Volt VDL-6009-4-BBZ User manual

VOLT®Low Voltage Landscape Lighting
VOLT®Dojo Deck Light
VDL-6009-4-BBZ
INSTALLATION INSTRUCTIONS
Specications and product details subject to change without notice.
© Copyright 2019, VOLT® Lighting, Lutz FL USA 33549 • All rights reserved.
[email protected] • 813.978.3700
Help Hotline:
1-813-978-3700 • Mon-Fri 8am-8pm • Sat-Sun 10am - 6pm (EST)
- 1 -

VOLT®Dojo Deck Light
VDL-6009-4-BBZ
Package Contents
Product Dimensions
Important: Please Read Before Installation
Important Safety Instructions
INSTALLATION INSTRUCTIONS
This xture is intended for installation in accordance with local codes and
the National Electric Code (NEC). Failure to adhere to these codes and
instructions may result in serious injury, property damage and void the
warranty.
These instructions do not intend to cover all variations in installation,
operation maintenance or mounting situations.
1. Make sure that the power is turned OFF before installing or servicing
this xture.
2. Warning: this xture is not intended to be installed within 10 feet [3
meters] of a pool, spa or fountain.
3. This xture is intended to be connected to a low voltage transformer.
4. Underground Low Energy Cable must not be buried over 6” (15.2 cm)
in order to connect to the main low voltage cable.
5. Wire connections must be made with UL listed wire connectors that
are suitable for outdoor use.
LIGHTED LAMP IS HOT!
WARNING – TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS.
1. Turn off/unplug and allow to cool before replacing lamp.
2. Lamp gets HOT quickly!
3. Do not touch the hot lens, guard or cowl.
4. Keep lamp away from materials that may burn.
5. Do not touch lamp at any time.
6. Use a soft cloth.
7. Oil from skin may damage lamp.
8. Do not operate the xture with a damaged or missing lens or shield.
A. (1) Fixture Body
!
!
www.voltlighting.com [email protected] • 813.978.3700
3”
B. (2) Lock Screw
3.5”
- 3 -- 2 -
ProTip for Hiding Splice Connections
ProTip for Hiding Lead Wire
Determine the location for the xture. Drill a hole straight through the
desired mounting location and run the lead wire out the backside of
the location so that the wires are not visible from the front side. Use a
matching trim piece and cut a groove in the back of trim. Cover the lead
wires with the matching trim piece.
All xtures come with 4’ of lead wire enabling you to hide the splice
connections out of sight. If you must make a splice connection in view, use
an inline heat shrink style connection that is less visible than traditional
twist caps.
1.75”

www.voltlighting.com [email protected] • 813.978.3700
INSTALLATION INSTRUCTIONS
Install Face Cover
3
Push face cover back onto the
xture body aligned with the gaps
in the xture body. Once the face
cover is ush with the xture body,
rotate the face cover until it stops
and locks into place.
Remove Face Cover
1
Rotate the face cover until it
stops and then lift the cover
straight off.
Note: The rst time it may be
difcult because the xture
has a very tight o-ring seal and
a grease sealant for moisture
protection.
Face Cover
Fixture Body
Rotate
Fixture
Body
- 5 -- 4 -
Install Fixture Body
2
Fixture Body
Lock Screw
Wall Anchor
(optional)
Attach the xture body to your
desired location and secure with lock
screws.
Note: Wall anchors may be required
for certain installation conditions
(e.g. Brick walls, Concrete Walls,
etc.). Mark on the wall using holes
on the xture body to drill holes for
your wall anchors. Remove base and
drill proper holes in the wall, then
insert wall anchors.
Hole
Face
Cover
Wire Connections
4
Strip both leads from luminaire
pigtail. Using two wire connectors
(sold separately), connect leads
from luminaire to main supply cable
leads.
Fixture
Wire
Connector
Main Supply Cable
Pigtail
VOLT®Dojo Deck Light
VDL-6009-4-BBZ

- 6 - - 7 -
www.voltlighting.com [email protected] • 813.978.3700

IS-VDL-6009-4-BBZ-VER3.pdf
