Vivotek AW-GET-094A-130 User manual

Publication date: Aug., 2014
Revision A1
i
AW-GET-094A-130 PoE Switch
User Manual
CopyrightVIVOTEK Inc. 2014 | All rights reserved. All brand and product names are
trademarks or registered trademarks of their respective owners.
Release: 1.22

Publication date:Aug., 2014
Revision A1
ii
The information in this document is subject to change without notice. Unless the explicit written permission of Manufacture Corporation, this
document in whole or in part shall not be replicated or modified or amended or transmitted, in any from, or by any means manual, electric,
electronic, electromagnetic, mechanical, optical or otherwise for any purpose.
DURATION OF HARDWARE WARRANTY
HARDWARE: In accordance with the provisions described under, Manufacture Corporation (hereinafter called “Manufacture”) warrants its
hardware products (hereinafter referred to as “Product”) specified herein to be for a period of twelve (12) months from the date of shipment.
Should a Product fail to perform during the effective warranty period as described above, Manufacture shall replace the defective Product or
part, or delivering a functionally equivalent Product or part in receipt of customer’s request, provided that the customer complies with the
return material authorization (RMA) procedures and returns all defective Product prior to installation of the replacements to Manufacture.
All defective Products must be returned to Manufacture with issuance of a Return Material Authorization number (RMA number) assigned to
the reseller from whom the end customer originally purchased the Product. The reseller is responsible for ensuring the shipments are
insured, with the transportation charges prepaid and the RMA number clearly marked on the outside of the package. Manufacture will not
accept collect shipments or those returned without an RMA number.
Manufacture shall not be responsible for any software, firmware, information or memory data contained in, stored on or integrated with any
Product returned to Manufacture pursuant to any warranty.
EXCLUSIONS.The warranty as mentioned above does not apply to the following conditions, in Manufacture’s judgment, it contains (1)
customer does not comply with the manual instructions offered by Manufacture in installation, operation, repair or maintenance, (2) Product
fails due to damage from unusual external or electrical stress, shipment, storage, accident, abuse or misuse, (3) Product is used in an extra
hazardous environment or activities, (4) any serial number on the Product has been removed or defaced, (5) this warranty will be of no
effect if the repair is via anyone other than Manufacture or the approved agents, or (6) In the event of any failuresor delays by either party
hereto in the performance of all or any part of this agreement due to acts of God, war, riot, insurrection, national emergency, strike, embargo,
storm, earthquake, or other natural forces, or by the acts of anyone not a party to this agreement, or by the inability to secure materials or
transportation, then the party so affected shall be executed from any further performance for a period of time after the occurrence as may
reasonably be necessary to remedy the effects of that occurrence, but in no event more than sixty (60) days. If any of the stated events
should occur, Party A shall promptly notify Party B in writing as soon as commercially practicable, but in no event more than twenty (20)
business days and provide documentation evidencing such occurrence. In no event shall the maximum liability of Manufacture under this
warranty exceed the purchase price of the Product covered by this warranty.
DISCLAIMER. EXCEPT AS SPECIFICALLY PROVIDED ABOVE AS REQUIRED “AS IS” AND THE WARRANTIES AND REMEDIES
STATED ABOVE ARE EXCLUSIVE AND IN LIEU OF ALL OTHERS, ORAL OR WRITTEN, EXPRESS OR IMPLIED. ANY AND ALL OTHER
WARRANTIES, INCLUDING IMPLIED WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND
NONINFRINGEMENT OR THIRD PARTY RIGHTS ARE EXPRESSLY EXCLUDED.
MANUFACTURE SOFTWARE LICENSE AGREEMENT
NOTICE: Please carefully read this Software License Agreement (hereinafter referred to as this “Agreement”) before copying or using the
accompanying software or installing the hardware unit with pre-enabled software or firmware (each of which is referred to as “Software” in
this Agreement). BY COPYING OR USING THE SOFTWARE, YOU ACCEPT ALL OF THE PROVISIONS AND CONDITIONS OF THIS
AGREEMENT. THE PROVISIONS EXPRESSED IN THIS AGREEMENT ARE THE ONLY PROVISION UNDER WHICH MANUFACTURE
WILL PERMIT YOU TO USE THE SOFTWARE. If you do not accept these provisions and conditions, please immediately return the unused
software, manual and the related product. Written approval is NOT a prerequisite to the validity or enforceability of this Agreement and no
solicitation of any such written approval by or on behalf of Manufacture shall be deemed as an inference to the contrary.
LICENSE GRANT. The end user (hereinafter referred to as “Licensee”) of the Software is granted a personal, non-sublicensable,
nonexclusive, nontransferable license by Manufacture Corporation (“Manufacture”): (1) To use the Manufacture’s software (“Software”) in
object code form solely on a single central processing unit owned or leased by Licensee or otherwise embedded in the equipment offered by
Manufacture. (2) To copy the Software only for backup purposes in support of authorized use of the Software. (3) To use and copy the
documentation related to the Software solely in support of authorized use of the Software by Licensee. The License applies to the Software
only except other Manufacture’s software or hardware products. Without the prior written consent of Manufacture, Licensee has no right to
receive any source code or design documentation with respect to the Software.
RESTRICTIONS ON USE; RESERVATION OF RIGHTS. The Software and related documentation are protected under copyright laws.
Manufacture and/or its licensors retain all title and ownership in both the Software and its related documentation, including any revisions
made by Manufacture. The copyright notice must be reproduced and included with any copy of any portion of the Software or related
documentation. Except as expressly authorized above, Licensee shall not copy or transfer the Software or related documentation, in whole
or in part. Licensee also shall not modify, translate, decompile, disassemble, use for any competitive analysis, reverse compile or reverse
assemble all or any portion of the Software, related documentation or any copy. The Software and related documentation embody
Manufacture’s confidential and proprietary intellectual property. Licensee is not allowed to disclose the Software, or any information about
the operation, design, performance or implementation of the Software and related documentation that is confidential to Manufacture to any
third party. Software and related documentation may be delivered to you subject to export authorization required by governments of Taiwan
and other countries. You agree that you will not export or re-export any Software or related documentation without the proper export licenses
required by the
governments of affected countries.
LIMITED SOFTWARE WARRANTY. Manufacture warrants that any media on which the Software is recorded will be free from defects in
materials under normal use for a period of twelve (12) months from date of shipment. If a defect in any such media should occur during the
effective warranty period, the media may be returned to Manufacture, then Manufacture will replace the media. Manufacture shall not be
responsible for the replacement of media if the failure of the media results from accident, abuse or misapplication of the media.
EXCLUSIONS.The warranty as mentioned above does not apply to the Software, which (1) customer does not comply with the manual
instructions offered by Manufacture in installation, operation, or maintenance, (2) Product fails due to damage from unusual external or
electrical stress, shipment, storage, accident, abuse or misuse, (3) Product is used in an extra hazardous environment or activities, (4) any
serial number on the Product has been removed or defaced, or (5) this warranty will be of no effect if the repair is via anyone other than

