VQ Model PIPER PA-18 SUPER CUB User manual

PIPER PA-18
Radio control model
R/C Flugmodell
MONTAGEANLEITUNG
INSTRUCTION MANUAL
SPECIFICATIONS
Wingspan 106.6in.
Length 67.7 in.
Electric Motor (See next page)
Glow Engine 26-30cc two stroke
Radio 6 Channel / 8 Servos
WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
ACHTUNG! Dieses ferngesteuerte Modell ist KEIN Spielzeug! Es ist für fortgeschrittene Modellflugpiloten bestimmt,
die ausreichende Erfahrung im Umgang mit derartigen Modellen besitzen Bei unsachgemäßer Verwendung kann
hoher Personen- und/oder Sachschaden entstehen. Fragen Sie in einem Modellbauverein in Ihrer Nähe um
professionelle Unterstützung, wenn Sie Hilfe im Bau und Betrieb benötigen. Der Zusammenbau dieses Modells ist
durch die vielen Abbildungen selbsterklärend und ist für fortgeschrittene, erfahrene Modellbauer bestimmt.
TECHNISCHE DATEN
Spannweite 2710mm
Lange 1720mm
Elektroantrieb (siehe nächste Seite)
Verbrennerantrieb 26-30cc 2-T
Fernsteuerung 6 Kanal / 8 Servos
ARF BY
SUPER CUB

1.5mm
AB
!
CA
L/R
Assemble left and right
sides the same way.
X
Drill holes using the stated
size of drill
(in this case 1.5 mm Ø)
Use epoxy glue
Take particular care here
Hatched-in areas:
remove covering
film carefully
Not included.
These parts must be
purchased separately
Check during assembly that these
parts move freely, without binding
Apply cyano glue
Low setting
SILICON
EPOXY A
EPOXY B
CA
GLUE
Epoxy Glue (5 minute type)
Silicon sealer
Cyanoacrylate
Glue
Minimum 6 channel radio
for airplane with 8 servos
Nylon tube
Extension for aileron
servo, Flap servo.
REQUIRED FOR OPERATION (Purchase separately)
Epoxy Glue (30 minute type)
TOLLS REQUIRED
Hobby knife
Needle nose Pliers
Phillip screw driver
Awl
Scissors Wire Cutters
(Purchase separately)
Hex Wrench
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
Sander
Masking tape - Straight Edged Ruler - Pen or pencil - Drill and Assorted Drill Bits
Read through the manual before you begin, so you will have an overall idea of what to do.
(Purchase separately)
.Motor control x1 .Aileron x2
.Elevator x2 .Rudder x1 .Flap x 2
CONVERSION TABLE
1.0mm = 3/64”
1.5mm = 1/16”
2.0mm = 5/64”
2.5mm = 3/32”
3.0mm = 1/8”
4.0mm = 5/32”
5.0mm = 13/64”
6.0mm = 15/64”
10mm = 13/32”
12mm = 15/32”
15mm = 19/32”
20mm = 51/64”
25mm = 1”
30mm = 1-3/16”
45mm = 1-51/64”
If exposed to direct sunlight and/or heat, wrinkels can appear. Storing the
model in a cool place will let the wrinkles disappear. Otherwise, remove
wrinkles in covering film with a hair dryer, starting with
low temperature. You can fix the corners by using a hot iron.
Bei Sonneneinstrahlung und/oder Wärme kann die Folie erschlaffen bzw. Falten
entstehen. Verwenden Sie ein Warumluftgebläse (Haartrockner) um evtl. Falten aus der Folie
zu bekommen. Die Kanten können Sie mit einem Bügeleisen behandeln. Nicht zuviel Hitze anwenden !
BENOTIGTE KOMPONENTEN FUR DEN ABFLUG (Nicht enthalten)
Klebstoff
Epoxy-Klebstoff (30min-Typ)
Epoxy-Klebstoff (5min-Typ)
Gas Engine: 26 ~ 30cc

35mm
19mm
HORIZONTAL STABILIZER
Cut two slots (only the covering) on the
top and along the trailing edge of the
horizontal stabilizer.
TOP VIEW / Draufsicht
TOP VIEW / Draufsicht
19mm
35mm
1
Full the elevator out of the
horizontal stabilizer.
2
Cut away only the
covering both side
Cut away only the covering on the
top and bottom
3
4
The slot on the horizontal stabilizer and the slot
on the fuselage must be coincidental.
A A’
A=A’
Trial fit the horizontal stabilizer in place . Check the alignment
of the horizontal stabilizer. When you are satisfied with the
alignment, use a pencil to trace around the top and bottom
of the stabilizer where it meets the fuselage.
5
HORIZONTAL STABILIZER - VERTICAL STABILIZER

