Vivotek AW-IHT-1271 User manual

M ANAGEMENT G UIDE
AW-IHT-1271
CLI User Guide
Industrial VivoCam L2+ Managed PoE Switch
8xGE PoE + 4xGE SFP
Release A1

ABOUT THIS GUIDE
PURPOSE This guide gives specific information on how to operate CLI
to manage this switch.
AUDIENCE The guide is intended for use by network administrators who
are responsible for operating and maintaining network
equipment; consequently, it assumes a basic working
knowledge of general switch functions, the RS-232 Console ,
Internet Protocol (IP), and Telnet Protocol.

Revision History
Release
Date
Revision
Initial Release
2018/03/30
A1

CONTENTS
ABOUT THIS GUIDE..................................................................................................................................................... II
REVISION HISTORY........................................................................................................................................ III
CONTENTS ............................................................................................................................................................ 1
1CLI MANAGEMENT......................................................................................................................................... 3
1-1 LOGIN......................................................................................................................................................................... 4
1-2 COMMANDS OF CLI.......................................................................................................................................................5
1-3 GLOBAL COMMANDS OF CLI ...........................................................................................................................................6
2CLEAR OF CLI.............................................................................................................................................. 9
3CONFIGURE COMMANDS OF CLI...................................................................................................................10
4 COPY COMMANDS OF CLI ................................................................................................................................147
5DELETE COMMANDS OF CLI .............................................................................................................................148
6 DIR COMMANDS OF CLI ...................................................................................................................................149
7 DISABLE COMMANDS OF CLI............................................................................................................................150
8DO COMMANDS OF CLI....................................................................................................................................151
9DOT1X OF CLI ...................................................................................................................................................152
10 ENABLE OF CLI................................................................................................................................................153
11 ERPS OF CLI ....................................................................................................................................................154
12 FIRMWARE OF CLI ..........................................................................................................................................155
13 IP OF CLI.........................................................................................................................................................156
14 IPV6 OF CLI.....................................................................................................................................................157
15 LINK-OAM OF CL I...........................................................................................................................................158
16 NO OF CLI.......................................................................................................................................................158
17 PING OF CLI....................................................................................................................................................160
18 PLATFORM OF CLI...........................................................................................................................................162

19 PTP OF CLI ......................................................................................................................................................163
20 RELOAD OF CLI ...............................................................................................................................................165
21 SEND OF CLI ...................................................................................................................................................166
22 SHOW OF CLI..................................................................................................................................................167
23 TERMINAL OF CLI ...........................................................................................................................................238
24 TRACEROUTE OF CLI .....................................................................................................................................240
25 VERIPHY OF CLI ............................................................................................................................................289

1 CLI Management
The following description is the brief of the network connection.
-- Locate the correct DB-9 (RS-232) cable with female DB-9 connector. RS-232 cable is used for connecting a terminal or
termial emulator to the Managed Switch’s RJ45 port to access the command-line interface.
-- Attach the RJ45 serial port on the switch’s front panel which used to connect to the switch for console configuration
-- Attach the other end of the DB-9 cable to anASCII terminal emulator or PC Com-1, 2 port. For example, PC runs
Microsoft Windows HyperTerminal utility.
-- At “Com Port Properties” Menu, configure the parameters as below: (see the next section)
Baud rate 115200
Stop bits 1
Data bits 8
Parity N
Flow control none

1-1 Login
The command-line interface (CLI) is a text-based interface. User can access the CLI through either a direct serial
connection to the device or a Telnet session (Default IP address: DHCP Client). The default uaser and password to login
into the Managed Switch are listed below:
Username: admin
Password: <none>
Note: <none> means empty string
After you login successfully, the prompt will be shown as “<sys_name>#“ . See the following two figures. It means you
behave as an administrator and have the privilege for setting the Managed Switch. If log as not the administrator, the
prompt will be shown as “<sys_name>>”, it means you behave as a guest and are only allowed for setting the system
under the administrator. Each CLI command has its privilege
Username: admin
Password: admin
AW-IHT-1271#

