Preface
Thank you for using our switches. This guide (Version: V1.11) provides you with detailed operation guide that
allows you to easily install and use the switches.
Scope
This manual describes the functions and physical features of the switches, and presents the installation procedure,
troubleshooting procedure, technical specifications, and specifications and usages rules of cables and connectors.
It is intended for the users that have some experience in installing and maintaining network hardware and want to
learn the above information. At the same time, it is assumed that the users of this switch are already familiar with
the related terms and concepts of Ethernet.
Document Structure
Chapter 1 "Product Overview" describes the main characteristics, technical specifications, and related
modules of this product.
Chapter 2 "Preparation before Installation" lists the safety, power supply, and site requirements that must
be met before the switch can be installed.
Chapter 3 “Product Installation” describes how to install the integrated switch and modules, and connect its
power cables and grounding lines.
Chapter 4 "System Debugging" describes the debugging after the switch is powered on for the first time.
Chapter 5 "Troubleshooting" describes possible problems, detections and solutions in the switch installation
and application.
Appendix A “Connector and Connection Media”
Appendix B “Mini-GBIC Modules”
Related Documents
Software manual of switches——covering CLI commands, software configuration guide, and version release notes.
Obtaining Documentation
You can obtain the documentation you need through the following channels:
Internet:
You can obtain the latest on-line documentation of Ruijie Networks at:
http://www.ruijie.com.cn
Documentation CD-ROM:
The documentation of Ruijie Networks switches is stored in the CD-ROM package, which is provided to you together
with the product you purchase. The CD-ROM is updated frequently, and may be more current than the printed
documents.
Obtaining Technical Assistance
Ruijie Networks provides excellent technical support services for all our products. You can obtain the technical
assistance you need through any of the following channels:
Ruijie Networks website, from which you can obtain the latest product documentation, causes and problems
analysis of product faults, application solutions, and software upgrade.
Customer service center of Ruijie Networks, which can provide all customers with needed technical
assistance for products, technologies and solutions. The customer service center provides responsive
technical support for your product installation problems, software configuration problems, and other network
performance problems.
Customer services hotline: [phone]
Customer services website: http://www.ruijie.com.cn

Customer services email: [email protected]
Documentation Conventions
The symbols used in this document are described as below:
This symbol draws the attention of readers to some suggestions and references.
This symbol reminds readers to be alert of wrong operations that may lead to loss of data or damage to equipment.

Chapter 1 Product Overview
1.1 Product Overview
The RG-S2600E series switches of Ruijie are mostly applied at the access layers of small- and medium-sized
networks to provide line-speed exchanging and complete QoS services, and ensure the undelayed transmission of
key data by applying different traffic classification rules to different services. The S2600E series provide flexible
medium interfaces and can meet the connection requirements of different media in network constructions.
Table 1-1 RG-S2600E series
Model 10/100Base-T
adaptive Ethernet
port
10/100/1000Base-T
adaptive Ethernet port
1000Base-X SFP
port
Console port Extension
Module Slot
RG-S2628G-E 24 2 2 1 1
RG-S2652G-E 48 2 2 1 1
RG-S2628G-P 24 2 2 1 1
RG-S2652G-P 48 2 2 1 1
The extension module slot supports M3000E-02SFP/GT and M3000E-STACK modules. The M3000E-02SFP/GT
module extends 2 1000M SFP fiber/copper combo ports, and the M3000E-STACK mudule provides 2 full-duplex
stack ports.
The 1000Base-X SFP port and the corresponding 10/100/1000Base-T adaptive Ethernet port form a fiber/copper
combo port. That is, only one port in the fiber/copper combo port is available at a particular time.Table 1-2 shows the
mappings between two ports that form an fiber/copper combo port.
Table 1-2 Mappings between two ports that form an fiber/copper combo port
Model 1000Base-X SFP port 10/100/1000Base-T adaptive Ethernet port
RG-S2628G-E 25F 25
26F 26
RG-S2652G-E 49F 49
50F 50
RG-S2628G-P 25F 25
26F 26
RG-S2652G-P 49F 49
50F 50
1.2 Main Technical Specifications of RG-S2600E
Table 1-3 Technical specifications of the S2600E series

