Arjo Dual-Loop Attachment Straps User manual

001-05415-EN rev 4 • 10/2020
INSTRUCTIONS FOR USE
Dual-Loop Attachment Straps

Design Policy and Copyright
® and ™ are trademarks belonging to the Arjo group of companies.
© Arjo 2020.
As our policy is one of continuous improvement, we reserve the right to
modify designs without prior notice. The content of this publication may not
be copied either whole or in part without the consent of Arjo.

001-05415-EN rev. 4
Table of Contents 1
Table of ContentsTable of Contents
General Information ....................................................................................................................2
Foreword.................................................................................................................................................. 2
Intended Use ........................................................................................................................................... 2
Operational Life ....................................................................................................................................... 2
Denitions Used in this Manual ............................................................................................................... 2
Symbols Used.......................................................................................................................................... 3
Safety Instructions ......................................................................................................................4
Safe Working Load .................................................................................................................................. 4
Safety Directions...................................................................................................................................... 4
Parts Designation .................................................................................................................................... 5
DUAL-LOOP ATTACHMENT STRAPS Compatibility ............................................................................. 5
Using the DUAL-LOOP ATTACHMENT STRAPS .......................................................................6
Using the Ferno Scoop EXL Stretcher with the Maxi Move................................................................ 6
Lifting from a Bed or Hospital Stretcher ................................................................................................................ 6
Care and Maintenance ................................................................................................................8
Recommended Cleaning ......................................................................................................................... 8
Cleaning the Straps............................................................................................................................................... 8
Storage conditions................................................................................................................................................. 8
Strap Inspection .................................................................................................................................................... 8
Specications ..............................................................................................................................9
Dimensions.............................................................................................................................................. 9
Technical Data ......................................................................................................................................... 9
Labels .................................................................................................................................................... 10

001-05415-EN rev. 4
General Information2
General InformationGeneral Information
Foreword
Arjo is dedicated to serving your needs and providing
the best products available along with training that
will bring your staff maximum benet from every
Arjo product.
All references to the patient in these instructions
refer to the person being lifted, and references to
the caregiver refer to the person who operates the
lifter or the product.
Some of the information in this manual may become
outdated, due to improvements made to the product
in the future. If you have any questions regarding
these instructions or your product, please contact
Arjo.
Arjo strongly advises and warns that only Arjo
Company Designated Parts, which are designed
for the purpose, should be used on product and
other appliances supplied by Arjo, to avoid injuries
caused by the use of inadequate parts.
The Arjo Company’s conditions of sale make
specic provision conrming no liability in such
circumstances.
Intended Use
The DUAL-LOOP ATTACHMENT
STRAPS are intended to be used with the
Ferno Scoop EXL Stretcher series in combination
with Arjo’s Maxi Move® oor lift equipped with a
compatible stretcher frame and only for transfer
purposes.
The
Ferno Scoop EXL Stretcher is intended to be
exclusively operated by a trained caregiver (as per
the product Users’ Manual) for transferring patients
who have been assessed as requiring lifting in a
supine position. No functions regarding the control
of this product should be performed by the patient.
The DUAL-LOOP ATTACHMENT STRAPS are
part of a series of quality products designed for
hospitals, nursing homes, long-term care and home
care environments, including private homes.
Operational Life
The DUAL-LOOP ATTACHMENT STRAPS have
been produced and tested for a life span of two
(2) years starting from the manufacturing date—
subject to maintenance as specied in the Care and
Maintenance section of this manual. Refer to the
manufacturing date on the strap labels.
WARNING: Arjo cannot ensure full safety for
an accessory of which the life span has been
exceeded.
The life span of this product is the safe operating
time period before an overhaul is required. Aging,
the weight of the patient and maintenance frequency
are factors that have an impact on the life span of
the DUAL-LOOP ATTACHMENT STRAPS.
Denitions Used in this Manual
WARNING:
Means: Failure to follow these instructions may
result in injury to yourself and others.
CAUTION:
Means: Failure to follow these instructions may
cause damage to the product.
NOTE:
Means: This is important info regarding the correct
use of the product.
Means: The name and address of the manufacturer.