1-2 Commands of CLI
The CLI is divided into serveral modes. If a user has enouth privilege to run a particular command, the user has to
run the command in the correct mode. To see the commands of the mode, please input “?” after the system prompt, then
all commands will be listed in the screen. The command modes are listed as belows:
Command Modes
MODE
PROMPT
COMMAND FUNCTION IN THIS MODE
exec
<sys_name>#
Display current configuration, diagnostics,
maintenance
config
<sys_name>(config)#
Configure features other than those below
Config-if
<sys_name>(config-interface)#
Configure ports
Config-if-vlan
<sys_name>(config-if-vlan)#
Configure static vlan
Config-line
<sys_name>(config-line)#
Line Configuration
Config-impc-profile
<sys_name>(config-impc-profile)#
IPMC Profile
Config-snmp-host
<sys_name>(config-snmp-host)#
SNMP Server Host
Config-stp-aggr
<sys_name>(config-stp-aggr)#
STP Aggregation
Config-dhcp-pool
<sys_name>(config-dhcp-pool)#
DHCP Pool Configuration
Config-rfc2544-profile
<sys_name>(config-rfc2544-profile)#
RFC2544 Profile
Commandsreside in the corresponding modes could runonly in that mode. If a user wants to run a particular command,
the user has to change to the appropriate mode. The command modes are organized as a tree, and users start to in
enable mode. The following table explains how to change from one mode to another.
Change Between Command Modes
MODE
ENTER MODE
LEAVE MODE

exec
--
--
config
Configure terminal
exit
config-interfcae
Interface <port-type> <port-type-list>
exit
config-vlan
Interface vlan <vlan_list>
exit
1-3 Global Commands of CLI
AW-IHT-1271# ?
clear Reset functions
configure Enter configuration mode
copy Copy from source to destination
delete Delete one file in flash: file system
dir Directory of all files in flash: file system
disable Turn off privileged commands
do To run exec commands in config mode
dot1x IEEE Standard for port-based Network Access Control
enable Turn on privileged commands
erps Ethernet Ring Protection Switching
exit Exit from EXEC mode
firmware Firmware upgrade/swap
help Description of the interactive help system
ip IPv4 commands
ipv6 IPv6 configuration commands
link-oam Link OAM configuration
logout Exit from EXEC mode
more Display file
no Negate a command or set its defaults
ping Send ICMP echo messages
platform Platform configuration
ptp Misc non persistent 1588 settings
reload Reload system.
send Send a message to other tty lines
show Show running system information

Exit
Exit from EXEC mode.
Syntax:
exit
Parameter:
None.
Example:
Help
Description of the interactive help system.
Syntax:
help
Parameter:
None.
Example:
AW-IHT-1271# help
Help may be requested at any point in a command by entering
a question mark '?'. If nothing matches, the help list will
be empty and you must backup until entering a '?' shows the
available options.
Two styles of help are provided:
1. Full help is available when you are ready to enter a
command argument (e.g. 'show ?') and describes each possible
argument.
2. Partial help is provided when an abbreviated argument is
entered
and you want to know what arguments match the input
(e.g. 'show pr?'.)
AW-IHT-1271#
AW-IHT-1271(config)# exit
AW-IHT-1271#
terminal Set terminal line parameters
traceroute traceroute program
veriphy VeriPHY keyword

logout
Exit from EXEC mode.
Syntax:
logout
Parameter:
none
Example:
end
Go back to EXEC mode.
Syntax:
end
Example:
(config)# end
AW-IHT-1271#
AW-IHT-1271# logout
press ENTER to get started

2 CLEAR of CLI
Table : CLEAR Commands
Command Function
access Access management
access-list Access list
dot1x IEEE Standard for port-based Network Access Control
eps Ethernet Protection Switching.
erps Ethernet Ring Protection Switching
evc Ethernet Virtual Connections
ip Interface Internet Protocol config commands
ipv6 IPv6 configuration commands
lacp Clear LACP statistics
link-oam Clear Link OAM statistics
lldp Clears LLDP statistics.
logging Syslog
mac MAC Address Table
mep Maintenance Entity Point
mvr Multicast VLAN Registration configuration
ptp
sflow Statistics flow.
spanning-tree STP Bridge
statistics Clear statistics for a given interface
access
Access management.
Syntax:
clear access management statistics
Parameter:
management Access management configuration.
statistics Statistics data.
Example:

