VOLCAN Energon300 User manual

Energon300 User Manual
customer service telephone numbers /
contact us /
Elite PowerElite Power

Product Specification 01
Safety Caution
2.1 Usage 03
3.1 Appearance 05
3.2 Using Your Product 07
3.3 Charging Your Product 09
2.2 Disposal 04
03
Get to Know Your Product 05
FAQ 10
Error Code 11
Package Content 12
Warranty 13
Contact us
1
2
3
4
5
6
7
814
Disclaimers： Contents
Please read all safety instructions, warning information, terms of use and disclaim-
ers carefully. Please refer to this user manual and the sticker on the product before
use. The user is fully responsible for all use and operation. Please be familiar with
the relevant laws and regulations in your region. It is your sole responsibility to
understand all relevant laws and regulations and use volcan products in a compli-
ant manner.

Product Specification
Input Port
DC Input
AC Adapter: DC 10.8-26V, 100W Max
Solar Panel: DC 10.8-26V, 100W Max, supports MPPT
Car Charger: supports 12V/24V, 100W Max
Battery Information
Cell Chemistry System
Lifecycles
Battery Maintenance
Protection Function
LiFePO4 System
3,000 cycles with battery capacity remaining above 70%
Charge every 3-6 month
Over-voltage Protection Low Temperature Protection
Over-load Protection High Temperature Protection
Over-temperature Protection Undervoltage Protection
Short Circuit Protection Over-current Protection
Disconnection Protection Balance Protection
01 02
300W Pure Sine Wave (Peak power 600W) 110V/60HZ
5V/9V/12V/15V/20V 3A 60W
5V/3A 9V/2.5A 12V/1.5A
5V/3A 9V/2.5A 12V/1.5A
12V/10A 120W Max
12V/10A 120W Max
AC Outport Port*1
USB-C*1 (bidirectional)
USB-C*1 (unidirectional)
USB-A Quick Charger *2
Car Charger Output*1
DC5521 Output*2
Output Port
Energon300
3.6 kg
242*180.4*102.95mm
299Wh 12.8V
-5-45℃
-10-45℃
CE FCC ROSH PSE
Product Information
Model
Net Weight
Dimensions (L*W*H)
Battery Capacity
Ambient Temperature Range by Charging
Ambient Temperature Range by Discharging
Certification
1
In view of the safety and technical problems, the safe and effective service life of this product is 5
years "battery life" from the production date. After the battery life expires, volcan will not bear
any responsibility for any safety risks arising from the product. The battery life mentioned above
refers to the reasonable and safe service life that consumers have under normal use conditions,
reasonable use intensity and normal maintenance of this product. If there are shorter provisions
on the safe service life under the conditions of national standards and industrial standards, or
the end consumer uses the product more frequently than the reasonable limit, uses the product
more than the normal use environmental conditions, or does not use the product and maintain
the product reasonably according to the product specifications and instructions, the effective
service life and safe service life of the product may be shortened accordingly.

Usage2 .1
Safety Caution
03 04
2
Do not place the product near heat sources during operation, such as fire or heating furnace.
Please keep the product away from any liquid. Do not immerse the product in water or get it
wet. Keep it away from rainy or humid environment.
Do not use the product in a strong static/magnetic environment.
Do not disassemble the product in any way or pierce the product with sharp objects.
To avoid short-circuiting, keep the product away from wires or other metal objects.
Do not use unofficial components or accessories, including but not limited to adapters,
charging cables, etc. To replace any components or accessories, official sales channels are
recommended for relevant purchase information.
Please strictly follow the ambient temperature specified in this user manual when using the
product. If the temperature is too high, serious hazardous situations such as fire or explosion
may occur. On the contrary, in too low temperature environment, the product performance may
be severely impacted, even it stops working.
Do not stack any heavy objects on the product.
Do not hinder the fan from running during operation, nor place the product in unventilated or
dusty area.
Please avoid collision, dropping or severe vibration. If subjected to a severe external collision,
you should turn off the power supply immediately and stop using the product. Make sure the
product is well fastened during transportation to avoid vibration and collision.
If accidentally drop the product into water while using, keep it away in a safe open area until it
is completely dry. The dried product should not be used again, and should be properly
disposed according to Section 2.2 below. If the product catches fire, it is recommended to use
fire extinguishers in the following order: water or water mist, sand, fire blanket, dry powder,
and carbon dioxide fire extinguisher.
Use a dry cloth to clean off the dirt on product ports.
Place the product on a flat surface to avoid damages from falling down. If the product flips over
and is severely damaged, turn it off immediately, place it in an open area away from people or
flammable materials, and dispose of it in accordance with local laws and regulations.
Please keep this product away from children and pets.
Disposal2.2
Make sure that the battery is fully discharged before disposing of it in a designated battery
recycling bin if it is possible. The product contains batteries with potentially hazardous
chemicals, therefore it is strictly prohibited to dispose of it in ordinary trash cans. Please
follow the local laws and regulations regarding battery recycling and disposal.
Do not dispose of the battery directly in the battery recycling bin if the battery cannot be fully
discharged due to product failures. In such case, contact professional battery recycling
authority for further processing.
Over-discharged battery cannot be recharged, please disposed of it.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
1
2
3
ATTENTION
If the ambient temperature is too high or the battery temperature is higher than 60 ℃
（140℉） due to continuous high-power discharge, the product cannot be charged.
When the battery temperature is less than 55℃（131℉）, the charging function will
automatically resume. If it is not used for a long time, it is best to fully charge it every
three months before storing; It is best to fully charge each charging.