Cut away only the covering
on the top and bottom
6
Remove the horizontal stabilizer from the fuselage.
Using the sharp hobby knife, carefully cut away the
covering inside the lines which were marked above.
7
CA
Thin CA
glue
CA
CA
CA
The elevator hinges are pre-glue into the
elevator halves. Working with one elevator half
for now, apply a thin layer of petroleum jelly to
only the pivot point of the two hinges.
Without using glue yet, push the elevator half
and its hinges into the hinge slots in the trailing
edge of the horizontal stabilizer. There should
be a minimal hinge gap and the end of the
elevator half should not rub against the
horizontal stabilizer.
When satisfied with the fit and alignment, hinge
the elevator half to the horizontal stabilizer,
using thick CA glue. Make sure to apply a thin
layer of CA glue to the top and bottom of both
hinges. Repeat the previous procedures to
hinge the second elevator half to the other side
of the horizontal stabilizer.
Pull the horizontal stabilizer through the other side
of the fuselage and repeat the previous procedures
to glue the second torque rod wire into the horizontal
stabilizer.
Realign the horizontal stabilizer, then glue the
horizontal stabilizer into the fuselage, using a
generous amount of thin CA. Apply thin CA to each
of the four joints and use a generous amount to
ensure to strong bond.
8
NOTE: You may need to open up the slots of the
horizontal stabilizer so that the vertical stabilizer
is not too difficult to push in.
Cut away only
the covering
both sides.
9
10

Trial fit the vertical stabilizer in place . Check the alignment
of the vertical stabilizer. When you are satisfied with the
alignment, use a pencil to trace around the right and left
of the stabilizer where it meets the fuselage.
Cut away only the covering
on the left and right side.
Remove the vertical stabilizer from the fuselage.
Using the sharp hobby knife, carefully cut away the
covering inside the lines which were marked above.
AB
Realign the vertical stabilizer , ensure that the vertical
stabilizer is perpendicular to the horizontal stabilizer.
Then glue the vertical stabilizer into the fuselage, using
a generous amount of 5 min. Epoxy. Apply thin epoxy
to each of the two joints and the entire bottom edge of
the vertical stabilizer, use a generous amount to
ensure to strong bond.
5 min.
Epoxy
11
12
13
2mm
3x12mm screw
CA
Apply a thin layer of petroleum
jelly to only the pivot point of the
torque rod bearing.
Glue the rudder torque rod bearing into the slot you cut previously in the vertical stabilizer,
using a thin layer of CA glue.
Petroleum
jelly
FUSELAGE - SIDE VIEW
VERTICAL STABILIZER
3x12.......2
....................2
TAIL WHEEL

.....6
4X20mm screw
Cut away only the covering
* WARNING: When removing any covering
from the airframe, please ensure that you
secure the cut edge with CA or similar cement.
This will ensure the covering remain tight.
3mm
BOTTOM - VIEW / Unteransicht
......4
Connector
3mm connector
3mm connector
Aluminum landing
gear
Hauptfahrwerk
3mm connector
BOTTOM - VIEW / Unteransicht
BOTTOM - VIEW / Unteransicht
MAIN LANDING GEAR
MAIN LANDING GEAR
MAIN LANDING GEAR

...1
Aluminum landing
gear Hauptfahrwerk
4x30mm
screw
4mm nut
............2
4X40mm screw
4mm nut-washer
BOTTOM - VIEW / Unteransicht
Aluminum landing
gear
Hauptfahrwerk
4x30mm
screw
4mm nut
3mm connector
FUSELAGE
MAIN LANDING GEAR
MAIN LANDING GEAR

5mm
13/64”
Using a aluminum motor mounting plate as a template, mark the fire-wall
where the four holes are to be drilled (1).
Remove the aluminum motor mounting plate and drill a 5mm hole
through the plywood at each of the four marks marked (2).
Note: The aluminum motor mounting and screws included with the engine.
1
3
4
Aluminum motor
mounting plate
2
5
B
B=152-158mm
6
.........4
5X60mm screw
5mm washer
5mm nut
..................16
..................12
ENGINE

