Volt 3V VB320S User manual

Instruction
Booklet
www.voltheat.com2017

Instruction Booklet
Instructions:
Remove battery(ies) and charger from packaging.
Plug the charger into a properly rated AC electrical outlet.
Connect the batteries to the input plugs from the charger. The LED lights on
the batteries will light up indicating it is receiving a charge.
Batteries are charged when the LED indicator on the charger turns green.
Fully discharged batteries will take 3-4 hours to charge fully.
Disconnect the charged battery(ies) and connect to the product.
Connect the batteries to your 3v® heated product.
Press the“power” button on the battery holding for 2 seconds to activate.
There are 4 power level settings which can be selected by pressing the
power button:
RED = 100% High
YELLOW = 75% Med/High
GREEN = 50% Medium
FLASHING GREEN = 25% Low
Press and hold the power button to power OFF or disconnect from the 3v
product.
1.
2.
3.
4.
5.
6.
7.
8.
9.
www.voltheat.com
2
VB320S BATTERY PACK
Specications:
3.7v 2.0AH Li-ion Battery, 7.4Wh
Input: 4.2v 0.5A-1A
Output: 3v-4.2v 2A Max
Battery Life: 300+ cycles

Instruction Booklet
Instructions:
Remove battery(ies) and charger from packaging.
Plug the charger into a properly rated AC electrical outlet.
Connect the batteries to the input plugs from the charger. The LED lights on
the batteries will light up indicating it is receiving a charge.
Batteries are charged when the LED indicator on the charger turns green.
Fully discharged batteries will take 3-4 hours to charge fully.
Disconnect the charged battery(ies) and connect to the product.
Connect the batteries to your 3v® heated product.
Press the“power” button on the battery holding for 2 seconds to activate.
There are 3 power level settings which can be selected by pressing the
power button on the battery or the power level setting on the remote.
High = Red
Medium = Orange
Low = Green
Press and hold the power button to power OFF or disconnect from the 3v
product.
1.
2.
3.
4.
5.
6.
7.
8.
9.
www.voltheat.com
2
VB320RC Remote
Battery Pack
Specications:
3.7v 2.0AH Li-ion Battery, 7.4Wh
Input: 4.2v 0.5A-1A
Output: 3v-4.2v 2A Max
Battery Life: 300+ cycles

Instruction Booklet
Instructions:
Using Wireless Remote Controller
Remove batteries and charger from packaging.
Plug the charger into a properly rated AC electrical outlet.
Note: Battery LED is only for charger power notication.
Connect the batteries to the input plugs from the charger. The LED lights on
the batteries will light up indicating it is receiving a charge.
Batteries will be fully charged when the LED’s on the battery display all four
green LED lights. Fully discharged batteries will take 2.5 – 6 hours to charge
fully.
Disconnect the charged batteries and connect to the 3v product.
Press the“power” button on the battery holding for 3 seconds to activate.
Press“power” button to select desired power level setting and to turn o. All
four LED lights indicate the highest power setting.
The wireless remote controls two batteries at the same time.
Press“ON”button and hold for 3 seconds to activate batteries.
Note: Must be within 6 feet.
Press“ON”button to select power level output.
Press the“OFF”button to power o.
1.
2.
3.
4.
5.
6.
7.
1.
2.
3.
4.
www.voltheat.com 3
VB320R REMOTE
BATTERY PACK
Specications:
Model#BP037202
3.7v 2.0AH Li-ion Battery, 7.4Wh
Input: 4.2v 0.5A-1A
Output: 3v-4.2v 1.5A Max
Battery Life: 300+ cycles

Instruction Booklet
Instructions:
Remove batteries and charger from packaging.
Plug the charger into a properly rated AC electrical outlet.
Connect the batteries to the input plugs from the charger.
Batteries will be fully charged when the LED indicator on the CHARGER
turns green. Fully discharged batteries can take up to 8 hours to charge
fully.
Disconnect the charged batteries and connect to the 3v product.
Press the“power” button on the battery holding for 2 seconds to activate.
Press“power” button to select desired power level setting and to turn o.
After 5 seconds the battery power level selected will be locked to prevent
accidental changing of power level setting. Hold the“power” button for 2
seconds to be able to change the power level setting.
1.
2.
3.
4.
5.
6.
7.
8.
www.voltheat.com
4
VB350
Specications:
3.7v 5.0AH Li-ion Battery, 18.5Wh
Input: 4.2v 0.5A-1A
Output: 3v-4.2v 3.5A Max
Battery Life: 300+ cycles

Instructions:
Do not attempt to disassemble or alter any part of the battery.
Do not store below -4° F (-20° C) or above 140° F (60° C).
Do not allow the battery to have contact with water or liquids.
If water or other liquids enter the battery interior, immediately disconnect
the battery from the product. Continued use of the product may result in
re or an electrical shock.
Do not place the battery near a heat source or expose the battery to direct
ame or heat, as battery may explode.
-
-
-
-
Instruction Booklet
www.voltheat.com 5
Note: Failure to charge battery prior to use will reduce battery life.
CHARGE BATTERY REGULARLY
It is important to maintain between a 25 – 50% charge in the battery when it is not in use
and will be left idle for an extended period of time. Be sure to store the battery in a cool,
dry place when not in use. Failure to follow these instructions will result in performance
problems and reduced battery life.

H2C BRANDS, LLC
110 Cumberland Park Drive Ste #205
St. Augustine, FL 32095
888.518.6871
