Vogue GD232-A User manual

Model:
GD232-A
Electric knife
Sharpener
Instruction manual
GD232-A_A5_v2_20201201.indb 1GD232-A_A5_v2_20201201.indb 1 2020/12/1 16:392020/12/1 16:39

2
AU Telephone Helpline: 1300225960
Safety Tips
• Position on a flat, stable surface.
• A service agent/qualified technician should carry out
installation and any repairs if required. Do not remove any
components on this product.
• Consult Local and National Standards to comply with the
following:
- Health and Safety at Work Legislation
- Fire Precautions
- Wiring Regulations
- Building Regulations
• DO NOT place hands near sharpening channels when in use.
• DO NOT sharpen scissors or any blade that does not fit freely
in the sharpening channels.
• DO NOT place wet blades in the sharpening slots.
• DO NOT immerse the appliance in water.
• DO NOT attempt to sharpen blades thicker than 3mm.
• Suitable for indoor use only.
• Always switch off and disconnect the power supply to the
appliance when not in use.
• This appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have been
given supervision or instruction concerning the use of the
appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play
with the appliance.
• Keep all packaging away from children. Dispose of the
packaging in accordance to the regulations of local authorities.
GD232-A_A5_v2_20201201.indb 2GD232-A_A5_v2_20201201.indb 2 2020/12/1 16:392020/12/1 16:39

3
AU
Telephone Helpline: 1300225960
• If the power cord is damaged, it must be replaced by a
VOGUE agent or a recommended qualified technician in order
to avoid a hazard.
• VOGUE recommends that this appliance should be periodically
tested (at least annually) by a Competent Person. Testing
should include, but not be limited to: Visual Inspection,
Polarity Test, Insulation Continuity and Functional Testing.
Introduction
Please take a few moments to carefully read through this manual. Correct maintenance and operation of
this machine will provide the best possible performance from your VOGUE product.
Pack Contents
The following is included:
• VOGUE electric knife sharpener • Adapter
• Instruction manual
VOGUE prides itself on quality and service, ensuring that at the time of packaging the contents are
supplied fully functional and free of damage.
Should you find any damage as a result of transit, please contact your VOGUE dealer immediately.
Operation
Note: The VOGUE Knife Sharpener automatically adjusts to accommodate
varying thickness of blade.
Power cable Power switch
Sharpening slot
GD232-A_A5_v2_20201201.indb 3GD232-A_A5_v2_20201201.indb 3 2020/12/1 16:392020/12/1 16:39

4
AU Telephone Helpline: 1300225960
Sharpening Tips
• Apply light pressure to the blade when sharpening for best results.
• Pull the blade in a single, smooth motion.
• To sharpen the tip of the blade, pull the handle up at the end of the pulling motion.
• Always alternate between the left and right slots of any sharpening stage.
Note: Ensure that knife blades are clean and dry before sharpening.
Sharpening Stage 1
Use for blades with a very blunt edge.
1. Connect the sharpener to the mains power supply.
2. Turn the power switch to ‘I’.
3. Hold the handle of the knife firmly and place the blade hilt in the left sharpening slot of Stage 1.
4. Apply enough pressure for the knife to make contact with the sharpening wheel.
5. Pull the blade back to the tip in a smooth motion. Do not twist or rock the blade.
6. Repeat this process for the right sharpening slot of Stage 1.
Note: As a guide, each pull for a 6 inch blade should take 2-3 seconds. An 8 inch
blade should take 4 seconds and longer blades 6+ seconds.
Sharpening Stage 2
Use for honing a blade or to achieve a razor sharp edge after stage 1.
• Repeat steps 3-6 as above, using Sharpening Stage 2.
Note: 1-2 pulls on each side of stage 2 is normally sufficient, though more pulls
will achieve a finer edge.
GD232-A_A5_v2_20201201.indb 4GD232-A_A5_v2_20201201.indb 4 2020/12/1 16:392020/12/1 16:39

5
AU
Telephone Helpline: 1300225960
Cleaning, Care & Maintenance
• Always turn off and disconnect the appliance from the power supply before cleaning.
• Use soapy water and a damp cloth to clean the exterior of the appliance.
• Remove the sharpening head by turning clockwise. The covers of the sharpening wheels (1 & 2) can
be removed by pushing the cover in at one end and lifting. Filings can then be emptied. Afterwards,
assemble the appliance in the reverse order.
1
2
Troubleshooting
If your VOGUE appliance develops a fault, please check the following table before making a call to the
Helpline.
Fault Probable Cause Solution
The unit is not
working
The unit is not switched on Check the unit is plugged in correctly and
switched on
Plug and lead are damaged Call VOGUE agent or qualified Technician
Power supply Check power supply
Internal wiring fault Call VOGUE agent or qualified technician
The knife is not
sharpening
Insufficient pressure applied to the knife Apply more pressure to the knife
Sharpening wheels are worn Call VOGUE agent or qualified technician
GD232-A_A5_v2_20201201.indb 5GD232-A_A5_v2_20201201.indb 5 2020/12/1 16:392020/12/1 16:39

