VIETA VPD770TD User manual

Table of Contents
1
Contents
P2
Safety Precautions
P3-P4
Before Use(Continued)
P1
Table of Contents
P5-P8
Identification of Controls
P5
Main Unit
P6
Battery Pack
P7
Remote control unit
P8-P9
Introduction
Getting Started P8-P11
P9
TFT screen adjust
P12
Playing an Audio CD or MP3/WMA
Basic operation P12-P17
P13
Audio CD and MP3/WMA Disc Features
P13-P14
Playing a JPEG Disc
P14
Playing a DVD VR format Disc
P10-P11
Playing a DVD or Video CD(Operation)
P15
Playing a DIVX Movie Disc
P16
Program playback(not for Picture CD/MP3)
P17-P22
SETUP Menu Setting
P9-P10P9-P10P9-P10
P27-P28
Parameters and specifications
P9-P10
P29
Troubleshooting tips
P9-P10P9-P10
P30
Definition of terms
P8
Insert the battery
P17
General Operation
P17-P19
General Setup Page
Speaker Setup Page
P19
Dolby Digital Setup
P20
Preference Page
P21-P22
P9-P10P9-P10P9-P10
P23-P26
DVB-T Introduction
Auto Scan
Manual Scan
Teletext
EPG
Reserve Channel
P23
P23-P24
P24
P24
P25
Channel Remap
Adjust Channel
OSD
P25
P25-P26
P26

NNotes on Copyrights:
It is forbiddenby law tocopy, broadcast,show,broadcast via
cable, play inpublic, or rentcopyrighted material without
permission.
This product featuresthe copy protectionfunction developed by
Macrovision.Copy protection signalsare recorded onsome discs.
When recording andplaying the picturesof these discspicture
noise will appear.This product incorporatescopyright protection
technology that isprotected by methodclaims of certainU.S.
Patents and otherintellectual property rightsowned by Macrovision
Corporation and otherrights owners.Use ofthis copyright protection
technology must beauthorized by MacrovisionCorporation, and is
intended for homeand other limitedviewing uses only unless
otherwise authorized bymacrovision Corporation. Reverse
engineering or disassemblyis prohibited.
SERIAL NUMBER:
You can find the serial number on the back of the unit.This number
is unique to this unit and not available to others.You should record
requested information here and retain this guide as a permanent
record of your purchase.
Model No. ______________________________
Serial No. ______________________________
Date of Purchase_________________________
Warning:To reduce the risk of electric shock,do not remove
the cover orback of thisproduct.There are nouser-serviceable
parts inside. Referservicing to qualifiedservice personnel.
2
Safety Precautions
Before using the player, please ensure that the local AC voltage is suitable for this unit.
N
Warning: when the unit using by child, parents must make sure
to let thechild understand allcontents in Instructionbook how
battery using toguarantee using batterycorrectly all thetime.
Warning: when find battery overheat, swell or dour, please
stop using batteryand contact servicecentre for getting
replacement.
Warning: do not charging battery on the place of insufficient
ventilation such as:mattress, sofa, cushion, soft mat......
Warning: we will not take any responsibility if user incorrectly
use battery,not following ourwarning instruction labelon the
battery case.
Warning: To reduce therisk of fireor electric shock,do not
expose this productto dripping orsplashing water,rain, or
moisture. Do notplace objects filledwith water such as vases,
on the Product.
Warning: Thisdigital video discplayer employs a laser system.
Use of controls,adjustments,or the performanceof procedures
other than thosespecified herein mayresult in hazardous
radiation Exposure.
Warning: To prevent directexposure to laserbeam,do not open
the enclosure.Visible laserradiation when open.
Warning: Never stare directly into the laser beam.
Caution: Do notinstall this productin a confined space such
as a bookcase or similarunit.
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
charge
over
heat
40 C
strong
impact