Model RG-S2628G-E
RG-S2652G-E RG-S2628G-P
RG-S2652G-P
Module type Ethernet 100M: FE-SFP-LX-MM1310
FE-SFP-LH15-SM1310
Ethernet 1000M: Mini-GBIC-SX
Mini-GBIC-LX
Mini-GBIC-LH40
Mini-GBIC-ZX50
Mini-GBIC-ZX80
Mini-GBIC-ZX100
1000Base-T：Mini-GBIC-GT
Note: the supported module type may change at any time. For the detailed change
information, consult the Ruijie Networks.
Extended Module Type M3000E-02SFP/GT
M3000E-STACK
SFP Port 100Base-X
1000Base-X
RPS Type Unsupported RG-RPS150
RG-RPS500
RG-RPS1100
Power Supply AC input:
Rated pressure range: 100-240V~
Maximum pressure range: 90-264V~
Frequency: 50-60Hz
Rated current: 2 A
AC input:
Rated pressure range: 100-240V~
Maximum pressure range: 90-264V~
Frequency: 50-60Hz
Rated current: 6 A
POE Function RG-S2628G-P: 24 ports with each support maximum 15.4W; supports the maximum
PoE 370W.
RG-S2652G-P：connects to RPS1100, 48 ports with each support maximum 15.4W and
supports the maximum PoE 370W; connects to RPS1100 and supports
the maximum PoE 740W.

Power consumption RG-S2628G-E: with extension modules < 27 W and without extension modules < 23 W
RG-S2652G-E: with extension modules < 38 W and without extension modules < 34 W
RG-S2628G-P: with extension modules, 24 ports and POE< 430 W and without
extension modules and POE <56 W
RG-S2652G-P: with extension modules, 48 ports and POE< 813 W(connecting
RPS1100) and without extension modules and POE <69 W
Temperature Working temperature: 0ºC to 50ºC
Storage temperature: -40ºC to 70ºC
Humidity Working humidity: 10% to 90% RH
Storage humidity: 5% to 90% RH
Fan RG-S2628G-E：no fan
RG-S2652G-E/RG-S2628G-P/RG-S2652G-P：supports adjustment of fan speed and
warning of fan trouble.
Temperature Warning Temperature warning function
EMC GB9254-1998
Security compliance GB4943-2001
Dimensions (w x d x h) RG-S2628G-E: 440 x 260 x 44 mm
RG-S2652G-E: 440 x 300 x 44 mm
RG-S2628G-P: 440 x 300 x 44 mm
RG-S2652G-P: 440 x 420 x 44 mm
Weight RG-S2628G-E: with extension modules 4.4 Kg and without extension modules 3.9 Kg
RG-S2652G-E: with extension modules 4.9 Kg and without extension modules 4.4 Kg
RG-S2628G-P: with extension modules 7.5Kg and without extension modules 7.0 Kg
RG-S2652G-P: with extension modules 8.1Kg and without extension modules 7.6 Kg
1.3 RG-S2600E Series Models
1.3.1 RG-S2628G-E Ethernet Switch
Product Appearance
The front panel of the RG-S2628G-E Ethernet switch provides twenty four 10/100Base-T Ethernet ports, two GE
SFP fiber/copper combo ports and one Console port. The backplanel provides AC power input ports and an
extension module slot. Figure 1-1 shows the appearance of the RG-S2628G-E.

Figure 1-1 Appearance of the RG-S2628G-E
Ports on the Front Panel
Figure 1-2 Schematic diagram of the RG-S2628G-E front panel
1. Switch status indicator
2. Extension module indicator
3. Extension port 1 status indicator
4. Extension port 2 status indicator
5. Console port
6. 10/100Base-T adaptive Ethernet port
7. 10/100Base-T adaptive Ethernet port indicator
8. 10/100/1000Base-T adaptive Ethernet port
9. 100/1000Base-X SFP port
10. 10/100/1000Base-T adaptive Ethernet port indicator
11. 100/1000Base-X SFP port indicator
Ports on the Backpanel
Figure 1-3 Schematic diagram of the RG-S2628G-E backpanel
1. Grounding pole
2. 3-core AC power interface
3. Power defense shedding plug
4. Extension module slot

