Press and hold for seconds.
To recall Location 2, press and release the button, then press
the button. After the buzzer sounds once, the TV ceiling
mount will automatically adjust to Location 2.
Operating Instructions
MINIMUM POSITION: To adjust TV mount to minimum position
(resting against the ceiling), simply give it a slight push. The mount
will automatically return to minimum position.
Recall Memory
Manual Position Adjustment
*Find troubles ooting guide on back cover.*
Plug the mount in. The buzzer on the mount will beep once.
Step 1:
Reset tilt angle.
IF MOUNT IS INSTALLED ON A PITCHED SURFACE:
Press and release to return the TV ceiling mount flat against the
ceiling surface. The system will beep once, then enter a working
condition.
Step 2:
BUTTON FUNCTIONS:
Downward movement
Upward movement
Memory button 1: Press and hold for seconds, the
buzzer will beep twice. Location 1 is saved.
Memory button 2. Press and hold for seconds, the
buzzer will beep twice. Location 2 is saved.
Stop button
To recall Location 1, press and release the button, then press
the button. After the buzzer sounds once, the TV ceiling
mount will automatically adjust to Location 1.
Repeat four times. The system will automatically find the
correct position, and it will automatically stop at the maximum
position.
Step 1:
Step 2:
MAXIMUM POSITION: To adjust TV mount to maximum position
(lowered completely), follow above instruction to return it to
minimum position. Once in the minimum position, give it a slight
push. The mount will automatically lower to maximum position.