001-05415-EN rev. 4
General Information 3
Symbols Used
General Symbols
Symbols Key to Symbols
Name and address of the
manufacturer
Manufacturing date.
REF Manufacturer’s catalogue number.
CE marking indicating conformity
with European Community
harmonised legislation.
Read the Instructions for use before
use.
SWL
Safe Working Load is the
maximum load the device
is rated for safe usage.
Correct way to proceed.
Wrong way to proceed.
Universal Dual Loop label
Strap Maintenance Related Symbols
Symbols Key to Symbols
80°C Washing temperature 80°C
(176°F) permanent cycle.
Do not bleach.
Do not dry clean.
Do not iron.
Do not tumble dry.
General InformationGeneral Information

001-05415-EN rev. 4
Safety Instructions4
WARNING: The DUAL-LOOP ATTACHMENT
STRAPS must be used as per instructions found
herein as well as the User’s Manual issued with
the Ferno Scoop EXL Stretcher, the lifter and
the stretcher frame.
The DUAL-LOOP ATTACHMENT
STRAPS are intended to be used with the
Ferno Scoop EXL Stretcher accessory in
combination with Arjo Maxi Move oor lift with
a compatible stretcher frame and only for
transferring purposes.
Failure to follow these instructions may result in
patients falling, causing injuries.
Before using your DUAL-LOOP ATTACHMENT
STRAPS, familiarise yourself with the various parts
and compatible accessories as illustrated in Fig. 1. 1
and Fig. 2 then read this manual in its entirety.
Prior to rst use, install the labels included with this
product to the four attachment points. See Fig.1.
Information in the manual is crucial to the proper
operation and maintenance of the product. It will
help protect your product and ensure that it performs
to your satisfaction.
The information in this booklet is important for your
safety and must be read and understood to help
prevent possible injuries.
If there is anything in the manual that is confusing
or hard to understand, call Arjo or their vendor (the
telephone number appears on the last page of this
manual.)
Safe Working Load
The DUAL-LOOP ATTACHMENT STRAPS have
been made with a lifting capacity of 227 kg (500 lb).
WARNING: The DUAL LOOP ATTACHMENT
STRAPS are intended to be used for patients
whose weight is within a specied safe working
load. Do not attempt to lift more than the lowest
weight limit indicated on the following:
• The lift;
• The Ferno Scoop EXL Stretcher
(160 kg [350 lb]);
• The accessories.
Failure to follow these instructions may result in
patients falling, causing injury.
Safety Directions
Always ensure that:
• Care is taken when manually lifting
alternative / optional components (e.g.
stretcher frames, spreader bars etc.,)
to avoid injuries. Do not attempt to
manually lift the complete lifter.
• The need for a second attendant to
support the patient must be assessed
for each individual case.
• Before an attempt is made to move the
patient, an assessment is performed
by a qualied professional.
• You are prepared before attempting
to transfer a patient.
• An assessment of the suitability for
transfer of a patient who is connected to
electrodes, catheters or other medical
devices is conducted by qualied personnel
before performing the transfer.
• Violent impact during transfers is avoided.
•
WARNING: Always inspect the DUAL-LOOP
ATTACHMENT STRAPS prior each use
in search of irregularities as per Care and
Maintenance section on page 8.
Failure to follow these instructions may result in
patients falling, causing injuries.
• The straps are properly fastened.
• The transfer procedures outlined
in this manual are followed.
• The straps are cleaned and
maintained according to the Care and
Maintenance section of this manual.
Safety InstructionsSafety Instructions

001-05415-EN rev. 4
Safety Instructions 5
Parts Designation
Fig. 1
DUAL-LOOP ATTACHMENT STRAPS Compatibility
The DUAL-LOOP ATTACHMENT STRAPS can only be used with the accessories shown in Fig. 2 below.
Fig. 2
Foldable Stretcher Frame № 700-19302 and
Stretcher Frame № (KPA3060-XX, KMA82339-XX)
WARNING:
Must not be used with a Maxi Move oor
lift featuring an extended jib (KMC**E). The
lift would become unstable which could
lead to patients falling, causing injuries. Only use with a Maxi Move oor
lift, for transferring only
Head section
Dual-Loop
Attachment
Straps
Dual-Loop
Attachment
Straps
Foot section
Waist section
Ferno Scoop
EXL Stretcher
Short loop
Long loop
Long loop
Short
loop
Dual-Loop Attachment Strap
WARNING: The DUAL-LOOP
ATTACHMENT STRAPS must never
be attached to the pins located within
the handholds, when using a Ferno
Scoop EXL Stretcher with pins. Failure
to follow these instructions may result
in patients falling, causing injuries.
Pin
Universal
Dual Loop
label

