VOLTIUM ENERGY SuperCharge User manual

USER MANUAL
Voltium Energy®SuperCharge 2&4 Bank IP67 Charger

Thank you for purchasing the
Voltium Energy®SuperCharge Charger.
Please follow the guidelines provided in this manual during the operation, maintenance, and repair
of this charger. The manufacturer states that they are not responsible for the outcomes of its
operation. If the user fails to comply with these requirements, we cannot be held responsible for
any operational outcomes.
SAVE THESE INSTRUCTIONS
This manual contains essential safety and operating instructions. To minimize the risk of injury, please carefully read
all the instructions and follow them every time you use this product.
ࠠCharging for two 12V LiFePO4/Lead
Acid/AGM batteries
ࠠActivation Function for low voltage
LiFePO4 batteries
VE-SC-IP67-2BANK-12V20A
IP67 Waterproof 2-Bank Battery Charger
ࠠCharging for four 12V LiFePO4/Lead
Acid/AGM batteries
ࠠActivation Function for low voltage
LiFePO4 batteries
VE-SC-IP67-4BANK-12V20A
IP67 Waterproof 4-Bank Battery Charger

TECHNICAL SPECIFICATIONS ........................4
FEATURES ........................................5
INTRODUCTION ...................................6
USAGE INSTRUCTIONS ..............................6
HOW IT OPERATES .................................7
OPERATION METHOD ...............................9
PROTECTION FUNCTION ...........................10
ASSEMBLY AND DIMENSION .........................10
WARNING .......................................11
MAINTENANCE ...................................11
SAFETY INSTRUCTIONS ............................12
TABLE OF CONTENTS

VERSION
2023.V1
4
USER MANUAL
VOLTIUM ENERGY®SUPERCHARGE
2&4 BANK IP67 CHARGER
TECHNICAL
SPECIFICATIONS
Product Name 2-Bank Battery Charger
2x12V 20A
4-Bank Battery Charger
4x12V 20A
Model VE-SC-IP67-2BANK-
12V20A
VE-SC-IP67-4BANK-
12V20A
Nominal AC Input Voltage 220-240V AC 220-240V AC
Nominal AC Input
Frequency 50Hz 50Hz
Output 2*12V/20A 4*12V/20A
Product Size 304*245*99mm 556*245*99mm
Charging Battery Type
Each bank is equipped
with a MODE button for
selecting the battery type:
12V LiFePO4, 12V Wet, and
12V AGM. There are a total
of 2 banks.
Each bank is equipped
with a MODE button for
selecting the battery type:
12V LiFePO4, 12V Wet, and
12V AGM. There are a total
of 4 banks.
LED Indicators Power, Battery Type & Charging Status LED Indicators
Activate Function
The Wake Up Function for Low Voltage LiFePO4 Battery
can be initiated by pressing the mode button on the bank
panel for 3-5 seconds.
Full Cut-off Voltage 14.1V-14.4V for 12V Lead Acid Battery & 14.4V-14.7V for
12V AGM / LiFePO4 Battery
Cooling Type
The product features an aluminum stretched plate and a
waterproof cooling fan at the bottom for enhanced heat
dissipation.
Ingress Protection Filled with pure epoxy resin for high waterproof level IP67
Circuit Protection Short-circuit Protection, Reverse Connection Protection,
Overcharge Protection, Overtemperature Protection
Working Temperature
Range -10°C~40°C
Nominal Working
Temperature 25°C
Relative Humidity 5%~95%

VERSION
2023.V1
5
USER MANUAL
VOLTIUM ENERGY®SUPERCHARGE
2&4 BANK IP67 CHARGER
FEATURES
ۗIP67 Rating;
ۗCapable of charging 2-4 batteries simultaneously (Quantity varies
by model);
ۗBuilt with marine-grade construction;
ۗEquipped with an aluminum stretched plate and waterproof
cooling fan at the bottom for efcient heat dissipation;
ۗIncludes LED indicators to display battery charging percentage;
ۗProvides fast charging at 20A for each bank;
ۗFeatures a wake-up function for low voltage in LiFePO4
batteries;
ۗAutomatically initiates small current charging after 24 hours of
full charge for LiFePO4 batteries;
ۗShort-circuit protection;
ۗReverse connection protection;
ۗOvercharge protection;
ۗOver-temperature protection.

