MODEL C24EA SERIES
ELECTRIC COUNTER CONVECTION STEAMER
MODEL: C24EA SERIES Electric Counter Convection Steamer
SPECIFICATIONS:
Single compartment electric convection steamer, Vulcan-Hart
Model No. (C24EA3) (C24EA5). Stainless steel exterior and
cooking compartment with coved interior corners. Manual
control with 60 minute timer. High output stainless steel
steam generator with manual drain and Smart Drain System
(timed drain) with PowerFlush. Heavy duty door and door
latch mechanisms. Shipped for 208/60-50/3 electrical service.
Can be eld converted to 208/60-50/1 and 240/60-50/3 and
240/60-50/1. Split water line connection. 11/2" NPT drain con-
nection.
Exterior dimensions:
3 pan: 24"w x 33"d x 191/2"h.
5 pan: 24"w x 33"d x 26"h.
■C24EA3 3 pan capacity
■C24EA5 5 pan capacity
STANDARD FEATURES
■Stainless steel exterior and cooking compartment with coved
interior corners.
■Leveling feet.
■Manual control with 60 minute timer.
■High output stainless steel steam generator with manual drain
Smart Drain System (timed drain) with PowerFlush.
■Heavy duty door and door latch mechanisms.
■Shipped for 208/60-50/3 electrical service. Can be eld con-
verted to 208/60-50/1 and 240/60-50/3 and 240/60-50/1.
■Split water line connection. 11/2" NPT drain connection.
■One year limited parts and labor warranty.
OPTIONS
■Professional Control Package includes:
■Superheated Steam System
■Staged Fill
■Lighted power switch with cook and ready lights
■Auto drain with Smart Drain System (timed drain) with
PowerFlush
■Timer 60 minute 60 cycle (50 cycle x 1.2) with Constant
Steam Setting
■Cord strain relief
■Second year extended limited parts and labor warranty
contract.
ACCESSORIES
■4" counter legs.
■12" x 20" stainless steel pans:
- 1" deep (solid) (perforated) Qty.____.
- 21/2" deep (solid) (perforated) Qty.____.
- 4" deep (solid) (perforated) Qty.____.
■Stainless steel pan cover. Qty.____.
■Open leg stand.
■28" open leg stand with pan slides 24"w x 28"h.
■34" open leg stand with pan slides 24"w x 34"h.
■Set of two universal pan slides for open leg stand.
■Stand sliding shelf.
■Stacking kit for two units with hardware, counter mount.
■Floor legs, 6".
■Floor caster, 6".
■Pull-out 12" x 20" sliding shelf (cooking compartment).
Qty. ____.
■Cord and plug set.
■Water treatment system.
Shown on optional stand with
extra set of pan slides and pans

VULCAN-HART COMPANY, P.O. BOX 696, LOUISVILLE, KY 40201, TEL. [phone]
502-778-2791 QUOTE & ORDER FAX: [phone]
NOTE: In line with its policy to continually improve its products, Vulcan-Hart Company reserves the right to change materials and
specications without notice.
Printed On Recycled Paper
F-32627 (06-08)
MODEL C24EA SERIES
ELECTRIC COUNTER CONVECTION STEAMER
SERVICE CONNECTIONS:
ELECTRICAL CONNECTIONS: Field Wire Electrical Connection 11/4"
(32 mm) K.O. service entrance.
DRAIN: 11/2" IPS piped to open drain. No solid connections. 60" length
before open air gap opening and not more than two bends or elbows.
GENERATOR WATER SUPPLY: 3/4" (19 mm) hose bib to generator,
ow rate .5 gpm @ minimum 25 to maximum 50 psi. (170-345 kPa).
CONDENSING WATER SUPPLY: 3/4" (19 mm) hose bib to condenser,
ow rate .5 gpm @ minimum 25 to maximum 50 psi. (170-345 kPa).
WATER QUALITY STATEMENT:
The fact that a water supply is potable is no guarantee that it is suitable
for steam generation. Your water supply must be within these general
guidelines:
SUPPLY PRESSURE 20 - 60 psig
HARDNESS* less than 3 grains
SILICA less than 13 ppm
TOTAL CHLORIDE less than 4.0 ppm
pH RANGE 7-8
UN-DISSOLVED SOLIDS less than 5 microns
* 17.1 ppm = 1 grain of hardness
Other factors affecting steam generation are iron content, amount of
chloridation and dissolved gases. Water supplies vary from state to
state and from locations within a state. Therefore it is necessary that
the local water treatment specialist be consulted before the installation
of any steam generating equipment.
NOTE:
• Dimensionswhichlocatetheaboveconnectionshavea
tolerance of + or -3" (+ or -75 mm).
• Installation of backow preventers, vacuum breakers
and other specic code requirements is the responsibility
of the owner and installer. It is the responsibility of the
owner and installer to comply with local codes.
• Plastic drains are not recommended due to inherent
limited temperatures of the plastic. Boiler purge tempera-
tures may exceed 180°F. The installer may be required to
provide means to reduce boiler purge water temperature
to be that of the condensate temperature of 140°F or
less.
• Thisapplianceismanufacturedforcommercialinstallation
only and is not intended for home use.
BASIC CONTROL PACKAGE
MODEL PH 208V 240V 480V
KW AMP KW AMP KW AMP
C24EA3 1 8.5 41 8.5 36
3 8.5 27 8.5 21 8.5 11
C24EA5 1 15 72 15 63
3 15 42 15 36 15 18
NOTE: 208 volt, 3 phase is an unbalance load, and amp listed is
the max on any leg. Refer to the I/O manual for further details.
PAN CAPACITY
MODEL 1" 21/2" 4" 6"
C24EA3 6 3 2 1
C24EA5 10 5 3 2
PROFESSIONAL CONTROL PACKAGE
MODEL PH 208V 240V 480V
KW AMP KW AMP KW AMP
C24EA3 1 9.25 45 9.25 39
3 9.25 29 9.25 23 9.25 12
C24EA5 1 15.75 76 15.75 66
3 15.75 44 15.75 38 15.75 19