Appearance3 .1
Get to Know Your Product
05 06
LCD Screen
The Battery Capacity, Lasting Time (hours) and Input & Output Power Consumption (watts) will
be displayed on the screen. When the protection function of each port is on, the corresponding
error code will be displayed and the buzzer will sound the alarm to prompt the user and turn
off the output.
3
①②
⑧ ⑨
⑩
③
④ ⑥
⑤⑦
ER
IN 12V USB PD AC
W
The current battery capacity is displayed
as a charge column.
It displays that the battery is charging.
It displays that 12V DC port output is on.
It displays that USB-A port output is on.
It displays that USB-C port output is on.
It displays that AC port output is on.
It displays that power-saving mode is on.
The current battery capacity, is displayed
as a percentage (%).
Error indication occurs when the battery fails.
No. Name Function Description
①
②
③
④
⑤
⑥
⑦
⑧
⑨
⑩
Charge Column Indication
of Battery
Charging Indication
12V DC Output Indication
USB-A Output Indication
USB-C Output Indication
AC Output Indication
Power-saving Mode
Battery Capacity Percentage
Error Indication
Normally, the input and output power and
frequency are displayed;
Abnormally, an error code will appear to
indicate the specific fault information.
Power Display
Frequency Display
Error Code

Using Your Product3.2
07 08
The LCD screen will light up by long pressing the power button for 3 seconds. When charging function is enabled,
the charging indicator will light up, the charge column will flash, and the charge percentage will change with the
change of the charging capacity.
Short press AC button to enable the AC function, and the corresponding AC icon will light up.
Short press DC button to enable the DC function, and the corresponding DC icon will light up.
USB A and USB C come with automatic wake-up function, and the indication icon will light up when the
corresponding port is plugged into the device.
Turn the dial switch to enable the power-saving mode.
Manually turn off all outputs, the display will stop showing DC/USB-C&USB/AC, and the product will shut down.
When the output exceeds the overload protection power, the overload protection will be triggered. The port will
disable the output, and can only be rebooted after removing the overload.
At the OFF state, long press the power button for 3 seconds to turn equipment on. The display shows
DC/USB-C&USB/AC, indicating that the corresponding function is on.
Quick-start mode: connecting USB-C or USB-A charging cable, the system will start automatically after
detection; the system will automatically shut down after detecting no load for 10 minutes.
Power on:
Manual shutdown:
Overload shutdown:
The product will automatically shut down when the battery is low, and it can be turned on after recharging.
Low battery shutdown:
The product will shut down when it is beyond the range of allowable temperature. Do not use it in this case. The
product should be placed in a ventilated environment at room temperature, please wait until the product tempera-
ture return to the normal range before using again.
Over temperature shutdown:
Automatic shutdown:
1
2
When the power-saving mode is OFF and AC is enabled, it will stay power on for 8 hours to ensure that low-power
appliances (such as Bluetooth headsets, electric toothbrushes, etc.) could be fully charged. After 8 hours, the device
detects that there is a load and it will continue to work; the device will automatically shut down when detecting no
load. With the power-saving mode on, it will disable the AC output and shut down at 2 hours if it is under low power
load.
Note: Some products, such as DC 12V car refrigerators have intermittent power consumption, or DC low-power loads
turn off DC output for 4 hours, and this function can ensure their normal use; the charging power of Bluetooth
headsets and other products is very low, and they will be fully charged within 8 hours.
Power save on/off
Long press the button to turn on/off the
product; Short press the button to turn
on DC function.
Turn on/off LCD side light.
Turn on/off AC function.
No Name Function Description
①
②
③
④
Power-saving Mode Button
POWER/ DC Button
LCD Side Light Button
AC Button
It is recommended to fully charge the product before using for the first time.
①②
③
④