VERSION
2023.V1
6
USER MANUAL
VOLTIUM ENERGY®SUPERCHARGE
2&4 BANK IP67 CHARGER
USAGE INSTRUCTIONS
CONNECTING THE CHARGER:
ࠠBefore charging, plug the AC cord into the electrical outlet rst.
ࠠNext, select the battery type by pressing the MODE button.
ࠠFinally, connect the DC output ring terminals.
ࠠOnce the correct connections are made, the charger will begin to output current.
Simultaneously, the charging status LED Indicators will display the battery charging
percentage.
DISCONNECTING THE CHARGER:
ࠠAfter charging is complete, disconnect the DC output ring terminals rst.
ࠠThen, unplug the AC cord from the electrical outlet.
CHANGING BATTERY TYPE DURING CHARGING:
ࠠIf you need to change the charging battery type while charging is in progress:
ࠠFirst, disconnect the DC output ring terminals.
ࠠPress the MODE button to select the new charging battery type.
ࠠFinally, reattach the ring terminals on the output cables to the battery terminals.
The Voltium Energy® SuperCharge IP67 Waterproof 2- and 4-bank battery charger is
specically designed to charge 12V LiFePO4, Lead acid, and AGM batteries. This charger
enhances battery life and reliability through its built-in protection features. It can charge in
serial connected 12V batteries (of same the model) to full capacity for a balanced battery setup
or simultaneously charge various 12V batteries.
These revised instructions provide clearer guidance on how to use the charger effectively and
safely.
INTRODUCTION

VERSION
2023.V1
7
USER MANUAL
VOLTIUM ENERGY®SUPERCHARGE
2&4 BANK IP67 CHARGER
CHARGING 12V LIFEPO4 BATTERY:
1. Once the 12V LiFePO4 battery is correctly connected to the charger’s output cable, the
charger will enter a 20A normal rated current charging mode.
2. Throughout the charging process, the LED Power Indicator will remain solidly lit. As the
battery voltage increases, the charging current gradually decreases.
3. When the charging current automatically drops to 1.5A±0.5A, the 100% LED indicator will
illuminate solid green, indicating a fully charged battery.
4. After the LiFePO4 battery reaches full charge, it will no longer have trickle charging
current, and the green LED indicator will remain solid during this phase.
5. Following a full charge for 24 hours, the charger will apply a 1.5A±0.5A charging current to
maintain the battery.
6. Once disconnected from the battery, the charger will return to a standby state, with all
four Charging Status LED Indicators turned off. The LED Power Indicator and Battery Type
LED Indicator will remain illuminated.
CHARGING 12V LEAD ACID / AGM BATTERY:
1. Once the 12V Lead Acid / AGM battery is correctly connected to the charger’s output
cable, the charger will enter a 20A normal rated current charging mode;
2. Throughout the charging process, the LED Power Indicator remains solidly on. As the
battery voltage increases, the charging current gradually decreases;
3. When the charging current automatically drops to 1.5A±0.5A, the 100% LED indicator light
will turn solid green, indicating a fully charged battery;
4. When the charging current drops to 0.8A±0.3A, the battery will stop charging. During this
phase, the 100% LED indicator light remains solid green;
5. After reaching a full charge, if the battery voltage drops to 12.9V±0.2V, a 1.5A±0.5A current
is used for trickle charging;
6. After disconnecting from the battery, the charger will return to standby mode with all four
Charging Status LED Indicators turned off. The LED Power Indicator and Battery Type LED
Indicator will remain illuminated.
When the charger is connected to AC voltage and the output cable is unconnected, the LED
Power Indicator on the panel remains solid, and the bank panel displays the last-selected battery
type. To choose the battery type for charging, simply press the mode button. The charger will
retain your selection, automatically recognizing it each time you connect the input in the future.
HOW IT OPERATES