Publication date: Aug., 2014
Revision A1
iii
Manufacture or the authorized agents. The maximum liability of Manufacture under this warranty is confined to the purchase price of the
Product covered by this warranty.
DISCLAIMER. EXCEPT AS PROVIDED ABOVE, THE SOFTWARE IS PROVIDED “AS IS ” AND MANMANUFACTURE AND ITS
LICENSORS MAKE NO WARRANTIES, EXPRESS OR IMPLIED, WITH REPSECT TO THE SOFTWARE AND DOCUMENTAITON.
MANUFACTURE AND ITS LICENSORS DISCLAIM ALL OTHER WARRANTIES, INCLUSIVE OF WITHOUT LIMITATION, IMPLIED
WARRANTIES OR MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT. FURTHER,
MANUFACTURE DOES NOT WARRANT, GUARANTEE, OR MAKE ANY REPRESENTATIONS REGARDING THE USE, OR THE
RESULTS OF THE USE, OF THE SOFTWARE OR RELATED WRITTEN DOCUMENTAITON IN TERMS OF CORRECTNESS, ACCURACY,
RELIABILITY, OR OTHERWISE.
CONSEQUENTIAL DAMAGES. IN NO EVENT SHALL MANUFACTURE OR ITS AUTHORIZED RESELLER BE LIABLE TO LICENSEE
OR ANY THIRD PARTY FOR (A) ANY MATTER BEYOND ITS REASONABLE CONTROL OR (B) ANY CONSEQUENTIAL, SPECIAL,
INDIRECT OR INCIDENTAL DAMAGES ARISING OUT OF THIS LICENSE OR USE OF THE SOFTWARE PROVIDED BY
MANUFACTURE, EVEN IF MANUFACTURE HAS BEEN NOTIFIED OF THE POSSIBILITY OF SUCH DAMAGES IN ADVANCE. IN NO
EVENT SHALL THE LIABILITY OF MANUFACTURE IN CONNECTION WITH THE SOFTWARE OR THIS AGREEMENT EXCEED THE
PRICE PAID TO MANUFACTURE FOR THE LICENSE.
TERM AND TERMINATION. The License is effective until terminated; however, all of the restrictions in regard to Manufacture’s copyright in
the Software and related documentation will cease being effective at the date of expiration; Notwithstanding the termination or expiration of
the term of this agreement, it is acknowledged and agreed that those obligations relating to use and disclosure of Manufacture’s confidential
information shall survive. Licensee may terminate this License at any time by destroying the software together with all copies thereof. This
License will be immediately terminated if Licensee fails to comply with any term and condition of the Agreement. Upon any termination of
this License for any reason, Licensee shall discontinue to use the Software and shall destroy or return all copies of the Software and the
related documentation.
GENERAL. This License shall be governed by and construed pursuant to the laws of Taiwan. If any portion hereof is held to be invalid or
unenforceable, the remaining provisions of this License shall remain in full force and effect. Neither the License nor this Agreement is
assignable or transferable by Licensee without Manufacture’s prior written consent; any attempt to do so shall be void. This License
constitutes the entire License between the parties with respect to the use of the Software.
LICENSEE ACKNOWLEDGES THAT LICENSEE HAS READ THIS AGREEMENT, UNDERSTANDS IT, AND AGREES TO BE BOUND BY
ITS TERMS AND CONDITIONS. LICENSEE FURTHER AGREES THAT THIS AGREEMENT IS THE ENTIRE AND EXCLUSIVE
AGREEMENT BETWEEN MANUFACTURE AND LICENSEE.