access-list
Access list.
Syntax:
Clear access-list ace statistics
Parameter:
ace Access list entry
statistics Traffic statistics
Example:
dot1x
IEEE Standard for port-based Network Access Control.
Syntax
Clear dot1x statistics
Clear dot1x statistics interface GigabitEthernet < PORT_TYPE_LIST>
Parameter
statistics Clears the statistics counters
interface Interface
GigabitEthernet 1 Gigabit Ethernet Port
PORT_TYPE_LIST Port list in 1/1-12 for Gigabitethernet
EXAMPLE
AW-IHT-1271# clear dot1x statistics interface GigabitEthernet 1/1-12
AW-IHT-1271#
AW-IHT-1271# clear access-list ace statistics
AW-IHT-1271#
AW-IHT-1271# clear access management statistics
AW-IHT-1271#

eps
Ethernet Protection Switching.
Syntax
clear eps <unit> wtr
Parameter
<uint> The EPS instance number.
wtr Clear active WTR
EXAMPLE
erps
Ethernet Ring Protection Switching
Syntax
clear erps 1-64 command [ ( clear | force | manual ) ( port0 | port1 ) ]
Parameter
1-64 ERPS group number
command Administrative Command
clear Clear command
force Force command
manual Manual command
port0 ERPS Port 0 interface
port1 ERPS Port 1 interface
EXAMPLE
evc
Ethernet Virtual Connections
AW-IHT-1271# clear erps 1 command clear port0
AW-IHT-1271#
AW-IHT-1271# clear eps 1 wtr
AW-IHT-1271#

Syntax
clear evc statistics
clear evc statistics interface [ * | GigabitEthernet ] <port_type_list>
Parameter
statistics Statistic counters
interface Interface
* All switches or All ports
GigabitEthernet 1 Gigabit Ethernet Port
<port_type_list> Port list for all port types
<port_type_list> Port list in 1/1-12
EXAMPLE
ip
Interface Internet Protocol config commands
Syntax
clear ip arp
clear ip dhcp detailed statistics { server | client | snooping | relay | helper | all } [ interface ( <port_type>
[ <in_port_list> ] ) ]
clear ip dhcp relay statistics
clear ip dhcp server binding <ip>
clear ip dhcp server binding { automatic | manual | expired }
clear ip dhcp server statistics
clear ip dhcp snooping statistics [ interface ( <port_type> [ <in_port_list> ] ) ]
clear ip igmp snooping [ vlan <v_vlan_list> ] statistics
clear ip statistics [ system ] [ interface vlan <v_vlan_list> ] [ icmp ] [ icmp-msg <type> ]
Parameter
arp Clear ARP cache
dhcp Dynamic Host Configuration Protocol
igmp Internet Group Management Protocol
statistics Traffic statistics
AW-IHT-1271# clear evc statistics
AW-IHT-1271#

relay DHCP relay agent configuration
snooping DHCP snooping
interface Select an interface to configure
GigabitEthernet 1 Gigabit Ethernet Port
vlan IPv4 traffic interface
<vlan_list> VLAN identifier(s): VID
EXAMPLE
ipv6
IPv6 configuration commands.
Syntax
clear ipv6 mld snooping [ vlan <v_vlan_list> ] statistics
clear ipv6 neighbors
clear ipv6 statistics [ system ] [ interface vlan <v_vlan_list> ] [ icmp ] [ icmp-msg <type> ]
Parameter
mld Multicasat Listener Discovery
neighbors Ipv6 neighbors
statistics Traffic statistics
snooping Snooping MLD
statistics Running MLD snooping counters
vlan Ipv6 interface traffic
<vlan_list> VLAN identifier(s): VID
icmp IPv6 ICMP traffic
AW-IHT-1271# clear ip arp
AW-IHT-1271# clear ip dhcp detailed statistics all
interface GigabitEthernet 1/1-12
AW-IHT-1271# clear ip dhcp relay statistics
AW-IHT-1271# clear ip dhcp server binding 192.168.1.11
AW-IHT-1271# clear ip dhcp server binding automatic
AW-IHT-1271# clear ip dhcp server statistics
AW-IHT-1271# Clear ip dhcp snooping statistics interface
GigabitEthernet 1/1-12
AW-IHT-1271# clear ip igmp snooping vlan 1 statistics
AW-IHT-1271# clear ip statistics system interface
AW-IHT-1271# clear ip statistics system interface vlan 1
icmp icmp-msg 2

