VSPL viraj SECURE FIRST SF-FBRL-2301 User manual

: VIRAJ SYNTEX PVT. LTD., Factory / Office : C-36, UPSIDC Industrial Area, Rooma, Kanpur - 209402 (UP) INDIA
Ph. Web : , E-mail : : [phone], 9839803488, 9839811500, 9839601191 www.vsplgroup.com [email protected]
The Lanyard SF-FBRL-2301 is classed as a Personal Protective Equipment (PPE) by the European Regulation 2016/425 and has been shown to comply with this Regulation through
the Harmonized European Standard EN 354 & EN 362.
CAREFULLY READ THESE INSTRUCTIONS BEFORE USING THIS ENERGY ABSORBER
This Lanyard is designed to minimise the risk of/provide protection against the danger of falling from heights. However, always remember that no item of PPE can
provide full protection and care must always be taken while carrying out the risk relation activity. Warning that it is essential for the safety of the user that if the product is re-sold outside
the original country of destination the reseller shall provide instructions for use, for maintenance, for periodic examination and for repair in the language of the country in which the product is to
be used.
PERFORMANCE AND LIMITATIONS OF USE
This Lanyard has been tested in accordance with EN 354 : 2010 and has achieved the following performance levels :
EN 355:2002 test Result/Comment
Clause 4.1
Design and Ergonomics
Clause 4.2
Materials & Construction
Clause 4.3
Static Strength
Actives required performance as stated in BS EN 354:2010 (PASS)
Lanyard free from sharp or excessively abrasive surface (PASS)
No unnecessary features which add significantly to overall mass (PASS)
Both the ends have a steel scaffold hook, for connection to harness and fall arrest system. (PASS)
Length does not exceed 2 m (PASS)
22KN sustained for 3 minutes without release (PASS)
SF-FBRL-2301
POSSIBLE USAGE :
This Lanyard can be used as a part of a fall arrest system or as a part of a restraint system. If using as a part of fall arrest system, a suitable anchor point (above the user's head, at least
10 KN) shall be used with this Lanyard.
LIMITATIONS :
1. Lanyard should be the personal property of its user.
2. The strength of the anchor device should Conform According to EN 795 Class B 1996.
3. If the Risk of the Fall is there it is Forbidden to Use Lanyard Alone and The Lanyard Should BE used only with an Energy Absorber.
4. It should not be used in highly acid or basic environments.
5. The Lanyard should be used by a trained, competent person or used by some one under the direct supervision of such a person.
6. The maximum length of the Lanyard including all components like Energy Absorbers, Connectors & terminations should not exceed 2 ms.
FITTING & SIZING :
Follow Step 1 to Step 2 t use the Lanyard.
Step 1: Connect the Snap Hook attached to the Lanyard to the attachment element of the full body harness. Ensure That the snap hook is Locked Tightly.
Step 2: Connect the other end Snap hooks to anchorage points. Ensure that the Snap Hooks is locked tightly.
INSTRUCTIONS TO BE FOLLOWED BEFORE USE :
Inspect the Lanyard for any rupture or damage of the rope, particularly the splicing of the rope at the ends should be intact. There should not be any cuts or abrasion marks on the lanyard. Also
ensure that both the connectors are in proper functioning.
Ensure the compliance with recommendations for use as applicable to the combination with other components of the fall arrest system (Connector EN 362, Full Body Harness EN 361) and
specified on the identification card for the fall arrest system or component concerned. Make sure that the connectors used are correctly attached to the loop and that they are locked.
A rescue plan needs to be evolved, before the product is to be used.
WARNING :
1. Do not use the Lanyard as a fall arrest component directly. It is to be used only as a connecting element.
2. In case of any doubt arising about the safety of the Lanyard it should be replaced immediately on consultation with an expert.
3. Withdraw from use any Lanyard that was subjected to a fall from a height.
4. The arrest distance should be double the total length of the lanyard and the connector plus 1.75 ms break distance to allow tearing of webbing inside.
5. The maximum length of the Lanyard including all components like Lanyard, Connectors & terminations should not exceed 2 ms.
6. A full body harness is the only acceptable body holding device that can be used in a fall arrest system.
PROTECTION OF THE ENERGY ABSORBER DURING USE :
Ageing due to cold, heat, moisture and direct sunlight.
Deterioration due to chemical such as oils, acids, solvents and sea water.
Inappropriate choice of the Lanyard in relation to the risk concerned eg. use the Lanyard as a fall arrest component.
