Item # __________________________
C.S.I. Section 11420
VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. 1-800-814-2028
502-778-2791 QUOTE & ORDER FAX: 1-800-444-0602
A2780
ISO9001
Vulcan-Hart Co.
F-32575 (10-03)
SPECIFICATIONS:
Direct steam, Super Steamer, Vulcan-Hart Model No. (VHL2D)
(VHL3D). 6 psi pressure steam cooker. Cooker body is 8
gauge satin finish type 304 stainless steel exterior. Doors have
a removable aluminum alloy inner liner with full perimeter
gasket and sealed by turning a "T" type handle. The door
cannot be opened while the steamer is on. Automatic timed
compartment controls with 60 minute timer (add suffix "S" to
model number). Lift out stainless steel wire Adapt-A-PanTM
supports eight 21/2", six 4", or four 6" deep food pans (one for
2 compartments)(two for 3 compartments) and one manual
pull out shelf. Cooker mounted on a 2" diameter welded
stainless steel tubing leg stand with 6" adjustable flanged feet,
for floor anchoring. Direct steam supply at 10 to 50 PSI with a
flow of (2 compts., 80 lbs. steam/hr.) (3 compts., 115 lbs.
steam/hr.).
Exterior dimensions:
VHL2D: 36"w x 33"d x 58"h (61"h with cabinet base).
VHL3D: 36"w x 33"d x 66"h (76"h with cabinet base).
U L listed. Classified by U L to NSF Std. #4.
VHLD SERIES
SUPER STEAMER, DIRECT STEAM
TWO OR THREE COMPARTMENT MODELS
MODELS: VHLD SERIES Direct Steam Super Steamer
■■VHL2D (S) (P) 2 compartments
■■VHL3D (S) (P) 3 compartments
STANDARD FEATURES
■Direct steam supply at 10 to 50 PSI with a flow of (2 compt.
- 80 lbs. steam/hr.) (3 compt. - 115 lbs. steam/hr.)
■6 psi pressure steam cooker.
■Cooker body is 8 gauge satin finish type 304 stainless steel
exterior. Doors have a removable aluminum alloy inner
liner with full perimeter gasket and sealed by turning a
"T" type handle. The door cannot be opened when steamer
is on.
■Automatic timed compartment controls with 60 minute
timer. (Add suffix "S" to model number.)
■Lift out stainless steel wire Adapt-A-Pan™ supports eight
21/2", six 4" or four 6" deep food pans (one for 2
compartments)(two for 3 compartments) and one manual
pull out shelf.
■Cooker mounted on a 2" diameter welded stainless steel
tubing leg stand with 6" adjustable flanged feet for floor
anchoring.
■One year limited parts and labor warranty.
OPTIONS
■■28" high cabinet with stainless steel front full height doors,
slip-off stainless steel side and aluminized rear panel with
6" adjustable legs with flanged feet for anchoring.
■■Pre-VentTM, automatic load compensated timed, combina-
tion pressure and free venting cooking with automatic
exhaust. (Add suffix "P" to model number).
■■Correction package:
a. Cabinet door with hasp (lock by others).
b. Security type tamper resistant fasteners.
c. Control cover (lock by others).
■■Control circuit step down transformer to 120V, if higher than
120 volt.
■■Second year extended limited parts and labor warranty.
ACCESSORIES
■■Stainless steel back panel.
■■Manual sliding shelf (Qty. ____).
■■Removable 12 x x20 sliding shelf (Qty. ____).
■■Adapt-A-Pan™ support (Qty. ____).
(Shown on optional cabinet base)