The above items are true of not only this unit but also most of the household electronic products.
Before Use(Continued)
3
To ensure proper use of this product, please read this owner's manual
carefully and retain for future reference.
This manual provides information on the operation and maintenance of
your DVD player. Should the unit require service, contact an authorized
service location.
Symbol Used in this Manual
The lightning flash symbol alerts you to the presence of dangerous
voltage within the product enclosure that may constitute a risk of
electric shock.
The exclamation point alerts you to the presence of important
operating and maintenance / servicing instructions.
Indicates hazards likely to cause harm to the unit itself or other
material damage.
Note:
Indicates special notes and operating features.
Introduction
Tip:
Indicates tips and hints for making the task easier.A section whose title
has one of the following symbols is applicable only to the disc
represented by the symbol.
Video CDs
Audio CDs
MP3 Discs
WMA Discs
JPEG Discs
Divx Discs
DVD
VCD
CD
MP3
WMA
JPEG
DIVX
About the Symbol Display
¡° ¡±may appear on your TV display during operation and indicates
that the function explained in this owner's manual is not available on
that specific DVD video disc.
N
N
Storing Discs
After playing,store thedisc in itscase.Do not exposethe disc todirect
sunlight or sourceof heat andnever leave itin a parkedcar exposed
to direct sunlight.
Cleaning Discs
Fingerprints and duston the disccan cause poorpicture quality and
sound distortion. Beforeplaying,clean the discwith a cleancloth.
Wipe the discfrom the centerout.
Notes on Discs
Handling Discs
Do not touchthe playback sideof the disc.Hold the discby the edges
so that fingerprintsdo not geton the surface.Never stick paperor tape
on the disc.
Do not usestrong solvents suchas alcohol,benzine,thinner,
commercially available cleaners,or anti-static sprayintended for older
vinyl records.
DVD and finalized DVD+R/RW

Before Use (Continued)
4
Notes:
Dirty disc may cause bad picture.
This indicates aproduct feature thatis
capable of playingDVD-RW discs
recorded with VideoRecording format.
1.Depending on theconditions of therecording equipment orthe
CD-R/RW (or DVD-R, DVD +R,DVD-RW, DVD+RW) disc itself,
someCD-R/RW (or DVD-R, DVD +R, DVD -RW,DVD +RW) discs
cannot be playedon the unit.
2.Do not attachany seal orlabel to eitherside (the labeledside or
the recorded side)of a disc.
3.Do not useirregularly shaped CDs(e.g., Heartshaped or
octagonal)since they mayresult in malfunctions.
4.Some playback operationsof DVDs andVideo CDs maybe
intentionally programmed bysoftware manufacturers. Thisunit
plays DVDS andVideo CDs accordingto disc content designed
by the softwaremanufacturer, thereforesome playback features
may not beavailable or otherfunctions may beadded.
Manufactured under licensefrom Dolby Laboratories."Dolby",
"Pro Logic", andthe double-D symbolare trademarks of
Dolby Laboratories.
Region code
This DVD playeris designed andmanufactured for
playback of region"3"encoded DVD software.
This unit canplay only DVDdiscs labeled "3"or "ALL".
Notes on RegionCodes
Most DVD discshave a globewith one ormore numbers in it clearly
visible on thecover. Thisnumber must match your DVD player's
region code orthe disc cannotplay. Ifyou try to play a DVD with
a different regioncode from your player,the message "Check
region Code" appearson the TVscreen.
N
N
3
_________________________________________
_________________________________________
_________________________________________
_________________________________________
_________________________________________
Video CD (VCD)
(8 cm / 12 cm disc)
DVD
(8 cm / 12 cm disc)
Types of Playable Discs
Audio CD
(8 cm / 12 cm disc)
In addition, this unit plays , DVD -R, DVD +R,DVD -RW,DVD +RW,
Kodak Picture CDs, SVCD, and CD-R / CD-RW that contains audio
titles,MP3, WMA,JPEG and DivX files.
RW
C0MPATIBLE

Weak batteries can leak and severely damage the remote control unit.
Identification of Controls
5
Main Unit
1. TFT screen
2. Speakers
3. MODE
Could enter TFT menu to adjust TFT parameter.
4. SOURCE
Press this button,switch to DVD/USB/DVBT.
5. SETUP
6. MENU(DVD only)
7. (Left/right/up/down)
Select an item in the menu.Enter confirms menu selection.
8. /TTX
Stop key in DVD mode,TTX key in DVB mode.
9. /EPG
Play/pause(DVD only).Electronic program guide menu in DVB mode..
10.Open
11.Power ON/OFF switch
12.DC in
connect the AC adapter
13.AV-IN/OUT switch
14.Headphone out jacks
15.AV JACK
16.Digital Audio out(coaxial)
17.Volume control
18.DC IN 9-12V
19.Power Indicator
20.ANT
21.USB input
1111
1212
1313
1414
1515
1616
1717
1818
1919
2020
2121
2222
4433
11
66
55
77
88
99
1010
Could adjust channel in DVB mode.
Could adjust Volume in DVD and DVB mode.