Applicable to Lanyard
Manufacturer
Certification Body
:
:SF-FBRL-2301
GEPTESZT Kft. - Budapest Gyenes u. 12. 1032, Hungary, Contact No:- [phone]
IDENTIFICATION NO. 2233
USER INSTRUCTIONS
2233
TM

It is recommended that the lanyard should be inspected and examined by a competent person for any damages or failures if the need arises, but at
least once a year. The observations should be recorded in the table below. In case such damages are observed, the Lanyard is to be replaced
immediately. It is recommended to check the legibility of the product markings.
Medical Information: It is appropriate to request medical and other information to assist an individual user with a disability in an emergency.
The instructions for use for the individual components are to be observed.
Check Card
Inappropriate combination with other equipment.
Use by a person lacking sufficient safety awareness.
Unnecessary physical loading (static or dynamic).
Improper use by untrained persons.
Deterioration through mechanical wear, water or soiling.
Inappropriate storage, maintenance or cleaning.
While using the Lanyard as connection element, make sure that they are not positioned in such a way that the user trips over it.
While using the Lanyard, any sharp metallic object near it can cause abrasion and destroy the lanyard. Other Safety Precaution That Have to Abserved While
using the Lanyard are extreme temperature Bailing or Looping of Lanyard or Ref lives Over Sharp Edges And Electrical Conductivity Any Sharp Metallic
Object Near it can cause obrasion and Destroy the Lanyard.
COMPATIBILITY : To optimize protection, in some instance it may be necessary to use the lanyard with suitable boots/gloves/helmet/ear defenders. In this
case, before carrying out the risk-related activity, consult your supplier to ensure that all your protective products are compatible and suitable for your
application.
STORAGE AND TRANSPORT : When not in use, store the Lanyard in a well ventilated area away from extremes of temperature. Never place heavy items on
top of it. If possible, avoid excessive folding and preferably store it hanging vertically. If the product is wet, allow it to dry fully before placing it into storage.
REPAIR : If the product becomes damaged, it will not provide the optimum level of protection, and therefore should be immediately either replaced or
repaired,. Never use the damaged product. Repair is permitted, provided that it is either done by the manufacturer or a competent repair centre or individual
approved by the manufacturer.
CLEANING : In case of minor soiling, wipe the Lanyard with cotton cloth or a soft brush. Do not use any abrasive material. For intensive cleaning wash the
lanyard in water at a temperature between 30ºC to 60ºC using a neutral detergent (pH±7). The washing temperature should not exceed 60ºC. Do not use acid
or basic detergents. After becoming wet. dry the lanyard naturally away from an open fire or other source of heat.
LIFESPAN : The expected lifespan of the Lanyard is 2-3 years but inspection before each use is compulsory. The lifespan greatly depends upon the conditions
of usage of the product.
PROTECTION AGAINST HAZARDS DURING USE :
MARKING ON LANYARD
TM
PLEASE READ USER MANUAL BEFORE
USING THE PRODUCT. DO NOT DEVIATE
FROM MANUFACTURER’S INSTRUCTIONS.
TYPE : FORKED LANYARD WITHOUT
MODEL No. : SF-FBRL-2301
BATCH NO. : xxxx
SERIAL NO. : xxxx
MONTH/YEAR MFG : xx/xxxx
MATERIAL : POLYAMIDE
LENGTH : xx Mtr .
MADE IN INDIA
STRENGTH (KN) : 22KN
EN 354:2010
ENERGY ABSORBER
2233
The Lanyard is marked with :
(i)
(ii)
(iii)
(iv)
(v)
(vi)
(vii)
(viii)
The CE mark showing that the
product meets the requirements
of the Regulation 2016/425
Identification of the Manufacturer
Type or Product Code
Batch/Lot No.
Month/Year of Manufacture
Material
Size
Serial No. of the Harness
1- Standard & Year
The user should read and understand
the information before using Harness
.
Notification body involved in the
production control phase CE 2233-
2-
3-
4-
Static strength of the Lanyard -15 KN
5-
GEPTESZT Kft. - Budapest Gyenes
u.12.1032, Hungary,
Contact No:- [phone]
1.
2.
3.
Type
Identification Mark
Batch No.
5.
6.
7.
Date of Purchase
Date of first Use
Name of User & Signature
IDENTIFICATION
Date Damage observed Repair Comments
SERVICE and INSPECTION RECORD
Next Due Date
4. Month/Year of Manufacture 8. Comments
Name & Date of
The Competent person
