Vielight XPLUS HEAD User manual

USE R GUIDE
G
H
X
PLUS
HEAD / BODY
HEAD
A
B
C
D
E
F
LED module
Middle support
Front support
X-Plus Nasal
applicator
USB-A
power plug
Nasal applicator
plug
Start button
and indicator*
1
X-Plus Head
Module
V3
I
* INDICATOR
Green steady: Device is connected to power source.
Green blinking: Device is in use.
Red blinking: Low power, re-charge power bank.
Power
adapter

K
BODY
Start button
and indicator*
2
N
LED module
M
LBack support
X-Plus Body
Module
JUSB-A
power plug
I
* INDICATOR
Green steady: Device is connected to power source.
Green blinking: Device is in use.
Red blinking: Low power & to re-charge power bank.
Power
adapter

Positioning
USING THE X-PLUS HEAD ON THE CEREBELLUM
3
4
2
1Insert the nasal applicator plug [D] into the socket on the X-Plus
Head Module [H]. Connect the power plug [F] to the Vielight power
adapter [I]. Connect the power adapter to an electrical outlet.
Press the start button [G] to begin a session. The unit switches o
automatically after about 20 minutes.
Place the X-Plus head LED module [C] on the head as shown in the
diagram below.
Insert nasal applicator [E] into either the right or the left nostril with
the clip on the outside and the lens in the nostril.
A
B
C
E
3
RECOMMENDED USAGE
For cerebellum: Use once every
two days.
The X-Plus can be used on various parts of
the body, such as, on the head, thymus
gland and gut.
Position the LED module [C] aligned
with the middle of the ear.
Adjust the supports [A] and [B} by
sliding them along the steel band for
best stability/t.
The length of the band can be
shortened or lengthened by pushing or
pulling the metal band in or out of the
Head module [H].
Insert the X-Plus
nasal applicator
[E] into either the
left or right nostril.

Positioning
Insert the nasal applicator plug [D] into the socket on the X-Plus
Head Module [K]. Connect power plug [J] to the Vielight power
adapter [I].
Place the X-Plus body LED module [N] on the chest or gut, as
shown in the diagram below.
Insert the nasal applicator [E] into either the right or the left
nostril with the clip on the outside and the lens in the nostril.
Press the start button [M] to begin a session. The unit switches o
automatically after about 20 minutes.
USING THE X-PLUS BODY ON THE THYMUS OR THE GUT
3
4
2
1
RECOMMENDED USAGE
Position the LED module on the gut. For
best t, push or pull the metal band.
The length of the band can be
shortened or lengthened by pushing or
pulling the metal band in or out of the
holders.
3 4
For thymus: Use once daily.
For gut: Use once daily.
Insert the X-Plus
nasal applicator
[E] into either the
left or right nostril.
Position the LED
module [M] on the
sternum. The thymus
gland is located just
behind the breast-
bone and between
the lungs.

5
USING THE NASAL
APPLICATOR
Press to widen
clip opening
Rib
Sleeve
Lens
If the applicator does not stay on
the nose, use the blue silicone
sleeve. The sleeve has a smooth
side and a ribbed side. Use the
ribbed side for a stronger grip.
When using the Vielight X-Plus, users should not experience
any adverse physical sensation. If you experience discomfort,
contact Vielight at [phone] (North America),
[email protected], or chat at www.vielight.com.
NOTE
1. To clean the Nasal Applicator, wipe gently with 70% alcohol or antiseptic wipes,
clean gently with soap and water, or sanitized with a UV lamp.
2. Use a soft, dry cloth to clean the other surfaces. Do not use abrasive cleaners.
3. Do not submerge any of the components on the headset in liquid or cover with
other material during use.
4. Store in a dry and dust-free location at temperatures between 10oC to 40oC,
away from direct sunlight.
5. We do not recommend sharing devices and nasal applicators as this increases
the risk of spreading infectious diseases.
CARE AND CLEANING

Most people do not experience physical discomfort while using
the X-Plus, although some feeling of warmth is expected.
When powered on,
invisible infrared
light and a faint
red light is emitted
from the diodes of
the LED module.
When
powered on,
a bright red
light is
emitted.
SAFETY ADVICE - LIGHT SOURCE
Nasal
applicator
LED
module
6
Caution: Do not
stare at the lights.
LED Specications:
Light source, LED module: 810 nm LED, 20 mW (for application to head)
Light source, LED module: 810 nm LED, 50 mW (for application to body)
Light source, nasal applicator: 633 nm LED (6.5 mW)
General Specications:
Treatment duration: Automatic shut-o at 20 +/- 0.1 minutes
Low power indicator: < 4.2 V
Power adapter: AC Input: 100-240 V, 0.5 A, 50/60 Hz
DC Output: 5 V, 2.0 A
SPECIFICATIONS

7
REF X-Plus
Follow the instructions
in the user guide.
DANGER
!
Optical Radiation
Apertures
Do not stare directly
at the IR sources
Wavelength: 810 nm
Danger:
Device emits
optical
radiation.
Caution:This device
operates using repeated
exposure to near
infrared radiation (NIR).
IR emitted from this
device may cause eye
irritation.
Do not stare directly at
the IR sources.
Caution: Optical radiation aperture
Interference may occur in the vicinity of known radio frequency (RF)
transmitting devices and equipment marked with the following
symbol.
Do not drop or physically alter the device or provided components.
IR emitted from this product may cause eye irritation. Do not stare
at operating diodes for an extended amount of time.
Read this guide thoroughly before use.
Label for X-Plus Head Label for X-Plus Body
WARNING!
CAUTION!
Model: X-PLUS H3 Manufactured by Vielight Inc.
346A Jarvis St, Toronto, ON, Canada-M4Y 2G6
S/N XP3H-20-XXXXXXXX
X
PLUS
HEAD
Model: X-PLUS B3 Manufactured by Vielight Inc.
346A Jarvis St, Toronto, ON, Canada-M4Y 2G6
S/N XP3B-20-XXXXXXXX
X
PLUS
BODY

8
X-Plus.101020.0
www.vielight.com
®
Vielight Inc.
471 Jarvis Street
Toronto
ON M4Y 2G8
Canada
CISPR 32:2012/
EN 55032:2012
CISPR 24:2012/
EN 55024:2010
(North America) [phone]
[email protected]
Your Vielight X-Plus V3 is warranted to be free of defect in material and workman-
ship under normal use.
This warranty is limited to a period of two years from the purchase date. Within
this period, repairs or exchange of parts that are deemed necessary by the
company will be made free of charge.
This warranty does not cover damage by the following;
a. Misuse, abuse or alteration to the product.
b. Damage caused by accident or neglect.
c. Service or repairs made by unauthorized persons.
LIMITED TWO - YEAR WARRANTY
WE SHALL NOT BE RESPONSIBLE FOR ANY INCIDENTAL, SPECIAL, OR
CONSEQUENTIAL DAMAGES RESULTING FROM THE USE OF THIS PRODUCT.
@