6
AU Telephone Helpline: 1300225960
Technical Specifications
Model Voltage Power Weight Dimensions
h x w x d mm
GD232-A 100-240V~
50/60Hz
18W 0.7Kg 220 x 78.5 x 81
Compliance
The product must not be disposed of as household waste. To help prevent possible harm to human
health and/or the environment, the product must be disposed of in an approved and environmentally safe
recycling process. For further information on how to dispose of this product correctly, contact the product
supplier, or the local authority responsible for waste disposal in your area.
VOGUE parts have undergone strict product testing in order to comply with
regulatory standards and specifications set by international, independent, and
federal authorities.
VOGUE products have been approved to carry the following symbol:
All rights reserved. No part of these instructions may be produced or transmitted in any form or by any means, electronic,
mechanical, photocopying, recording or otherwise, without the prior written permission of VOGUE.
Every effort is made to ensure all details are correct at the time of going to press, however, VOGUE reserve the right to
change specifications without notice.
GD232-A_A5_v2_20201201.indb 6GD232-A_A5_v2_20201201.indb 6 2020/12/1 16:392020/12/1 16:39

DECLARATION OF CONFORMITY
• Conformiteitsverklaring • Déclaration de conformité • Konformitätserklärung • Dichiarazione di conformità •
• Declaración de conformidad • Declaração de conformidade
Equipment Type • Uitrustingstype • Type d'équipement • Gerätetyp
• Tipo di apparecchiatura • Tipo de equipo • Tipo de equipamento
Model • Modèle • Modell • Modello
• Modelo • Malli
Knife Sharpener
GD232 (-E & -A)
Application of Territory Legislation
& Council Directives(s)
Toepassing van Europese
Richtlijn(en) • Application de la/des
directive(s) du Conseil • Anwendbare
EU-Richtlinie(n) • Applicazione delle
Direttive
• Aplicación de la(s) directiva(s) del
consejo • Aplicação de directiva(s) do
Conselho
Low Voltage Directive (LVD) - 2014/35/EU
EN 60335-1: 2012 +A11:2014
EN 60335-2-14:2006 +A12:2016
EN 62233:2008
EN 62368-1:2014 +A11:2017
Electro-Magnetic Compatibility (EMC) Directive
2014/30/EU - recast of 2004/108/EC
EN 55014-1:2017
EN 55014-2:2015
EN 55015:2013 +A:2015
EN 55024:2010 +A1:2015
EN 55032:2015
EN 55035:2017
EN 61000-3-2: 2014
EN 61000-3-3: 2013
EN 61547:2009
Restriction of Hazardous Substances Directive
(RoHS) 2015/863 amending Annex II to Directive
2011/65/EU
Electrical Safety
AS/NZS 60335.1:2011 +A1:2012 +A2:2014
+A3:2015 +A4:2017
AS/NZS 60335.2.14:2013
AS/NZS 61558.1:2008 +A1:2009 +A2:2015
AS/NZS 61558.2.16:2010 +A1:2010 +A2:2012
+A3:2014
Electromagnetic Compatibility
AS/NZS CISPR32:2015
EN 55014-1:2017
EN 55014-2:2015
EN 61000-3-2: 2014
EN 61000-3-3: 2013
Producer Name • Naam fabrikant • Nom du producteur • Name des Herstellers
• Nome del produttore • Nombre del fabricante • Nome do fabricante
Vogue
I, the undersigned, hereby declare that the equipment specified above conforms to the above Territory Legislation, Directive(s) and
Standard(s).
Ik, de ondergetekende, verklaar hierbij dat de hierboven gespecificeerde uitrusting goedgekeurd is volgens de bovenstaande Richtlijn(en)
en Standaard(en).
Je soussigné, confirme la conformité de l'équipement cité dans la présente à la / aux Directive(s) et Norme(s) ci-dessus
Ich, der/die Unterzeichnende, erkläre hiermit, dass das oben angegebene Gerät der/den oben angeführten Richtlinie(n) und Norm(en)
entspricht.
Il sottoscritto dichiara che l'apparecchiatura di sopra specificata è conforme alle Direttive e agli Standard sopra riportati.
El abajo firmante declara por la presente que el equipo arriba especificado está en conformidad con la(s) directiva(s) y estándar(es) arriba
mencionadas.
Eu, o abaixo-assinado, declaro que o equipamento anteriormente especificado está em conformidade com a(s) anterior(es) Directiva(s) e
Norma(s)
Date • Data • Date • Datum • Data •
Fecha • Data
18TH November 2020
Signature • Handtekening •
Signature • Unterschrift Firma •
Firma • Assinatura
Full Name • Volledige naam • Nom
et prénom • Vollständiger Name •
Nome completo • Nombre completo
• Nome por extenso
Ashley Hooper
Eoghan Donnellan
Josie Holt
Position • Functie • Fonction •
Position • Qualifica • Posición •
Função
Technical & Quality
Manager
Commercial
Manager/ Importer
Commercial Manager/ Responsible
Supplier
Producer Address • Adres fabrikant •
Adresse du producteur • Anschrift
des Herstellers • Indirizzo del
produttore • Dirección del fabricante
• Morada do fabricante
Fourth Way,
Avonmouth,
Bristol,
BS11 8TB
United Kingdom
42 North Point
Business Park
New Mallow Road
Cork
Ireland
15 Bagdally Road,
Campbelltown
NSW 2560
DocuSign Envelope ID: 473DCCD5-E7C5-4294-84B0-5A1F66B2649B
GD232-A_A5_v2_20201201.indb 7GD232-A_A5_v2_20201201.indb 7 2020/12/1 16:392020/12/1 16:39