VERSION
2023.V1
8
USER MANUAL
VOLTIUM ENERGY®SUPERCHARGE
2&4 BANK IP67 CHARGER
CHARGING STATUS
LED INDICATORS EXPLANATION
25% Red LED The 25% Charge LED will light up when the battery voltage is
lower than 12.5V.
50% Red LED The 50% Charge LED will light up when the battery voltage is
higher than 12.5V but lower than 13.7V.
75% Red LED The 75% Charge LED will light up when the battery voltage is
higher than 13.7V.
100% Red LED
All the Charge LEDs will light up when fully charged.
“ACTIVATE” MODE BUTTON:
Inside the LiFePO4 battery, there’s a low voltage protection PCBA. When the low-voltage
protection activates, the battery won’t provide voltage output at its terminals, and the charger
can’t charge it. To initiate “ACTIVATE” charging:
1. Connect the AC cord to an electrical outlet;
2. Press the MODE button to select the LiFePO4 battery charging mode;
3. Continuously press the MODE button on the bank panel for 3-5 seconds. The LiFePO4
Battery Type LED Indicator will ash slowly;
4. Attach the ring terminals on the output cables to the battery terminals correctly;
5. Once connected, the 12V LiFePO4 battery bank charger will deliver a pulse output of
1.5A±0.5A to charge the 12V LiFePO4 battery until it exits low-voltage protection. The
charger will enter normal charging mode;
6. During the pulse charging state, if you continuously press and hold the button on the panel
for 3-5 seconds, it will exit the “ACTIVATE” charging function, and the charger will return
to standby mode, with only the LED Power Indicator illuminated.

VERSION
2023.V1
9
USER MANUAL
VOLTIUM ENERGY®SUPERCHARGE
2&4 BANK IP67 CHARGER
1. MATCHING THE CHARGER WITH THE AC POWER GRID AND BATTERY PACK:
Before using the charger, ensure that the AC power grid voltage and frequency fall within
the specied range indicated on the “Basic Parameters” label. If the voltage is lower than the
nominal input voltage (less than 220V), the charger will automatically shut down for protection
and affecting battery charging performance.
Additionally, for compatibility between the charger and the battery pack, refer to the battery
specications provided on the “Basic Parameters” label on the charger. Conrm that the
battery type (12V LiFePO4 / Lead Acid / AGM Batteries) and the battery pack’s rated voltage
(V) match the information on the label. Mismatched settings can result in undercharging,
overcharging, or even permanent damage to the battery pack or charger.
2. AC POWER WIRE, DC CHARGING CABLE POLARITY, AND PRECAUTIONS:
AC input wire: On the side of the charger, you will nd markings for I, N, and Earth on the
input cable plug. Please ensure correct identication. The I, N, and Earth markings on the AC
plug must correspond with those of the socket outlet.
Charging output cable: The charger’s output cable is equipped with distinctive colors. The red
cable connects to the battery’s “+” (positive), while the black cable connects to the battery’s
“-” (negative). Use the M8 ring terminals on the charging output cable to connect them to the
corresponding battery terminals. It is crucial that the polarity of the charging socket matches
the polarity of the charging plug; otherwise, charging will not be possible. Always verify this
before using the charger.
Following these guidelines will help ensure safe and efcient charging of your batteries.
OPERATION
METHOD