B
B=152-158mm
Using a aluminum motor mounting plate as a template, mark the fire-wall
where the four holes are to be drilled (1).
Remove the aluminum motor mounting plate and
drill a 5mm hole through the plywood at each of the
four marks marked (2).
Note: The aluminum motor mounting and screws
included with the motor.
2.mm
2.mm
Relive the cowl to clear the silencer,
carburetor and plug.
23x8mm screw
............4
ELECTRIC MOTOR
COWLING
4 - 6mm

Akku Kiettband
aus dem PICHLER
Sortiment
Best.Nr. C4739
Fuel tank seat bell
X
Tipp
Fuel tank flat (3mm plywood)
30cc Fuel tank
Fuel tank seat bell
Li-po battery
Fuel tank assembly
FUEL TANK & LIPO. BATTERY

Throttle
pushrod
FRONT
Servo tray
Elevator
pushrod
Elevator servo
Rudder servo
Throttle servo
Servo tray
FUEL TANK
Rudder
pushrod
SERVO TRAY - TOP VIEW
FRONT
REAR
IN CASE OF THE ELEVATOR SERVO IN SIDE
OF THE FUSELAGE
IN CASE OF THE ELEVATOR SERVO
OUT SIDE OF THE FUSELAGE
SERVO

Control horn
......................4
2x30mm screw
...................8
X
Aileron, flap servo
and light extension
cord not include.
2x10mm
screw
2x10mm
screw
Flap servo hatch
Flap servo Servo mount
Aileron servo hatch
Aileron servo Servo mount
WING BOTTOM
WING BOTTOM
Aileron (Flap) servo hatch
Aileron ( flap) push rod
Aileron (flap) control horn
Wing - Bottom view / Unteransicht
BOTTOM - VIEW / Unteransicht
Servo hatch Pushrod
Aileron servo and hatch
RIGHT
Aileron servo and hatch
LEFT
1.5mm
1.5mm
Flap servo and hatch
RIGHT
Flap servo and hatch
LEFT
WING SECTION
2mm
2X30mm
...............4
Connector
SERVO

L/R
Assemble left and right
wing halves the same way
Aluminum tube
BOTTOM - VIEW / Unteransicht
Cut away only
the covering
CA
CA
L/R
Do the same way with other
wing halves.
Slide the aluminum tube into
the fuselage as shown.
WING
WING

3x12mm
.........4
.........4
L/R
Do the same way with
other wing halves.
Secure the wing halves in place
using 5x20mm screw.
5x20mm
5mm washer
.......2
..................2
Cut away only
the covering
CA
FRONT
FRONT
LEFT BRACE (TOP VIEW)
RIGHT BRACE (TOP VIEW)
BOTTOM - VIEW / Unteransicht
3x12mm
1.5mm
L/R
Do the same way with other
wing halves.
3x12mm
.........2
WING
WING
WING

0.7mm dia. Cable
...1 roll
2mm metal tube
.....................4
Stabilizer
CA
CA
2mm metal tube
..............4
BOTTOM - VIEW
Unteransicht
..............2
3x6.......2
TAIL
TAIL
TAIL

IMPORTANT: Please do not clean your model with pure alcohol, only use liquid soap with water or use glass cleaner to clean on surface of
your model to keep the colour not fade.
All details are subject to change
without notice !
Technische Anderungen und Irrtumer
vorbehalten !
CA
X
2x6mm
..........6
1mm
BURDA VERSION
AUSTRIA VERSION
Note: Cut out the stickers and apply them in the proper area. Do not peel the backing paper off all at once. Peel off one corner of the backing and cut off with
scissors. Arrange sticker on model and when satisfied adhere the corner without backing.
Carefully peel back the rest of the backing while at the same time adhering the rest of the sticker.
Try not to make air bubbles, if there are some, carefully puncture sticker (center of bubble) but not model surface with the tip of the knife or sharp pin and
squeeze out the air.
At curves stretch sticker and apply a little heat so that no ceases occur. Cut off the excess that is produced.
95 ~ 100mm
30mm
15mm
Aileron
Rudder 15mm
30mm
Querruderausschlag
Seitenruderausschlag
Do not try to fly an out-of balance model!
Uberprufen Sie vor dem Flug den Schwerpunkt. 15mm
15mm
Elevator
Hohenruderausschlag
Flap
20mm
LIGH
DECOR
BALANCE
