VISIONARY DESIGNS MOD-1370 Manual

© 2018
Order #XXXXX
Completed MOD-1371
Assembly
Completed MOD-1370
Assembly
MOD- 1371 Assembly MOD- 1370 Assembly
Steps:
1) Connect curved vertical pieces together, using set screw.
2) Attach base plate to bottom of curved vertical, using bolt.
3) Attach mount to top of curved vertical, using bolt.
NOTE: Mount must rotate left and right before installing clamshell.
4) Attach clamshell to mount, using hex nuts. See Clamshell Attachment detail.
5) Insert iPad into clamshell and feed cord through hole. See Cord Management
for iPad detail. Steps:
1) Attach base plate to post, using bolt.
2) Loosen set screw to remove lower
portion of curved vertical from MOD-1371.
3) Place upper portion of curved vertical into
top of post. Tighten set screw to secure.
4) Attach clamshell to mount, using hex nuts.
5) Insert iPad into clamshell and feed cord
through holes. See Cord Management
for iPad detail.
Base Plate
Bolt Bolt
Base
Plate
Curved
Vertical
Mount
MOD-1371
Clamshell
Foam Lining
Removed
Home Button Shield
Optional Cover for Home Button
1) Remove foam lining from inside bottom of
clamshell.
2) Attach Home Button Shield with double-sided
tape to inside of clamshell, keeping top of
shield flush with clamshell opening.
NOTE: This is a permanent fix and can’t be
easily removed.
Rotate clamshell
to turn iPad from portrait
to landscape orientation.
Post rotates
vertically
Hex
Nuts
Clamshell Attachment
Post
Set
Screw
Set
Screw
Cord Management for iPad
Attach iPad cord to supplied USB
extension cord. Feed USB cord
through top hole of post, then out
bottom hole of post. Connect to power.
Cord
Access
iPad
Lock Lock
Clamshell
MOD-1370 iPad Kiosks
SETUP INSTRUCTIONS
If you would like to tell us about your experience with your setup instructions please email us at [email protected]

© 2018
Order #XXXXX
DO NOT USE POWER TOOLS
ALL CONNECTIONS MUST
BE TIGHTLY SECURED
Part Identification - Numbering
Spline Connection Base Plate & Extrusion Connection
General Setup Instructions
- Read entire setup instruction manual prior to
unpacking parts and pieces.
- The setup instructions are created specifically
for this configuration.
- Setup instructions are laid out sequentially in
steps, including exploded views with detailed
explanation for assembly.
WARNING
Cleaning & Packing
- For Cleaning Metal, Plex, & Laminate Parts:
Use a MILD NON-ABRASIVE cleanser and
soft cloth/paper towel to clean all surfaces.
- Keep exhibit components away from heat
and prolonged sun exposure.
Heat and UV exposure will warp and
fade components.
- Retain all provided Packing Materials.
All provided packing materials are for
ease of repacking & component protection.
Disassembly
- For loss prevention, tighten all setscrews
and locks during disassembly
7A
Hex Tool - Essential for Assembly
Extrusion & Lock Connection Engaged Lock
LADDERS OR LIFTS
MAY BE REQUIRED
General Information