Power Supply System
The RG--S2628G-E adopts the AC power input.
AC input:
Rated pressure range: 100-240V~
Maximum pressure range: 90-264V~
Frequency: 50-60Hz
Rated current: 2 A
Power cable current: 10A
Heat Dissipation System
The RG-S2628G-E is designed with no fans. To ensure good dissipation, sufficient ventilation space(10cm distance
from both sides and the backplane of the cabinet) should be reserved to avoid blocking the air inlet of the cabinet;
otherwise, the dissipation might be affected.
1.3.2 RG-S2652G-E Ethernet Switch
Product Appearance
The front panel of the RG-S2652G-E Ethernet switch provides forty eight 10/100Base-T Ethernet ports, two GE SFP
fiber/copper combo ports and one Console port. The backplanel provides AC power input ports and an extension
module slot. Figure 1-4 shows the appearance of the RG-S2652G-E.
Figure 1-4 Appearance of the RG-S2652G-E
Ports on the Front Panel
Figure 1-5 Schematic diagram of the RG-S2652G-E front panel
1. Switch status indicator
2. Extension module indicator
3. Extension port 1 status indicator
4. Extension port 2 status indicator
5. Console port

6. 10/100Base-T adaptive Ethernet port
7. 10/100Base-T adaptive Ethernet port indicator
8. 10/100/1000Base-T adaptive Ethernet port
9. 100/1000Base-X SFP port
10. 10/100Base-T adaptive Ethernet port indicator
11. 100/1000Base-X SFP port indicator
Ports on the Backpanel
Figure 1-6 Schematic diagram of the RG-S2652G-E backpanel
1. Grounding pole
2. 3-core AC power interface
3. Power defense shedding plug
4. Fan outlet
5.Extension module slot
Power Supply System
The RG--S2652G-E adopts the AC power input.
AC input:
Rated pressure range: 100-240V~
Maximum pressure range: 90-264V~
Frequency: 50-60Hz
Rated current: 2 A
Power cable current: 10A
Heat Dissipation System
The RG-S2652G-E adopts turbine fans for heat dissipation purposes, thereby ensuring the device to function
normally in the specified environment. At least 10cm distance space should be reserved around both sides and the
backplane of the cabinet to allow air circulation. Figure 1-7 shows the flow scheme of heat dissipation.

Air outlet
Figure 1-7 Flow scheme of heat dissipation
1.3.3 RG-S2628G-P Ethernet Switch
Product Appearance
The front panel of the RG-S2628G-P Ethernet switch provides twenty four 10/100Base-T Ethernet ports, two GE
SFP fiber/copper combo ports and one Console port. The backpanel provides AC power input ports, RPS input
interfaces, and an extension module slot. Figure 1-8 shows the appearance of the RG-S2628G-P.
Figure 1-8 Appearance of the RG-S2628G-P
Ports on the Front Panel
Figure 1-9 Schematic diagram of the RG-S2628G-P front panel
1. POE mode indicator
2. Switch status indicator
3. Extension module indicator
4. Extension port 1 status indicator
5. Extension port 2 status indicator

6. RPS link indicator
7. POE mode switchover button
8. Console port
9. 10/100Base-T adaptive Ethernet port
10. 10/100Base-T adaptive Ethernet port indicator
11. 10/100/1000Base-T adaptive Ethernet port
12. 100/1000Base-X SFP port
13. 10/100/1000Base-T adaptive Ethernet port indicator
14. 100/1000Base-X SFP port indicator
Ports on the Backpanel
Figure 1-10 Schematic diagram of the RG-S2628G-P backpanel
1. Grounding pole
2. RPS power interface
3. 3-core AC power interface
4. Power defense shedding plug
5. Fan outlet
6. Extension module slot
Power Supply System
The RG-S2628G-P adopts the AC power input and redundant power input.
AC input:
Rated voltage range: 100-240V~
Maximum pressure range: 90-264V~
Frequency: 50-60Hz
Rated current: 6 A
Power cable current: 10A
Redundant power input:
The switch power can be supplied by the redundant power input or both the AC input and redundant power input.
When both the AC input and the redundant power input are available, the switch power is supplied by the AC power
input; while the AC input is unavailable, the switch power supply switches to the redundant power input seemlessly.

