Videx DINPAD-M User manual

1DINPAD-M
DINPAD-M
These low profile multiprotocol keypads are designed to fit a
UK single gang electrical back box and are available in 6
different colour finishes.
The DINPAD-M has a selectable Wiegand output (26, 30, 34
and 40 bit) and is compatible with Portal Plus.
9mm
80mm
80mm
Technical Characteristics
Operating Voltage: 12V dc
Current consumption: Max 70mA
Output: Wiegand (26, 30, 34, 40 bit), Clock & Data
or Codix
IP rating: IP40
Housing: ABS
Mounting: UK electrical flush back box (single gang)
Wiring: Terminal block
Operating temperature: -20°C to +50°C
Note: Wall mount box not supplied!
Mounting
User Manual

2DINPAD-M
DINPAD-M
Terminals
Connection to DINMTPX
proximity reader
12v DC
12v DC
GND
Ground
Codix
Codix output
D1 / data
Wiegand output (D1) or data
D0 / clock
Wiegand output (D0) or clock
LED Green -
Green LED -
LED Red -
Red LED -
Tamper
Tamper (clean contact)
Tamper
Wiring
Portal Plus (Wiegand) -
MST
T2A/250V
S
C
PS
E
RU
Earth
screw
RS 485 A RS 485 B
Reader 2
Ac. Granted LED
Ac. Denied LED
GND
12V Out
D0
D1
Reader 1
Ac. Granted LED
Ac. Denied LED
GND
12V Out
D0
D1
GND
12vdc
Door Sensor2
Door Sensor1
GND
Exit Button2
Exit Button1
GND
Door 1 Door 2
NO
NC
NO
NC
Com
Com
TAMPER
LR- LG-
D0 D1
COD GND +12
max. 50m
LED Status
Green LED
Externally controlled
Red LED
Externally controlled
Orange LED
Key press and Menu
Resetting master code
1. Disconnect power
2. Press and hold “A” and reconnect power
3. Hold the “A” key for at least 3 seconds.

3DINPAD-M
DINPAD-M
When DINPAD-M is connected to EWS Controller, settings must be done
in the PROS Software and in the DINPAD-M Keypad.
Example:
Create a User to access with Card or PIN Code. The Card Number is
8744987 and the PIN Code 12345.
Settings in the PROS Software
1. In the PROS Software, right click on the Reader and select properties.
In the Properties window select for Type: “DINPAD-M” (1.1)
2. Select the Wiegand 26bit (1.2)
3. Press Save & Exit. In the event window a confirmation message will
appear as shown in fig.2
4. Adjust the PIN Length. Go to Settings/ System parameters. For
Keycode length select 5 digits. (fig3)
5. Go To Users Menu and select the user. In the Field User ID (Card
Number) write 8744987. In the Field ”Keycode” write the PIN Code
12345. Save the User. (fig.4)
Settings in the DINPAD-M
1. Enter the Menu of DINPAD-M. Press B+000000.
2. Press 6, press 4. The Preset, programs the DINPAD-M Keypad to work
with EWS controller in Wiegand 26bit.
3. Adjust the PIN Length. Press 4, then press 5.
4. Exit the Menu with A
Type 12345 and access will be granted.
fig.2
fig.3
fig.4
Test
fig.1

4DINPAD-M
DINPAD-M
Connecting DINPAD-M with DINMTPX
1. Connect both devices with the cable provided.
DINMTPX-M
tamp LR- LG- D1 D0 gnd +12V
2. Connect the DINPAD-M keypad to the controller. The proximity reader is not connected to the controller.
LD16
R55
C28
L2
L11
C18
C33
R9
R45
D13
GND
LD14
R46
ZD3 C29
L9
LD13
R14 ZD4 C32
L7 L1
C27
L6
R32
ZD5
R3 R4
L8
R47
FUSE1
IC8 IC7 ICN2
R1
LD5
C6
FUSE3
+12V
ZD2
LD15
R13
ZD1
D3
R2
+12V
A
+12V
led2
A
D0 D1 led2 D1
A
led1
A
GND led1 D0
GND
R2 R1
Free Led 1
Free Led 2
GND
12V out
D0
D1
Free Led 1
Free Led 2
GND
12V out
D0
D1
Fuse
EWS
max. 50m
DINPAD-M
12V
LED Green -
Codix
D1/ data
D0/ clock
LED Red -
GND
Tamper
Tamper
DINMTPX
3. In the software, in reader’s properties, for type of the reader select LCSP, DINPAD-M.
4. Put the Keypad to work as master unit.
Press B+000000
Press 0
Press 1
Press A to exit
Press B+000000
Press 6
Press 4 (or “3” for Wiegand34)
Press A to exit
5. EWS Mode.

