ViewSonic NMP599-W-2 User manual

NMP599-W-2
Port Connections
-
Replacement of a battery with an incorrect type that can be defeat a safeguard;
-
Disposal of a battery into fire or a hot oven, or mechanically crushing or cutting of a
battery, that can result in an explosion;
-
Leaving a battery in an extremely high temperature surrounding environment that
canresult in an explosion or the leakage of flammable liquid or gas;
-
A battery subjected to extremely low air pressure that may result in an explosion or
the leakage of flammable liquid or gas.
This device
complies with Industry Canada licence-exempt RSS standard(s). Operation
is subject to the following two conditions: (1) this device may not cause interference,
and (2) this device must accept any interference, including interference that may cause
undesired
operation of the device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil
doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible
d'en compromettre le fonctionnement.
FCC
Radiation Exposure Statement:
This
equipment complies with FCC RF radiation exposure and Industry Canada
RSS
-102 RF exposure limits set forth for an uncontrolled environment. This device and
its antenna must not be co
-located or operating in conjunction with any other antenna
or transmitter. To comply with FCC RF exposure and Industry Canada RSS
-102 RF
exposure
compliance requirements, this grant is applicable to only Mobile Configura-
tions.
The antennas used for this transmitter must be installed to provide a separation
distance of at least 20 cm from all persons and must not be co
-located or operating in
conjunction
with any other antenna or transmitter.
Cet equipement est conforme aux limites d’exposition aux rayonnements enoncees
pour
un environnement non controle et respecte les regles d’exposition aux frequences
radioe lectriques
(RF) CNR-102 de I’IC. Cet equipement doit etre installe et utilize en
gardant une distance de 20 cm ou plus entre le radiateur et le corps humain (a
I’exception
des extremites : mains, poignets, pieds et chevilles).
CAUTION
Risk of explosion if the battery is replaced by an incorrect type
Wait
one-half hour after switching off before handling parts.
NMP599-W-2_QSG_ENG_Rev.1a
Quick Start Guide
T
his printed quick start guide provides a quick walk-through of the setup process. For complete
documentation, please visit
http://www.viewsonic.com/us/support.
Box Content
Mounting and Installation (USB mouse required)
NMP599-W-2
Device
Power adapter
Wi-Fi antenna
HDMI cable
Velcro (2sets)
Power bracket and
micro-SD card bracket
and screw*2
1. Attach the wireless antenna by screwing the antenna clockwise onto the post.
2. Mount the media player to the back of the monitor using the Velcro strips.
i. Separate the Velcro strip into singles.
ii. Attach one strip onto the bottom flat surface
of the media player.
3. Attach the other strip to the surface on the
back of the display.
4. Secure the media player to the display.
5. Connect the HDMI cable and AC adapter.
1. Kensington lock 5. HDMI out 9. USB port 13. Wireless antenna port
2. ADB 6. Power LED 10. Ethernet/PoE
3. Reset 7. USB port 11. DC in
4. Audio out 8. Micro SD 12. Mounting hole (screw spec: M4)
System Setup
1. Device Startup
Plug in the AC adapter to the media player
and it will power on automatically.
Once the user has exited the boot up screen,
users can go through system configurations
in both landscape and portrait orientations.
Device quick
guide
Software quick
guide

Content Management
CARE AND WARNING
How do I interrupt playback and enter setup menu?
Use USB mouse to click and hold one corner of the screen for 10 seconds to exit
playback and enter setup menu.
How do I provide a DEBUG log for a behaving media player to the support team?
Please follow the instructions below to collect the player’s DEBUG log:
1 Prepare a blank USB stick in FAT-32 format.
2 Create a folder name “DEBUG” (case insensitive) in the root of USB stick.
3 Make sure the player is operating (see welcome screen or playing content)
4 Insert the USB stick into player and wait for yellow
dot on upper right corner to stop blinking.
5 Within the “DEBUG” folder, is a folder with a string of number as its name. If
the string of numbers is all zero’s, the debug log has not been collected properly.
Repeat step 1~4 again and make sure to wait until stop blinking.
6 Zip the “DEBUG” folder and send to ViewSonic Support Team.
Please consult the software documentation for information specific to your content
management solution.
Troubleshooting
How to reset the media player to factory default
WARNING: Changes or modifications to this unit not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference when the equipment is operated in a commercial
environment. This equipment generates, uses, and can radiate radio frequencyenergy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to
radio communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correctthe interference at his own expense.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
2. Autoplay Content
When boot up is complete, if the system detects
preloaded content, the loading circle will
appear. Once the loading circle completes,
content will be played. To stop autoplay and
enter “Basic settings” users need to select the
pause button in the center of the loading circle.
3. Basic settings
When boot up is complete and there is no
preloaded contents, the user will see the “Basic
settings” which allows the user to make
configurations or autoplay pre-loaded content.
4. Make configurations
To change media player system language, use
a USB mouse to select “(Current
Language)….” For system configurations,
select “Advanced.”
Important recommended configurations:
1. Set correct time, date and time zone for
properly scheduled playback.
2. Set password to prevent unauthorized
access during setup menu.
3. Set network for establishing network
connection.
5. Set content
Users can set content by clicking “Set Content”
to enter the URL or use the desired content
management system to upload the contents onto
the media player.
Factory resetting the media player will result in the removal of all saved
contents, passwords and configurations in settings. Please refer to the steps
below to complete the media player factory resetting process:
1 Use a pen to press and hold the reset button – do not release until step 4.
2 Insert the power cord.
3 Wait 30 seconds for the system reboot indicates that your data is erased.
4 Release the reset button and the media player will initialize to factory
default state.
Support
Information
