Notice ActivHub IR100 – MUV110065-V1R0
models
VPES-02000
IR100

SUMMARY
Content Page
1. OVERVIEW 4.
1.1 - GENERAL PRESENTATION 4.
1.2 - ACTIVHUB IR100 COMPOSITION 4.
2. PRODUCT DESCRIPTION 5.
2.1 - GLASSES 5.
2.2 - INFRA-RED EMITTER 6.
2.2.1 - EMITTER AT A GLANCE 6.
2.2.2 - BASIC SPECIFICATIONS 6.
2.2.3 - DIRECT INFRA-RED SPREAD OF THE EMITTER 6.
2.2.4 - CONFIGURATION ROOM 6.
3. ACTIVHUB IR100 FASTENING 7.
4. CONNECTION & SYNCHRONIZATION 8.
4.1 - SYSTEM CONNECTION 8.
4.2 - TECHNICAL SPECIFICATIONS 9.
5. WARRANTY 10.
6. CONTACTS 10.
ENGLISH

1. PRODUCT PRESENTATION
1.1 - General presentation
As a resultof Volfoni’s long experience managing of the world’s
largest stock of 3D glasses, EDGE™ 1.2 exhibits the latest ergonomic
and technical innovations. EDGE™’s comfort and easy of use is
unmatched within the eld of 3D glasses.
EDGE™ 1.2: High quality 3D glasses
• Unbeatable luminosity and natural colors
• Stylish ergonomic design, rugged and lightweight
• Exceptional comfort with universal nosepiece and 3 sizes of
adaptable arms
• Automatic infrared synchronization, super wide receiving angle
• Very low maintenance with high durability coating and
generic low cost battery
ActivHub IR100: All integrated 3D infra-red emitter
• Infra-red emitter working with quality and lightweight 3D glasses
• Cost saving solution for auditoriums up to 100 seats
• Easy and fast set-up with any 3D-Ready™ projectors
• No silver screen required, image quality preserved at all seating
position
Accessories:
• Protective bag for distribution and storage
• Battery replacement tool
• Antibacterial cleaning wipes
• Adaptable “arms” to feet t any head size
1.2 - ActivHub IR100 Composition
Thank you for using our ActivHub IR100. Before starting, please
check if the following parts are included in the package.
A full ActivHub IR100 includes:
1 • EDGE™ 1.2 3D glasses
2 • Long range IR emitter
(infra-red emitter and synchronizer integrated)
3 • 4 cables :
- 1 power cable 110/220V with US & EUR adapter - 3.1
- 1 sync cable : GPIO SubD37 - 3.2
- 1 sync cable : BNC - 3.3
- 1 sync cable: SubD9 - 3.4
4 • 1 ceiling mountable with screws
4.
3. Security universal mount
1. EDGE™ 1.2 Glasses 2. IR / RF Emiter & Synchronizer +
5. Power adapter
7. VGA-DB9 SYNC Splitter
6. Din3-DB9 SYNC Cable
4. Mounting screw
and nylon fastener

LITHIUM BATTER Y
CR2032
3V
HL
B
2. PRODUCT DESCRIPTION
2.1 - Glasses EDGE™ 1.2
The VOLFONI Active 3D Glasses use fast-response liquid crystal
lenses to createthe best image quality. It is the brightest and most
cost-saving 3D solution currently on the market.
BATTERY TOOL
to unlock the battery
GLASSES USE AND SETUP
The 3D glasses do not need any setup to start. It is nevertheless
necessary to check all settings and connections of the 3D digital
cinema system before projection. Whenstarted, the lenses need
2 seconds to warm up and turn into working mode. In working
mode thelenses appear clear. When the 3D projection is nished
or turned into 2D, the lenses willremain clear for about 5 minutes.
They will go directly into operation mode againwhen a new signal
is received.
BATTERY REPLACEMENT
To open the battery encasement on the right arm of the glasses:
- Use your Volfoni battery tool.
- Put the glasses on a desk/table as it will be easier to hold.
- Find the small hole on the right arm of the glasses, where the
arm connects with the battery encasement, 1 et 2.
- Put the battery tool inside and when you hear a “click”, you
can pop open the battery encasement, 3.
Note: Please make sure that there is no obstacle in front
of the IR captor during 3D projection.
Note: When the battery has less than three hours
remaining, the lenses will ash once a second to indicate
that you must change the battery. It is recommended
to check the battery life before distributing to viewers.
make sure you install the
battery in the right position
STEP 1
STEP 3
Insert the tool into the hole in the
under right side of glasses until
you hear the “click”.
Reinsert the battery and
push to hear the “click” to
lock it.
Operating temperature: 0°C to 40°C
Storage temperature: -10°C to 60°C
STEP 2
Pull towards you with your nail to
remove the battery tray
∙ IR CAPTOR: Keep it clean for
optimal efciency
∙ NOSEPIECE
∙ BATTERY AREA: Battery tray
∙ ADJUSTABLE ARMS: 3 sizes (S,M,L)
PULL OUT
LITHIUM
BATTERY
+
IR CAPTOR
keep it clean for
optimal efciency
NOSEPIECE
BATTERY AREA
battery tray
ADJUSTABLE ARMS:
3 sizes (S,M,L)
5.
click
click
PUSH

