Viking DGVU200 User manual

Viking Installation Guide
Designer DGVU Built-In Gas Cooktops

Table of Contents
Warnings & Important Safety Instructions _______________________________________________3
Dimensions (30”) ____________________________________________________________________6
Dimensions (36”) ____________________________________________________________________7
Specifications _______________________________________________________________________8
Cutout Dimensions __________________________________________________________________9
Downdraft Dimensions ______________________________________________________________9
Clearance Dimensions (Proximity to Cabinets)__________________________________________10
Clearance Dimensions (Wood/Composite or Steel Overlay)______________________________11
Electrical & Gas Requirements _______________________________________________________12
General Information ________________________________________________________________14
Installation_________________________________________________________________________15
LP Conversion __________________________________________________________________16
LP Pressure Regulator Conversion_________________________________________________17
Gas & Electrical Connection ______________________________________________________18
Bracket Installation ______________________________________________________________18
Final Installation ________________________________________________________________18
Final Preparation ___________________________________________________________________19
Performance Checklist ______________________________________________________________19
Service & Registration_______________________________________________________________20

IMPORTANT
• Before beginning, read these instructions
thoroughly and carefully.
• Installation and service must be
performed by a qualified installer, service
agency, or the gas supplier.
•DO NOT remove permanently affixed
labels, warnings, or plates from the
product as this may void the warranty.
• Observe all local and national codes,
requirements and ordinances.
• Installation must conform with local codes
or in the absence of codes, the National
Fuel Gas Code, ANSI Z223.1- latest
edition and the National Electrical Code,
ANSI/NFPA 70- latest edition.
In Canada: Installation must be in
accordance with the current CAN/CGA
B149.1 & 2 Gas Installation codes and with
the current CSA C22.1 Canadian Electrical
Codes Part 1 and/or local codes.
• Installation of any gas-fired equipment
should be made by a licensed plumber.
• A manual gas shut-off valve must be
installed in the gas supply line ahead of
the cooktop in the gas stream for safety
and ease of service.
In Massachusetts: This appliance must be
installed by a licensed plumber or gas-fitter.
A “T” handle manual gas valve must be
installed in the gas supply line to the
appliance.
• Installers should leave these instructions
with the consumer who should retain them
for the local inspector’s use and for future
reference.
3
–Please Read and Follow
Your safety and the safety of others is
very important.
We have provided many important safety
messages in this manual and on your
appliance. ALWAYS read and obey all
safety messages.
This is the safety alert symbol. This
symbol alerts you to hazards that
can kill or hurt you and others.
All safety messages will be preceded by
the safety alert symbol and the word
“DANGER,” “WARNING” or “CAUTION.”
These words mean:
Hazards or unsafe practices
which WILL result in severe personal
injury or death
DANGER
Hazards or unsafe practices
which COULD result in severe personal
injury or death
Hazards or unsafe practices which
COULD result in minor personal injury
or property damage.
All safety messages will identify the
hazard, tell you how to reduce the chance
of injury, and tell you what can happen if
the instructions are not followed.
WARNING
CAUTION