6
Identification of Controls
Battery Pack
22
33
11
Detaching the batterypack to separatethe battery pack,pull
the switch whichis locate besidethe battery packthen slide
down the battery pack at thesame time.
Charge the batterypack before usingit for thefirst time.
Attaching the batterypack
1.Match the hooksof the batterypack into theholes on the
bottom of theplayer.
2.Combine the batterypack to pushup until youcan
hear the clicksound.
1.Power charge indicatorduring recharging ,indicator is red.If
recharging is complete,charge indicator changesto green.
2.Remote sensor.
3.Battery pack.
12
3
RELEASE
N
Warning:
For production safety, This DVD player was designed current protection.
When you chargingbattery, andwhen DVD player is power on ,the charging
mode is SLOW , when DVD player is power off, thecharging mode is FAST .
The indicator turnsto green whencharging completed.
Note: In SLOW charging mode ,charge time isapproximate twenty hours.
In FAST charging mode, chargetime is approximate four hours.
"" ""
""
""

111414
1818
88
1111
2222
1515
1919
2020
99
1010
1313 2525
1616
77
66
2323
2424
1717
1212
55
2121
SOURCE
STEP
SUBTITLE ANGLE/
TTX AUDIO PBC/
SCAN
TITLE
MODE
SETUP
REPEAT
/DEL
TV/
RADIO
PRO/
EPG DISPLAY /FAV /PROT
Turn off the power and keep AC cord pulled out from the outlet when connecting the systerm.
7
Remote control unit
Identification of Controls
GO TO MUTE
22
33
44
2626
2727
1.POWER
Switches Player ONand OFF.
2.0-9 NUMBER BUTTON
Selects numbered itemsin a menu.
.TITLE
Return to DVDtitle menu.
6.ENTER
Confirms menu selection.
8.ZOOM
Enlarges video image.
9.REPEAT/DEL
Repeat chapter,track, title allin DVD mode.
Delete channel inDVB mode.
10.TV/RADIO(DVB only)
Switch TV andRadio channels.
11. PRO/EPG
Place a trackon the programlist in DVDmode.
EPG(Electronic program guide)in DVB mode.
3.SUBTITLE
Selects a subtitlelanguage.
4.ANGLE/TTX
Selects a DVDcamera angle if available
in DVD mode.Teletext key in DVBmode.
5
7.SETUP
Accesses or removessetup menu.
12.DISPLAY
Accesses On-Screen display.
16.10+ BUTTON
Add 10+ whileyour selection is more
than10.
17. PBC/SCAN
PBC on/off switchin DVD mode .
Scan key inDVB mode.
18.AUDIO
Selects an audiolanguage.
19. PLAY/PAUSE ( )
Starts playback orpause playback(DVD only).
20. STOP ( )
Stops playback(DVD only).
21.MODE
Set LCD parameter.(adjust bightness.
con trast,color and 4:3 or 16:9 mode).
22.MENU
Accesses menu ona DVD disc.
(Left/right/up/down)or set PBCon or off
on a VCDdisc.
23. Reverse Skip( )
Go to previouschapter / track or to the
beginning(DVD only).
24. Forward Skip( )
Go to thenext chapter /track(DVD only).
25. /PROT
Fast forward inDVD. Set protect
channel in DVBmode.
26.MUTE
Disable Audio output.
27.GO TO
Goto time point, title orchapter you want.
13. /FAV
Fast backward inDVD .Set favourite
channel in DVBmode.
14.SOURCE
Press the buttonswitch to DVD/DVBT/USB.
15.SETP
Step to motion.
ZOOM MENU

Identification of Controls
8
Insert the battery
Refer to thedrawing, take theback cover ofthe remote controloff
and remove theempty battery receptacle.
Prior to shipping,a separating filmwas applied to the battery.
Remove this film.
Insert the batteryinto the receptacleand insert thereceptacle into
the remote.
For the bestresults,aim the remotetowards at theplayer's receiving
window. Staywithin 15 feetand angles of60 degrees orless.
Under normal usethe battery willlast for oneyear.
Remove battery duringstorage or whenyou are not using the DVD
player for along time.
Introduction
Getting Started
DVD+R/RW
DVD -R andDVD +R aretwo different standardsfor recordable DVD
drives and discs.This format allowsinformation to be recorded onto
the DVD disconly once. DVD +RW and DVD-RW are two standards
for re-writable media,meaning the DVD content can be erased and
re-recorded. Single-sided discs can hold 4.38 gigabytes and
double-sided discs holdtwice as much.There are no dual layer
single sided recordablediscs.
VCD (Video CD)
A VCDholds up to74 minutes (650 MB disc) or 80 minutes (700 MB
disc) of MPEG-1full-motion video along with quality stereo sound.
MPEG
MPEG is aninternational standard for video and audio compression.
MPEG-1 is usedin encoding video for VCD and provides for
multichannel surround sound coding such as PCM, Dolby Digital,
and MPEG audio.
MP3
MP3 is apopular compression format used for digital audio files that
yields very highnear-CD quality.
WMA
Windows media audiofile. Atype of coding / decoding developed by
Microsoft Corp.
JPEG
Joint Pictures ExpertGroup. JPEG is a compressed file format that
allows you tosave images with no limit on the number of colors.
DIVX
Divx is thename of arevolutionary new video codec.which is based
On the newMPEG-4 compression standard for video.You will be
able to playDivx movies using this DVD player.
1.Open the batterydoor. 2.Insert twoAAA sizebatteries.
12

