Viper AS1050R User guide

Use and maintenance
Operating guidelines AS1050R
Disconnect battery charger
and store the cable.
Fill the solution tank with
fresh water and add low foam
detergent according to needs.
The water temperature must
not exceed 40 °C.
Install the squeegee and x it
by using the two knobs.
Adjust squeegee angle and
blade pressure for optimal
water pick-up by turning
the adjustment knob on
the support.
Click One Touch button to
activate all functions
Adjust the maximum
speed with the speed
adjustment dial.
Use buttons to change
cleaning settings from the
dashboard
Turn the main key to on and press the click on button to install the brush
automatically. Deck will lower and brushes turn slowly to attach.
Loosen the two knobs to
remove the side skirt.
To install the brush/pad holder, pull up the metal handle and slide
in the brush/pad holder until it stops against the pins in the proper
position and release the handle. Put back the side skirt
Solution level indicator is on the side of the tank showing current
level. If the solution tank is empty or recovery tank full, an indicator
on the display will show up with sound warning.
During the cleaning job it’s
possible to adjust the solution
ow, the brush pressure,
activiting Eco Mode or Silent
Mode from the dashboard.
October 2020

Local Viper dealer:
Phone number:
SN:
Maintenance
Operating guidelines AS1050R
October 2020
Turn OFF the machine using
the key.
Empty the tank with the hose in the back. Empty and
clean the debris tray in the tank, ush&clean out the
recovery tank.
Empty solution tank.
Check and clean lter (weekly).
With the key turned on press the brush
click off button to remove the brushes/pad
holders for inspection and cleaning.
Park the machine leaving the recovery tank
open.
Take the squeegee off, check and clean
the blades.
Hang the squeegee on the machine to dry.
Connect the battery charger to the
charging inlet on the machine and switch
on the charger.
V112_0019_V1 10/2020