Publication date:Aug., 2014
Revision A1
iv
Table of Contents
CAUTION ..........................................................................................................................VII
ELECTRONIC EMISSION NOTICES......................................................................................VII
WARNING: .......................................................................................................................VIII
1.INTRODUCTION........................................................................................................2
1-1. OVERVIEW OF THE 8XGE POE+1XGE SFPWEB SMART POESWITCH........................2
1-2. CHECKLIST ...................................................................................................................3
1-3.FEATURES......................................................................................................................3
1-4.VIEW OF 9-PORTGBEWEB SMART SWITCH..................................................................5
1-4-1. User Interfaces on the Front Panel (Button, LEDs and Plugs)...........................5
1-4-2. User Interfaces on the Rear Panel.......................................................................7
1-5.VIEW OF THE OPTIONAL MODULES...............................................................................7
2.INSTALLATION..........................................................................................................8
2-1. STARTING 9-PORTGBEWEB SMART POESWITCH UP...................................................8
2-1-1. Hardware and Cable Installation........................................................................8
2-1-2. Cabling Requirements .......................................................................................10
2-1-3. Configuring the Management Agent of9-PortGbE Web Smart Switch ..............14
2-1-4. IP Address Assignment ......................................................................................15
2-2. TYPICALAPPLICATIONS ..............................................................................................20
3.BASIC CONCEPTAND MANAGEMENT.............................................................21
3-1.WHAT’S THE ETHERNET..............................................................................................22
3-2. LOGICAL LINK CONTROL (LLC).................................................................................23
3-3. MEDIAACCESS CONTROL (MAC) ..............................................................................25
3-4. FLOW CONTROL .........................................................................................................30
3-5. HOW DOES A SWITCH WORK?......................................................................................33
3-6.VIRTUAL LAN............................................................................................................37
3-7. LINK AGGREGATION ...................................................................................................43
4. OPERATION OF WEB-BASED MANAGEMENT...................................................45
4-1.WEB MANAGEMENT HOME OVERVIEW ......................................................................46
4-2. CONFIGURATION.........................................................................................................48
4-2-1. System Information............................................................................................49
4-2-2. System Time.......................................................................................................52
4-2-3. Port Configuration ............................................................................................53
4-2-4. VLAN Mode Configuration................................................................................55
4-2-5. VLAN Group Configuration ..............................................................................56
4-2-6. VLAN Port Isolation Configuration...................................................................61
4-2-7. PoE Configuration.............................................................................................62
4-2-8. PoE State...........................................................................................................64
4-2-9. PoE Auto Checking............................................................................................66
4-2-10. PoE Scheduling ...............................................................................................68
4-2-11. Aggregation......................................................................................................70
4-2-12. RSTP................................................................................................................71
4-2-13. IGMP Snooping..............................................................................................73
4-2-14. Mirroring Configuration .................................................................................75
4-2-15. QoS(Quality of Service) Configuration...........................................................76
4-2-16. Loop Detection................................................................................................79
4-2-17. Broadcast Strom Protection.............................................................................81
4-3. Monitoring............................................................................................................83