Weak batteries can leak and severely damage the remote control unit.
Title (DVD videodiscs only)
A titleis generally adistinct section ofa DVD disc.For example the
main feature couldbe title 1,a documentary describinghow the film
was made couldbe title 2,and cast interviewscould be title3. Each
title is assigneda reference numberenabling you tolocate it easily.
Chapter (DVD videodiscs only)
A chapteris a segmentof a titlesuch as ascene in afilm or one
interview in aseries. Each chapteris assigned achapter number,
enabling you tolocate the chapteryou want. Dependingon the disc,
chapters may notbe recorded.
PBC: Playback Control(Video CD only)
Playback control isavailable for VideoCD (VCD) version 2.0 disc
formats. PBC allowsyou to interactwith the systemvia menus,
search functions, orother typical computer-likeoperations.
Moreover, stillpictures of highresolution can beplayed if theyare
included in thedisc. Video CDsnot equipped with PBC (Version 1.1)
operate in thesame way asaudio CDs.
Track
A distinctelement of audiovisualinformation, such asthe picture or
sound track fora specific language(DVD), or amusical piece ona
video or audioCD. Each trackis assigned atrack number,enabling
you to locatethe track youwant. DVD discsallow one trackof
video (with multipleangles) and severaltracks ofAudio.
Getting Started
Introduction
9
If you wantto adjust theeffect of TFT you canuse the"MODE"and
" "on thepanel."BRIGHTNESS" "CONTRAST" "COLOR"and
"SCREEN MODE":16:9 /4:3 are adjustable.
Note:
1.If you wantto adjust TFT's effect.while using external video you
must set themachine to"video output"state and adjust the parameter
and then setit to "videoin"state.
2.If you wantto set theparameter to defaultvalue.you can gointo
"setup"menu and set the "Default" option.See "set defaultsetting".
TFT screen adjust
N

Getting Started
Playback Setup
1. turn onthe power switchat the left side of the product.
2. Press OPENto open thedisc tray and insert your chosen
disc in thetray, withthe playback side down.
3. Close thetray. Playbackwill start automatically.
Use the buttonsto select thetitle/chapter you want to
view, thenpress ENTER tostart.Press MENU to return to the
menu screen.
Use the numberbuttons to select the track you want to view and
press MENU toreturn to the menu screen. Menu settings and
operating procedures maydiffer.Follow theinstructions on the
each menu screen.
Notes:
1.If parental controlis set and the disc isn't fit for the rating
setting you mustinput the password.(See "parental" on page 22).
2.DVDs may havea region code.Your player does not play
discs that havea region code different from yourplayer.
3.Unless stated otherwise,all operations described use the
remote control.Some featuresmay also be available on the
setup menu.
Playing a DVD or Video CD(Operation)
VCD
DVD
N
Most of the functions can be controlled by remote control unit.Most of the functions can be controlled by remote control unit.
10
Specifications and design are subject to change without prior notice.
Most of the functions can be controlled by remote control unit.Most of the functions can be controlled by remote control unit.
DVD VCD
Moving to anotherCHAPTER/TRACK
When a titleon a dischas more thanone chapter ora disc has
more than onetrack, you canmove to anotherchapter/track as
follows:
1.Press SKIP or briefly during playbackto select the next
(or previous)chapter/track orto return tothe beginning ofthe current
chapter/track.
2.Press SKIP twicebriefly to step back to the previous
chapter/track.
3.Togo directly toany chapter duringDVD playback, inputthe
chapter/track number .
Changing the Audio Channel
Press AUDIOrepeatedly during playbackto hear adifferent audio
channel (Stereo, Left,or Right).
Repeat
You can play a title/chapter/all/track on a disc repeatedly.
Press REPEATduring playback toselect a desiredrepeat mode.
VCD
DVD VCD

