VQ Model VQAO14 Instruction Manual

RADIO CONTROL MODEL
MITSUBISHI A6M5
“ZERO”
VQAO14 Gray
VQAO15 Green
SPECIFICATIONS
Wingspan
Length
Flying weight
Electric Motor
Glow Engine
Radio
Technische Daten
Spannweite
Länge
Fluggewicht
Elektroantrieb
Verbrennerantrieb
Fernsteuerung
1580mm
1160mm
2700g
700 Watt
7.5cc 2T / 11cc 4-T
5 Channel / 5 Servos
1580mm
1160mm
2700g
700 Watt
7.5cc 2T / 11cc 4T
5 Kanal / 5 Servos
WARNING! This radio controlled model is NOT a toy. If modified or flown carelessly it could go out of controll and
cause serious human injury or property damage. Before flying your airplane, ensure the air field is spacious enough.
Always fly it outdoors in safe areas and seek professional advice if you are unexperienced.
ACHTUNG! Dieses ferngesteuerte Modell ist KEIN Spielzeug! Es ist für fortgeschrittene Modellflugpiloten bestimmt,
die ausreichende Erfahrung im Umgang mit derartigen Modellen besitzen Bei unsachgemäßer Verwendung kann
hoher Personen- und/oder Sachschaden entstehen. Fragen Sie in einem Modellbauverein in Ihrer Nähe um
professionelle Unterstützung, wenn Sie Hilfe im Bau und Betrieb benötigen. Der Zusammenbau dieses Modells ist
durch die vielen Abbildungen selbsterklärend und ist für fortgeschrittene, erfahrene Modellbauer bestimmt.
BUILDING INSTRUCTIONS / MONTAGEANLEITUNG
R/C FLUGMODEL
VQAO151 White

Minimum 5 channel radio
for airplane with 5 servos
.60 ~.70 - 4 cycle
10.5x6 for .40 - 2 cycle engine
11x6 for .46 - 2 cycle engine
12x6 for .60 - 4 cycle engine
12x7 for .70 - 4 cycle engine
13x6 for Brushless Motor
Silicone tube
Extension for aileron
servo, retract servo.
.46 ~ .50 - 2 cycle
Linkage Stopper x2
(for retract servo)
TOLLS REQUIRED
Hobby knife
Needle nose Pliers
Phillip screw driver
Awl
Scissors
Wire Cutters
(Purchase separately) Hex Wrench
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
.........................................................
Sander
Masking tape - Straight Edged Ruler - Pen or pencil - Rubbing alcohol - Drill and Assorted Drill Bits
Retract landing
gear VQAR04
Retract servo
x1
.Motor control x1 .Aileron x2
.Elevator x1 .Rudder x1
700 Watt
Brushless Motor
ESC-60A
Li-Po Battery
CONVERSION TABLE
1.0mm = 3/64”
1.5mm = 1/16”
2.0mm = 5/64”
2.5mm = 3/32”
3.0mm = 1/8”
4.0mm = 5/32”
5.0mm = 13/64”
6.0mm = 15/64”
10mm = 13/32”
12mm = 15/32”
15mm = 19/32”
20mm = 51/64”
25mm = 1”
30mm = 1-3/16”
45mm = 1-51/64”
OPTIONAL ACCESSORIES / BENOTIGTES ZUBEHOR
SILICON
EPOXY A
EPOXY B
CA
GLUE
Epoxy Glue (5 minute type)
Silicon sealer
Cyanoacrylate
Glue Epoxy Glue (30 minute type)
(Purchase separately)
Klebstoff
Epoxy-Klebstoff (30min-Typ)
Epoxy-Klebstoff (5min-Typ)
Low setting
If exposed to direct sunlight and/or heat, wrinkels can appear. Storing the
model in a cool place will let the wrinkles disappear. Otherwise, remove
wrinkles in covering film with a hair dryer, starting with
low temperature. You can fix the corners by using a hot iron.
Bei Sonneneinstrahlung und/oder Wärme kann die Folie erschlaffen bzw. Falten
entstehen. Verwenden Sie ein Warumluftgebläse (Haartrockner) um evtl. Falten aus der Folie
zu bekommen. Die Kanten können Sie mit einem Bügeleisen behandeln. Nicht zuviel Hitze anwenden !
1.5mm
AB
!
CA
L/R
Assemble left and right
sides the same way.
X
Drill holes using the stated
size of drill
(in this case 1.5 mm Ø)
Use epoxy glue
Take particular care here
Hatched-in areas:
remove covering
film carefully
Not included.
These parts must be
purchased separately
Check during assembly that these
parts move freely, without binding
Apply cyano glue