Publication date: Aug., 2014
Revision A1
v
4-3-1. Statistics Overview ............................................................................................84
4-3-2. Detailed Statistics..............................................................................................85
4-3-3. RSTP Status.......................................................................................................88
4-3-4. IGMP Status ......................................................................................................90
4-3-5. Ping Status.........................................................................................................92
4-4. MAINTENANCE ...........................................................................................................94
4-4-1. Warm Restart.....................................................................................................95
4-4-2. Factory Default .................................................................................................96
4-4-3.Software Upgrade...............................................................................................97
4-4-4.Configuration File Transfer................................................................................98
4-4-5. Logout................................................................................................................99
5. MAINTENANCE..........................................................................................................100
5-1. RESOLVING NO LINK CONDITION .............................................................................100
5-2. Q&A ........................................................................................................................100
APPENDIX A TECHNICAL SPECIFICATIONS.........................................................101

Publication date:Aug., 2014
Revision A1
vi
Revision History
Release Date Revision
1.22 Aug. 21/2014 A1

Publication date: Aug., 2014
Revision A1
vii
Caution
Circuit devices are sensitive to static electricity, which can damage their
delicate electronics. Dry weather conditions or walking across a carpeted floor may
cause you to acquire a static electrical charge.
To protect your device, always:
Touch the metal chassis of your computer to ground the static electrical charge
before you pick up the circuit device.
Pick up the device by holding it on the left and right edges only.
If you need using outdoor device connect to this device with cable then you
need to addition an arrester on the cable between outdoor device and this
device.
Fig. Addition an arrester between outdoor device and this switch
The switch supports the SFP Vendor includes: Manufacture, Agilent, Avago and
Finisa
Electronic Emission Notices
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a
class A computing device pursuant to Subpart J of part 15 of FCC Rules, which are
designed to provide reasonable protection against such interference when operated
in a commercial environment.
European Community (CE) Electromagnetic Compatibility Directive
This equipment has been tested and found to comply with the protection
requirements of European Emission StandardEN55022/EN61000-3 and the Generic
European Immunity Standard EN55024.
EMC:
EN55022(2003)/CISPR-2( 2002) class A
IEC61000-4-2 (2001) 4K V CD, 8KV, AD
IEC61000-4-3( 2002) 3V/m
IEC61000-4-4(2001) 1KV – (power line), 0.5KV – (signal line)

Publication date:Aug., 2014
Revision A1
viii
Warning:
Self-demolition on Product is strictly prohibited. Damage caused by self-
demolition will be charged for repairing fees.
Do not place product at outdoor or sandstorm.
Before installation, please make sure input power supply and product
specifications are compatible to each other.

