minimum 4mm²
section (11AWG).
Connect the cable for the earthing equipotential
connection with the eyelet terminal supplied
(suitable for cables with 4mm² (11AWG) up to 6mm²
(9AWG) section).
Fasten the eyelet using the M5 screw and lock
washer supplied.
Characteristics of the M5 screw:
• Material: A4 Class 70
• Screw head: ISO 4762
• Length: 8mm (0.3in)
Fig. 14
6.4.2 Connection of the safety earthing
The earthing cable must be connected to the
internal connector (J1, 6.3 Connector board
description, page 19).
6.5 Connecting the power supply
Depending on the version, the device can be
provided with different power supply voltages. The
power supply voltage is indicated on the product
identification label.
Earth cable should be about 10mm longer
than the other two, so that it will not be
disconnected accidentally if pulled.
The ground conductor should be equal or
greater in section than the section of the
power supply cables.
The power supply cable must be covered
by the silicone sheath (01) supplied.
The silicone sheath must be fastened
with the corresponding cable tie (02).
For installations according to UL/CSA
standards, pass the power supply cable
through the cables input on the left (03), as
indicated in the figure.
If using the PELCO multipolar cable and
a fibre optic cable, you are advised to use
the left cables input (03) for the multipolar
cable and the right cables input (04) for the
fibre optic.
02
01
03 04
Fig. 15
Extract the removable power line connector from
the connector board (J1, 6.3 Connector board
description, page 19).
Connect the electrical power cables as indicated in
the relevant table (Tab. 7, page 21).
