Vivo DESK-SHELF42-OB User manual

Black 42" Clamp-on Overhead Shelf
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
Instruction Manual
https://vivo-us.com/products/desk-shelf42-ob
SKU: DESK-SHELF42-OB
[email protected]om www.vivo-us.com 309-278-5303
Chat live with an agent!
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST

2 3
If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a
qualified technician. Check carefully to make sure there are no missing or defective parts. Improper installation may
cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual
and do not exceed weight capacity. We cannot be liable for damage or injury caused by improper mounting, incorrect
assembly, or inappropriate use.
WARNING!
WARNING: CHOKING HAZARD
SMALL PARTS - NOT FOR CHILDREN UNDER 3 YEARS. ADULT SUPERVISION IS REQUIRED.
ASSEMBLY STEPS
PACKAGE CONTENTS
A (x1)
Shelf
TOOLS NEEDED
Phillips
Screwdriver
B (x2)
Support
D (x2)
Clamp
S-A (x4)
M5x12mm
Screw
C (x1 )
Crossbar
S-B (x10)
M5x35mm
Screw
S-C (x4)
M6x25mm
Screw
T-A (x1)
4mm Allen
Wrench
DO NOT EXCEED WEIGHT CAPACITY.
Failure to do so may result in serious injury.
22lbs
(10kg)
STEP 1
STEP 2
STEP 4
STEP 3
Connect Supports (B) to Crossbar (C)
using M6x25mm Screws (S-C) and 4mm
Allen Wrench.
Secure assembled frame to Shelf (A)
using M5x35mm Screws (S-B) and a
Phillips screwdriver.
Adjust Clamps (D) to have a opening slightly larger than your desktop thickness.
Slide shelf onto desktop and tighten Clamps (D) to secure.
Secure Clamps (D) to Supports (B) using M5x12mm Screws (S-A) and 4mm Allen Wrench (T-A).
S-B
S-B
S-C
C
T-A
A
B
D
D
S-A
Desk
D
B

LAST UPDATED: 10/26/2022
REV1