icmp-msg IPv6 ICMP traffic for designated message type
interface Select an interface to configure
system IPv6 system traffic
< 0~255> ICMP message type ranges from 0 to 255
EXAMPLE
lacp
Clear LACP statistics
Syntax
Clear lacp statistics
Parameter
statistics Clear all LACP statistics
EXAMPLE
lldp
Clears LLDP statistics.
Syntax
Clear lldp statistics
Clear lldp statistics| begin | exclude | include >< LINE >
Parameter
statistics Clears LLDP statistics.
| Output modifiers
begin Begin with the line that matches
exclude Exclude lines that match
include Include lines that match
<LINE> String to match output lines
EXAMPLE
AW-IHT-1271# clear lacp statistics
AW-IHT-1271#
AW-IHT-1271# clear ipv6 mld snooping vlan 3 statistics
AW-IHT-1271# clear ipv6 neighbors
AW-IHT-1271# Clear ipv6 statistics system icmp icmp-msg 2

link-oam
Clear Link OAM statistics
Syntax
clear link-oam statistics
clear link-oam statistics interface ( * | GigabitEthernet ) <port_type_list>
Parameter
statistics Clear Rx/Tx counters
interface Clear Link OAM statistic on a specific interface or all interfaces.
* All switches or All ports
GigabitEthernet 1 Gigabit Ethernet Port
<port_type_list> Port list for all port types
<port_type_list> Port list in 1/1-12
EXAMPLE
logging
Syslog.
Syntax
clear logging [ info ] [ warning ] [ error ] [ switch <switch_list> ]
Parameter
error Error
info Information
warning Warning
EXAMPLE
mac
AW-IHT-1271# clear logging info error warning
AW-IHT-1271#
AW-IHT-1271# clear link-oam statistics interface
GigabitEthernet 1/12
AW-IHT-1271# clear lldp statistics | begin LINE
AW-IHT-1271#

MAC Address Table.
Syntax
Clear mac address-table
Parameter
address-table Flush MAC Address table.
EXAMPLE
mep
Maintenance Entity Point
Syntax
Clear mep <uint> [ bfd | dm | lm | tst ]
Parameter
<uint> The MEP instance.
bfd Clear G.8113.2 BFD CC/CV statistics counters.
dm Clear DM measuring information.
lm Clear LM measuring information.
tst Clear TST measuring information.
EXAMPLE
mvr
Multicast VLAN Registration configuration.
Syntax
clear mvr [ vlan <v_vlan_list> | name <mvr_name> ] statistics
Parameter
name MVR multicast name
statistics Running MVR protocol counters
vlan MVR multicast vlan
< word16> MVR multicast VLAN name
<vlan_list> MVR multicast VLAN list
AW-IHT-1271# clear mep 1 dm
AW-IHT-1271#
AW-IHT-1271# clear mac address-table
AW-IHT-1271#

EXAMPLE
ptp
Syntax
clear ptp <0-3> servo
Parameter
<0-3>
Servo
EXAMPLE
sflow
Statistics flow.
Syntax
clear sflow statistics { receiver [ <receiver_index_list> ] | samplers [ interface [ <samplers_list> ] ( <port_type>
[ <v_port_type_list> ] ) ] }
Parameter
interface Interface
receiver Clear statistics for receiver.
<port_type> GigabitEthernet
<Samplers : option> runtime
<port_type_list> Port list in 1/1-12 for Gigabitethernet
EXAMPLE
AW-IHT-1271# clear sflow statistics interface
GigabitEthernet 1/1-12
AW-IHT-1271# clear ptp 1 servo
AW-IHT-1271#
AW-IHT-1271# clear mvr vlan 25 statistics
AW-IHT-1271#