User Manual
Publication date:Aug., 2014
Revision A1
1
About this user’s manual
This user’s manual provides instructions on how to install your Web Smart Switch.
This guide also covers management options and detailed explanation about
hardware and software functions.
Overview of this user’s manual
Chapter 1 “Introduction” describes the features of 9-port Gigabit Web
Smart PoE Switch
Chapter 2 “Installation”
Chapter 3 “Operating Concept and Management”
Chapter 4 “Operation of Web-based Management”
Chapter 5 “Maintenance”

Publication date:Aug., 2014
Revision A1
2
1. Introduction
1-1. Overview of the 8xGE PoE + 1xGE SFP Web Smart PoE
Switch
The 9-port Gigabit Web Smart PoE Switch is a standard switch that meets all
IEEE 802.3/u/x/z Gigabit, Fast Ethernet specifications. The switch has 8
10/100/1000Mbps TP ports and 1GigabitSFP transceiver slot. It supports http
interface for switch management. The network administrator can logon the switch to
monitor, configure and control each port’s activity. In addition, the switch implements
the QoS (Quality of Service), VLAN, and Trunking. It is suitable for office application.
The switch also implements the support of Power saving for reducing the
power consumption using the "ActiPHY Power Management" and "Perfect Reach
Power Management" techniques. They enable efficient saving the switch power by
automatically detecting the idle clients and cable length and thus provide different
power.
10/100/1000Mbps TP is a standard Ethernet port that meets all IEEE
802.3/u/x/z Gigabit, Fast Ethernet specifications. 1000Mbps SFP Fiber transceiver
is a Gigabit Ethernet port that fully complies with 1000Base-SX/LX standards.
1000Mbps Single Fiber WDM (BiDi)transceiver is designed with an optic
Wavelength Division Multiplexing (WDM) technology that transports bi-directional
full duplex signal simultaneously over a single fiber.
•Key Features in the Device
QoS:
The switch offers powerful QoS function. This function supports 802.1p
VLAN tag priority and DSCP on Layer 3 of network framework.
VLAN:
The switch supports Port-based VLAN, IEEE802.1Q Tag VLAN, for 9 active
VLANs and VLAN ID 1~4094.
Port Trunking:
Allows one or more links to be aggregated together to form a Link
Aggregation Group by the static setting.
Power Saving:
The Power saving feature utilizes the "ActiPHY Power Management" and
"PerfectReach Power Management" techniques to detect the idle clients
and cable length automatically and thus supplies different power to each
port.
PoE:
The 8 PoE ports allow power to be supplied to end devices, such as
Wireless Access Points or VoIP Phones, directly through the existing LAN
cables, eliminating costs for additional AC wiring and reducing installation

Publication date: Aug., 2014
Revision A1
3
cost. The PoE feature is compliant with IEEE802.3at/af standard. The
switch provides the endpoint with 54VDC power through RJ-45 pin 1, 2, 3,
6.A total of 130 watts power (up 16.25 watts for 8 ports) is provided.
Broadcast Storm Protection：
Prevents traffic on a LAN from being disrupted by a broadcast storm on a
port.
1-2. Checklist
Before you start installing the switch, verify that the package contains the
following:
the Web Smart PoE Switch
Modules (optional)
Mounting Accessory (for WallMount)
This User's Manual in CD-ROM
QIG
AC Power Cord
Please notify your sales representative immediately if any of the aforementioned
items is missing or damaged.
1-3.Features
The 9 Port GbE Web Smart PoE Switch, a standalone off-the-shelf switch,
provides the comprehensive features listed below for users to perform system
network administration and efficiently and securely serve your network.
•Hardware
8 10/100/1000Mbps Auto-negotiation Gigabit Ethernet TP ports
1 100/1000Mbps SFP Fiber port
512KB on-chip frame buffer
GEPoESM-SW09.130,supports 130 watts for PoE Power and up to 16.25
watts for 8 ports.
Jumbo frame support 9KB
Programmable classifier for QoS (Layer 2/Layer 3)
8K MAC address and support VLAN ID (1~4094)
Per-port shaping, policing, and Broadcast Storm Control
Power Saving with "ActiPHY Power Management" and "PerfectReach Power
Management" techniques.
IEEE802.1Q-in-Q nested VLAN support
Full-duplex flow control (IEEE802.3x) and half-duplex backpressure
Extensive front-panel diagnostic LEDs; System: Power, Alarm, TP Port1-8:
LINK/ACT, PoE,10/100/1000Mbps, SFP Port 9: SFP(LINK/ACT)