IMPORTANT
4
–Please Read and Follow
FIRE/EXPLOSION
HAZARD
IF THE INFORMATION IN
THIS MANUAL IS NOT
FOLLOWED EXACTLY, A FIRE OR
EXPLOSION MAY RESULT CAUSING
PROPERTY DAMAGE, PERSONAL
INJURY, OR DEATH.
•DO NOT store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
• WHAT TO DO IF YOU SMELL GAS:
–DO NOT try to light any appliance.
–DO NOT touch any electrical switch.
–DO NOT use any phone in your
building.
–Immediately call your gas supplier
from a neighbor’s phone.
–Follow the gas supplier’s instructions.
–If you cannot reach your gas supplier,
call the fire department.
• Installation and service must be
performed by a qualified installer,
service agency, or the gas supplier.
DANGER
CHEMICAL HAZARD
If not installed, operated and
maintained in accordance
with the manufacturer’s
instructions, this product could expose
you to substances in fuel or from fuel
combustion which can cause death or
serious illness and which are known to
cause cancer, birth defects, or other
reproductive harm.
For example, benzene is a chemical
which is part of the gas supplied to the
cooking product. It is consumed in the
flame during combustion. However
exposure to a small amount of benzene
is possible if a gas leak occurs.
Formaldehyde and soot are byproducts
of incomplete combustion. Properly
adjusted burners with a bluish rather
than yellow flame will minimize
incomplete combustion.
WARNING
BURN HAZARD
The use of cabinets for storage above the
appliance may result in a potential burn
hazard. Combustible items may ignite,
metallic items may become hot and
cause burns. If a cabinet storage is to be
provided the risk can be reduced by
installing a range hood that projects
horizontally a minimum of 5” (12.7 cm)
beyond the bottom of the cabinets.
CAUTION Before placing the cooktop into operation,
always check for gas leaks with a soapy
water solution or other acceptable method.
DO NOT USE AN OPEN FLAME TO
CHECK FOR LEAKS.
CAUTION
This appliance shall not be used for
space heating. This information is based
on safety considerations.
WARNING

IMPORTANT
5
–Please Read and Follow
ELECTRICAL GROUNDING
INSTRUCTIONS
The cooktop must be electrically grounded
in accordance with local codes or, in the
absence of codes, with the ANSI/NFPA
No. 70-latest edition. Installation should
be made by a licensed electrician. This
appliance is equipped with a three-prong
grounding plug for your protection against
shock hazard and should be plugged
directly into a properly grounded
receptacle. DO NOT cut or remove the
grounding prong from the plug.
For personal safety, this appliance
must be properly grounded. DO NOT
under any circumstances cut or
remove the third (ground) prong from
the power plug.
WARNING
SITE PREPARATION
It is recommended that a thorough site
inspection be conducted PRIOR to
unpacking and moving this appliance.
WARNING

Dimensions
6
30-3/4”
(78.2 cm)
21”
(53.4 cm)
28-1/8”
(71.4 cm)
18-1/4”
(47.0 cm)
10-3/16”
(27.1 cm)
2”
(5.1 cm)
2”
(5.1 cm)
4”
(10.2 cm)
2-13/16”
(7.2 cm)
Wiring diagram
and rating
plate location
Power
cord Regulator
7-3/16”
(18.4 cm)
30” Gas Cooktop

Dimensions
7
36-3/4”
(93.3 cm)
21”
(53.4 cm)
34-1/8”
(86.6 cm)
18-1/4”
(47.0 cm)
10-3/16”
(27.1 cm)
2”
(5.1 cm)
2”
(5.1 cm)
4”
(10.2 cm)
2-13/16”
(7.2 cm)
W
iring diagram
and rating
plate location
Power
cord Regulator
7-3/16”
(18.3 cm)
36” Gas Cooktop

Specifications
8
Designer Gas Cooktops
Description
DGVU200 DGVU260
Overall width 30-3/4” (78.1 cm) 36-3/4” (93.3 cm)
Overall height from bottom
to top of grate
4” (10.2 cm)
Overall depth from rear 21” (53.3 cm)
Cutout width 28-1/2” (72.4 cm) min. to
29” (73.6 cm) max.
34-1/2” (87.6 cm) min. to
35” (88.9 cm) max.
Cutout height 2-13/16” (7.2 cm)
Cutout depth 19” (48.3 cm) min. to
19-5/8” (49.8 cm)
Gas requirements Accepts standard residential ½” (1.3 cm) I. D. gas service line.
Shipped natural; gas regulator and orifice spuds are supplied with the product.
To field convert from natural or LP/Propane, the orifice spuds and regulator
must be physically changed.
Electrical requirements 120 VAC/60 Hz; 4 ft. (121.9 cm), 3-wire cord with grounded
3-prongplugattachedtoproduct.
Maximum amp usage 2.0 amps
Surface element rating
Left front
Left rear
Center front/rear
Right front
Right rear
15,000 Nat./LP (BTU)
(4.4 Nat./LP (kw))
4,000 Nat./LP (BTU)
(1.0 Nat./LP (kw))
N/A
9,000 Nat./LP (BTU)
(2.6 Nat./LP (kw))
12,000 Nat./LP (BTU)
(3.5 Nat./LP (kw))
15,000 Nat./LP (BTU)
(4.4 Nat./LP (kw))
4,000 Nat./LP (BTU)
(1.0 Nat./LP (kw))
9,000 Nat./LP (BTU)
(2.6 Nat./LP (kw))
12,000 Nat./LP (BTU)
(3.5 Nat./LP (kw))
12,000 Nat./LP (BTU)
(3.5 Nat./LP (kw))
Approximate
shipping weight 35 lb. (13.1 kg) 60 lb. (27.2 kg)

