vufold INTU Micro User manual

Fitting Instructions
Micro Beadfit Blinds
.
.

INSTALLATION INSTRUCTIONS
INTU Micro Beadfit
What you will need :
Scissors
Bracket Fitting
Tool
P Clips Side Extrusions
Top Corner
Brackets
Bottom Corner
Brackets
Supplied :
Not Supplied :
.
.
Scan our QR code to view our fitting video
or visit www.vufold.co.uk

1. Place the top corner bracket into the top le slot on
the bracket fitting tool.
2. Position the bracket behind the rubber seal at the top
right corner of the frame. Carefully push until the metal
legs are behind the rubber seal. Check the bracket is
square to the sides of the frame and fully secure.
3. Place the top corner bracket into the top right slot on
the bracket fitting tool.
4. Position the bracket behind the rubber seal at the top
le corner of the frame. Carefully push until the metal
legs are behind the rubber seal. Check the bracket is
square to the sides of the frame and fully secure.
INSTALLATION STEPS
INTU Micro Beadfit

7. Place the bottom corner bracket into the bottom
right slot on the bracket fitting tool.
8. Position bracket behind the rubber seal at the bottom
right corner of the frame. Carefully push until the metal
leg is behind the rubber seal. Check the bracket is square
to the sides of the frame and fully secure.
6. Position bracket behind the rubber seal at the
bottom right corner of the frame. Carefully push until
the metal leg is behind the rubber seal. Check the
bracket is square to the sides of the frame and fully
secure.
5. Place the bottom corner bracket into the bottom le
slot on the bracket fitting tool.
9. Place the flat side of the side extrusion against the
glass with the notch to the bottom.
10. Slide the side extrusion up until its slots into the
top corner fixing bracket. The side extrusion should
rest under the bracket. Push the slot at the base of the
extrusion over the bottom corner bracket. Repeat for
both sides.

12. Remove the endcap covers from the headrail by
pulling them o.
13. Remove the Velcro straps that wrap around the
blind. Do not remove the elastic bands.
14. Remove the cords from the elastic band and allow
to hang from the blind. Do not remove elastic bands
from the blind.
15. Align headrail endcaps with both top corner fixing
brackets and push fully home. Your headrail should now
be mounted to the frame.
11. At the appropriate position(s) on each side profile, fit
retention clips (long side profiles only). Press into position
using the fitting tool.
16. Align the bottom button with the bottom corner
brackets. Slide the bottom button onto the bracket
until it locates. Repeat for other side.

18. If your blind requires further tension, pull the cord
through the hole in the bottom button until you feel the
blind has suicient tension and tie a fresh knot.
17. Cut and remove the elastic bands from the blind.
Test the tension by raising the blind, ensure it stays fully
raised when released. Ensure bottom bar is straight
by adjusting it from side to side.
19. Re-attach the endcap covers by aligning the central
post with the central hole on the endcap. Push the
endcap cover in fully until a click is heard. Ensure the
blind is lowered before doing this to prevent catching
the fabric.
20. Your blind is now fully installed and ready to use.