Getting started
11
DVD Video Discs- "Repeat Chapter / Title/Off"
Chapter: repeats thecurrent chapter. Chapter
Title: repeats the current title.
All : repeatsall the trackson a disc.
Off : doesnot play repeatedly.
Video CDs, discs- "Repeat Track /All/Off"
Track : repeats the current track
All : repeatsall the trackson a disc.
Off : doesnot play repeatedly.
Notes:
1.On a VideoCD with PBC, you must set PBC to Off to use the
repeat function.
2.If you pressSKIP ( or ) once duringRepeat Chapter(Track)
playback, the repeatplayback cancels
Zoom
Use zoom toenlarge the videoimage:
1.Press ZOOM duringplayback or stillplayback to activatethe
Zoom function. Thesquare frame appears briefly in the right bottom
of the picture.
2. Each pressof the ZOOMbutton changes theTV screen inthe
following sequence:
3. Use the buttons to movethrough the zoomedpicture.
4. To resume normal playback, press ZOOM button until screen
becomes 1X.
Note:Zoom may notwork on some DVDs.
Playing a DVD or Video CD(Operation)
N
DVD VCD
N
MENU
1. Press MENU.Ifthe current titlehas a menu,the menu appearson
the screen. Otherwise,the disc menumay not appear.
2. The MENUoffers features suchas camera angles,spokenlanguage
and subtitle options,and chapters forthe title.
3. Press MENUto exit.
Camera Angle
If the disccontains scenes recordedat different cameraangles, you
can change toa different cameraangle during playback. Press
ANGLE repeatedly duringplayback to selecta desired angle.Note
that the numberof the currentangle appears onscreen.
.
Note:
The angle indicatorwill blink onthe TV screenduring scenes
recorded at differentangles as an indication that angle switching is
possible.
Changing the Audio Language
Press AUDIOrepeatedly during playbackto hear adifferent audio
language or audiotrack.With DVD-RW discsrecorded in VR mode
that have botha main anda Bilingual audiochannel, you can
switch between Main(L), Bilingual (R),or a mixof both (Main+
Bilingual) by pressingAUDIO.
Subtitles
Press SUBTITLE repeatedlyduring playback tosee the different
subtitle languages.
DVD
DVD
DVD
N
TITLE button
DVD disc:
Press TITLE button, then the DVD menu or titles available on the disc
will be displayed. Then you can use " " and ENTER button to select
programs.
Special DVD FeaturesChecking the contentsof DVD discs:
Menus DVDs may offermenus that allow you to access special
features. To use the disc menu, press MENU. Input the
corresponding number oruse the buttonsto highlight
your selection.Then pressENTER.
DVD

Basic operation
12
File names shouldhave a maximum of 8 letters and must incorporate
an" .mp3" or" .wma" extension.
They should notcontain special letters such as "/? * : < > l "etc.
The total numberof files on one disc should be less than 650.
This DVD playerrequires discs and recordings tomeet certain
technical standards inorder to achieve optimal playback quality.
Pre-recorded DVDs areautomatically set to these standards. There
are many differenttypes of recordable disc formats(including CD-R
containing MP3 orWMA files) and these require certain pre-existing
conditions (see above)to ensure compatible playback.
Customers should notethat permission is required in order to
download MP3 /WMA files and music from the Internet. Our company
has no rightto grant such permission. Permission should always be
sought from thecopyright owner.
WMA
MP3
WMA
MP3
MP3 WMA
MP3 WMA
Disc
The DVD playercan play CDand MP3/WMAformatted recordings
on CD-R,CD-RW,DVD+Rand DVD+RW discs.
Audio
Once anAudio CD isinserted it willbe played automatically. Its
playblack information willbe show onscreen,such as chapter
elapse time.
/
1. Press to select a folder, and pressENTER to see the folder
contents.
2. Press to select a trackthen press PLAY or ENTER. Playback
starts.
/ disc compatibilitywith this playeris limited as
follows:
1.Sampling frequency: within8 - 48kHz( ),within 32- 48kHz
( ).
2.Bit rate: within8 - 320kbps( ),32 - 192kbps( ).
The player cannotread an / file that hasa file
extension other thanMP3/WMA.
CD-R physical formatshould be ISO9660.
If you recordMP3/ WMAfiles using softwarethat cannot create
a file system(eg. Direct-CD) itis impossible toplayback MP3/WMA
files.We recommend thatyou use Easy-CD Creator,which creates
an ISO 9660file system.
CD
MP3 WMA
Audio CD and MP3/WMA Disc Features