9
C
B
A
C
Note: Based on 24” deep cabinet with 3/4” backsplash.
DGVU200 DGVU260
A 28-1/2” (72.4 cm) min. to
29” (73.6 cm) max.
34-1/2” (87.6 cm) min. to
35” (88.9 cm) max.
B 19” (48.3 cm) min. to
19-5/8” (49.8 cm)
C2-1/2” (6.4 cm)
C
EF
D
A
B
Note: Refer to the downdraft installation instructions.
Downdraft Dimensions
DGVU200 DGVU260
A 29-1/8” (74.0 cm) 34-7/8” (88.6 cm)
B 20-5/8” (52.3 cm)
C27 (68.6 cm) 33” (84.0 cm)
D2-1/4” (5.7 cm)
E1-1/16” (1.1 cm) 15/16” (1.0 cm)
F1-1/16” (1.1 cm) 15/16” (1.0 cm)
Cutout Dimensions

Clearance Dimensions (Proximity to Cabinets)
30” min.
(76.2 cm)
13” max.
(
33.0 cm)
8” min.
(20.3 cm)
18” min.
(45.7 cm)
2-1/2”
(6.35 cm)
2-1/2”
(6.35 cm)
36” min.
(
91.4 cm)
Note: Dimensions shown are for use with
combustible surfaces unless otherwise stated.
Proximity to Side Cabinet Installation
• The cooktop may be installed directly to
existing base cabinets.
• The cooktop CANNOT be installed directly
adjacent to sidewalls, tall cabinets, tall
appliances, or other side vertical surfaces
above 36” (91.4 cm) high. There must be a
minimum of 5” (12.7 cm) side clearance from
the cooktop to such combustible surfaces
above the 36” (91.4 cm) counter height.
• Within the 8” (20.3 cm) side clearance to
combustible vertical surfaces above
36” (91.4 cm), the maximum wall cabinet
depth must be 13” (33.0 cm) and wall cabinets
within this 8” (20.3 cm) side clearance must be
18” (45.7 cm) above the 36” (91.4 cm) high
countertop.
• Wall cabinet above the cooktop must
be a minimum of 30” (76.2 cm) above the
countertop for a full width of the cooktop.
This minimum height requirement does not
apply if a rangehood is installed over the
cooking surface.
• A 120 volt wall receptacle should be
located approximately 6” (15.2 cm) below
the countertop cutout and 12” (30.5 cm)
from the right side of the cutout.
Minimum Clearances from Adjacent
Combustible Construction
• Wall cabinets directly above the product must be
minimum 30” (76.2 cm) above the countertop
• Side 5” (12.7 cm)
• Rear 2-1/2” (6.4 cm) min.
• Within 6” side clearance. Wall cabinets no
deeper than 13” (33.0 cm)
• Must be minimum 18” (45.7 cm) above
countertop
10