L/R
2mm
3x12mm screw
Trial fit the push rod into the wing. Join the pushrod to the retract
gear arm and trial fit the retract into the wing.
After checking that the retract works smoothly, fix the retract on the
wing with 3x12mm screws
1- Using a pencil, mark the center of the brace.
2- Trial fit the wing joiner into one of the wing panels. It should
insert smoothly up to the center line marked above.
3- Slide the other wing half onto the dihedral brace until
the wing panel meet. If the fit is over tight, it may be
necessary to lightly sand the dihedral brace.
4- Check for the correct dihedral angle.
5- Mix approximately 30 minute epoxy and apply a generous amount of epoxy into the wing joiner cavity of one wing half.
6- Coat one half of the dihedral brace with epoxy up to the center line. Install the epoxy-coated side of the dihedral brace
into the wing joiner cavity up to the center line, marking sure that the “V” of the dihedral brace is positioned correctly
7- Do the same way with the other wing half.
8- Carefully slide the wing halves together, ensuring that they are accurately aligned. Firmly press the two halves
together, allowing the excess epoxy to run out. Clear off the excess epoxy.
Center line
X
Aileron servo
X
Included with the
radio set
Plastic control horn
....................2
2x20mm screw
...............4
2mm
Aileron extension cord
X
Secure one end of the aileron
extension cord with adhesive tape
Querruder servo
Nehmen Sie Epoxykleber, um die
Tragflachen fest miteinander zu Verbinden
und streifen Sie den herausquellenden
Kleber nach dem Verbinden mit einem
fusselfreien Tuch SOFORT ab!
1- Retract landing gear / Fahwerk
2- Aileron servo / Querruder servo
3- Joining the wing / Flache
Use epoxy glue to bury the opening
Retract pushrod
3x12mm schraube
Servoverlangerungskabel
Ansicht von unten
Bottom view
Ansicht von unten
Bottom view /
3x12mm screw
................8
Steel clevis
.........2
40mm
15mm
Fahrwerkanlenkgestange
Wing joiner
Tragflachenverbinde
X
WARNING: Please do not clean off the excess epoxy on the wing with strong solvent or pure alcohol, only use
kerosene to keep the colour of your model not fade.

5- Retract servo / Einziehfahrwerk servo
CENTER
WING
SECTION
BOTTOM
Retract servo
/ Retract servo
X
Link the servo and retract gear arm with push rod. Be sure to adjust the stroke so
that the landing gear locks in both up and down position.
2” (~50mm)
1”(25mm)
19/64”
(7.5mm)
8-5/16”(~210mm)
RETRACT PUSHROD (SIDE VIEW)
With the retract and retract servo in the retracted position, mark the position where
each of the pushrod will attach to the servo arm, a small piece of masking tape
works well for this. Cut off the excess length each rod.
(TOP VIEW)
Cut away only
the covering
4- Servo mount / Servohalterung
A
FWU2
FWU1
A
CENTER
WING
SECTION
CA
CA
CA
CA
BOTTOM
Retract servo mount (plywood A,B,C)
Install the retract servo onto the retract
servo mount and secure it in place with
four screw (included with radio set).
Einbau des Servos fur
das Einziehfahrwerk
Instruction how to build in the retracting landing gear
(This Gearis OPTIONAL )
Einbauhilfe bei Anbringen eines
Einziehfahrwerks (Optional
bestellbar; nicht im Baukasten
enthalten!)
Einbau des Servos fur
das Einziehfahrwerk
6- Linkages / Ruderanlenkung
Fahrwerkanlenkgestänge
EINGEFAHREN AUSGEFAHREN
Einziehfahrwerk servohalterung
Schneiden Sie etwas
Folie weg
FWU2 FWU1

Ply gear mount
plate x 2
Gear mount x 2
2mm
Bottom view /Ansicht von unten
ELECTRIC RETRACT
LANDING GEAR
7- Electric retract landing gear / Einziehfahrwerk
RECEIVER
ELECTRIC RETRACT
LANDING GEAR
ON
OFF
GEAR
EXTENDED POSITION
RETRACTED POSITION
2mm
Main landing gear
2mm
3x12mm
screw
Gear mount
1
3x20mm
Nylon gear
strap
2mm
23x20mm
Ply gear
mount flat
Square
plastic
2mm
3
3x20mm screw
..........8
3x12mm screw
......16
Nylon gear strap
.......4
3x20mm screw
Wing - bottom view
8- Fixed gear / Starres Fahrwerk
ABS Wheel well cover
CA
Bottom view /Ansicht von unten
4
9- Fixed gear / Starres Fahrwerk
Square plastic x 2

