VIRDI AC1100 User manual

AC1100 User Guide
Version eng-1.10
Copyright 2000 By Union Community Co., LTD.

MiKey AC1100 User guide 2
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
<Revison History>
Version
Date
Description
Firmware Version
1.00
2016-04-24
Initial Release
V1.00.000-010
1.01
2016-05-10
Update
1.02/3
2016-05-31
Update Images
V1.00.000-013
1.09
2017-01-10
Face detection capture image update

MiKey AC1100 User guide 3
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
< Glossary>
Admin, Administrator
-A user who can enter into the terminal menu mode, he/she can register/modify/delete terminal
users and change the operating environment by changing settings.
-If there is no administrator for a terminal, anyone can change the settings. In this regard, it is
recommended to register at least one administrator.
-Caution is required with registration and operation because an administrator has the right to
change critical environmental settings of the terminal.
Authentication Method
-This represents the various types of authentication, including Mobile authentication, Password
authentication, RF (card) authentication or a combination of these methods.
Example: Card or Password: Authentication with Card or Password

MiKey AC1100 User guide 4
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
Contents
<Revison History> .................................................................................................... 2
< Glossary> ............................................................................................................... 3
Contents ................................................................................................................... 4
1. Before use ............................................................................................................. 6
1.1. Safety precautions ................................................................................................. 6
1.2. Specific names of the terminal .............................................................................. 7
1.3. Normal Window Display ........................................................................................ 8
1.3.1. Icons ............................................................................................................... 8
1.3.2. Window Messaging....................................................................................... 10
1.4. Voices in the operation ........................................................................................ 17
1.5. Beep or sound effect in the operation ................................................................ 17
2. Product introduction .......................................................................................... 18
2.1. Product characteristics ....................................................................................... 18
2.2. Product components ........................................................................................... 19
2.2.1. Stand-alone (entrance) ................................................................................. 19
2.2.2. Connected with PC server ............................................................................ 20
2.3. Product specification ........................................................................................... 21
3. Environment setting ........................................................................................... 22
3.1. Checks before setting the environment ............................................................. 22
3.1.1. Entering the admin menu .............................................................................. 22
3.1.2. Administrator authorization ........................................................................... 23
3.1.3. How to enter the menu without administrator authorization ........................... 23
3.1.4. How to save the set values ........................................................................... 24
3.2. Menu composition ............................................................................................... 25
3.3. User management ................................................................................................ 28
3.3.1. Adding User .................................................................................................. 29
3.3.1.1. Photo registration .................................................................................. 30
3.3.1.5. Password registration ............................................................................ 31
3.3.1.6. Card registration .................................................................................... 32
3.3.1.8. Authorization method ............................................................................. 33
3.3.1.9. Save ...................................................................................................... 34
3.3.2. Deleting User ................................................................................................ 35
3.3.3. Modify User .................................................................................................. 37
3.3.4. Delete all Users ............................................................................................ 38
3.3.5. View.............................................................................................................. 39
3.4. Network Settings .................................................................................................. 41
3.5. Application ........................................................................................................... 43
3.5.1. Application mode .......................................................................................... 43
3.5.1.1. Modes ................................................................................................... 43
3.5.2. Function keys ............................................................................................... 45
3.6. System .................................................................................................................. 47
3.6.1. System ......................................................................................................... 47
3.6.2. Mobile Key
.................................................................................................... 49 3.6.3. Face
Detection ............................................................................................. 51 3.6.5.
Time/Date ..................................................................................................... 53
3.6.6. Database ...................................................................................................... 54
3.6.1.1. Database Confirmation .......................................................................... 55
3.7. Terminal settings ................................................................................................. 56