001-05415-EN rev. 4
Using the DUAL-LOOP ATTACHMENT STRAPS6
Using theUsing the DUAL-LOOP ATTACHMENT STRAPSDUAL-LOOP ATTACHMENT STRAPS
Using the Ferno Scoop EXL Stretcher
with the Maxi Move
Lifting from a Bed or Hospital Stretcher
The following procedure should only be performed
using the
DUAL-LOOP ATTACHMENT STRAPS .
WARNING: Inspect the straps prior to each use.
See “Straps Inspection” on page 8. Never
use a strap if damaged or badly worn as it may
result in the patient falling, causing injuries.
WARNING: To prevent the Maxi Move from
tipping, resulting in patient falls and injuries, the
Maxi Move must be used with legs open at all
times. The patient should be kept at nearly bed
height or lower and transfers must always be
performed on at, level surfaces or oors.
1) Install the stretcher frame on the Maxi Move
(refer to the
Maxi Move Instructions for Use
No.001.25060.**
).
2) Position the patient onto the Ferno Scoop EXL
Stretcher
(refer to the product’s Users’ Manual).
3) Make sure that the DUAL-LOOP ATTACHMENT
STRAPS
have been installed in the correct
locations. If the four straps have not yet been
attached to the
Ferno Scoop EXL Stretcher,
proceed to attach them according to the precise
locations and in the correct way as shown in
Fig. 3.
Fig. 3
4) Bring the stretcher frame over to the patient and
align the stretcher frame’s suspension point
labels with the installed attachment straps.
Lower the stretcher frame sufciently to be able
to connect the attachment straps securely on
the hooks (See Fig. 4).
Fig. 4
WARNING: When lowering the stretcher frame,
over the patient, be careful that it does not
accidentally strike the patient.
5) Attach all the straps to the stretcher frame.
Choose the loop to use (long or short) at
head section and at foot section depending
on patient’s morphology. Most of the time long
loops can be used everywhere. See Fig. 5.
Fig. 5
WARNING: Use only the hooks identied by the
“Suspension Point” labels (see Fig. 5), on the
stretcher frame to attach the Ferno Scoop EXL
Stretcher
to the frame. Failure to follow these
instructions may result in patient falls causing
injuries.
WARNING: Always check that all the DUAL-
LOOP ATTACHMENT STRAPS
remain secured
as the patient’s weight is taken up. A strap that
is incorrectly fastened could detach, resulting in
the patient falling.
Install the
DUAL-LOOP
ATTACHMENT
STRAPS only in
the handholds
indicated by the
green circles.
Use hooks
indicated by
labels only
Use hooks
indicated by
labels only

001-05415-EN rev. 4
Using the DUAL-LOOP ATTACHMENT STRAPS 7
WARNING: Before raising the patient, always
make sure the
Ferno Scoop EXL Stretcher is
not caught on any obstructions (i.e. the bed
headboard or footboard). Catching on such an
obstruction could result in the patient falling.
6) Raise the patient sufciently to clear the bed/
hospital stretcher (See Fig. 6).
Fig. 6
7) Proceed with the transfer.
NOTE: When transferring the patient through a
door, rotate the stretcher frame until the patient’s
head is close to the mast (see Fig. 7). In this
position, the complete unit may be moved through
wide doorways.
Fig. 7
8) Lower the patient down onto the new location.
Fig. 8
9) When the patient’s body weight is fully
unsupported, unhook the straps from the
stretcher frame.
10) Roll the Maxi Move away.
11) Open the latches and gently slide the two
stretcher sections from underneath the patient.
Reconnect the
Ferno Scoop EXL Stretcher for
further use.