CA
Bottom view /Ansicht von unten
10- Fixed gear / Starres Fahrwerk
Bottom view /Ansicht von unten
2x6mm screw
..........4
....2
...2
4mm collar
!
4.5mm
! Engine thrust on balk head
is already adjust at factory
Sturz und Zug beachten!
FRONT-VIEW
Vorderansicht
! Align the mark on both mounts
with the mark on the fuselage
!
! Align the mark on both mounts
with the mark on the fuselage
...4
.................4
4x25mm screw
Blind-nut 5/32x1”
11- Engine mount / Motoreinbau

! Engine thrust on balk head
is already adjust at factory
3x25mm screw
.............4
FRONT-VIEW
12- Four-stroke engine / 4T Motor
FRONT-VIEW
TOP-VIEW
13 Two-stroke engine / 2T Motor-
Nut...................4
6.5
TOP-VIEW
106~108mm
106~108mm
AB
3mm
3.2mm
3x25mm screw
106~108mm
X
3x20mm screw
4mm
14- Fuel tank installation / Tankeinbau
To muffler
Filler tube
To engine
!Secure install the fuel tank, ensuring
it will not rattle during flights.
With hang silencer (Pitts-style)
! Engine thrust on balk head
is already adjust at factory
4-13/64”
Draufsicht Vorderansicht
Draufsicht
Vorderansicht
Sturz und Zug beachten!
Checking for leaks - block the vents and blow
into the feed - if in doubt submersing the tank
in a blow of water will show up any problems.
Blow
Water
2
After confirming the direction .
Insert this assembly, clunk end
first, into the fuel tank and tighten
and screw the fuel tank cap on
firmly.
1 3

2.5x10mm screw
2mm
16- Cowling installation / Motorhaube
5mm
CA
Fuel tube or
nylon tube
(not included)
STEP 1
STEP 2
STEP 3
Cowl
Nylon
tube Mount
2.5x10mm screw
2.5x10mm screw
............4
15- Electric motor/Elektromotor
Firewall
106~108mm
(4-13/64”)
B’
B
B=B’
A
A=A’
A’
TOP-VIEW
SIDE-VIEW
- Using a plywood motor mounting plate as a template, mark the
fire wall where the four holes are to be drilled (1).
! Engine thrust on balk head
is already adjust at factory
5mm
13/64”
-Attach the aluminum motor mounting plate on to the motor and
secure it in place with four screws ( included with motor set) (7).
! Align the mark on the plywood motor
mount with the mark on the fuselage.
! Align the mark on the plywood motor mount
with the center lines on aluminum motor mount.
- Remove the plywood motor mounting plate and drill
a 13/64”(5mm) hole through the fire-wall at each of the
four marks marked (2).
- Using a aluminum motor mounting plate as a template, mark the
plywood motor mounting plate where the four holes are to be
drilled (3).
- Remove the aluminum motor mounting plate and drill a 1/8”(3mm)
hole through the plywood at each of the four marks marked (4).
-Push the four 5x70mm bolts through the fire-wall as shown (5).
- Reposition the plywood motor mounting plate (2pcs) and secure
it in place with eight 5mm nuts and washers (6).
Note: B=B’(Side-view) and A=A’(Top-view)
-Attach the motor on to the plywood motor mounting plate and
secure it in place with four 3x15mm (1/8x19/32”) screws(8).
3mm
1/8”
12
34
5x70mm.......4
5mm nut.......12
5mm washer...16
3mm screw/nut...4
Plywood motor
mounting plate
(2pcs)
Aluminum motor
mounting plate
7 - 8
5
6
Motorspant

....X 4
3x10mm screw
Cut away only
the film both
side
Cut away only
the film both side
AB
! Securely glue together
If coming off during fly,
you lose control of your
air plane.
2x12mm screw
Elevator control horn
1.5mm
Cut away only
the film both side
Plastic control horn
2x12mm screw
............................3
.......................6
Plastic back plate
...........................3
A = A’
B = B’
C = C’
STEP 1: Attach the control horn on
the rudder and elevator
STEP 2: Installing the stabilizer
(A=A’ and C=C’)
STEP 3: Installing the vertical fin
(B=B’)
3
Rudder control horn
A’
A
BB’
C C’
1
12
3x10mm
screw
Tail gear
Tail gear mount STEP 1 STEP 2
STEP 4: Installing other elevator
AB
17- Vertical-Horizontal Stabilizers / Hohenleiwerk - Seitenleiwerk
18- Tail gear / Heckspornrad