MiKey AC1100 User guide 5
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
3.7.1. Sounds ......................................................................................................... 56
3.7.2. Terminal option
............................................................................................. 57
3.7.3. Terminal Input ............................................................................................... 59
3.7.4. Terminal Lock ............................................................................................... 61
3.7.5. Terminal Wiegand ......................................................................................... 62
3.7.6. Terminal External .......................................................................................... 63
3.8. Display settings ................................................................................................... 65
3.8.1. Theme .......................................................................................................... 65
3.8.2. Camera ......................................................................................................... 66
3.8.2.1. Camera Flash Option ..................................................................................
66
3.8.3. Language ..................................................................................................... 67
3.8.4. LCD option ................................................................................................... 67
3.8.5. Message time settings .................................................................................. 68
3.9. Terminal information ............................................................................................ 70
3.9.1. System information ....................................................................................... 70
3.9.2. Terminal information ..................................................................................... 71
3.9.3. Network information ...................................................................................... 72
3.9.4. User information ........................................................................................... 73
3.9.5. Log information ............................................................................................. 74
3.9.6. About ............................................................................................................ 75
3.10. SD USB ............................................................................................................... 76
3.20. Language Translations/Customizing Text Items .............................................. 82
4. How to use terminal ................................................................................................ 84
4.1. Authorization mode change ................................................................................ 84
4.2. ID input ................................................................................................................. 85
4.3. Authorization ........................................................................................................ 86
4.3.3. Card authorization ........................................................................................ 86
4.3.4. Password authorization ................................................................................ 86

MiKey AC1100 User guide 6
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
1. Before use
1.1. Safety precautions
Warning
Handling with wet hands or
allowing liquid to flow into it is
prohibited.
-> It may cause an
electric shock or damage.
Do not place a fire source
near the terminal.
-> It may cause a fire.
Do not disassemble, repair, or
modify the terminal at
discretion.
-> It may cause an electric
shock, fire or damage.
Keep out of reach of
children.
-> It may cause an
accident or damage.
-If the above warning is ignored, it may result in death or serious injury.
Cautions
Keep away from direct
sunlight
-> It may cause deformation
or color change.
Avoid high humidity or dust
-> The terminal may be
damaged.
Avoid using water, benzene,
thinner, or
alcohol for cleaning -> It may
cause an electric
shock or fire.
Do not place a magnet
close to the terminal.
-> The terminal
may break
down or
malfunction.
Do not contaminate the
fingerprint input area.
-> Fingerprints may not be
well recognized.
Avoid using insecticide or flammable spray
near the terminal.
-> It may result in
deformation or
color change.
Avoid impacts or using sharp
objects on the terminal.
-> The terminal may be
damaged and broken.
Avoid severe temperature
changes
-> The terminal may be
broken.
-If the above cautions are ignored, it may result in property loss or human injury.
※Under no circumstances will UNION COMMUNITY be responsible for accidents or
damages caused by inappropriate use of the product without referring to the user
manual.

MiKey AC1100 User guide 7
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
1.2. Specific names of the terminal

MiKey AC1100 User guide 8
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
1.3. Normal Window Display
1.3.1. Icons
Fire detection
None
: Normal
: Fire Detected state (external device or server program)
Warning indicator
None
: Normal
: Abnormal terminal state (tampered)
Door state
: Door state unknown
: The Door is closed
: The Door is opened
Server connection
state
: LAN line is not connected
: Not connected to the server program
: Connected to the server program
: Bluetooth Mobile App Connected State
Bluetooth
Status Touch
Present time

MiKey AC1100 User guide 9
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
: WiFi Dongle Connected to device –not connected to network
: WiFi Dongle Connected and successfully connected to AP
WiFi Connection
State

MiKey AC1100 User guide
10
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
1.3.
2
.
Window Messaging
-
Standard
wind
ow
-
Screen Saver
window

MiKey AC1100 User guide
11
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
All Function Keys disabled
-
No Status Text/ Status Text Background
-
No Extended Key
VoiP Function
VoIP enabled, not registered.
VoIP enabled, registered on iPBX network
Select Green Icon to access VoIP call menu.