At present, the redundant power supply interface can be used together with the RPS150, RPS500, and RPS1100
that are manufactured by Ruijie Networks. Unless otherwise stated, other power supply modules cannot be used for
power input; otherwise, an abnormality may occur on the switch or the switch may become damaged.
Heat Dissipation System
The RG-S2628G-P adopts turbine fans for heat dissipation purposes, thereby ensuring the device to function
normally in the specified environment. Sufficient space(10cm distance from both sides and the backplane of the
cabinet) should be reserved to allow air circulation. Figure 1-11 shows the flow scheme of heat dissipation.
Figure 1-11 Flow scheme of heat dissipation
1.3.4 RG-S2652G-P Ethernet Switch
Product Appearance
The front panel of the RG-S2652G-P Ethernet switch provides forty eight 10/100Base-T Ethernet ports, two GE SFP
fiber/copper combo ports and one Console port. The backplanel provides AC power input ports, RPS input port
and an extension module slot. Figure 1-12 shows the appearance of the RG-S2652G-P.

Figure 1-12 Appearance of the RG-S2652G-P
Ports on the Front Panel
Figure 1-13 Schematic diagram of the RG-S2652G-P front panel
1. POE mode indicator
2. Switch status indicator
3. Extension module indicator
4. Extension port 1 status indicator
5. Extension port 2 status indicator
6. RPS link indicator
7. POE mode switchover button
8. Console port
9. 10/100Base-T adaptive Ethernet port
10. 10/100Base-T adaptive Ethernet port indicator
11. 10/100/1000Base-T adaptive Ethernet port
12. 100/1000Base-X SFP port
13. 10/100/1000Base-T adaptive Ethernet port indicator
14. 100/1000Base-X SFP port indicator
Ports on the Backpanel
Figure 1-14 Schematic diagram of the RG-S2652G-P backpanel
1. Grounding pole
2. RPS input interface
3. 3-core AC power interface
4. Power defense shedding plug
5. Fan outlet
6. Extension module slot
Power Supply System
The RG-S2652G-P adopts the AC power input and redundant power input.

AC input:
Rated voltage range: 100-240V~
Maximum voltage range: 90-264V~
Frequency: 50-60Hz
Rated current:6 A
Power cable current: 10A
Redundant power input:
The switch power can be supplied by the redundant power input or both the AC input and redundant power input.
When both the AC input and the redundant power input are available, the switch power is supplied by the AC power
input; while the AC input is unavailable, the switch power supply switches to the redundant power input seemlessly.
At present, the redundant power supply interface can be used together with the RPS150, RPS500, and RPS1100
that are manufactured by Ruijie Networks. Unless otherwise stated, other power supply modules cannot be used for
power input; otherwise, an abnormality may occur on the switch or the switch may become damaged.
Heat Dissipation System
The RG-S2652G-P adopts turbine fans for heat dissipation purposes, thereby ensuring the device to function
normally in the specified environment. 10cm distance space should be reserved at both sides and the backplane of
the cabinet to allow air circulation. Figure 1-15 shows the flow scheme of heat dissipation.
Air intake
Air intake
Figure 1-15 Flow scheme of heat dissipation
1.4 LED Indicators
Table 1-4 Indicators for the RG-S2628G-E/RG-S2628G-P
Indicator Panel
Identification
Status Meaning
POE indicator (only for
the S2628G-P) POE Solid green The port indicator indicates the switching state.
Solid yellow The port indicator indicates the POE power
supply state.

Indicator Panel
Identification
Status Meaning
Link indicator Status Off The switch is not powered on.
Blinking green The switch is being initialized. If the blinking
persists, however, it indicates that an
abnormality occurs.
Solid green Normal switching is performed by the switch.
Solid yellow It indicates a warning on the switch
temperature. Check the working environment of
the switch immediately.
Solid red Indicates a fault on the switch. For details, refer
to Section 5.2 Troubleshooting Common Faults.
Extension module
indicator Module Off There is no extension module or the extension
module is not correctly installed.
Solid green The extension module is correctly installed.
Extension module port
indicator
For the
M3000E-02SFP/GT
A/B
Off The port is not connected to a link.
Solid green The 1000 M link that the port connects to is Up.
Blinking green Data at a rate of 1000 M are being transceived
at the port.
Solid yellow The 100 or 10 M link that the port connects to is
Up.
Blinking yellow Data at a rate of 100 or 10 M are being
transceived at the port.
Extension module port
indicator
For the M3000E-STACK
Off The stack port is not connected to a link.
Solid green The stack port links up.
Blinking green Data are being transceived at the stack port.
RPS link indicator (only
for the S2628G-P)
RPS
Off The redundant power supply module is not
connected or is not powered on.
Solid green The redundant power supply module is
connected and can supply power.
Solid yellow The redundant power supply module is
supplying power.
Solid red The redundant power supply module is
connected but does not supply power.
10/100Mbps RJ-45 port
indicator 1~24
Off The port is not connected to a link.
Solid green The 100 M link that the port connects to is Up.
Blinking green Data at a rate of 100 M are being transceived at
the port.
Solid yellow The 10 M link that the port connects to is Up.
Blinking yellow Data at a rate of 10 M are being transceived at
the port.
POE state indicator (only
for S2628G-P and the
POE indicator is solid 1~24 Off The POE is not powered on.
Solid green The POE has been powered on.

