VONROC RB501DC User manual

EN Original Instructions 06
NL Vertaling van de oorspronkelijke gebruiksaanwijzing 00
FR Traduction de la notice originale 00
ELECTRIC ROLLER BLIND
RB501DC / RB502DC / RB503DC / RB504DC
RB505DC / RB506DC / RB507DC
BLACK / GREY / WHITE

WWW.VONROC.COM
2
A B
1x 4x
INSTALLING ROLLERBLIND

WWW.VONROC.COM
3
0,5 c
m
3
5
4
F
F
-
1
,
0
c
m
F
A B
W
F = W-3,5 cm
W
F = W-3 cm
W
F = W-3,5 cm
W
F = W-3 cm
1 2

WWW.VONROC.COM
4
7.1
6.1
6.2
7.2
6
7
Click!
Click!
3
4
5
2
Click!
1
English
Shortly press the down button to check if the
blind unrolls the right way. If the blind moves
up, the rotational direction must be changed.
WARNING: risk of damage.
Stop the blind before reaching
the end positions.
Shortly press the program button with a pin on the
motor. The blind will start stepping, indicating that
program mode has been activated.
(The blind keeps stepping until the program mode
is deactivated.)
Repeat steps 6.1 - 6.2 to remove a blind from
a channel.
Press the pair button on the back of the remote
control to pair the blind.
The blind will shortly stop stepping indicating that the
remote has been paired to the blind.
Pair
button
Up
Down
Activate the motor
Check rotational direction
Simultaneously press the up and down button
to change the rotational direction.
English
MOTION CMD-02 TUBULAR MOTOR MOTION CMD-02 TUBULAR MOTOR
Pair a remote
Activate the motor by moving the switch to 1.
End limits must be programmed to use a blind properly and to prevent it from being damaged.Proceed
to step 12 if end limits are already set.
W
-1
c
m
W
W-0,5 cm
W
W
-0
,5
c
m
W
W-0,5 cm
W
1
2
3
Click!
A B
ACTIVATE THE MOTOR
Activate the motor by moving the switch to 1.

WWW.VONROC.COM
5
4
5
6
7
Click!

WWW.VONROC.COM
6
ACTIVATE THE BLIND
Follow the steps in the online manual
CMD-02 to activate the blind:
rtube.nl/red1942 rtube.nl/red1943
FOR MORE INFORMATION
AND SUPPORT:

EN
7
WWW.VONROC.COM
1. SAFETY INSTRUCTIONS
Read the enclosed safety warnings, the additional
safety warnings and the instructions. Failure to
follow the safety warnings and the instructions may
result in electric shock, fire and/or serious injury.
Save the safety warnings and the instructions for
future reference.
The following symbols are used in the user
manual or on the product:
Read the user manual.
Indoor use only.
Do not dispose of the product in unsuitable
containers.
The product is in accordance with the
applicable safety standards in the European
directives.
GENERAL SAFETY WARNING
This appliance can be used by children aged from
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the ap-
pliance in a safe way and understand the hazards
involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made
by children without supervision.
Children of less than 3 years should be kept away
unless continuously supervised. Children aged
from 3 years and less than 8 years shall only switch
on/off the appliance provided that it has been
placed or installed in its intended normal operating
position and they have been given supervision or
instruction concerning use of the appliance in a
safe way and understand the hazards involved.
Children aged from 3 years and less than 8 years
shall not plug in, regulate and clean the appliance
or perform user maintenance.
ADDITIONAL SAFETY WARNINGS FOR
ELECTRICAL ROLLER BLINDS
WARNING: To reduce the risk of severe injury or
death, it is important to follow these instructions
for personal safety. Save these instructions.
• Read an follow all installation instructions
• Young children can strangle themselves with
the loop of pull cords, chains and tepas and
cords that operate window coverings.
• To avoid strangulation and entanglement, keep
cords out of reach of young children.
• Cords may ensnare a child’s neck
• Move beds, cots and furniture away from win-
dow covering cords
• Do not tie cords together
• Make sure cords do not twist together and form
a loop
• Do not perform repairs yourself.
• Do not attempt to open the device or disas-
semble it. You run the risk of electric shock and
voiding the limited warranty. No user-servicea-
ble parts are inside.
• This appliance can be used by children aged
8 years and above and persons with reduced
physical, sensory or mental capabilities or lack
of experience and knowledge if they have been
given supervision or instruction concerning use
of the appliance in a safe way and understand
the hazards involved. Children should not play
with the appliance. Cleaning and user mainte-
nance should not be performed by unsupervi-
sed children.
• Do not allow children to play with fixed controls.
Keep remote controls away from children.
• Frequently examine the installation for imbalan-
ce and signs of wear or damage to cables and
springs. Do not use if repair or adjustment is
necessary
• The drive must be disconnected from its power
source during cleaning, maintenance and when
replacing parts.
• The A-weighted emission sound pressure level
of the drive is equal to or less than 70 dB(A).
• Indoor and household use only
• Disconnect the drive from the power supply
or switch off the automatic controls when
maintenance, such as window cleaning is being
carried out in the vicinity
• When operating a biased switch, make sure that
other persons are kept away
• Do not operate when maintenance, such as win-
dow cleaning, is being carried out in the vicinity
• The tube motor must only be supplied with
safety extra low voltage corresponding to the
marking on the appliance