2x10mm screw
19 Tail gear cover
2mm
2x10mm screw
....X4
2mm
CA
Place the rudder on the trailing edge
of vertical stabilizer as show (make
sure the rudder move freely without
binding) . Mark the mounting hole
position with a pencil. Remove the
rudder and drill 2mm hole as show.
Replace the rudder on the trailing
edge of vertical stabilizer and se-
cure it in place using 5 minute epoxy.
Place the ABS tail gear cover on
the bottom of fuselage as show
and secure it in place using four
2x10mm screw
Slide the tail wheel onto the tail gear
axle and secure it with the supplied
2mm collar.
Attach the ABS tail cover in
place and secure it with litter
CA glue or screws (screws
not included)
20- Tail wheel / Spornrad
2.2mm collar
...........1
25mm wheel
21 Servo installation / Servoeinbau
X
Rudder pushrod
2 mm
(Or throttle pushrod)
Rudder push rod
Rudder servo
Throttle push rod
Elevator servo
Elevator push rod
BOTTOM VIEW
X
Elevator pushrod x2
2 mm
Elevator servo
Throttle / Rudder
servo
Connector
........ 3
...... 1
Connector
...........1
NOTE: Place of servos may be change depend of engine
(Four-stoke or two-stroke engine)
AB
(5 min.)
Unteransicht

23- Battery / Akku
BATTERY
BATTERY
Securely install the battery, ensuring it will not come loose
or rattle during flights.
FRONT-VIEW
!
To rudder servo To elevator servo
Rudder rod
Elevator rod Elevator rod
BOTTOM VIEW
22- Linkages / Alenkungen
Connector
20~25mm
6~8mm
10~12mm
RUDDER STROKE ELEVATOR STROKE
AILERON STROKE
24- Control Surface / Ruderausschlage
IMPORTANT: Flying your model at these throws will provide you with the greatest chance for successful first flights. If,
after you have become accustomed to the way the Zero flies, you would like to change the throws to suit your taste
, that is fine. However, too much control throw could make the model difficult to control, so remember, “more is not
always better”.
51/64 ~ 1”
20~25mm
51/64 ~ 1”
13/32 ~ 15/32”
13/32”
10mm
15/64 ~ 5/16”
15/64 ~ 5/16”
6~8mm
Unteransicht
Vorderansicht
Seitenruderausschlag
Querruderausschlag
Hohenruderausschlag

107 mm
Wing center section
DO NOT try to fly an out-of-balance model !
25- Balance / Schwerpunkt
How to add noseweight
To get the correct C.G., Several strips of lead
weight were required in the nose of this model .
To minimize the amount of weight required, it is
desirable to position the weight as far forward
as possible. This can be done by making a
platform form leftover basswood stick and 3.2mm
(1/8”) ply wood. Using 4x35mm bolts to mount the
engine would also be long enough to mount the
flatform. The lead should be permanently glued on
with epoxy.
IMPORTANT: Recheck the C.G. After the weight
has been installed. Basswood stick
Flatform
(3.2mm ply)
Lead should be
permanently glued
on flatform with
epoxy
Battery pack
26- Decor / Aufkleber
Note: Cut out the stickers and apply them in the proper area. Do not peel the backing paper off all at once.
Peel off one corner of the backing and cut off with scissors. Arrange sticker on model and when satisfied adhere the corner without
backing.
Carefully peel back the rest of the backing while at the same time adhering the rest of the sticker.
Try not to make air bubbles, if there are some, carefully puncture sticker (center of bubble) but not model surface with the tip of the
knife or sharp pin and squeeze out the air. At curves stretch sticker and apply a little heat so that no ceases occur. Cut off the excess
that is produced.
4-13/64”
E-141
VQAO14 Gray
450
VQAO15 Green
All details are subject to change
without notice !
Technische Anderungen und Irrtumer
vorbehalten !
IMPORTANT: Please do not clean your model with pure alcohol, only use liquid soap with water or use glass cleaner
to clean on surface of your model to keep the colour not fade.
VQAO151 White