2.2 - Infra-red Emitter / Synchronizer
Model Name:VPES-02000
Long Range IR Emitter with built-in Synchronizer (VPES-02000) is a
compact and very powerful technology for viewing 3D content
in (bar, club, school, museum, events…) and small theater (up to
100 seats).
Thanks to its lightweight design, the ActivHub IR100 enhances heat
dissipation (LED life protection). It is provided with a universal mounting
head for security and is easy to install. It is also convenient to target
the screen with the emitter laser pointer.
2.2.1 - Emitter/Synchronizer at a glance
2.2.2 Basic specications
IR Wavelength: 940nm
Max emitting range: 30 m (98.5 feet)
Power supply: 24VDC, 3A Power Adapter
Dimension: 361 x 70 x 44 mm (14.1 x 2.75 x 1.8 inches)
Weight: 500 grams (17,64 oz)
2.2.3 Direct infra-red spread of the emitter
2.2.4 Room conguration
Long Range IEmitter / Synchroniser
SYNC IN(DB9)
Mounting Hol e
Laser Pointer
Powe r LE D
6.
0°
50m
60m
15°
30°
45°
15°
30°
45°
65m
22m
18m
13m
18m
12m
21m
Power in

3. ACTIVHUB IR100 FASTENING
INSTALLATION
STEP 1
STEP 2
STEP 3
STEP 4
STEP 5
Use the wall base to mark each
hole to drill with a pencil.
Drill the holes with the given bit (for wood surface only)
Insert wall anchors
Tightly screw the base to the wall
Assemble the arm to the base
and then screw the emitter on it
(For solid concrete and drywall only)
WALL FASTENER
Before installing the emitter in the front of the screen, make sure
you have all the needed tools and the instruction manual. This
wall xing part is provided with all the screws and wall anchors you
might need. Follow the instructions to fasten this kit.
WALL TYPES & HOLES SIZES
Parts
1
2
3
4
5
Qty
2
2
1
1
1
Product description
Mounting plate
Screw covers
Extension
Adjusting Knuckle
Emitter plate
1/2” drywall
13 mm
(1/2”)
(1/4”)
6.35 mm
NOT
INCLUDED
solid concrete
44 mm (1 3/4”)
(3/32”)
4.7 mm
NOT
INCLUDED
wood stud
32 mm (1 1/4”)
(3/32”)
2.5 mm
INCLUDED
7.
1234
5

4. CONNECTION & SYNCHRONIZATION
4.1 - System connection
8.
If the graphic card
has 3 pin mini-DIN
SYNC output port,
connect the IR emitter
with this DIN 3 SYNC
Cable only.
DIN3-DB9 SYNC Cable
(accessory)
VGA SYNC Splitter
(accessory)
Outlet
3D Ready
PC System
120Hz 3D Ready
Projector
Wireless 3D
Actice Glasses
Model: NE1
Long Range
IR Emitter
OR
HDMI cable
SUB-D37 female / SUB-D9 female
(3 meters by default - up to 30 meters)
Power Supply 24V-240V
(3 meters provided)
Compatible 3D
video projector
Outlet
3D video player
ActivHub IR100

4.2 - Technical specications
Please see below the connection diagram for the settings.
Please refer to the following technical board for the digital projector.
These parameters are for information, it could be adapted if
necessary.
TECHNICAL SPECIFICATIONS
Warning: Depending on your equipment and the room conguration,
you may have to adjust these parameters. We recommend to
conde the set-up of 3D parameters and color adjustments directly
to integrators.
For any trouble, please consult our website www.volfoni.com,
or send an email to [email protected].
For any trouble, please consult our website
www.volfoni.com,
or send an email to [e-mail].
Fall time
Rise time
Contrast > 1:150 (no ghosting)
Transmission in the clear state
Chromaticity
Standard parameters
EDGE 1.0™ PCE SERIES
Double ash (4.2)
Triple ash (6.2)
EDGE 1.0™ STN SERIES
Double ash (4.2)
Triple ash (6.2)
Weight
Battery
Autonomy
Darktime: 500
Delay: -200
Darktime: 800
Delay: -200
Darktime: 500
Delay: -320
Darktime: 800
Delay: -320
58 grs (2 ounces)
Disposable
300 hrs
9.
0.2 ms
1.8 ms
> 1:150 (no ghosting)
33%
Color correction not
mandatory

y
5. Warranty
The ActivHub IR100 is warrantied to the original purchaser for three
to twelve months according to local legislation. Infra-red emitter/
synchronizer and cables should be returned in original box along
with original proof of purchase.Infra-red emitter/synchronizer that
are broken or scratched are not covered.
Volfoni does not cover uninterrupted or error-free operation of the
product under warranty.