Publication date:Aug., 2014
Revision A1
4
•Management
•Supports concisely the status of port and easily port configuration
•Supports per port traffic monitoring counters
•Supports a snapshot of the system Information when you login
•Supports port mirror function
• Supports the static trunk function
• Supports802.1Q VLAN
•Supports user management and limits one user to login
•Maximal packet length can be up to 9600 bytes for jumbo frame application
•Supports Broadcasting Suppression to avoid network suspended or crashed
•Supports to send the trap event while monitored events happened
•Supports default configuration which can be restored to overwrite the current
configuration which is working on via Web UI and Reset button of the switch
•Supports on-line plug/unplug SFP modules
•Supports Quality of Service (QoS) for real time applications based on the
information taken from Layer 2 to Layer 3.
•Built-in web-based management providing a more convenient GUI for the user

Publication date: Aug., 2014
Revision A1
5
1-4. View of 9-PortGbE Web Smart Switch
1-4-1. User Interfaces on the Front Panel (Button, LEDs and Plugs)
There are 8 TP Gigabit Ethernet PoE ports and 1 SFP fiber ports for optional
removable modules on the front panel of the switch. LED display area, locating on
the left side of the panel, contains a Power LED, which indicates the power status
and 8 ports working status of the switch.
Fig. 1-1 Full View of 9-PORT GBE WEB SMART PoE SWITCH
Fig. 1-2 Front View of 9-PORT GBE WEB SMART PoE Switch

Publication date:Aug., 2014
Revision A1
6
•Reset Button Indicators
Pressing
time(seconds) Function
3~10 Warm boot
>10 Reset factory default+ reboot
•LED Indicators
LED Color Function
System LED
POWER Green Lit when +3.3V power is coming up
ALARM Green
/Yellow
Yellow ON: temperature > 50° or when looping occurred.
10/100/1000Ethernet TP Port 1 to 8 LED
LINK/ACT Green
Lit when connection with remote device is good
Blinks when any traffic is present
PoE Yellow/
Off
Lit Yellow when PoE mode enable
Off when PoE mode disable
1000SX/LX Gigabit Fiber Port 9 LED
LINK/ACT Green
Lit when SFP connection with remote device is good
Blinks when any traffic is present
SPD
Green/
Yellow/
Off
Lit Green when SFP link on 1000Mbps speed
Lit Yellow when SFP link on 100Mbps speed
Off when no link occur
Table1-1

Publication date: Aug., 2014
Revision A1
7
1-4-2. User Interfaces on the Rear Panel
1-5. View of the Optional Modules
In the switch, Port 9100/1000Mbps SFP Fiber with auto-detected function.
100/1000Mbps SFP Fiber transceiver is used for high-speed connection expansion;
nine optional SFP types provided for the switch are listed below:
1000Mbps LC, MM, SFP Fiber transceiver (SFP.LC)
1000Mbps LC, SM 10km, SFP Fiber transceiver (SFP.LC.S10)
1000Mbps LC, SM 30km, SFP Fiber transceiver (SFP.LC.S30)
1000Mbps LC, SM 50km, SFP Fiber transceiver (SFP.LC.S50)
1000Mbps BiDi SC, SM 20km, 1310nm SFP Fiber WDM transceiver
(SFP.BS3.S20)
1000Mbps BiDi SC, SM 20km, 1550nm SFP Fiber WDM transceiver
(SFP.BS5.S20)
PS: The other specifications are available upon request.
Fig. 1-3 Rear View of9-PORT GBE WEB SMART PoE SWITCH
Fig. 1-4 Front View of 1000Base-SX/LX LC, SFP Fiber Transceiver
Fig. 1-5 Front View of 1000Base-LX BiDi SC SFP Fiber Transceiver