11
66”min.
(167.6 cm)
to
72”max.
(182.9 cm)
66”min.
(167.6 cm)
to
72”max.
(182.9 cm)
24”
(61.0 cm)
or
27”
(38.6 cm)
30”
(76.2 cm)
6”
(15.2 cm)
Wood/Composite
or Steel Overlay
Wood/Composite
or Steel Overlay
30”min.
(76.2 cm)
to
36”max.
(91.4 cm)
30”min.
(76.2 cm)
to
36”max.
(91.4 cm)
Wall Installation
Island Installation
Clearance Dimensions (Wood/Composite or Steel Overlay)
The bottom of a standard hood should be
30” (76.2 cm) min. to 36” (91.4 cm) max. above
the countertop. This would typically result in the
bottom of the hood being 66” (167.6 cm) to
72” (182.9 cm) above the floor. These dimensions
provide for safe and efficient operation of the
hood. Refer to the rangehood installation
instructions for additional information.

Electrical & Gas Requirements
Electrical Requirements
There is no connection necessary beyond
plugging the unit into a polarized, grounded,
120 volt, 60 Hz, 15 amp circuit. A minimum of
120 VAC is required for proper operation of gas
ignition systems. DO NOT use a GFI circuit.
This circuit, however, MUST be grounded and
properly polarized. The unit is equipped with
16-3 SPT2 power cord.
Note: If electrical power is not supplied or is
interrupted, the open top burners will have to be
lit manually with a match.
Gas Connection
• The DGVU cooktops are shipped natural gas,
and manufactured for use with natural gas or
LP/Propane gas. Check the rating plate located
on the bottom of the burner box for type of
gas needed.
• To convert to natural gas or LP/Propane gas,
contact a qualified service technician.
• The installer must use a flexible connector of at
least ½” I.D. (1.3 cm) NPT and comply with
ANSI Z21.41 and Z21.69 standards.
IMPORTANT: The gas supply (service) line
must be the same size or greater than the
inlet line of the cooktop. All cooktops use
a 1 /2” (1.3 cm) NPT (Sch40) inlet.
• Sealant on all pipe joints must be resistive to
LP/Propane gas.
Manual shut-off valve:
• The supplied valve must be installed in the
gas service line ahead of the appliance and
regulator in the gas stream. It should be
positioned where it can be reached quickly in
the event of an emergency.
In Massachusetts: A “T” handle type manual
gas valve must be installed in gas supply line to
the appliance.
Pressure regulator:
• The regulator supplied with the DGVU
cooktops must be installed before any gas
connections are made. It is pre-set for use with
natural gas. This must be converted to use with
LP/Propane gas.
• Manifold pressure should be checked with a
manometer. Natural gas requires 5.0” WCP
and LP/Propane requires 10.0” WCP. Incoming
line pressure upstream for the regulator must
be 1” WCP higher than the manifold pressure
in order to check the regulator.
• The regulator used on this cooktop can
withstand a maximum input pressure of 1/2 PSI
(14.0” WCP). If the line pressure is in excess of
that amount, a step down regulator will be
required.
• The manual shut off valve and pressure
regulator on these cooktops must be
disconnected from the gas supply piping
system during any pressure testing of that
system at pressures in excess of 1/2 PSI
(3.45kPa.)
• The cooktop must be isolated from the gas
supply piping system by closing its individual
manual shut-off valve during any pressure
testing of the gas supply piping system at test
pressures equal to or less than 1/2 PSI
(3.45kPa).
IMPORTANT: NEVER refuse old connectors
when installing this cooktop.
Rigid Connections:
• Incoming gas is brought from an intake pipe at
the rear of the unit to the pressure regulator;
then to the manifold pipe for distribution. The
intake pipe and shut-off valve are not supplied.
The intake pipe and the shut-off valve should
be connected to the regulator to complete the
connection.
In Massachusetts: This appliance must be
installed with a 36” (3-foot) long flexible gas
connector.
• The alignment of the valves should be checked
after connecting the cootkop to the gas supply
to be sure the manifold pipe has not been
moved. A misalignment may cause the valve
knob stem to rub on the control panel,
resulting in a gas leak at the valve.
12