FAQ4
Charging Your Product3.3
09 10
Q1: What type of battery does the product use?
A: This product uses a high-quality cylindrical LiFePO4 cell.
Q2: What equipment can the AC output port of the product carry?
A: The AC rated power of this product is 300W and the peak power is 600W, which can supply
power to some common appliances, but it is recommended to confirm the power of the
appliance before use, and ensure that the sum of the power of all load equipment is less than
the rated power.
Q3: How do I know how long the product can be powered?
A: The LCD screen of this product will display the remaining usage time, which can be considered
as an estimation of the powering time for the product if the power consumption is stable.
Q4: How to judge whether the product is charging?
A: The product will display the charge column and flash when charging, meanwhile, the battery
capacity percentage will also change, and display the input power.
Q5: How to clean this product?
A: You may wipe this product with a dry, soft, clean cloth or tissue.
Q6: How to store the product?
A: When you store the product, please turn it off first, and then store it in a dry, ventilated place
with room temperature. Do not place this product near water sources. For long-term storage, it is
recommended to charge the battery to 80% every three months to prolong the life of this
product.
Q7: Can this product be taken on the plane?
A: No.
Q8: Is the actual output capacity of the product consistent with the capacity stated in the
user manual?
A: The capacity indicated in the user manual is the rated capacity of the battery of this product.
Since this product has a certain efficiency loss during charging and discharging process, the
actual output capacity of the product is lower than the capacity specified in the user manual.
Q9: Why does the product make a "buzzing" sound when using?
A: Because this product uses an air-cooling system, when the fan is working normally, it will
make a slight sound. While, it is a normal phenomenon.
Q10: Why I can’t use the product within the rated output power range?
a.Battery capacity is low and needs to be charged.
b.The power of some devices at startup may be higher than the peak power of the product, or
the actual power of the devices may be higher than the rated power of the product.
Q11: Will the charger be damaged due to heat during use?
A: When the charger is in normal use, there will be some slight heat, which is a normal phenom-
enon.
Q12: Is it possible to charge and discharge at the same time?
A: Yes.
Charge through AC adapter + USB-C port:
160W max, about 2 hours for a full charge
Charge through AC adapter:
10.8-26V/5A, 100W max, about 3 hours
for a full charge
Charge through USB-C port:
60W max, about 5 hours for a full charge
Charge through solar panel:
10.8-26V, 100W max, about 3.5 hours
for a full charge
1
2
3
4
5
6
7
8
9
10
11
12
USB-C
Port charging
Cigarette
lighter socket
On-board
charger
AC socket
AC adapter
The battery is fully charged when all battery level segments stop blinking and remain solid. After
the battery is fully charged it is best to unplug the charging cables. The battery will not over charge,
but removing the cables is the best practice.
The actual solar panel charging efficiency can vary widely depending on weather, ambient
temperature, sunlight's strength, the angle that the solar panels face to the straight sunlight and
other factors. The maximum output voltage of the solar panel should not exceed 23.5V. It is
recommended to use solar panels with an open circuit output voltage of 10.8-23.5V.

Package Content6
DC output and car charging output overload
DC short circuit and car charging short circuit overload
AC output overload, overtemperature, overvoltage and
undervoltage, short circuit
PD (bidirectional) output short circuit, overload
Battery over temperature
Battery low temperature
PD (unidirectional)/USBA short circuit, overload
DC charging overvoltage
Battery overcurrent
Battery undervoltage alarm
Battery low voltage alarm
Prompting users to perform deep discharge and learn how to do it.
Error Code Causes
E01
E02
E03
E04
E05
E06
E07
E08
E10
E11
E12
E13 Host
Instructions
Charger
No. Specification / Item
1
1
1
Count
1
2
3
Error Code
5
11 12
V300 On-board
charging line
AC charging
line and Adapter
(2 parts)
user 's manual

Contact us8
1
2
3
4
5
6
7
Warranty
7
Energon300
certificate
Product model
examination clerk
Inspection results
13 14
For the power supply products purchased through regular channels, our company
provides customers with warranty of 24 months from the date of purchase.
Note: Customers need to provide proof of purchase or other valid evidence when seeking
warranty service.
Warranty Period
Within 24 months from the date of purchase of this product, if the product is found to have any
inherent quality problem or manufacturing defect, we will repair it for you free of charge.
Replacement
If the product cannot be repaired due to its own quality defects during the warranty period, we
will provide you with a replacement product (not lower than the performance of the original
product), and the warranty period of the replacement product is the remaining warranty period
of the original product.
Email: [e-mail]
Customer service hotline:
The following conditions are not covered by the warranty:
Products purchased through informal purchase channels, or non-authentic products of our
company;
Giveaway and optional accessories;
Normal appearance wear and tear during use;
Misuse, abuse, accidental damage, intentional damage;
Unauthorized disassembly and repair by unauthorized maintenance personnel;
Problems caused by the use and storage not in accordance with the requirements of Chapter
2 and Chapter 3 of this manual, and failure to carry out troubleshooting as required in
Chapter 5 of this manual.
Damage caused by natural disasters, lightning, earthquake, tsunami and other irresistible
factors.
The company only guarantees the matters specified in this manual. All warranties are
limited to the repair or replacement of defective products at Volcan's discretion. Volcan shall
not be liable for any accidental or indirect damages related to the product.
The effectiveness, interpretation and implementation of this Manual are all based on the
laws of the People's Republic of China (excluding Hong Kong, Macao Special Administrative
Region and Taiwan, China, China, and excluding conflict of laws rules). The disputes arising
from your use of Volcan products shall be settled through negotiation between Volcan and
you. If the negotiation fails, either party may bring a lawsuit to the court with jurisdiction at
the defendant's location.