13
Pause
1. Press PLAY/PAUSE duringplayback.
2. To return to playback, press PLAY/PAUSE again.
Moving to anotherTrack
1. Press SKIP( or ) briefly during playback to go to the next
(or previous) trackor to returnto the beginning of the currenttrack..
2. Press SKIP twice briefly togo back tothe previous track.
3. You can playany track byinputting its number.
Repeat Track/Folder/All/Off
You can play a track/folder/all on a disc.
1. Press REPEAT when playing a disc. Therepeat icon appears.
2. Press REPEAT to selecta desired repeatmode.
Track: repeatsthe current track.
Folder: repeats thecurrent folder.
All: repeatsall the trackson a disc.
Off(No display): normalplayback.
Note:
If you pressSKIP ( )onceduring Repeat Track playback,
the repeat playbackcancels.
Repeat A-B
1.Torepeat a sequenceduring disc playbackpress A-Bat your
chosen starting point.The Repeat icon"A"appear on the menu
screen.
2.Press A-Bagain at yourchosen end point.TheRepeat icon
"AB" appear onthe menu screen,and the sequencebegins to
play repeatedly.
3.Toexit the sequenceand return tonormal play,pressA-B
again.The Repeat icondisappears from themenu screen.
WMA
MP3
CD
WMA
MP3
CD
WMA
MP3
CD
CD
N
Basic operation
Slide Show
There are 16types for slideshow.
You can press Program repeatly to select the slide show Mode.
Still Picture
1. Press PLAY/PAUSE during slide show.The player will now go into
PAUSE mode.
2. To return to the slide show, press PLAY/ PAUSEagain.
Viewing a JPEGDisc
Using this DVDPlayer you canview Kodak PICTURE CDs and discs
with JPEG files.
1.Insert a discand close thetray. The file menu appears on the TV
screen.
2. Press toselect a folder, and pressENTER. Alist of files in the
folder Appears.If you are in a file list and want to return to the
previous Folder list,use the buttons on the remote to highlight and
press ENTER.
3. If youwant to viewa particular file, press to highlight a file and
press ENTER orPLAY. Viewing thefile proceeding starts.
4.If the DISCyou insert isa Kodak Picture CD it will be played
automatically.
NOTE:
Press" " tomove to thenext page , " " to return to previons
folder,and "MENU" return to menu.
Zoom
1.Press 'ZOOM' .
2,Used " "to enlarge,or " " to shorten the picture.
JPEG
JPEG
JPEG
N
Playing a JPEG Disc
Playing an Audio CD or MP3/WMA

To rotatepicture
Press or duringshowing a pictureto rotate thepictureclockwise or
counter clockwise.
To listento MP3/WMA music watching picture
You can display files while listering to MP3/WMA music files
recorded on thesame disc.
1.select a MP3/WMAdesired.
2.select a picture.
JPEG disc compatibilitywith this playeris limited as follows:
1.Depending upon thesize and numberof JPEG files,it could take
a long timefor the DVDplayer to readthe disc¡¯s contents. If you
don¡¯t see anon screen display after several minutes, some of the
files may betoo large reducethe resolution of the JPEG filesto
less than 2Mpixels as 2760x 2048 pixelsand burn anotherdisc.
2.The total numberof files andfolders on thedisc should beless
than 650.Some discsmay be incompatibledue to a different
recording format orthe condition ofdisc.Ensure that allthe
selected files havethe." jpg" extensionswhen copying intothe CD
layout. If thefiles have. "jpg"or. "jpeg"extensions, please rename
them as."jpg" file.Filenames without."jpg" extensionwill not be
able to beread by thisDVD player.Even though thefiles are shown
as JPEG imagefiles in WindowsExplorer.
Playing a JPEG Disc
14
JPEG
This unit willplay DVD-R/RW discsrecorded using the DVD-Video
format that havebeen finalized usinga DVD-recorder.
This unit willplay DVD-RW discsrecorded using the Video
recording (VR) format.
1. Insert adisc and closethe tray.TheDVD-VR menu appears on
the TV screen.
2. Press / to select atrack then pressPLAY or ENTER and
playback starts.
What is "CPRM"
CPRM is acopy protection system(with scramble system)only
allowing therecording of'Copy once' broadcastprograms.CPRM
stands for content Protection for RecordableMedia.
This player isCPRM compatible, whichmeans that youcan record
copy-once broadcast programs,but you cannot then make acopy
of those recordings.CPRMrecordings can onlybe made on
DVD-RW discs formattedin VR mode,and CPRM recordings can
onlybe played onplayers that arespecifically compatible withCPRM.
Note:
Unfinalized DVD-R/RW discscannot be played in this player.Some
DVD-VR disc aremade with CPRMdata by DVDRECORDER.
Player does notsupport these kindsof discs anddisplay
"unknown disc".
Playing a DVD VR format Disc
N
Basic operation