001-05415-EN rev. 4
Care and Maintenance8
Care and MaintenanceCare and Maintenance
Recommended Cleaning
WARNING: Cleaning products must be used in
accordance with the manufacturer’s instructions.
To prevent injuries, always wear protection for
eye, hand and clothing when handling cleaning
products.
The DUAL-LOOP ATTACHMENT STRAPS should
be inspected between each patient use and cleaned
if needed.
Cleaning the Straps
The laundering staff or service must be aware of the
following care instructions:
• washing temperature must not
exceed 80°C (176°F),
• always use mild detergents,
• never wring, press or iron,
• never bleach,
• rinse thoroughly,
• never tumble dry,
• never place in contact with a heat source,
• never dry clean.
Refer to the care label on the strap (See Fig. 9).
Fig. 9
Storage conditions
Straps should be store away from direct sunlight,
stress, pressure, excessive heat or humidity. The
straps should be kept away from contact with sharp
objects, corrosives or other possible damaging
material.
Strap Inspection
Look for any sign of irregularities as shown in Fig. 10 .
A
D
C
B
Fig. 10
a) Loose threads in
stitched area,
b) Edge wear (fraying),
c) Noticeable discoloration
or stain resulting from
the use of bleach or
other chemicals (strap
color is lighter than color
in stitched area or the
ID labels are faded),
d) Middle wear, rip or hole.
WARNING: If the strap inspection reveals any
signs of irregularities, stop using the strap.
If you have any doubts about the strap’s safety,
replace it with a new one.
Continuing to use a damaged strap can seriously
compromise the caregiver’s or patient’s safety.
Verify the manufacturing date label found on each
attachment strap (shown in Fig. 11) to ensure that
the straps have not exceeded their life span.
Fig. 11

001-05415-EN rev. 4
Specications 9
Dimensions
Fig. 12
655 mm
LABELS (Refer to Care and Maintenance Section).
560 mm
(26 mm)
Technical Data
PRODUCT INFORMATION DUAL-LOOP ATTACHMENT STRAPS (354-14912)
Total weight 0.03 kg (0.07 lb)
SWL 227 kg (500 lb)
Material Polyester webbing
ENVIRONMENTAL CONDITIONS
Ambient temperature range Operation and Storage: -40°C to 70°C (-40°F to 158° F)
Relative humidity range Operation and Storage: 10% to 100%
Atmospheric pressure range Operation and Storage: 500 hPa to 1060 hPa
END OF LIFE DISPOSAL
• The packaging containers should be recycled according to the national or local regulations.
• Strap should be recycled according to national or local regulations.
SpecicationsSpecications