VERSION
2023.V1
10
USER MANUAL
VOLTIUM ENERGY®SUPERCHARGE
2&4 BANK IP67 CHARGER
SHORT-CIRCUIT OR REVERSE CONNECTION PROTECTION:
When the output terminals are short-circuited or reverse-connected to the battery, the
charger will not provide any DC output. In this case, the LED Power Indicator will ash rapidly.
NO-LOAD PROTECTION:
If the batteries are not connected, the charger will not output any DC current.
OVERTEMPERATURE PROTECTION FUNCTION:
When the temperature inside the charger’s radiator reaches or exceeds 80°C±5°C, the
charger will automatically reduce the output current as a safety measure against overheating.
As the internal temperature decreases, the charging current will gradually increase, eventually
returning to the maximum of 20A. The charger includes a waterproof cooling fan mounted
externally. This fan operates when the temperature of the bottom aluminum stretched plate
reaches or exceeds 50°C±5°C and stops when it falls below 40°C±5°C.
AUTOMATIC SHUTDOWN AFTER FULL CHARGING:
The charger features an automatic shutdown function once the battery reaches a full charge,
following the charger’s pre-programmed parameters. The charger will only initiate a new
charging cycle when AC power is disconnected or when the battery requires further charging,
ensuring optimal battery health and safety.
PROTECTION
FUNCTION
ASSEMBLY AND DIMENSION
ࠠFor secure installation, it is advisable to afx the charger in a stable position.
ࠠEnsure there is a clearance of at least 30mm around the charger for safety.
ࠠTo secure the charger, use M6 screws with a recommended hole diameter of 6.5mm in the
bottom aluminum stretched plate.
ࠠAvoid placing the charger directly above or below the battery being charged, as gases or
uids from the battery can corrode and damage the charger.
ࠠNever operate the charger in an enclosed space or obstruct ventilation in any way. When
charging, ensure the battery is located in a well-ventilated area.
ࠠFamiliarize yourself with all specic precautions provided by battery manufacturers,
including whether to remove or keep cell caps on during charging and recommended
charging rates.

VERSION
2023.V1
11
USER MANUAL
VOLTIUM ENERGY®SUPERCHARGE
2&4 BANK IP67 CHARGER
ࠠThis appliance is not intended for use by individuals, including children, with limited physical,
sensory, or mental capabilities or those who lack the understanding and knowledge
required for safe operation.
ࠠUse this charger exclusively for charging 12V LiFePO4 / Lead Acid / AGM Batteries.
ࠠDo not use this charger to power extremely low-voltage electrical systems or charge dry-
cell batteries, as it may lead to battery rupture.
ࠠWhen it’s necessary to remove a battery from a vehicle or boat for charging, always
disconnect the grounded terminal from the battery rst.
ࠠNever use the battery charger unless the battery voltage matches the charger’s specied
output voltage rating.
ࠠWhen working in proximity to batteries, always protect your eyes. Avoid placing wrenches
or other metal objects across the battery terminals or on top of the battery, as this can
result in sparking or battery explosions.
ࠠIf the charger has experienced a severe impact, has been dropped, or shows any signs of
damage, do not operate it. Instead, have a qualied service technician inspect and repair it
as necessary.
ࠠEnsure proper ventilation when using the charger during charging. Avoid exposure to heat,
ames, or sparks.
ࠠThe battery charger must be plugged into an earthed socket-outlet for safe operation.
ࠠNever charge a frozen battery.
ࠠUsers should clean the charger shell and remove dust at least every six months.
WARNING
MAINTENANCE

VERSION
2023.V1
12
USER MANUAL
VOLTIUM ENERGY®SUPERCHARGE
2&4 BANK IP67 CHARGER
IMPORTANT SAFETY INSTRUCTIONS:
PROTECTION FROM WATER:
ࠠDO NOT expose the plug or ring terminals to rain or snow.
ࠠDO NOT submerge the charger in water or use it when the AC plug is wet.
PROPER HANDLING:
When disconnecting the unit from the power source, pull the cord by the plug rather than by
the cord.
AVOID DAMAGED COMPONENTS:
ࠠDO NOT operate the charger with a damaged cord or plug.
DAMAGE AWARENESS:
ࠠDO NOT operate the charger if it has received a sharp blow, been dropped, or otherwise
damaged in any way. Damage to the power cable, device, or charging cable increases the
risk of electrical shock. For inspection and repair, take the charger to a qualied technician.
NO DISASSEMBLY:
ࠠDO NOT disassemble the charger. Incorrect assembly could result in electrical shock or
re.
MAINTENANCE AND CLEANING:
To reduce the risk of electric shock, unplug the charger from the outlet before attempting any
maintenance or cleaning. Turning off controls will not reduce the risk.
SAFETY
INSTRUCTIONS
