Volt VAL-2043-LI-ABK User manual

VOLT®Line Voltage Landscape Lighting
VOLT®Max All-Star 120V Integrated Spotlight
VAL-2043-LI-ABK
INSTALLATION INSTRUCTIONS
Specications and product details subject to change without notice.
© Copyright 2018, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3700
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
- 1 -

VOLT®Line Voltage Landscape Lighting
VOLT®Max All-Star 120V Integrated Spotlight
INSTALLATION INSTRUCTIONS
www.voltlighting.com
- 2 -
Important: Please Read Before Installation
Important Safety Instructions
1. This LED Floodlight uses the latest in solid state lighting technology for
long life, low maintenance, and high efciency.
2. An internal power-factor-corrected switch mode supply allows this
xture to be used from any nominal 100V-277V, 60Hz AC supply without
any variation in light output.
3. Suitable for use in:
a. Ambient Temperatures of: -20~+40°C (-4~+104°F)
a. Wet Locations
Note: Save these instructions for future reference.
To avoid the risk of re, explosion, or electric shock, this product should
be installed, inspected, and maintained by a qualied electrician only, in
accordance with all applicable electrical codes.
To avoid electric shock:
1. Be certain electrical power is OFF before and during installation and
maintenance.
2. Luminaire must be connected to a wiring system with an equipment-
grounding conductor.
To avoid explosion:
1. Make sure the supply voltage is the same as the rated luminaire voltage.
2. Do not install where the marked operating temperatures exceed the
ignition temperature of the hazardous atmosphere.
3. Do not operate in ambient temperatures above those indicated on the
luminaire.
For supply connections use wire rated for at least 90°C (194°F)
Warning: these luminaire should ONLY be installed by a qualied electrician.
!
!

Package Contents
Product Dimensions
A. (1) Stake
[email protected] • 813.978.3700
6.25”
7.75”
B. (1) Fixture
7.75”
- 3 -
Install Stake and Conduit
1
Dig a hole in the ground for the conduit runs and the stake. Install
the conduit. Slide the stabilizer grid onto the stake and secure with
the screws. Place the stake over the conduit runs. Backll against the
mounting stake.
Stake
Stabilizer
Grid
Conduit
Ground Level

www.voltlighting.com
INSTALLATION INSTRUCTIONS
- 4 -
Remove the cap from the stake
by loosening the set screws.
Remove Cap from Stake
2
Set Screw
Cap
Stake
Thread the cap onto the xture
body and hand tighten until
snug.
Install Cap to Fixture
3
Fixture
Cap
VOLT®Line Voltage Landscape Lighting
VOLT®Max All-Star 120V Integrated Spotlight

[email protected] • 813.978.3700
- 5 -
Wire Connection and Fixture Installation
4
Allow enough wire from the
xture for adjustment purposes.
Connect the wires from
the xture into the wiring
terminal. The white wire goes
to the “Neutral” terminal; the
black wire goes to the “Live”
terminal; and the green wire
goes to the “Ground” terminal.
Fix them in place with the
connector screws.
Loosen the set screw at the joint
and adjust the xture body to
the desired direction. When the
desired direction is achieved,
tighten the set screw until snug.
Adjust Lamp Direction
5
Fixture Body
Set Screw
Set Screw
Cap
Stake
Wire
Connector
Supply
Wires
Fixture
Wires

www.voltlighting.com
- 6 -
INSTALLATION INSTRUCTIONS
VOLT®Line Voltage Landscape Lighting
VOLT®Max All-Star 120V Integrated Spotlight
After installation,
A. Double check whether the lighting xture is rmly xed.
B. Double check the wires are connected correctly.
Lastly, turn on the power and check if the lighting xture is working properly. If
not, turn off the power and contact us at 813-978-3700.

Specications and product details subject to change without notice.
© Copyright 2018, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3700
www.voltlighting.com
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
- 7 -

IS-VAL-2043-LI.ver4