15
Using this DVDPlayer you canplay DivX disc.
1. Insert adisc and closethe tray.Thefolder menu appears on the
TV screen.
2. Press to select a folder, and pressENTER. Alist of files in
the folder appears.If you arein a filelist and want to return to the
Folder list,use the or button onthe remote tohighlight or
button and pressENTER.
3. If youwant to viewa particular file,press / to highlighta file
and press ENTERor PLAY.
4. Press STOPto exit.
5.Press NEXT tomove to the next page.
Divx disc compatibilitywith this playeris limited asfollows:
1.Available resolution sizeof the Divx file is under 720x576 (W xH)
pixel.
2.The file nameof the Divx subtitle is available by 56 characters.
3.If there isimpossible code toexpress in theDivx file, it may be
displayed as "_ "mark onthe display.
If the numberof the screenframe is over30 per second,this
unit may notoperate normally.
If the videoand audio structureof recorded fileis not interleaved,
either video oraudio is outputted.
Playable DivX file
".avi ", ".mpg", ".mpeg".
Playing a Divx Movie Disc
Playable Codec format
"DIVX3.xx ", "DIVX4.xx", "DIVX5.xx "
Playable Audio format
"AC3 ", "PCM", "MP3 ","WMA ".Samplingfrequency:
within 8 -48 kHz (MP3),within32 - 48kHz(WMA) Bit rate:
within 8 -320kbps (MP3), 32- 192kbps (WMA)
Basic operation

When this unit is not used, please turn off the power and leave no disc inside. 16
Program playback(not for Picture CD/MP3)
DVD/VCD/CD
The program functionenables you tostore your favouritetracks from
any disc inthe player memory.
1. Press PROGRAM
The program menuappears.
2.Use the numericalkeypad(0-9) to directinput the titles,tracks or
chapters (single tracknumber with digit'0' in front,for example '05').
3.Move the cursorby pressing toselect START.
4. To resume normal playback from programmed playback,Press
PROGRAM and pressSTOP button on the program menu.
Helpful Hint:
- Program canbe activated onlywhen a discis in the DVD player.
- When theprogram menu appears,the setup menusetting is
forbiddened.
Program:TT(06)/CH(- -)
Exit NEXT
TT: CH:
TT: CH:
TT: CH:
TT: CH:
2
3
4
5
TT: CH:
TT: CH:
TT: CH:
TT: CH:
TT: CH:
6
7
8
9
10
TT: CH:
1
Program:TT(06)/CH(- -)
Exit NEXT
TT: 05 CH:01
TT: CH:
TT: CH:
TT: CH:
2
3
4
5
TT: CH:
TT: CH:
TT: CH:
TT: CH:
TT: CH:
6
7
8
9
10
TT: 06 CH:01
1
Start
Program:TT(06)/CH(- -)
Exit NEXT
TT: 05 CH:01
TT: CH:
TT: CH:
TT: CH:
2
3
4
5
TT: CH:
TT: CH:
TT: CH:
TT: CH:
TT: CH:
6
7
8
9
10
TT: 06 CH:01
1
Stop
Basic operation

SETUP Menu Setting
General Operation
1.Press SETUP toenter the Setup Menu.
2.Press ENTER to the next level submenu or confirm your
selection.
3.Press to enterthe submenu or returen to the previous menu
4.Press to highlightthe desired menu.
To exitfrom the menu
Press SETUP The settings will be stored in the player's memory
even if theplayer is switched off.
enter
General Setup Page
The options includedin General Setup page are:"TV DISPLAY",
"ANGLE MARK","OSD LANGUAGE","DIGITAL OUTPUT""CLOSED
CAPTIONS","SCREEN SAVER",Followthe steps below:
1.Press SETUP toenter the setup menu.
2.Press to selectthe 'General Setup page'.
General Operation&General Setup Page
17
TV Display
Set the aspectratio of theDVD Player accordingto the TVyou have
connected.
4:3 PANSCAN
If you havea normal TV and want bothsides of thepicture to be
trimmed or formatted tofit your TVscreen.
4:3 LETTERBOX
If you have a normal TV. In thiscase , awide picture withblack
bands on theupper and lowerportions of the TV screen will be
displayed.
16:9
If you have a wide-screen TV,then you can select the item.
16:9
Wide
4:3
Letter Box
4:3
Pan Scan
1.Press to highlight'TV Display'.
2.Enter its submenuby pressing .
3.Move the cursorby pressing tohighlight the selecteditem.
- - GENERAL SETUP PAGE - -
OSD LANGUAGE
CLOSED CAPTIONS
ANGLE MARK
GO TO GENERAL SETUP PAGE
DITITAL OUTPUT
SCREEN SAVER
Dolby
TV DISPLAY
- - GENERAL SETUP PAGE - -
OSD LANGUAGE
CLOSED CAPTIONS
ANGLE MARK
SCREEN SAVER
Dolby
SET TV DISPLAY MODE
PS 4:3 PANSCAN
4:3 LETTERBOX
16:9
TV DISPLAY
DITITAL OUTPUT

