Volt VPL-1006 User manual

VOLT®Low Voltage Landscape Lighting
VOLT® Coachman LED Path & Area Light
VPL-1006
INSTALLATION INSTRUCTIONS
Specications and product details subject to change without notice.
© Copyright 2021, VOLT® Lighting, Lutz FL USA 33549 • All rights
reserved. [email protected] • 813.978.3700
- 1 -
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)

VOLT®Coachman LED Path & Area Light
VPL-1006
Important: Please Read Before Installation
Important Safety Instructions
INSTALLATION INSTRUCTIONS
!
!
www.voltlighting.com
- 2 -
This luminaire is intended for installation in accordance with local codes
and the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the warranty.
These instructions do not intend to cover all variations in installation, operation
maintenance or mounting situations.
1. Make sure that the power is turned OFF before installing or servicing this
luminaire.
2. WARNING: risk of electrical shock. Install all luminaires 10 feet (3.05M) or
more from pool, spa or fountain.
3. This luminaire is intended to be used only with a power supply
(transformer) rated maximum of 300 watts (25 AMPS) at 15 volts.
4. Wiring connections must be made with UL listed wire connectors that are
suitable for outdoor use.
5. Position the low voltage wire and wire connector so that it is located
within 6 inches (15.2 cm) from a building structure, a luminaire or tting.
6. The main low voltage cable is intended for shallow burial - less than 6
inches (152 mm).
LIGHTED LAMP IS HOT!
WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before reducing lamp.
2. Lamp gets HOT quickly!
3. Do not touch the hot lens, guard or cowl.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time.
6. Use a soft cloth.
7. Oil from skin may damage lamp.
8. Do not operate the xture with a damaged or missing lens or shield.

[email protected] • 813.978.3700
Package Contents
A. (1) Fixture
B. (1) Stem
Additional Parts Required (sold separately)
A. (1) LED SCB Lamp
Product Dimensions
62.25”
TOP VIEW
11”
11”
9.5”
- 3 -
C. (1) Ultra Realistic LED Moving
Flame Bi-Pin Candle
D. (1) 17” Stake

INSTALLATION INSTRUCTIONS
2
1
www.voltlighting.com
- 4 -
VOLT®Coachman LED Path & Area Light
VPL-1006
Remove the Hat
Hat
Set
Screw
Hat Mount
Stem
Inner Lens
Remove the hat from the stem by
removing the set screws from the
hat mount.
Install LED Lamp
Insert the lamp with the correct
wattage and type marked on the
xture label.
CAUTION: Do not exceed maximum
wattage marked on luminaire label.
NOTE: DO NOT touch bulb with bare
hands. Use soft cloth to handle
bulb.
Lower
Socket
LED
SCB
LAMP
Hat

[email protected] • 813.978.3700
4
- 5 -
3
Reinstall Hat
LED SCB
Lamp
Hat
Set
Screw
Hat
Mount
Stem
Inner Lens
After installing the LED lamp into
the socket, place the hat back
onto the mount at the top of the
stem.
Secure both pieces in place
with the set screws previously
removed. Hand tighten until
snug.
Remove Upper Part of Hat
Remove the upper part of the hat
by loosening the set screws.
Lower Hat
Upper Hat
Set Screw

INSTALLATION INSTRUCTIONS
6
5
www.voltlighting.com
- 6 -
VOLT®Coachman LED Path & Area Light
VPL-1006
Install LED Bi-Pin Candle
LED Bi-Pin
Candle
Upper
Socket
Insert Ultra Realistic LED
Moving Flame Bi-Pin Candle.
CAUTION: Do not exceed
maximum wattage marked
on luminaire label.
Reinstall Upper Part of Hat
Place the upper part of the hat
back onto the lower part of
the hat and secure with the set
screws previously removed. Hand
tighten until snug.
Upper
Hat
Set Screw

[email protected] • 813.978.3700
- 7 -
Install Stem
7
Extension
Stem
Supply
Wires
Pass the supply wires through the
stem and extension. Then thread
the extension onto the stem. Hand
tighten until snug.

www.voltlighting.com
- 8 -
9
Stake
Stabilizer
Grid
Conduit
Ground Level
8
Install Stake and Conduit
Dig a hole in the ground for the conduit runs and the stake. Install
the conduit. Slide the stabilizer grid onto the stake and secure with
the screws. Place the stake over the conduit runs. Backll against
the mounting stake.
Remove Cap from Stake
Remove the cap from the
stake by loosening the set
screws.
Set Screw
Cap
Stake

10
Extension
Fixture Wires
Cap
11
Install Cap to Fixture
Thread the cap onto the xture body and
hand tighten until snug.
Wire Connection and Fixture Installation
Set Screw
Cap
Stake
Wire Connector
Supply Wires
Fixture
Wires
[email protected] • 813.978.3700
- 9 -
Strip both leads from the luminaire pigtail. Using two wire
connectors (sold separately), connect the leads from the
luminaire to the main supply cable leads.

www.voltlighting.com
- 10 -

[email protected] • 813.978.3700
- 11 -

is-VPL-1006-ver6.pdf
Specications and product details subject to change without notice.
© Copyright 2021, VOLT® Lighting, Lutz FL USA 33549 • All rights
reserved. [email protected] • 813.978.3700