Indicator Panel
Identification
Status Meaning
yellow) Solid yellow The POE is overloaded, and is not powered on.
Solid red The port POE does not supply power.
1000Mbps SFP port
indicator 25F, 26F
Off The port is not connected to a link.
Solid green The 1000 M link that the port connects to is Up.
Blinking green Data at a rate of 1000 M are being transceived
at the port.
Solid yellow The 100 M link that the port connects to is Up.
Blinking yellow Data at a rate of 100 M are being transceived at
the port.
1000Mbps RJ-45 port
indicator
25, 26
Off The port is not connected to a link.
Solid green The 1000 M link that the port connects to is Up.
Blinking green Data at a rate of 1000 M are being transceived
at the port.
Solid yellow The 100 or 10 M link that the port connects to is
Up.
Blinking yellow Data at a rate of 100 or 10 M are being
transceived at the port.
Table 1-5 Indicators for the RG-S2652G-E/RG-2652G-P
Indicator Panel
Identification
Status Meaning
POE indicator (only for
the S2652G-P) POE Solid green The port indicator indicates the switching state.
Solid yellow The port indicator indicates the POE power
supply state.
Link indicator Status Off The switch is not powered on.
Blinking green The switch is being initialized. If the blinking
persists, however, it indicates that an
abnormality occurs.
Solid green Normal switching is performed by the switch.
Solid yellow It indicates a warning on the switch
temperature. Check the working environment of
the switch immediately.
Solid red Indicates a fault on the switch. For details, refer
to Section 5.2 Troubleshooting Common Faults.
Extension module
indicator Module Off There is no extension module or the extension module is not correctly installed.
Solid green The extension module is correctly installed.
Extension module port
indicator
For the
M3000E-02SFP/GT
A/B
Off The port is not connected to a link.
Solid green The 1000 M link that the port connects to is Up.
Blinking green Data at a rate of 1000 M are being transceived

Indicator Panel
Identification
Status Meaning
at the port.
Solid yellow The 100 or 10 M link that the port connects to is
Up.
Blinking yellow Data at a rate of 100 or 10 M are being
transceived at the port.
Extension module port
indicator
For the M3000E-STACK
Off The stack port is not connected to a link.
Solid green The stack port links up.
Blinking green Data are being transceived at the stack port.
RPS link indicator (only for
the S2652G-P)
RPS
Off The redundant power supply module is not
connected or is not powered on.
Solid green The redundant power supply module is
connected and can supply power.
Solid yellow The redundant power supply module is
supplying power.
Solid red The redundant power supply module is
connected but does not supply power.
10/100Mbps RJ-45 port
indicator
1~48
Off The port is not connected to a link.
Solid green The 100 M link that the port connects to is Up.
Blinking green Data at a rate of 100 M are being transceived at
the port.
Solid yellow The 10 M link that the port connects to is Up.
Blinking yellow Data at a rate of 10 M are being transceived at
the port.
POE state indicator (only
for S2652G-P and the
POE indicator is solid
yellow) 1~48
Off The POE is not powered on.
Solid green The POE has been powered on.
Solid yellow The POE is overloaded, and is not powered on.
Solid red The port POE does not supply power.
1000Mbps SFP port
indicator
49F, 50F
Off The port is not connected to a link.
Solid green The 1000 M link that the port connects to is Up.
Blinking green Data at a rate of 1000 M are being transceived
at the port.
Solid yellow The 100 M link that the port connects to is Up.
Blinking yellow Data at a rate of 100 M are being transceived at
the port.
1000Mbps RJ-45 port
indicator
49, 50
Off The port is not connected to a link.
Solid green The 1000 M link that the port connects to is Up.
Blinking green Data at a rate of 1000 M are being transceived
at the port.
Solid yellow The 100 or 10 M link that the port connects to is
Up.