001-05415-EN rev. 4
Specications10
Labels
Fig. 13

Intentionally left blank

Intentionally left blank

AUSTRALIA
Arjo Australia
Building B, Level 3
11 Talavera Road
Macquarie Park, NSW, 2113,
Australia
Phone: [phone]
BELGIQUE / BELGIË
Arjo Belgium
Evenbroekveld 16
9420 Erpe-Mere
Phone: [phone]
Fax: [phone]
E-mail: [email protected]
BRASIL
Arjo Brasil Equipamentos Médicos Ltda
Rua Marina Ciufuli Zanfelice, 329 PB02
Galpão - Lapa
São Paulo – SP – Brasil
CEP: 05040-000
Phone: [phone]
E-mail: [email protected]
E-mail: [email protected]
CANADA
Arjo Canada Inc.
90 Matheson Boulevard West
Suite 300
CA-MISSISSAUGA, ON, L5R 3R3
Tel/Tél: [phone]
Free: [phone] Institutional
Free: [phone] Home Care
Fax: [phone]
E-mail: [email protected]
ČESKÁ REPUBLIKA
Arjo Czech Republic s.r.o.
Na Strzi 1702/65
140 00 Praha
Czech Republic
Phone No: [phone]
e-mail: [email protected]
DANMARK
Arjo A/S
Vassingerødvej 52
DK-3540 LYNGE
Tel: [phone]
Fax: [phone]
E-mail:
[email protected]
DEUTSCHLAND
Arjo GmbH
Peter-Sander-Strasse 10
DE-55252 MAINZ-KASTEL
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
ESPAÑA
ARJO IBERIA S.L.
Poligono Can Salvatella
c/ Cabanyes 1-7
08210 Barberà del Valles
Barcelona - Spain
Telefono 1: [phone]
Telefono 2: [phone]
FRANCE
Arjo SAS
2 Avenue Alcide de Gasperi
CS 70133
FR-59436 RONCQ CEDEX
Tél: [phone]
Fax: [phone]
E-mail: [email protected]
HONG KONG
Arjo Hong Kong Limited
Room 411-414, 4/F, Manhattan Centre,
8 Kwai Cheong Road, Kwai Chung, N.T.,
HONG KONG
Tel: [phone]
Fax: [phone]
ITALIA
Arjo Italia S.p.A.
Via Giacomo Peroni 400-402
IT-00131 ROMA
Tel: [phone]
Fax: [phone]
E-mail: Italy[email protected]
MIDDLE EAST
Arjo Middle East FZ-LLC
O󰀩ce 908, 9th Floor,
HQ Building,North Tower,
Dubai Science Park,
Al Barsha South
P.O Box 11488, Dubai,
United Arab Emirates
Direct [phone]
Fax [phone]
Email: [email protected]
NEDERLAND
Arjo Nederland BV
Biezenwei 21
4004 MB TIEL
Postbus 6116
4000 HC TIEL
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
NEW ZEALAND
Arjo Ltd
34 Vestey Drive
Mount Wellington
NZ-AUCKLAND 1060
Tel: [phone]
Free Call: 0800 000 151
Fax: [phone]
E-mail: [email protected]
NORGE
Arjo Norway AS
Olaf Helsets vei 5
N-0694 OSLO
Tel: [phone]
Faks: [phone]
E-mail: [email protected]
ÖSTERREICH
Arjo GmbH
Lemböckgasse 49 / Stiege A / 4.OG
A-1230 Wien
Tel: [phone]
Fax: [phone]
POLSKA
Arjo Polska Sp. z o.o.
ul. Ks Piotra Wawrzyniaka 2
PL-62-052 KOMORNIKI (Poznań)
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
PORTUGAL
Arjo em Portugal
MAQUET Portugal, Lda.
(Distribudor Exclusivo)
Rua Poeta Bocage n.º 2 - 2G
PT-1600-233 Lisboa
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
SUISSE / SCHWEIZ
Arjo AG
Fabrikstrasse 8
Postfach
CH-4614 HÄGENDORF
Tél/Tel: [phone]
Fax: [phone]
SUOMI
Arjo Scandinavia AB
Riihitontuntie 7 C
02200 Espoo
Finland
Puh: [phone]
E-mail: Asiakaspalvelu.[email protected]
SVERIGE
Arjo International HQ
Hans Michelsensgatan 10
SE-211 20 MALMÖ
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
UNITED KINGDOM
Arjo UK and Ireland
Houghton Hall Park
Houghton Regis
UK-DUNSTABLE LU5 5XF
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
USA
Arjo Inc.
2349 W Lake Street Suite 250
US-Addison, IL 60101
Tel: [phone]
Free: [phone] Institutional
Free: [phone] Home Care
Fax: [phone]
E-mail: [email protected]
JAPAN
Arjo Japan K.K.
東京都港区虎ノ門三丁目7 番8 号
ランディック第2 虎ノ門ビル9 階
Tel: [phone]
Fax: [phone]
E-mail: [email protected]
www.arjo.com Address page Rev 26 • 11/2020

At Arjo, we are committed to improving the everyday lives of people affected by reduced mobility and age-related health challenges.
With products and solutions that ensure ergonomic patient handling, personal hygiene, disinfection, diagnostics, and the effective
prevention of pressure ulcers and venous thromboembolism, we help professionals across care environments to continually raise
the standard of safe and dignied care. Everything we do, we do with people in mind.
ArjoHuntleigh AB
Hans Michelsensgatan 10
211 20 Malmö, Sweden
www.arjo.com