Publication date:Aug., 2014
Revision A1
8
2. Installation
2-1. Starting 9-PortGbE Web Smart PoE Switch Up
This section will give users a quick start for:
- Hardware and Cable Installation
- Management Station Installation
- Software booting and configuration
2-1-1. Hardware and Cable Installation
At the beginning, please do first:
Wear a grounding device to avoid the damage from electrostatic discharge
Be sure that power switch is OFF before you insert the power cord to power
source
•Installing Optional SFP Fiber Transceivers to the 9-PortGbE Web Smart
Switch
Note: If you have no modules, please skip this section.
•Connecting the SFP Module to the Chassis:
The optional SFP modules are hot swappable, so you can plug or unplug it
before or after powering on.
Fi
g
. 2-1Installation of O
p
tional SFP Fiber Transceive
r

Publication date: Aug., 2014
Revision A1
9
1. Verify that the SFP module is the right model and conforms to the chassis
2. Slide the module along the slot. Also be sure that the module is properly
seated against the slot socket/connector
3. Install the media cable for network connection
4. Repeat the above steps, as needed, for each module to be installed into
slot(s)
5. Have the power ON after the above procedures are done
•TP Port and Cable Installation
In the switch, TP port supports MDI/MDI-X auto-crossover, so both types of
cable, straight-through (Cable pin-outs for RJ-45 jack 1, 2, 3, 6 to 1, 2, 3, 6 in
10/100M TP; 1, 2, 3, 4, 5, 6, 7, 8 to 1, 2, 3, 4, 5, 6, 7, 8 in Gigabit TP) and
crossed-over (Cable pin-outs for RJ-45 jack 1, 2, 3, 6 to 3, 6, 1, 2) can be used.
It means you do not have to tell from them, just plug it.
Use Cat. 5 grade RJ-45 TP cable to connect to a TP port of the switch and the
other end is connected to a network-aware device such as a workstation or a
server.
Repeat the above steps, as needed, for each RJ-45 port to be connected to a
Gigabit 10/100/1000 TP device.
Now, you can start having the switch in operation.
•Power On
The switch supports 100-240 VAC power supply. The power supply will
automatically convert the local AC power source to DC power. It does not matter
whether any connection plugged into the switch or not when power on, even
modules as well. After the power is on, all LED indicators will light up and then all off
except the power LED still keeps on. This represents a reset of the system.
•Firmware Loading
After resetting, the bootloader will load the firmware into the memory. It will
take about 30 seconds, after that, the switch will flash all the LED once and
automatically performs self-test and is in ready state.