5DINPAD-M
DINPAD-M
0
Master/Slave
selection
1
Master
2
Slave
Entering Menu is always done with B + 000000 if the Master Code is not changed.
Submenu 0 - Master/Slave Selection. 1(Master) when the keypad is connected with proximity reader DINMTPX. Default = 0(Slave)
Submenu 1 - Change Master Code. The Master Code must be 6 digits. After enrolling new Master Code the DINPAD-M automatically exits
the Menu and the new master code must be typed to enter the menu.
Submenu 2 - Select Type of Wiegand. With this the Keypad can be adjusted to send 4 different Wiegand Outputs. The Wiegand selected
must be the same as the controller’s Wiegand Input where the DINPAD-M Keypad is being connected. Example: If you use a controller that
recognizes Wiegand 34bit, then enter the menu of DINPAD-M, press 2, then press 3.
Submenu 3 - Select Output Protocol. The Keypad can send the Code by different Protocols. Use “Single Wiegand” when connected to third
party controllers. When “Single Wiegand” is selected, what is typed on the Keypad the same will be sent as Wiegand Number. Use Double
Wiegand when connected to EWS, use Clock&Data when connected to controller with Clock&Data input, use Codix when connected to Vi200,
EX5, EX7, INOX99 or VKP99.
Submenu 4 - PIN Code Length. If “0” is selected, then any PIN Code with any length can be sent, but the PIN Code is typed with “A” for
confirmation( ex. 123 + A). If 1 to 8 is selected the PIN Code length is determinated by the number selected.
Submenu 5 - Entry Mode. “Only PIN Code” is disabling the proximity and DINPAD-M+DINMTPX works as keypad only. “Only Card” is
disabling the Keypad and DINPAD-M+DINMTPX works as Proximity Reader. “Card and PIN Code” defines the double security, both the Card
and PIN Code is required for the Wiegand to be sent. “Card or PIN Code” enables normal operation.
Submenu 6 - Presets. The Presets are set of preprogrammed parameters for easy programming.
6-1 “Wiegand 26bit Normal” - Type: Wiegand 26bit; Output: Single Wiegand; PIN Length: 4 digits; Entry Mode: Card or PIN Code
6-2 “Wiegand 34bit Normal” - Type: Wiegand 34bit; Output: Single Wiegand; PIN Length: 4 digits; Entry Mode: Card or PIN Code
6-3 “Wiegand 34bit EWS Mode” - Type: Wiegand 34bit; Output: Double Wiegand; PIN Length: 4 digits; Entry Mode: Card or PIN Code
6-4 “Wiegand 26bit EWS Mode” - Type: Wiegand 26bit; Output: Double Wiegand; PIN Length: 4 digits; Entry Mode: Card or PIN Code
6-5 “Codix” - Output: Codix; PIN Length: any length with “A” in the end; Entry Mode: Card or PIN Code
Presets 6-3 and 6-4 to be used always when DINPAD-M is connected to EWS firmware ver.2.42 or higher.
Submenu 7 - Site Code Length. Set the code length sent to Host. Default is “0”. To be used only in specific cases.
Submenu 8 - Enter Site Code. Put the site code always in 5 digit format (ex. 00170).
Submenu 9 - Backlight. Turns ON/OFF the backlight.
Validation OK? No
Yes
Enter “Master Code” B + 000000
Error Beep
(3 short beeps)
1 small beep + 1 long beep + Orange LED is ‘ON’
Press “A” to validate
and exit the menu
(orange LED OFF)
Change
Master Code
1
Enter New
Master Code
Press 6 Digits
2
Select Type of Wiegand
1
Wiegand
26bit
234
Wiegand
30bit
Wiegand
34bit
Wiegand
40bit
3
Select Output Protocol
1 2 34
Single
Wiegand
Double
Wiegand
Clock &
Data
Codix
PIN Code Length
4
01 - 8
for any length
with “A”
in the end
for lengths
between
1 to 8 digits
6
Presets
1 2 34 5
Wiegand
26bit
normal
Codix
Wiegand
34bit
normal
Wiegand
34bit
EWS
Wiegand
26bit
EWS
7
Site Code Length
1 2 34
No Site
Code
Site Code
between
0 to 15
Site Code
between
0 to 255
Site Code
between
0 to 65535
Enter Site
Code
8
5 digits
Backlight
9
0 1
Backlight
OFF
Backlight
ON
5
Entry Mode
1 2 34
only PIN
Code
only
Card
Card and
PIN
Code
Card or
PIN
Code
Direct Menu
exit

6DINPAD-M
DINPAD-M

6DINPAD-M
DINPAD-M

6DINPAD-M
DINPAD-M