SETUP Menu Setting
General Setup Page
18
ANGLE MARK
Displays current anglesetting information onthe right hand corner
of the TFT screen if available on the disc.
OSD LANGUAGE
You can select your own preferred language seetings.This DVD
system will automaticallyswitch to theselected language whenever
you load adisc.If the languageselected is notavailable on thedisc,
the disc's defaultlanguage will beused instead. TheOSD language
in the systemmenu will remainonce selected.
1.Press to highlight'Angle Mark'.
2.Enter its submenuby pressing .
3.Move the cursorby pressing tohighlight the selecteditem.
On:Enable Angle Mark.
Off:Disable the currentangle setting display.
- - GENERAL SETUP PAGE - -
ON
Dolby
OSD LANGUAGE
CLOSED CAPTIONS
ANGLE MARK
SCREEN SAVER
ENG
ON
ON
SET OSD LANGUAGE
ENGLISH
DANNISH
DUTCH
FINNISH
FRENCH
GERMAN
ITALIAN
PORTUGUESE
1.Press the keysto highlight 'OSDLang'.
2.Enter its submenuby pressing .
3.Move the cursorby pressing the to highlight the selected item.
4.Select a languageand press ENTER.
- - GENERAL SETUP PAGE - -
SET ANGLE MARK
Dolby
ON
OSD LANGUAGE
CLOSED CAPTIONS
ANGLE MARK
SCREEN SAVER
ON
OFF
ENG
ON
ON
PS
TV DISPLAY
CLOSED CAPTIONS
Closed captions aredata that arehidden in thevideo signal ofsome
discs.Captions are differentfrom subtitles because captions hearing
are impaired byshowing the soundeffects(e.g.,"phone ringing" and
" footsteps"),while subtitlesdo not.
Before you selectthis function,please ensurethat the disccontains
closed captions informationand your TVset also has this function.
PS
TV DISPLAY
DITITAL OUTPUT RAW
DITITAL OUTPUT RAW
DIGITAL OUTPUT
You can select the Audio for digital output .Connect the unit to
Amplifier. Thenyou can enjoy the hifi Audio.
- - GENERAL SETUP PAGE - -
ON
Dolby
OSD LANGUAGE
CLOSED CAPTIONS
ANGLE MARK
SCREEN SAVER
ENG
ON
ON
SETUP SPDIF
PS
TV DISPLAY
DITITAL OUTPUT RAW SPDIF/OFF
SPDIF/RAW
SPDIF/PCM
1.Press the keysto highlight 'DIGITAL OUTPUT '.
2.Enter its submenuby pressing .
3.Move the cursorby pressing the to highlight the selected item.
4.Select digital outputmode and enter

SETUP Menu Setting
19
General Setup Page
- - GENERAL SETUP PAGE - -
ON
Dolby
OSD LANGUAGE
CLOSED CAPTIONS
ANGLE MARK
SCREEN SAVER
ENG
ON
ON
SCREEN SAVER
ON
OFF
1.Press to highlight'Screen Saver'.
2.Enter its submenuby pressing .
3.Move the cursorby pressing tohighlight the selecteditem.
On:In STOP,PAUSE orNo DISC mode,if no actions are performed
about 3 minutes,theScreen Saver willbe activated.
Off:Screen Saver isdisabled.
PS
TV DISPLAY
Speaker Setup Page
Speaker Setup Page
The options includedin Speaker Setup Page is 'Downmix'.
1.Press SETUP.
2.Press to select the 'Speaker Setup page'.
DOWNMIX
This options allows you to set the stereo analog output of your
DVD Player.
- - ANALOG AUDIO SETUP PAGE - -
GO TO SPEAKER SETUP PAGE
DOWNMIX
Dolby
- - ANALOG AUDIO SETUP PAGE - -
Dolby
SET DOWNMIX MODE
STEREO
LT/RT
DOWNMIX STR
1.Press the keys to highlight 'Downmix'.
2.Enter its submenu by pressing .
3.Move the cursor by pressing the keys to highlight the selected
item.
LT/RT :Select this option if yourDVD Player is connected to a
Dolby Pro Logic decoder.
Stereo :Select this option when output delivers sound from only
the two front speakers.
SCREEN SAVER
This function isused to turnthe screen saverOn or Off.
1.Press to highlight'Closed Captions'.
2.Enter its submenuby pressing .
3.Move the cursorby pressing tohighlight the selecteditem.
On:Enable Closed Captions.
Off:Disable Closed Captions.
- - GENERAL SETUP PAGE - -
Dolby
CLOSED CAPTION
ON
OSD LANGUAGE
ANGLE MARK
ENG
CLOSED CAPTIONS
SCREEN SAVER
ON
ON
ON
OFF
PS
TV DISPLAY
DITITAL OUTPUT RAW
DITITAL OUTPUT RAW