Publication date:Aug., 2014
Revision A1
10
2-1-2. Cabling Requirements
To help ensure a successful installation and keep the network performance good,
please take a care on the cabling requirement. Cables with worse specification will render the
LAN to work poorly.
2-1-2-1. Cabling Requirements for TP Ports
For Fast Ethernet TP network connection
The grade of the cable must be Cat. 5 or Cat. 5e with a maximum length of
100 meters.
Gigabit Ethernet TP network connection
The grade of the cable must be Cat. 5 or Cat. 5e with a maximum length of
100 meters. Cat. 5e is recommended.
2-1-2-2. Cabling Requirements for 1000SX/LXSFP Module
It is more complex and comprehensive contrast to TP cabling in the fiber
media. Basically, there are two categories of fiber, multi-mode (MM) and single
mode (SM). The later is categorized into several classes by the distance it supports.
They are SX, LX, LHX, XD, and ZX. From the viewpoint of connector type, there
mainly are LC and BIDI SC.
Gigabit Fiber with multi-mode LC SFP module
Gigabit Fiber with single-mode LC SFP module
Gigabit Fiber with BiDi SC 1310nm SFP module
Gigabit Fiber with BiDi SC 1550nm SFP module
The following table lists the types of fiber that we support and those else not
listed here are available upon request.
Gigabit Ethernet
1000SX 850nm
Multi-mode Fiber Cable and Modal Bandwidth
Multi-mode 62.5/125m Multi-mode 50/125m
Modal
Bandwidth Distance Modal Bandwidth Distance
160MHz-Km 220m 400MHz-Km 500m
200MHz-Km 275m 500MHz-Km 550m
1000Base-
LX/LHX/XD/ZX
Single-mode Fiber 9/125m
Single-mode transceiver 1310nm 10, 30Km
Single-mode transceiver 1550nm 50Km
1000Base-LX
Single Fiber
(BIDI SC)
Single-Mode
*20Km
TX(Transmit) 1310nm
RX(Receive) 1550nm
Single-Mode
*20Km
TX(Transmit) 1550nm
RX(Receive) 1310nm
Table2-1

Publication date: Aug., 2014
Revision A1
11
2-1-2-3. Switch Cascading in Topology
•Takes the Delay Time into Account
Theoretically, the switch partitions the collision domain for each port in switch
cascading that you may up-link the switches unlimitedly. In practice, the network
extension (cascading levels & overall diameter) must follow the constraint of the
IEEE 802.3/802.3u/802.3z and other 802.1 series protocol specifications, in which
the limitations are the timing requirement from physical signals defined by 802.3
series specification of Media Access Control (MAC) and PHY, and timer from some
OSI layer 2 protocols such as 802.1d, 802.1q, LACP and so on.
The fiber, TP cables and devices’ bit-time delay (round trip) are as follows:
1000Base-X TP, Fiber 100Base-TX TP 100Base-FX Fiber
Round trip Delay: 4096 Round trip Delay: 512
Cat. 5 TP Wire: 11.12/m Cat. 5 TP Wire: 1.12/m Fiber Cable: 1.0/m
Fiber Cable : 10.10/m TP to fiber Converter: 56
Bit Time unit : 1ns (1sec./1000 Mega bit) Bit Time unit: 0.01s (1sec./100 Mega bit)
Table 2-2
Sum up all elements’ bit-time delay and the overall bit-time delay of
wires/devices must be within Round Trip Delay (bit times) in a half-duplex network
segment (collision domain). For full-duplex operation, this will not be applied. You
may use the TP-Fiber module to extend the TP node distance over fiber optic and
provide thelong haul connection.
•Typical Network Topology in Deployment
A hierarchical network with minimum levels of switch may reduce the timing
delay between server and client station. Basically, with this approach, it will
minimize the number of switches in any one path; will lower the possibility of
network loop and will improve network efficiency. If more than two switches are
connected in the same network, select one switch as Level 1 switch and connect all
other switches to it at Level 2. Server/Host is recommended to connect to the Level
1 switch. This is general if no VLAN or other special requirements are applied.

Publication date:Aug., 2014
Revision A1
12
Case1: All switch ports are in the same local area network. Every port can access
each other (See Fig. 2-2) *
If VLAN is enabled and configured, each node in the network that can
communicate each other directly is bounded in the same VLAN area.
Here VLAN area is defined by what VLAN you are using. The switch
supports both port-based VLAN and tag-based VLAN. They are different in practical
deployment, especially in physical location. The following diagram shows how it
works and what the difference they are.
Case2a: Port-based VLAN (See Fig.2-3). *
1. The same VLAN members could not be in different switches.
2. Every VLAN members could not access VLAN members each other.
3. The switch manager has to assign different names for each VLAN groups
at one switch.
Fi
g
. 2-2No VLAN Confi
g
uration Dia
g
ram
Fig. 2-3 Port-based VLAN Diagram