MiKey AC1100 User guide
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
12
Touch the
status touch area
along the top of the display
to see detail status information. See 1.3 Main window
display. This will appear for 10 seconds.
Top pop up is a
custom user message
.In UNIS user
management you can make a custom message
for every
user during the users authentication period.
If camera setting for Display Current Picture or Display User
picture is set and
registered
card is used.
Picture will be
displayed on the top.
See Section 3.8.2
If card, mobile key, password is suc
cessful, the general
Success message will be displayed.
Bottom Message is black can be 1 of 3 different options.
This depends on the setting in Display
User Display
Options
-
User Name
-
User ID
-
User Key

MiKey AC1100 User guide
13
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
- When authorization is failed.
- When unregistered user ID is entered.
- When unregistered card is entered
- Passback error when using anti-passback function.
- When a user tried the authorization more than twice in one
meal time when using as meal personnel management
-When the server does not respond during the authorization
attempt to the server
-When the network is disconnected during the authorization
attempt to the server

MiKey AC1100 User guide
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
14
- When the terminal is set locked
- When it is not the meal time when set in the meal personnel
management.
-
When Bluetooth is connected with administrator Mobile
App. Admin mode blocking.
-
Registration without
authorization
right or
authorization
attempt when the entrance is not permitted.
-
When the user is
designated in the blacklist

MiKey AC1100 User guide
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-
dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
15
-
Waiting for User ID Input
If more than 2 function keys are enabled from the function
key
setting menu, in administrator mode, the
button will appear
on the main window. If this button is selected the extended
function keys can be seen. Select the mode button
-
blue, or scroll
down/up until you can see the mode you would like to select.
Se
lect back or the blue button mode.
Timeout after 5 seconds of
no activity.

MiKey AC1100 User guide
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-
dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
16
-
Waiting for Password Input
-
Waiting for Card
-
When the
terminal
program is being upgraded
(
In this state, you should not turn off the
terminal
)

MiKey AC1100 User guide
17
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-
dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
1.4. Voices in the operation
Operation type
Voice
When the
authorization was
successful
You are authorized.
When the
authorization was
failed.
Please try again.
Waiting for Card
Please enter your card
ID Input
Enter your ID
1.5. Beep or sound effect in the operation
Beep
Card Reading
When the card was read
ErrorTone
wave sound
When failed
When the authorization has failed and Voice disabled
Trilling
sound
When success
When the authorization was successful and Voice
disabled
Key Press
Sound during number entry
Tick
Function Key
Sound during function key selection

MiKey AC1100 User guide 18
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
2. Product introduction
2.1. Product characteristics
Multi-Modal product with card, password or mobile key authentication methods. Face
Detection requires the current authenticating user to present their face during card,
password or Mobile Key authentication. This requires a user to be in front of the card
reader so the device can take a picture of the person who authenticated.
Built in camera flash allows pictures and face detection during dark conditions.
Daylight Sensor automatically turns the flash on during dark conditions.
RF (125 kHz) Type (optional)
Smart card (13.56MHz) Type (optional)
Entrance management system using TCP/IP or WiFi (optional) connected to a server
database.
Various registration and authorization methods
Card
Card registration
Card authorization
Password
Password registration
Password authorization
Mobile Key
Mobile Key Temporary key registration
Mobile Key User key registration
Card or
password
Card, password registration
Card or password authorization
Card and
password
Card, password registration
Password authorization after card authorization
(ID or card) &
password
Card, password registration
Password authorization after ID input or password authorization
after card.

MiKey AC1100 User guide 19
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
2.2. Product components
2.2.1. Stand-alone (entrance)
DC12V
Adapter
Electric lock
(
Lock+, Lock
-
, Monito
r)

MiKey AC1100 User guide 20
Union Community / Hyundai Topics building 5th floor, 44-3, Bangi 2-dong,
Songpa-gu, Seoul, Korea (138-050)
Tel: [phone], Fax: [phone], E-Mail:[e-mail]
2.2.2. Connected with PC server
(Entrance, attendance, meal personnel management)
TCP/IP