13
Rigid Connections (cont.)
• Installer-supplied intake pipes should be
checked visually for any foreign matter before
installing in a service line.
LP/Propane Conversion
The DGVU cooktops are shipped natural gas,
and manufactured for use with natural gas or
LP/Propane gas. Check the rating plate located
on the bottom of the burner box for type of
gas needed.
• To convert to natural gas or LP/Propane gas,
the orifice spuds and regulator must be
physically changed. Gas conversions must be
completed by a qualified service technician.
• The installer must use a flexible connector of at
least ½” I.D. (1.3 cm) NPT and comply with
ANSI Z21.41 and Z21.69 standards.
To convert from both natural to LP/Propane and
LP/Propane to natural a conversion kit is
supplied.
Before placing the cooktop into operation,
always check for gas leaks with a soapy
water solution or other acceptable method.
DO NOT USE AN OPEN FLAME TO
CHECK FOR LEAKS.
CAUTION
Electrical & Gas Requirements
Initial Ignition of Burners
• All cooktops are tested before leaving the
factory. Field adjustments may be necessary for
proper mixture of gas and air for proper
operation. Contact a qualified technician to
make any necessary adjustments.
• The surface burners use electric igniters in
place of standing pilots.
Proper Lighting and Shutdown Instructions
To ignite electric igniters on the surface burners:
1. Turn the knob counterclockwise to any
position.
2. Upon ignition of the surface burner, turn the
knob to the desired position (HI, Med or Low).
3. To shutdown the burner, turn knob clockwise
to the OFF position.
In case of failure, shut the gas OFF using the
installer supplied manual shut-off valve.
Conversion must be performed by a
qualified installer, service agency, or the
gas supplier in accordance with the
manufacturer’s instructions. Failure to
follow instructions could result in serious
injury or property damage.
WARNING
Electrical power and gas must be turned
off prior to conversion.
WARNING

General Information
Electrical Requirement
• A standard 120V/60 Hz, 15 amp circuit,
3-wire ground, 3-prong plug is equipped.
• A minimum of 120 VAC is required for proper
operation of gas ignition systems. The circuit
must be MUST be properly grounded and
polarized.
IMPORTANT: It is recommended to have the
electrical wiring and installation of your
cooktop connected by a qualified electrician.
IMPORTANT: The cooktop must be electrically
grounded in accordance with local codes or, in
the absence of local codes, with the National
Electrical Code, ANSI/NFPA 70 latest edition or
Canadian Electrical Code (CSA).
Surface Burners
Initial Ignition of Burners
• All cooktops are tested before leaving the
factory. Field adjustments may be necessary
for proper mixture of gas and air for proper
operation. Contact a qualified technician to
make any necessary adjustments.
• The surface burners use electric igniters in
place of standing pilots.
To ignite electric igniters on the surface burners:
• Turn the knob counterclockwise to any
position.
• Upon ignition of the surface burner, turn the
knob to the desired position (HI, Med or Low).
• To shutdown the burner, turn knob clockwise
to the OFF position.
• In case of failure, shut the gas OFF using the
installer supplied manual shut-off valve.
Site Preparation
Note: It is recommended that a thorough site
inspection be conducted prior to unpacking and
moving this appliance.
• Confirm available access to adequate power–
see electrical requirements.
• Be sure that the countertop for this appliance
is level and cut according to the cutout
requirements and dimensions–see cutout
requirements and dimensions.
• All wall coverings, countertop and cabinets
around the cooktop should withstand heat up
to 200°F (90° C).
• Keep appliance free from combustible
materials, gasoline, and other flammable
vapors.
Installation Procedure
Remove packaging materials and literature
package from the cooktop before beginning
installation. Remove Installation Instructions
from literature pack and read them carefully
before you begin.
ELECTRICAL SHOCK
HAZARD
Plugintoa3prongoutlet.
DO NOT remove ground prong.
DO NOT useanadapter.
DO NOT use an extension cord.
Failure to follow these instructions can
result in death, fire, or electrical shock.
CAUTION
DO NOT use an extension cord with this
appliance. Such use may result in fire,
electrical shock or other personal injury
WARNING
14

15
2
1
1
22
2
12
Remove the grates and burner caps. Turn the cooktop upside down and place on the
packaged foam top. Note: Make sure there are no loose
objects on the cooktop before turning upside down.
3
Optional Gasket
4
Installation
Peel away the plastic covering and place the gasket
material all the way around the burner flange.
IMPORTANT: Make sure the corners are covered
completely, leaving no air gaps.
Turn the cooktop over and place into
countertop opening.