8
EN
WWW.VONROC.COM
• This appliance contains batteries that are
non-replaceable
Electrical safety
When using electric machines always observe the
safety regulations applicable in your country to
reduce the risk of fire, electric shock and personal
injury. Read the following safety instructions and
also the enclosed safety instructions.
Always check that the voltage of the power
supply corresponds to the voltage on the
rating plate.
If the supply cord of this power tool is
damaged, it must be replaced by a specially
prepared supply cord available through the
service organization.
2. MACHINE INFORMATION
Intended use
The electrical roller blinds is intend for indoor,
non-commercial, household use for blinding
windows. Do not use the product for any other
purpose. Assembly can be completed by non-pro-
fessionals.
3. INSTALLATION
WARNING: Important safety instructions. Follow all
instructions, since incorrect installation can lead to
severe injury
MOTOR
• The motor can only be used with soft material
for driven parts
• Hazardous unprotected moving parts of the
drive must be installed higher than 2.5m above
the floor or any other level surface that could
provide access to it.
• Install the actuating members of a manual
release at a height of less than 1.8m
• The actuating member of a biased switch is to
be located within direct sight of the driven part
but away from moving parts. It is to be installed
at a minimum hight of 1.5m and not accessible
to the public
• The mass and the dimension of the driven part
must be compatible with the rated torque and
rated operating time
• Fixed controls have to be clearly visible after
installation
• The driven part must be compatible with the
rated torque (0.3N.m) and rated operating time
(12min).
• Minimum tube diameter motor: ø25mm.
• The drive is intended to be installed at a hight of
at least 2.5m above floor or any other accessi-
ble level surface.
• All-pole disconnection switches must be incor-
porated in the fixed wiring in accordance with
the wiring rules.
• The appliance must only be supplied at safety
extra low voltage corresponding to the marking
on the appliance
• Before installing the drive, remove any unne-
cessary cords or components and disable any
equipment not needed for powered operation.
• The battery must be removed from the appli-
ance before it is scrapped. The appliance must
be disconnected from the supply mains when
removing the battery. The battery is to be dispo-
sed of safely.
4. OPERATION
Check the device for damage before use
and only use in good working condition.
5. MAINTENANCE
Before cleaning and maintenance, always
switch off the machine.
Always disconnect the machine from the
main power supply before carrying out any
maintenance work.
• Use a damp, soft, lint-free cloth. Avoid getting
moisture in openings
• Do not use aerosol sprays, solvents, alcohol or
abrasives.
ENVIRONMENT
Faulty and/or discarded electrical or
electronic apparatus have to be collected at
the appropriate recycling locations.

EN
9
WWW.VONROC.COM
Only for EC countries
Do not dispose of power tools into domestic waste.
According to the European Guideline 2012/19/EU
for Waste Electrical and Electronic Equipment and its
implementation into national right, power tools that
are no longer usable must be collected separately
and disposed of in an environmentally friendly way.
WARRANTY
VONROC products are developed to the highest
quality standards and are guaranteed free of
defects in both materials and workmanship for the
period lawfully stipulated starting from the date of
original purchase. Should the product develop any
failure during this period due to defective material
and/or workmanship then contact VONROC directly.
The following circumstances are excluded from this
guarantee:
• Repairs and or alterations have been made
or attempted to the machine by unauthorized
service centers;
• Normal wear and tear;
• The tool has been abused, misused or
improperly maintained;
• Non-original spare parts have been used.
This constitutes the sole warranty made by compa-
ny either expressed or implied. There are no other
warranties expressed or implied which extend
beyond the face hereof, herein, including the im-
plied warranties of merchantability and fitness for
a particular purpose. In no event shall VONROC be
liable for any incidental or consequential damages.
The dealers remedies shall be limited to repair or
replacement of nonconforming units or parts.
The product and the user manual are subject to
change. Specifications can be changed without
further notice.

WWW.VONROC.COM
10

11
VONROC • Lingenstraat 6 • 8028 PM Zwolle • The Netherlands
Zwolle, 01-04-2023 H.G.F Rosberg
CEO
(EN) We declare under our sole responsibility that this product is in
conformity with directive 2011/65/EU of the European
parliament and of the council of 8 June on the restriction of the
use of certain hazardous substances in electrical and electronic
equipment is in conformity and accordance with the following
standards and regulations:
(NL) Wij verklaren onder onze volledige verantwoordelijkheid dat dit
product voldoet aan de conform Richtlijn 2011/65/EU van het
Europees Parlement en de Raad van 8 juni 2011 betreffende
beperking van het gebruik van bepaalde gevaarlijke stoffen in
elektrische en elektronische apparatuur en in overeenstemming
is met de volgende standaarden en reguleringen:
(FR) Nous déclarons sous notre seule responsabilité que ce produit
est conforme aux standards et directives suivants: est conforme
à la Directive 2011/65/EU du Parlement Européen et du Conseil
du 8 juin 2011 concernant la limitation d’usage de certaines
substances dangereuses dans l’équipement électrique et
électronique.
DECLARATION OF CONFORMITY
RB501DC / RB502DC / RB503DC / RB505DC / RB506DC / RB507DC
BLACK / GREY / WHITE - ELECTRIC ROLLER BLIND
EN 55014-1:2017/A11:2020, EN 55014-2:2015, EN 61000-3-2:2014,
EN IEC 61000-3-2:2019, EN 61000-3-3:2013 EN 61000-3-3:2013/A1:2019,
EN 301 489-1 V2.2.3:2019, FINAL DRAFT EN 301 489-3 V2.2.0,
EN 300 220-2 V3.1.1:2017, EN 50663:2017, EN 60335-2-97:2016/A12:2015,
EN 62233:2008, EN 60335-1:2012/A2:2019, EN IEC 55014-1:2021, EN IEC 55014-2:2021

©2023 VONROC
WWW.VONROC.COM
2304-12
Coulisse Manual No.
MN230022