16
LP Conversion
3
60 105
105
90
105
90115
60
115
4
1
1
1
1
2
Reference chart to determine which injectors are
needed for each burner.
Install and tighten injectors.
5
Replace aluminum flame spreaders.
1
Remove aluminum gas spreaders.
2
2
2
2
2
1
Remove injectors using a 9/32” nut driver.
LP conversion should only be performed
by a qualified service technician
WARNING

17
Unscrew regulator cap.
LP Pressure Regulator Conversion
4
2
1
Replace regulator cap.
5
Test gas pressure. When converting the regulator for different
settings, the function of the regulator must be checked at a pressure at
least 1” WC (249Pa) above the specified manifold pressure.
2
1
2
Disconnect electrical power and shut off gas.
1
3
1
5
2
4
3
Unscrew the plastic conversion plug from the cap
and turn over. Screw plug back into cap with the wide
section away from cap.

18
Place brackets in the slots and lower until the
bracket catches. Use the bolt to tighten the cooktop
to the countertop. Note: There must be a 1” (2.5 cm)
clearance under counter on all four sides of cooktop.
Note: If cabinet construction does not provide
enough clearance for installing brackets on the front
and back of the burner box, install the brackets on
the sides of burner box.
Final Installation
Note: Refer to
“Electrical & Gas
Requirements”
section for
proper
installation
information.
1
Gas & Electrical Connection
Cooktop
Bracket
Countertop
1
Bracket Installation
1
2
2
1
1
1
1
Replace the burner caps and grates.
Note: The narrow edge of grate goes toward center of unit.

19
• New units are cleaned at the factory to remove
any visible signs of dirt, oil, grease, etc.
remaining from the manufacturing process.
Some stainless steel parts may have a plastic
protective wrapper which must be peeled off.
The cooktop should be washed thoroughly
with hot, soapy water and then rinsed and
wiped dry to remove these film residues and
any installation dust or debris before being
used for food preparation.
• All stainless steel body parts should be wiped
regularly with hot, soapy water and with a
liquid cleanser designed for this material if
build-up occurs. DO NOT use steel wool,
abrasive cloths, cleansers, or powders. If it is
necessary to scrape stainless steel to remove
encrusted material, soak with hot, wet cloths to
loosen the material, then use a wood or nylon
scraper. DO NOT use a metal knife, spatula, or
any other metal tool to scrape stainless steel.
Scratches are almost impossible to remove.
A qualified installer should carry out the following
checks:
hCheck top burner
ignition. The low
flame should light at
every port.
hStarting with the left
front burner, turn the
corresponding knob to the HI position–see
drawing for proper flame height.
hRepeat steps for other burners.
1-1/2”
(3.8 cm)
3/8”
(0.95 cm)
Performance Checklist
Final Preparation

20
Service & Registration
Only authorized replacement parts may be used in performing service on the appliance.
All servicing should be referred to a qualified technician.
Contact Viking Range Corporation, 1-888-VIKING1 (845-4641), for the nearest service parts
distributor in your area or write to:
VIKING RANGE CORPORATION
PREFERRED SERVICE
1803 Hwy 82W
Greenwood, Mississippi 38930 USA
The serial number and model number for your appliance can be found by looking under the
cooktop.
Record the following information indicated below. You will need it if service is ever required.
Model number ____________________________________________________________________________________
Serial number _____________________________________________________________________________________
Date of purchase __________________________________________________________________________________
Date installed ______________________________________________________________________________________
Dealer's name _____________________________________________________________________________________
Address ___________________________________________________________________________________________
These installation instructions should remain with the unit
for future reference.
